Intel® Server System
M50CYP2UR Family
System Integration and Service Guide
A guide providing instructions for the insertion and
extraction of system components and available
Intel accessories and spares
Rev. 1.0
May 2021
Delivering Breakthrough Data Center System Innovation –Experience What’s Inside!

2
<This page intentionally left blank>

Intel® Server System M50CYP2UR Family System Integration and Service Guide
3
Document Revision History
Date
Revision
Changes
May 2021
1.0
Initial production release

Intel® Server System M50CYP2UR Family System Integration and Service Guide
4
Disclaimers
Intel technologies’ features and benefits depend on system configuration and may require enabled hardware, software, or service
activation. Performance varies depending on system configuration. No computer system can be absolutely secure. Check with your
system manufacturer or retailer or learn more at intel.com.
You may not use or facilitate the use of this document in connection with any infringement or other legal analysis concerning Intel
products described herein. You agree to grant Intel a non-exclusive, royalty-free license to any patent claim thereafter drafted which
includes subject matter disclosed herein.
No license (express or implied, by estoppel or otherwise) to any intellectual property rights is granted by this document.
The products described may contain design defects or errors known as errata which may cause the product to deviate from
published specifications. Current characterized errata are available on request.
Intel disclaims all express and implied warranties, including without limitation, the implied warranties of merchantability, fitness
for a particular purpose, and non-infringement, as well as any warranty arising from course of performance, course of dealing, or
usage in trade.
This document contains information on products, services and/or processes in development. All information provided here is subject
to change without notice. Contact your Intel representative to obtain the latest Intel product specifications.
Copies of documents which have an order number and are referenced in this document may be obtained by calling 1-800-548-4725
or by visiting www.intel.com/design/literature.htm.
Intel, the Intel logo, Xeon, and Intel Optane are trademarks of Intel Corporation or its subsidiaries in the U.S. and/or other countries.
*Other names and brands may be claimed as the property of others.
© Intel Corporation

Intel® Server System M50CYP2UR Family System Integration and Service Guide
5
Safety Warnings
Heed safety instructions: Before working with your server product, whether you are using this guide or any
other resource as a reference, pay close attention to the safety instructions. You must adhere to the
assembly instructions in this guide to ensure and maintain compliance with existing product certifications
and approvals. Use only the described, regulated components specified in this guide. Use of other
products/components will void the UL listing and other regulatory approvals of the product and will most
likely result in noncompliance with product regulations in one or more regions in which the product is sold.
System power on/off: The power button DOES NOT turn off the system AC power. To remove power from
the system, you must unplug the AC power cord. Make sure the AC power cord is unplugged before you
open the chassis, add, or remove any components.
Hazardous conditions, devices and cables: Hazardous electrical conditions may be present on power,
telephone, and communication cables. Turn off the server and disconnect the power cord,
telecommunications systems, networks, and modems attached to the server before opening it. Otherwise,
personal injury or equipment damage can result.
Installing or removing jumpers: A jumper is a small plastic encased conductor that slips over two jumper
pins. Some jumpers have a small tab on top that you can grip with your fingertips or with a pair of fine needle
nosed pliers. If your jumpers do not have such a tab, take care when using needle nosed pliers to remove or
install a jumper; grip the narrow sides of the jumper with the pliers, never the wide sides. Gripping the wide
sides can damage the contacts inside the jumper, causing intermittent problems with the function controlled
by that jumper. Take care to grip with, but not squeeze, the pliers or other tool you use to remove a jumper,
or you may bend or break the pins on the board.
Electrostatic Discharge (ESD)
Electrostatic discharge can cause damage to the computer or the components within it. ESD can occur
without the user feeling a shock while working inside the system chassis or while improperly handling
electronic devices like processors, memory or other storage devices, and add-in cards.
Intel recommends the following steps be taken when performing any procedures described within this
document or while performing service to any computer system.
•Where available, all system integration and/or service should be performed at a properly equipped
ESD workstation
•Wear ESD protective gear like a grounded antistatic wrist strap, sole grounders, and/or conductive
shoes
•Wear an anti-static smock or gown to cover any clothing that may generate an electrostatic charge
•Remove all jewelry
•Disconnect all power cables and cords attached to the server before performing any integration or
service
•Touch any unpainted metal surface of the chassis before performing any integration or service
•Hold all circuit boards and other electronic components by their edges only
•After removing electronic devices from the system or from their protective packaging, place them
component side up on to a grounded anti-static surface or conductive workbench pad. Do not place
electronic devices on to the outside of any protective packaging.

Intel® Server System M50CYP2UR Family System Integration and Service Guide
6
Caution: Slide / Rail mounted equipment is not to be used as a shelf or a workspace
Intel warranties that this product will perform to its published specifications. However, all computer systems
are inherently subject to unpredictable system behavior under various environmental and other conditions.
This product is not intended to be the sole source for any critical data and the user must maintain a verified
backup. Failure to do so or to comply with other user notices in the product user guide and specification
documents may result in loss of or access to data.
Weight of the system:
•Due to the weight of a system, Intel recommends carrying the system with two people supporting the
system from the sides or using a mechanical lift or a cart when moving the system from one location
to another.
•If your system has rack handles installed, do not lift or carry the system by the rack handles
•When lifting or moving a chassis, always grasp it by all four corners. Do not grasp the chassis by two
points at opposing diagonal corners, doing so may damage the internal components.
•If you can only grasp the chassis at two different points, always grasp the chassis by the sides at the
midpoint.

