Intel NSC2U - IP Network Server User manual

vIP Network Server NSC2U
vFront and Rear I/O flexibility, with up to 8 x Gb NICs in front
vShort depth, ruggedized 2U chassis
v“Appliance” look and feel
vLong life support (3 years)
vDual, redundant AC or DC power option
vHardware RAID option
vIndustry-leading performance/watt

.
IP Network Server NSC2U
Features Benefits
Support for two 64-bit Quad-Core Intel® Xeon® processors
(5400 series or 5300 series)
vNew 45nm enhanced Intel® Core™ microarchitecture boosts performance on multiple
applications/user environments and data-demanding workloads
vFaster performance with improved energy efficiency enables denser deployments
Three-year extended lifecycle support with possible extension
to five years
vReduces customer risk for long product roll-outs
vFewer platform transitions requiring additional testing and software
Shallow 20-inch depth vIncreases installation and service flexibility
600W AC or DC hot-swap power supply vFlexibility of installation and applications
vUninterrupted operation (DC-backed power)
Two rear-panel GbE NIC (Cu) ports vScalable Ethernet ports, upgradeable to 20 GbE (max) based on PCI configuration and
optional I/O modules
Eight FB-DIMM slots (240-pin DDR2-533/667) vMaximum 32 GB memory (non-mirrored mode)
Drive trays for up to six hot-swap 2.5-inch SAS hard disk drives vHigh-performance, enterprise-class drives for 24/7 operation
Bay supports optical drive (purchased separately) vAccommodates Slimline CD-ROM; CD-R/W; CD DVD-R/W
Customizable front bezel vAdaptable to customer needs and environment
Up to five PCI slots for flexibility and additional I/O vLow-profile riser supports two PCIe x4 slots
vFull-height, full-length riser supports two PCIe x4 slots and one PCI-X slot
Optional Features Benefits
Hardware RAID 5 vGreater protection and reliability of data storage
Intel® Remote Management Module 2 vLights-out management
Flash storage capability supports 3rd party
solid state drives (purchased separately)
vHigh-speed, high-density storage, faster boot times, USB interface
Optional I/O modules (rear) vEnables additional external SAS storage or two additional GbE NIC (Cu) ports on rear panel
Additional four or eight front-panel GbE NIC ports (copper or fiber) vHigh-performance, enterprise-class drives for 24/7 operation
Additional full-height risers for PCI-X vPCI-X (active): three independent PCI-X, each with maximum 133 MHz
vPCI-X (passive): two PCI-X with maximum 100 MHz and
one PCI-X (66 MHz) all on a shared PCI bus
vFeatures & Benefits
AB D
CE
F
R
GH I JK
MO
LN
P
Q
IP Network Server NSC2U front panel
A Anti-static connection
B Optical drive bay
(optional)
C 4x GbE ports (optional)
D For future design use
E Serial port (COM 2)
F USB port
G Power LED
H Status LED
I Disk activity LED
J NIC activity LED
K ID LED
L Power switch
M Reset switch
N NMI switch
O ID switch
P Drive fault indicator
Q Drive activity indicator
R Hard drive bay
(supports six 2.5” SAS)
0 1
MLKG F
JIH
ADE
BC
IP Network Server NSC2U rear panel
A Low-profile add-in
cards or filler panels
B Full-height add-in
cards or filler panels
C Grounding lugs (for DC)
D Power supply #2 slot
(filler panel shown)
E Power supply #1
(AC module shown; DC
modules also available)
F Filler panel (optional
GCM port)
G Filler panel (optional
dual NIC or external
SAS ports)
H USB ports
I Video connector
J RJ45 NIC 2 Connector
K RJ45 NIC 1 Connector
L RJ45 Serial port
(COM 2)
M PS2 mouse and
keyboard
IP Network Server NSC2U, featuring the Quad-Core Intel® Xeon®
processors 5400 and 5300 series, provides extended lifecycle support
and improved performance-per-watt over previous generation rack-
mount servers. Due to high I/O throughput and performance, the NSC2U
is an excellent choice for network security applications with large I/O
requirements, including intrusion detection/intrusion prevention, VPN/
firewall, and unified threat management solutions.
The NSC2U features shallow depth, DC power capabilities, and the
ruggedness usually found on carrier-grade servers. It is well suited
for enterprise application acceleration and content caching, and is
an ideal platform for running Telco SoIP, including IMS, IPTV, video
on demand (VoD), SIP application servers, IP-PBX, and IP-PSTN
gateways.
