Intel SR1530CLR - Server System - 0 MB RAM User manual

Intel® Server Systems
SR1530CL/SR1530HCL/SR1530HCS
and SR1530CLR/SR1530HCLR
/SR1530HCLSR
Technical Product Specification
Intel order number D71005-005
Revision 2.2
May 2010
Enterprise Platforms and Services Division - Marketing

Revision History Intel® Server Systems SR1530CL/SR1530HCL/SR1530HCS
and SR1530CLR/SR1530HCLR/SR1530HCLSR
Revision 2.2
Intel order number D71005-005
ii
Revision History
Date Revision
Number
Modifications
September 2006 1.0 Initial release.
January. 2007 2.0 Added Intel®Server Systems SR1530HCL/SR1530HCLS and made regulatory
updates.
September. 2007 2.1 Updated product codes and processor information.
May 2010 2.2 Deleted CCC and CNCA.
Disclaimers
Information in this document is provided in connection with Intel®products. No license, express or implied, by
estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's
Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any
express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to
fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property
right. Intel products are not intended for use in medical, life saving, or life sustaining applications. Intel may make
changes to specifications and product descriptions at any time, without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked "reserved" or
"undefined." Intel reserves these for future definition and shall have no responsibility whatsoever for conflicts or
incompatibilities arising from future changes to them.
This document contains information on products in the design phase of development. Do not finalize a design with
this information. Revised information will be published when the product is available. Verify with your local sales office
that you have the latest datasheet before finalizing a design.
The server boards/systems referenced in this document may contain design defects or errors known as errata which
may cause the product to deviate from published specifications. Current characterized errata are available on
request.
Intel, Pentium, Itanium, and Xeon are trademarks or registered trademarks of Intel Corporation.
*Other brands and names may be claimed as the property of others.
Copyright © Intel Corporation 2010. All rights reserved.

Intel® Server Systems SR1530CL/SR1530HCL/SR1530HCS Table of Contents
and SR1530CLR/SR1530HCLR/SR1530HCLSR
Revision 2.2
Intel order number D71005-005
iii
Table of Contents
1. Introduction ..........................................................................................................................1
1.1 System Views..........................................................................................................1
1.2 System Dimensions.................................................................................................2
1.3 System Components ...............................................................................................3
1.4 System Boards ........................................................................................................5
1.5 Hard Drive and Peripheral Bays ..............................................................................5
1.6 Power Sub-System..................................................................................................7
1.7 System Cooling........................................................................................................7
1.8 Rack and Cabinet Mounting Options.......................................................................7
2. Power Sub-System...............................................................................................................8
2.1 Mechanical Overview...............................................................................................8
2.2 Output Connectors...................................................................................................9
2.2.1 P1 – Main Power Connector....................................................................................9
2.2.2 P2 – Processor Power Connector .........................................................................10
2.2.3 P3 – Baseboard Signal Connector ........................................................................10
2.2.4 P4 and P5 – SATA Hard Drive Power Connectors................................................10
2.2.5 P6 – CD Power Connector ....................................................................................11
2.2.6 P7 – HSBP Power Connector................................................................................11
2.3 Efficiency ...............................................................................................................11
2.4 AC Input Voltage Requirement..............................................................................11
2.5 Protection Circuits..................................................................................................12
2.5.1 Over-current Protection (OCP) ..............................................................................12
2.5.2 Over-voltage Protection (OVP)..............................................................................12
2.5.3 Over-temperature Protection (OTP).......................................................................13
2.6 AC Power Cord Specification Requirements.........................................................13
3. Cooling Sub-System ..........................................................................................................14
3.1 Power Supply Fans................................................................................................15
3.2 Processor Air Duct and Air Baffle..........................................................................15
4. Peripheral and Hard Drive Support...................................................................................17
4.1 Optical Drive Support.............................................................................................18
4.1.1 Optical Drive Support.............................................................................................18
4.2 Hard Disk Drive Support........................................................................................19