Intel® Server System M50CYP2UR Family System Integration and Service Guide
7
Table of Contents
1. Introduction............................................................................................................................................................... 15
1.1 Reference Documents and Support Collaterals................................................................................................17
2. Essential System Component Installation and Service ................................................................................... 19
2.1 Chassis Component Identification..........................................................................................................................20
2.2 System Cover Removal / Installation.....................................................................................................................20
2.2.1 System Cover Removal................................................................................................................................................20
2.2.2 System Cover Installation...........................................................................................................................................22
2.3 Air Duct Removal / Installation.................................................................................................................................22
2.3.1 Air Duct Removal............................................................................................................................................................24
2.3.2 Air Duct Installation.......................................................................................................................................................25
2.4 Processor Assembly and Installation.....................................................................................................................26
2.4.1 Processor Heat Sink Module (PHM) Assembly ..................................................................................................27
2.4.2 Processor Installation...................................................................................................................................................30
2.5 Memory Module Installation .....................................................................................................................................33
2.5.1 DIMM Installation ...........................................................................................................................................................33
2.6 Power Supply Module Installation..........................................................................................................................35
2.6.1 Power Supply Module Installation..........................................................................................................................35
3. Optional Accessory Kit Integration and Service................................................................................................ 36
3.1 System Cover Removal / Installation.....................................................................................................................37
3.1.1 System Cover Removal................................................................................................................................................37
3.1.2 System Cover Installation...........................................................................................................................................38
3.2 Air Duct Removal / Installation.................................................................................................................................39
3.2.1 Air Duct Removal............................................................................................................................................................40
3.2.2 Air Duct Installation.......................................................................................................................................................41
3.3 Riser Card Assembly / Add-in Card Assembly Installation / Removal.....................................................43
3.3.1 Riser Card Bracket Removal....................................................................................................................................... 45
3.3.2 Riser Card Installation ..................................................................................................................................................46
3.3.3 PCIe* Add-in Card Installation..................................................................................................................................46
3.3.4 Riser Card Assembly Installation –Riser Slot #1, Riser Slot #2, and Riser Slot #3.............................48
3.4 Drive Removal, Assembly, and Installation.........................................................................................................48
3.4.1 2.5” SSD Drive Assembly for 7 mm Drives ..........................................................................................................50
3.4.2 2.5” SSD Drive Installation ......................................................................................................................................... 51
3.4.3 2.5” SSD Drive / Drive Blank Removal...................................................................................................................53
3.4.4 3.5” HDD Drive Assembly ...........................................................................................................................................53
3.4.5 Assembly of 2.5” SSD Drive into a 3.5” Drive Carrier......................................................................................54
3.4.6 3.5” Drive Carrier Installation....................................................................................................................................56
3.4.7 3.5” Drive Carrier Removal.........................................................................................................................................56
3.5 Ethernet Network Adapter for OCP* –Installation / Removal ....................................................................57
3.5.1 OCP* Adapter Bay Filler Removal / Installation ................................................................................................57

Intel® Server System M50CYP2UR Family System Integration and Service Guide
8
3.5.2 OCP* Adapter with Pull Tab Installation ..............................................................................................................59
3.5.3 OCP* Adapter with Pull Tab Removal ...................................................................................................................59
3.5.4 OCP* Adapter with Ejector Latch Installation.....................................................................................................60
3.5.5 OCP* Adapter with Ejector Latch Removal..........................................................................................................60
3.5.6 OCP* Adapter with Internal Lock Installation.....................................................................................................61
3.5.7 OCP* Adapter with Internal Lock Removal..........................................................................................................62
3.6 M.2 Storage Device Installation / Removal..........................................................................................................62
3.6.1 M.2 SSD Installation......................................................................................................................................................63
3.6.2 M.2 SSD Removal...........................................................................................................................................................64
3.7 Internal Fixed Mount SATA SSD Installation / Removal ................................................................................64
3.7.1 Internal Fixed Mount SSD Installation................................................................................................................... 66
3.7.2 Internal Fixed Mount SSD Removal........................................................................................................................67
3.8 Midplane Card Installation / Removal (iPC –CYPSWITCHMP)....................................................................68
3.8.1 Midplane Card Installation......................................................................................................................................... 68
3.8.2 Midplane Card Removal ..............................................................................................................................................69
3.9 Trusted Platform Module (TPM) Installation......................................................................................................70
3.10 Intel® VROC 7.5 Key Installation / Removal ........................................................................................................71
3.10.1 Intel® VROC 7.5 (VMD NVMe* RAID) Key Installation......................................................................................71
3.10.2 Intel® VROC 7.5 (VMD NVMe* RAID) Key Removal...........................................................................................72
3.11 Intel® SAS Interposer Card and SAS RAID Module Installation / Removal ............................................72
3.11.1 Intel® SAS Interposer Card Installation.................................................................................................................73
3.11.2 Intel® SAS Interposer Card Removal ......................................................................................................................74
3.11.3 Intel® SAS RAID Module Installation ......................................................................................................................75
3.11.4 Intel® SAS RAID Module Removal............................................................................................................................76
3.12 Intel® SAS Expander Card Installation / Removal.............................................................................................77
3.12.1 Intel® SAS Expander Card Installation...................................................................................................................77
3.12.2 Intel® SAS Expander Card Removal........................................................................................................................78
3.13 Intel® RAID Maintenance Free Backup Unit (RMFBU) and Mounting Bracket Installation /
Removal..............................................................................................................................................................................78
3.13.1 Intel® RMFBU Mounting Bracket Installation......................................................................................................80
3.13.2 Intel® RMFBU Mounting Bracket Removal ...........................................................................................................81
4. System Software Updates and Configuration.................................................................................................... 82
5. System Service –System Features Overview..................................................................................................... 83
5.1 Front Drive Bay Options..............................................................................................................................................83
5.2 Back Panel, Front Control Panel, Front I/O Features......................................................................................84
5.3 Drive Tray LED Identification.....................................................................................................................................85
5.4 Server Board Features..................................................................................................................................................87
5.5 System Configuration and Recovery Jumpers ..................................................................................................89
6. System Service and FRU Replacement................................................................................................................ 90
6.1 System Cover Removal / Installation.....................................................................................................................90
6.1.1 System Cover Removal................................................................................................................................................91
6.1.2 System Cover Installation...........................................................................................................................................92

Intel® Server System M50CYP2UR Family System Integration and Service Guide
9
6.2Air Duct Removal / Installation.................................................................................................................................92
6.2.1 Air Duct Removal............................................................................................................................................................94
6.2.2 Air Duct Installation.......................................................................................................................................................95
6.3 System Fan Assembly Replacement......................................................................................................................96
6.4 Individual Fan Replacement ......................................................................................................................................98
6.5 Memory Module Replacement .................................................................................................................................99
6.6 Power Supply Module Replacement................................................................................................................... 100
6.7 Processor Replacement............................................................................................................................................ 101
6.7.1 Processor Heat Sink Module (PHM) and Processor Removal................................................................... 102
6.7.2 PHM and Processor Installation............................................................................................................................ 103
6.8 Drive Removal, Installation, and Assembly ...................................................................................................... 108
6.8.1 2.5” SSD Drive Removal............................................................................................................................................ 110
6.8.2 2.5” SSD Drive Assembly for 7 mm Drives ....................................................................................................... 110
6.8.3 2.5” SSD Drive Installation ...................................................................................................................................... 111
6.8.4 3.5” Drive Carrier Removal...................................................................................................................................... 113
6.8.5 3.5” HDD Drive Assembly ........................................................................................................................................ 113
6.8.6 Assembly of 2.5” SSD Drive into a 3.5” Drive Carrier................................................................................... 114
6.8.7 3.5” Drive Carrier Installation................................................................................................................................. 116
6.9 Backplane Replacement........................................................................................................................................... 117
6.9.1 8 x 2.5” Backplane....................................................................................................................................................... 117
6.9.2 12 x 3.5” Backplane Installation............................................................................................................................ 119
6.9.3 8 x 2.5” Backplane and 12 x 3.5” Backplane Cabling ................................................................................... 120
6.10 System Battery Replacement................................................................................................................................. 121
6.11 Server Board Replacement ..................................................................................................................................... 122
Appendix A. Getting Help ........................................................................................................................................ 124
Appendix B. Internal Cable Routing Channels.................................................................................................... 125
Appendix C. General Memory Population Rules................................................................................................ 126
C.1 DDR4 DIMM Population Rules ............................................................................................................................... 126
C.2Intel® Optane™ DC Persistent Memory 200 Series Module Rules........................................................... 127
Appendix D. System Status LED Operating States and Definition ................................................................. 129
Appendix E. POST Code Diagnostic LED Decoder............................................................................................. 131
E.1 Early POST Memory Initialization MRC Diagnostic Codes......................................................................... 132
E.2 BIOS POST Progress Codes.................................................................................................................................... 134
Appendix F. POST Error Codes .............................................................................................................................. 137
F.1 POST Error Beep Codes ........................................................................................................................................... 143
F.2 Processor Initialization Error Summary............................................................................................................. 144
Appendix G. System Packaging Assembly Instructions.................................................................................... 146
Appendix H. Safety Instructions............................................................................................................................. 149
Appendix I. Glossary ............................................................................................................................................... 161