Table of Contents Intel® Server Systems SR1530CL/SR1530HCL/SR1530HCS
and SR1530CLR/SR1530HCLR/SR1530HCLSR
Revision 2.2
Intel order number D71005-005
iv
4.2.1 Hot-Swap Hard Disk Drive Trays...........................................................................19
4.2.2 Drive Blanks...........................................................................................................20
4.2.3 System Fan Connectors........................................................................................21
5. Front Control Panel............................................................................................................22
5.1.1 Power/Sleep LED ..................................................................................................24
5.1.2 System Status LED................................................................................................24
5.1.3 Drive Activity LED..................................................................................................25
6. PCI Riser Cards and Assembly.........................................................................................26
7. Backplane Board................................................................................................................27
7.1.1 Hard Drive Activity LED .........................................................................................29
8. Supported Intel®Server Boards........................................................................................30
8.1 Intel®Server Board S5000VCL Feature Set..........................................................30
9. Environmental and Regulatory Specifications................................................................31
9.1 System Level Environmental Limits.......................................................................31
9.2 Serviceability and Availability.................................................................................31
9.3 Replacing the CMOS Battery.................................................................................32
9.4 Product Regulatory Compliance............................................................................33
9.5 Use of Specified Regulated Components..............................................................33
9.6 Electromagnetic Compatibility Notices ..................................................................35
9.6.1 USA .......................................................................................................................35
9.6.2 FCC Verification Statement...................................................................................36
9.6.3 ICES-003 (Canada)...............................................................................................36
9.6.4 Europe (CE Declaration of Conformity) .................................................................36
9.6.5 Japan EMC Compatibility ......................................................................................36
9.6.6 BSMI (Taiwan).......................................................................................................37
9.6.7 RRL (Korea)...........................................................................................................37
9.7 Product Ecology Compliance.................................................................................38
9.8 Other Markings......................................................................................................40
Appendix A: Integration and Usage Tips................................................................................41
Appendix B: POST Code Diagnostic LED Decoder...............................................................42
Appendix C: POST Error Beep Codes.....................................................................................46
Glossary.....................................................................................................................................47
Reference Documents..............................................................................................................48

Intel® Server Systems SR1530CL/SR1530HCL/SR1530HCS List of Figures
and SR1530CLR/SR1530HCLR/SR1530HCLSR
Revision 2.2
Intel order number D71005-005
v
List of Figures
Figure 1. Intel®Server System SR1530CL/SR1530CLR (SATA) .................................................1
Figure 2. Intel®Server Systems SR1530HCL/SR1530HCLR (SATA) and
SR1530HCLS/SR1530HCLSR (SAS)....................................................................................2
Figure 3. Major System Components - SR1530CL/SR1530CLR (SATA).....................................3
Figure 4. Major System Components - SR1530HCL/SR1530HCLR (SATA) and
SR1530HCLS/SR1530HCLSR (SAS)....................................................................................4
Figure 5. Back Panel Features .....................................................................................................5
Figure 6. Drive Bays (SR1530CL/SR1530CLR) ...........................................................................6
Figure 7. Drive Bays - SR1530HCL/SR1530HCLR (SATA) and SR1530HCLS/SR1530HCLSR
(SAS)......................................................................................................................................6
Figure 8. Power Supply Mechanical Drawing...............................................................................8
Figure 9. AC Power Cord Specifications.....................................................................................13
Figure 10. Fan Module Assembly - SR1530CL/SR1530CLR (SATA).........................................14
Figure 11. Fan Module Assembly - SR1530HCL/SR1530HCLR (SATA) and
SR1530HCLS/SR1530HCLSR (SAS)..................................................................................15
Figure 12. Air Baffle (SR1530CL/SR1530CLR)..........................................................................16
Figure 13. Air Baffle (SR1530HCL/SR1530HCLR).....................................................................16
Figure 14. Drive Bays SR1530CL/SR1530CLR (SATA).............................................................17
Figure 15. Drive Bays - SR1530HCL/SR1530HCLR (SATA) and SR1530HCLS/SR1530HCLSR
(SAS)....................................................................................................................................18
Figure 16. Hard Drive Tray Assembly.........................................................................................20
Figure 17. Drive Tray with Drive Blank .......................................................................................20
Figure 18. Front Control Panel - SR1530CL/SR1530CLR (SATA).............................................22
Figure 19. Front Control Panel - SR1530HCL/SR1530HCLR (SATA) and
SR1530HCLS/SR1530HCLSR (SAS)..................................................................................23
Figure 20. PCI Riser Card Assembly..........................................................................................26
Figure 21. Hot Swap Passive Backplane - SR1530HCL/SR1530HCLR (SATA) and
SR1530HCLS/SR1530HCLSR (SAS)..................................................................................27
Figure 22. Diagnostic LED Placement Diagram Example ..........................................................42