Intel® Server System M50CYP2UR Family System Integration and Service Guide
10
List of Figures
Figure 1. Chassis Component Identification..................................................................................................................................20
Figure 2. System Top Cover Panel Shipping Screws..................................................................................................................21
Figure 3. System Top Cover Removal...............................................................................................................................................21
Figure 4. System Top Cover Installation..........................................................................................................................................22
Figure 5. Standard Air Duct for Processor Heat Sink with 2U Height .................................................................................23
Figure 6. Standard Air Duct for Processor Heat Sink with 1U Height .................................................................................23
Figure 7. GPGPU Air Duct for Processor Heat Sink with 1U Height .....................................................................................23
Figure 8. Air Duct Removal....................................................................................................................................................................24
Figure 9. GPGPU Air Duct Bracket Removal...................................................................................................................................24
Figure 10. Air Duct Installation............................................................................................................................................................25
Figure 11. GPGPU Air Duct Bracket Installation...........................................................................................................................25
Figure 12. Supported 2U Processor Heat Sinks...........................................................................................................................26
Figure 13. Processor Heat Sink Module (PHM) Reference Diagram.....................................................................................27
Figure 14. Installing Processor Carrier Clip onto Processor –Part 1...................................................................................28
Figure 15. Installing Processor Carrier Clip onto Processor –Part 2...................................................................................28
Figure 16. Removing Heat Sink from its Packaging....................................................................................................................29
Figure 17. Setting the Processor Heat Sink Anti-tilt Wires to the Outward Position ...................................................29
Figure 18. Pin 1 Indicator of Processor Carrier Clip....................................................................................................................30
Figure 19. Socket Protective Cover Removal ................................................................................................................................30
Figure 20. PHM Alignment with Socket Assembly......................................................................................................................31
Figure 21. PHM Installation onto Server Board............................................................................................................................32
Figure 22. Tighten Heat Sink Fasteners...........................................................................................................................................32
Figure 23. DIMM Blank Removal.........................................................................................................................................................33
Figure 24. Memory Module Installation...........................................................................................................................................34
Figure 25. Power Supply Installation................................................................................................................................................35
Figure 26. System Top Cover Panel Shipping Screws............................................................................................................... 37
Figure 27. System Top Cover Removal............................................................................................................................................38
Figure 28. System Top Cover Installation....................................................................................................................................... 38
Figure 29. Standard Air Duct for Processor Heat Sink with 2U Height...............................................................................39
Figure 30. Standard Air Duct for Processor Heat Sink with 1U Height...............................................................................39
Figure 31. GPGPU Air Duct for Processor Heat Sink with 1U Height...................................................................................40
Figure 32. Air Duct Removal .................................................................................................................................................................40
Figure 33. GPGPU Air Duct Bracket Removal ................................................................................................................................41
Figure 34. Air Duct Installation............................................................................................................................................................41
Figure 35. GPGPU Air Duct Bracket Installation...........................................................................................................................42
Figure 36. Bracket for Riser Card on Riser Slot #1–Two Views.............................................................................................43
Figure 37. Bracket for Riser Card on Riser Slot #2–Two Views.............................................................................................44
Figure 38. Bracket for Riser Card on Riser Slot #3–Two Views.............................................................................................44
Figure 39. Riser Card Bracket Removal............................................................................................................................................45

Intel® Server System M50CYP2UR Family System Integration and Service Guide
11
Figure 40. Riser Card Installation on the Bracket ........................................................................................................................46
Figure 41. PCIe* add-in Card Installation for Riser Card on Riser Slot #1 or Riser Slot #3........................................46
Figure 42. PCIe* add-in Card Installation for Riser Card on Riser Slot #2.........................................................................47
Figure 43. Riser Card Assembly Installation ..................................................................................................................................48
Figure 44. 2.5” Drive Bay Components ............................................................................................................................................49
Figure 45. 3.5” Drive Bay Components ............................................................................................................................................49
Figure 46. Separating Top and Bottom Parts of Drive Blank.................................................................................................. 50
Figure 47. Attaching the Drive Blank to 7 mm SSD ....................................................................................................................50
Figure 48. 2.5” 7 mm Drive Outside Chassis, Ready for Installation....................................................................................51
Figure 49. 2.5” 7 mm Drive Installation into 2.5” Drive Bay ....................................................................................................51
Figure 50. 2.5” 15 mm Drive Outside Chassis, Ready for Installation.................................................................................52
Figure 51. 2.5” 15 mm Drive Installation into 2.5” Drive Bay..................................................................................................52
Figure 52. 2.5” Drive Removal..............................................................................................................................................................53
Figure 53. 3.5” Drive Carrier Assembly – Drive Blank / Drive Removal ..............................................................................53
Figure 54. 3.5” Drive Carrier Assembly –Drive Installation to Carrier ................................................................................54
Figure 55. 3.5" Drive Carrier to 2.5” SSD Bracket – Tab Removal and Mount SSD to Bracket..................................54
Figure 56. 3.5" Drive Carrier to 2.5” SSD Bracket – Mount Bracket Assembly to Carrier............................................55
Figure 57. 3.5” Drive Carrier to 2.5” SSD Bracket – Secure SSD to Carrier .......................................................................55
Figure 58. 3.5” Drive Carrier Installation .........................................................................................................................................56
Figure 59. 3.5” Drive Carrier Removal...............................................................................................................................................56
Figure 60. OCP* Adapter Bay Filler Removal.................................................................................................................................58
Figure 61. OCP* Adapter Bay Filler Installation............................................................................................................................58
Figure 62. OCP* Adapter with Pull Tab Installation....................................................................................................................59
Figure 63. OCP* Adapter with Pull Tab Removal.........................................................................................................................59
Figure 64. OCP* adapter with Ejector Latch Installation...........................................................................................................60
Figure 65. OCP* Adapter with Ejector Latch Removal...............................................................................................................60
Figure 66. Internal Lock with Unlock and Lock Orientation....................................................................................................61
Figure 67. OCP* Adapter with Internal Lock Installation..........................................................................................................61
Figure 68. OCP* Adapter with Internal Lock Removal...............................................................................................................62
Figure 69. M.2 SSD Connector Location..........................................................................................................................................63
Figure 70. M.2 SSD Installation ...........................................................................................................................................................63
Figure 71. M.2 SSD Removal ................................................................................................................................................................64
Figure 72. Peripheral Power Connector Identification..............................................................................................................65
Figure 73. SATA Ports on Server Board........................................................................................................................................... 65
Figure 74. Attaching SSD to Drive Bracket .....................................................................................................................................66
Figure 75. Installing SSD Bracket .......................................................................................................................................................66
Figure 76. Removing SSD Bracket......................................................................................................................................................67
Figure 77. Removing SSD from Bracket...........................................................................................................................................67
Figure 78. Midplane Card Installation ..............................................................................................................................................68
Figure 79. Midplane Card Removal....................................................................................................................................................69
Figure 80. Trusted Platform Module (TPM) Installation ...........................................................................................................70

Intel® Server System M50CYP2UR Family System Integration and Service Guide
12
Figure 81. Intel® VROC Key Insertion................................................................................................................................................71
Figure 82. Intel® VROC Key Removal ................................................................................................................................................72
Figure 83. SAS Interposer Card Installation...................................................................................................................................73
Figure 84. SAS Interposer Card Removal........................................................................................................................................74
Figure 85. Intel® SAS RAID Module Installation............................................................................................................................75
Figure 86. Intel® SAS RAID Module Removal.................................................................................................................................76
Figure 87. SAS Expander Card Installation.....................................................................................................................................77
Figure 88. SAS Expander Card Removal.......................................................................................................................................... 78
Figure 89. Installing Latch on the Plastic Case .............................................................................................................................79
Figure 90. Insert Super Cap Battery ..................................................................................................................................................79
Figure 91. Intel® RMFBU Mounting Bracket Installation - Chassis........................................................................................80
Figure 92. Intel® RMFBU Mounting Bracket Installation - Air Duct.......................................................................................80
Figure 93. Intel® RMFBU Mounting Bracket Removal - Chassis.............................................................................................81
Figure 94. Intel® RMFBU Mounting Bracket Removal - Air Duct............................................................................................81
Figure 95. 8 x 2.5” Front Drive Bay Configuration.......................................................................................................................83
Figure 96. 16 x 2.5” Front Drive Bay Configuration ....................................................................................................................83
Figure 97. 24 x 2.5” Front Drive Bay Configuration ....................................................................................................................83
Figure 98. 12 x 3.5” Front Drive Bay Configuration ....................................................................................................................83
Figure 99. Back Panel Features ...........................................................................................................................................................84
Figure 100. Front Control Panel Features ......................................................................................................................................84
Figure 101. Front I/O Features ............................................................................................................................................................85
Figure 102. 2.5” Hot Swap Drive Slot LED Identification..........................................................................................................85
Figure 103. 3.5” Drive Slot LED Identification...............................................................................................................................85
Figure 104. Intel® Server Board M50CYP2SBSTD Component / Feature Identification............................................. 87
Figure 105. Intel® Light-Guided Diagnostics –LED Identification.........................................................................................88
Figure 106. Exploded View of POST Code Diagnostic, System ID, and System Status LEDs ...................................88
Figure 107. Intel® Light-Guided Diagnostics - DIMM Fault LEDs...........................................................................................89
Figure 108. Reset and Recovery Jumper Block Locations.......................................................................................................89
Figure 109. System Top Cover Panel Shipping Screws ............................................................................................................91
Figure 110. System Top Cover Removal .........................................................................................................................................91
Figure 111. System Top Cover Installation....................................................................................................................................92
Figure 112. Standard Air Duct for Processor Heat Sink with 2U Height............................................................................93
Figure 113. Standard Air Duct for Processor Heat Sink with 1U Height............................................................................93
Figure 114. GPGPU Air Duct for Processor Heat Sink with 1U Height................................................................................93
Figure 115. Air Duct Removal...............................................................................................................................................................94
Figure 116. GPGPU Air Duct Bracket Removal .............................................................................................................................94
Figure 117. Air Duct Installation .........................................................................................................................................................95
Figure 118. GPGPU Air Duct Bracket Installation ........................................................................................................................95
Figure 119. System Fan Assembly Removal..................................................................................................................................96
Figure 120. System Fan Assembly Installation –Part 1...........................................................................................................97
Figure 121. System Fan Assembly Installation –Part 2............................................................................................................97

Intel® Server System M50CYP2UR Family System Integration and Service Guide
13
Figure 122. Individual Fan Removal or Installation ....................................................................................................................98
Figure 123. Memory Module Removal.............................................................................................................................................99
Figure 124. Memory Module Installation..................................................................................................................................... 100
Figure 125. Power Supply Removal ............................................................................................................................................... 101
Figure 126. Power Supply Installation .......................................................................................................................................... 101
Figure 127. PHM Assembly Removal from Processor Socket............................................................................................. 102
Figure 128. Reinstall the Socket Cover......................................................................................................................................... 102
Figure 129. Processor Removal from PHM Assembly ............................................................................................................ 103
Figure 130. Processor Carrier Clip Removal from PHM Assembly.................................................................................... 103
Figure 131. Installing Processor Carrier Clip onto Processor –Part 1............................................................................. 104
Figure 132. Installing Processor Carrier Clip onto Processor –Part 2............................................................................. 104
Figure 133. Removing Heat Sink from its Packaging .............................................................................................................. 105
Figure 134. Processor Heat Sink Anti-tilt Wires in the Outward Position...................................................................... 105
Figure 135. Pin 1 Indicator of Processor Carrier Clip.............................................................................................................. 106
Figure 136. Socket Protective Cover Removal........................................................................................................................... 106
Figure 137. PHM Alignment with Socket Assembly ................................................................................................................ 107
Figure 138. PHM Installation onto Server Board ...................................................................................................................... 107
Figure 139. Tighten Heat Sink Fasteners ..................................................................................................................................... 108
Figure 140. 2.5” Drive Bay Components....................................................................................................................................... 109
Figure 141. 3.5” Drive Bay Components....................................................................................................................................... 109
Figure 142. Drive Removal ................................................................................................................................................................. 110
Figure 143. Separating Top and Bottom Parts of Drive Blank ............................................................................................ 110
Figure 144. Attaching the Drive Blank to 7 mm SSD............................................................................................................... 111
Figure 145. 2.5” 7 mm Drive Outside Chassis, Ready for Installation.............................................................................. 111
Figure 146. 2.5” 7 mm Drive Installation into Chassis............................................................................................................ 111
Figure 147. 2.5” 15 mm Drive Outside Chassis, Ready for Installation ........................................................................... 112
Figure 148. 2.5” 15 mm Drive Installation into Chassis......................................................................................................... 112
Figure 149. 3.5” Drive Removal........................................................................................................................................................ 113
Figure 150. 3.5” Drive Assembly –Drive Blank / Drive Removal........................................................................................ 113
Figure 151. 3.5” Drive Assembly – Drive Installation to Carrier.......................................................................................... 114
Figure 152. 3.5" Drive Carrier to 2.5” SSD Bracket – Tab Removal and Mount SSD to Bracket............................ 114
Figure 153. 3.5" Drive Carrier to 2.5” SSD Bracket – Mount Bracket Assembly to Carrier ...................................... 115
Figure 154. 3.5” Drive Carrier to 2.5” SSD Bracket – Secure SSD to Carrier.................................................................. 115
Figure 155. 3.5” drive Assembly Installation.............................................................................................................................. 116
Figure 156. 8 x 2.5” Backplane Removal ...................................................................................................................................... 117
Figure 157. 8 x 2.5” Backplane Installation................................................................................................................................. 118
Figure 158. 12 x 3.5” Backplane Removal ................................................................................................................................... 119
Figure 159. 12 x 3.5” Backplane Installation .............................................................................................................................. 120
Figure 160. Replacing the System Battery................................................................................................................................... 121
Figure 161. Server Board Removal ................................................................................................................................................. 122
Figure 162. Server Board Installation............................................................................................................................................ 123

Intel® Server System M50CYP2UR Family System Integration and Service Guide
14
Figure 163. System Cable Routing Channels ............................................................................................................................. 125
Figure 164. Intel® Server System M50CYP2UR Family Memory Slot Layout................................................................ 126
Figure 165. Onboard POST Diagnostic LEDs ............................................................................................................................. 131
List of Tables
Table 1. Intel® Server M50CYP Family Reference Documents and Support Collaterals ............................................17
Table 2. Supported Intel® Ethernet Network Adapters for OCP*..........................................................................................57
Table 3. SAS/SATA/NVMe* Drive Status LED States..................................................................................................................86
Table 4. Drive Activity LED States ......................................................................................................................................................86
Table 5. Intel® Optane™ DC Persistent Memory 200 Series Module Support Guidelines........................................ 128
Table 6. Standard DRAM DIMMs Compatible with Intel® Optane™ Persistent Memory 200 Series Module ... 128
Table 7. System Status LED State Definitions............................................................................................................................ 129
Table 8. POST Progress Code LED Example............................................................................................................................... 132
Table 9. MRC Progress Codes........................................................................................................................................................... 132
Table 10. MRC Fatal Error Codes..................................................................................................................................................... 133
Table 11. POST Progress Codes...................................................................................................................................................... 134
Table 12. POST Error Messages and Handling.......................................................................................................................... 138
Table 13. POST Error Beep Codes.................................................................................................................................................. 143
Table 14. Integrated BMC Beep Codes ......................................................................................................................................... 143
Table 15. Mixed Processor Configurations Error Summary................................................................................................. 144

Intel® Server System M50CYP2UR Family System Integration and Service Guide
15
1. Introduction
The Intel® Server System M50CYP2UR family is a purpose built, storage-optimized system that delivers
power and performance at a peak efficiency in a 2U rack mount server form factor. The server system
supports up to two 3rd Gen Intel® Xeon® Scalable processors, delivering high core count and new hardware-
enhanced security features. Previous generation Intel® Xeon® processor and Intel® Xeon® Scalable processor
families are not supported.
The system provides high memory bandwidth and capacity of up to 32 DDR4 DIMMs for memory intensive
workloads. The product family supports Intel® Optane™ DC persistent memory 200 series modules.
For details on all system features, refer to the Intel® Server System M50CYP2UR Family Technical Product
Specification. See Table 1.
See Table 1 for a list of documentation available. For the latest revision of the document, go to
https://www.intel.com/content/www/us/en/support/products/77593/server-products/server-systems.html.

Intel® Server System M50CYP2UR Family System Integration and Service Guide
16
About This Document
This document provides system integrators and service technicians with instructions for the installation and
removal of system components. The document also provides available Intel accessories supported by this
server system.
The document is organized into two sections. The first section (Chapters 2 through 4) is focused on the
installation of system components and accessories into an L6 or L9 integrated server system
1
.
The second section (Chapters 5, 6, and appendices A-G) is focused on system service. This section provides
the service technician with valuable system information and procedures necessary to successfully identify
and replace a faulty system component.
System Integration
Chapter 2 –L6 System Integration –Essential System Components –Installation procedures for the
following system components: Processors, Memory, and Power Supply. Removal and installation of the
system top cover and air ducts are covered.
Chapter 3 –L9 System Integration - Provides detailed instructions necessary to enhance system
configurations by installing additional components and/or available accessory kits.
Chapter 4 –System Software Update and Configuration –A short overview describing the system
software stack installed on new Intel servers and where to get the latest revisions.
System Service
Chapter 5 –System Service –System Features Overview. An overview that identifies and locates the
features associated with the Intel® Server System M50CYP2U family.
Chapter 6 –System Service and FRU Replacement. Provides installation procedures for system field
replaceable units (FRUs).
Appendix A –Getting Help. Provides server system support and contact information.
Appendix B –Internal Cable Routing Channels. Provides cable routing guidance.
Appendix C –General Memory Population Rules. Provides a summary of general memory population
rules.
Appendix D –System Status LED Operating States and Definition. Provides system status LED
operating states and definition.
Appendix E –POST Code Diagnostic LED Decoder. Lists of Diagnostic LED codes.
Appendix F –POST Code Errors. List of POST code errors that represent specific failures, warnings, or
information.
Appendix G –System Packaging Assembly Instructions. Provides detailed instructions to repack
the server system into the original Intel packaging.
1
An L6 integrated system requires essential components to be installed to make it power-on ready. An L9
integrated system is power-on ready but may require additional options and/or accessories to be installed in
order to enable specific system features.

Intel® Server System M50CYP2UR Family System Integration and Service Guide
17
1.1 Reference Documents and Support Collaterals
For additional information, see the product support collaterals specified in the following table. The following
webpage provides support information for the M50CYP family:
https://www.intel.com/content/www/us/en/support/products/200321.html
Table 1. Intel® Server M50CYP Family Reference Documents and Support Collaterals
Topic
Document Title or Support Collateral
Document
Classification
For system integration
instructions and service guidance
Intel® Server System M50CYP2UR Family System Integration and Service
Guide
Public
For system integration
instructions and service guidance
Intel® Server System M50CYP1UR Family System Integration and Service
Guide
Public
For technical system-level
description
Intel® Server System M50CYP2UR Family Technical Product Specification
Public
For technical system-level
description
Intel® Server System M50CYP1UR Family Technical Product Specification
Public
For technical board-level
description
Intel® Server Board M50CYP2SB Family Technical Product Specification
Public
For server configuration guidance
and compatibility
Intel® Server M50CYP Family Configuration Guide
Public
For information on the Integrated
BMC Web Console
Intel® Integrated Baseboard Management Controller Web Console
(Integrated BMC Web Console) User Guide
For the Intel® Server Board D50TNP and M50CYP Families
Public
For BIOS technical information
on Intel® Server M50CYP Family
BIOS Firmware External Product Specification (EPS)
For the Intel® Server Board D50TNP and M50CYP Families
Intel
Confidential
For BIOS setup information on
Intel® Server M50CYP Family
BIOS Setup Utility User Guide
For the Intel® Server Board D50TNP and M50CYP Families
Public
For BMC technical information on
Intel® Server M50CYP Family
Integrated Baseboard Management Controller Firmware External Product
Specification
For the Intel® Server System D50TNP and M50CYP Families
Intel
Confidential
Base specifications for the IPMI
architecture and interfaces
Intelligent Platform Management Interface Specification Second
Generation v2.0
Intel
Confidential
Specifications for the PCIe* 3.0
architecture and interfaces
PCIe* Base Specification, Revision 3.0
http://www.pcisig.com/specifications
Public
Specifications for the PCIe* 4.0
architecture and interfaces
PCIe* Base Specification, Revision 4.0
http://www.pcisig.com/specifications
Public
Specification for OCP*
Open Compute Project* (OCP*) Specification
Intel
Confidential
TPM for PC Client specifications
TPM PC Client Specifications, Revision 2.0
Intel
Confidential
Functional specifications of 3rd
Gen Intel® Xeon® Scalable
processor family
3rd Generation Intel® Xeon® Scalable Processors, Codename Ice Lake-SP
External Design Specification (EDS): Document IDs: 574451, 574942,
575291
Intel
Confidential
BIOS and BMC Security Best
Practices
Intel® Server Systems Baseboard Management Controller (BMC) and BIOS
Security Best Practices White Paper
https://www.intel.com/content/www/us/en/support/articles/000055785/s
erver-products.html
Public
Managing an Intel Server
Overview
Managing an Intel Server System 2020
https://www.intel.com/content/www/us/en/support/articles/000057741/s
erver-products.html
Public

Intel® Server System M50CYP2UR Family System Integration and Service Guide
18
Topic
Document Title or Support Collateral
Document
Classification
For technical information on
Intel® Optane™ persistent
memory 200
Intel® Optane™ Persistent Memory 200 Series Operations Guide
Intel
Confidential
For setup information for Intel®
Optane™ persistent memory 200
Intel® Optane™ Persistent Memory Startup Guide
Public
For latest system software
updates: BIOS and Firmware
Intel® System Update Package (SUP) for Intel® Server M50CYP Family
Public
Intel® System Firmware Update Utility (SYSFWUPDT) - Various operating
system support
Intel® System Firmware Update Utility User Guide
To obtain full system information
Intel® SYSINFO Utility for Intel® Server M50CYP Family
Public
Intel® System Information Utility User Guide
To configure, save, and restore
various system options
Intel® SYSCFG Utility for Intel® Server M50CYP Family –Various operating
system support
Public
Intel® System Configuration Utility User Guide
Product Warranty Information
Warranty Terms and Conditions
https://www.intel.com/content/www/us/en/support/services/000005886
.html
Public
Note: Intel Confidential documents are made available under a Non-Disclosure Agreement (NDA) with Intel
and must be ordered through your local Intel representative.

Intel® Server System M50CYP2UR Family System Integration and Service Guide
19
2. Essential System Component Installation and Service
The Intel® Server System M50CYP2UR family is offered with different levels of system integration. Systems
that are not power-on ready are identified as L6 integrated systems. An L6 integrated system requires
essential components (sold separately) to be installed. If your Intel system did not come pre-installed with
any of the following components, then follow the procedures in this chapter:
•1 (Required) processor or 2 (Optional) processors –3rd Gen Intel® Xeon® Scalable processor family
•Memory –Up to 32 DDR4 DIMMs
•1 (Required) or 2 (Optional) power supplies
If your Intel server system came pre-installed with all the components listed above, then skip this chapter
and go to Chapter 3 for installation procedures associated with all other system options and accessories.
Before You Begin
Before integration of any system components, review all the safety and ESD precautions found in the Safety
Warnings section at the beginning of this document.
System Reference
In the following procedures, all references to left, right, front, top, and bottom assume the reader is facing
the front of the server chassis.
Instruction Format
Each procedure described in this chapter follows an illustration first format. This format gives the reader the
option to follow a quicker path to component integration by first seeing an illustration of the intended
procedure. If necessary, the reader can then follow the step-by-step instructions that will accompany each
procedure.

Intel® Server System M50CYP2UR Family System Integration and Service Guide
20
2.1 Chassis Component Identification
The following figure identifies the chassis components.
Figure 1. Chassis Component Identification
2.2 System Cover Removal / Installation
The system top cover consists of two panels –one over the front half of the system and one over the back
half of the system. To maintain system thermals, both top cover panels must always be in place when the
system is operational.
Required Tools and Supplies
•Anti-static wrist strap and conductive workbench pad (recommended)
•Phillips* head screwdriver #1
2.2.1 System Cover Removal
Removal of both top cover panels is necessary when installing or replacing any system component within the
server chassis. Before removing the top cover, power down the system and unplug all peripheral devices and
the power cable(s).