List of Tables Intel® Server Systems SR1530CL/SR1530HCL/SR1530HCS
and SR1530CLR/SR1530HCLR/SR1530HCLSR
Revision 2.2
Intel order number D71005-005
vi
List of Tables
Table 1. Intel®Server System SR1530CL/SR1530CLR Dimensions ...........................................2
Table 2. Intel®Server Systems SR1530HCL/SR1530HCLR and SR1530HCLS/SR1530HCLSR
Dimensions.............................................................................................................................2
Table 3. Cable Harness Definition................................................................................................9
Table 4. P1 – Main Power Connector Pin-out...............................................................................9
Table 5. P2 – Processor Power Connector Pin-out....................................................................10
Table 6. P3 – Baseboard Signal Connector Pin-out...................................................................10
Table 7. P4 and P5 – SATA Hard Drive Power Connector Pin-out.............................................10
Table 8. P6 – CD Power Connector Pin-out...............................................................................11
Table 9. P7 – CD Power Connector Pin-out...............................................................................11
Table 10. Power Supply Efficiency .............................................................................................11
Table 11. AC Input Rating...........................................................................................................12
Table 12. Over-current Protection (OCP) ...................................................................................12
Table 13. Over-Voltage Protection (OVP) Limits ........................................................................13
Table 14. Cooling Zones.............................................................................................................15
Table 15. 44-pin Internal IDE Connector Pin-out........................................................................19
Table 16. System Fan Connector Pin-outs.................................................................................21
Table 17. Control Panel LED Functions......................................................................................23
Table 18. SSI Power LED Operation..........................................................................................24
Table 19. Control Panel LED Operation .....................................................................................24
Table 20. Passive SATA/SAS Backplane Power Connector Pin-out (J7)...................................27
Table 21. Passive SATA/SAS Backplane Connector to Hard Drive Pin-out (J1, J2, J3)............28
Table 22. Passive SATA/SAS Backplane I/O Connector to Baseboard Pin-out (J4, J5, J6)......28
Table 23. Hard Drive Activity LED for SAS Drives......................................................................29
Table 24. Hard Drive Activity LED for SATA II Drives.................................................................29
Table 25. Hard Drive Activity LED for SATA I Drives..................................................................29
Table 26. Feature Set.................................................................................................................30
Table 27. System Environmental Limits Summary .....................................................................31
Table 28. Product Safety & Electromagnetic (EMC) Compliance...............................................34
Table 29: POST Progress Code LED Example ..........................................................................42
Table 30. Diagnostic LED POST Code Decoder........................................................................43

Intel® Server Systems SR1530CL/SR1530HCL/SR1530HCS List of Tables
and SR1530CLR/SR1530HCLR/SR1530HCLSR
Revision 2.2
Intel order number D71005-005
vii
Table 31. POST Error Beep Codes ............................................................................................46
Table 32. BMC Beep Codes.......................................................................................................46

List of Tables Intel® Server Systems SR1530CL/SR1530HCL/SR1530HCS
and SR1530CLR/SR1530HCLR/SR1530HCLSR
Revision 2.2
Intel order number D71005-005
viii
< This page intentionally left blank. >

Intel® Server Systems SR1530CL/SR1530HCL/SR1530HCS Introduction
and SR1530CLR/SR1530HCLR/SR1530HCLSR
Revision 2.2
Intel order number D71005-005
1
1. Introduction
The Intel®Server Systems SR1530CL/SR1530CLR and SR1530HCL/SR1530HCLR are 1U
server systems that are designed to support the Intel®Server Board S5000VCL/S5000VCLR
(SATA). The Intel®Server System SR1530HCLS/SR1530HCLSR is designed to support the
Intel®Server Board S5000VCLSASBB/BBS5000VCLSASR (SAS). The server boards and the
systems have features that are designed to support the high-density server market. This chapter
provides a high-level overview of the system features. Greater detail for each major system
component or feature is provided in the following chapters.
1.1 System Views
Figure 1. Intel®Server System SR1530CL/SR1530CLR (SATA)

Introduction Intel® Server Systems SR1530CL/SR1530HCL/SR1530HCS
and SR1530CLR/SR1530HCLR/SR1530HCLSR
Revision 2.2
Intel order number D71005-005
2
Figure 2. Intel®Server Systems SR1530HCL/SR1530HCLR (SATA) and
SR1530HCLS/SR1530HCLSR (SAS)
1.2 System Dimensions
Table 1. Intel®Server System SR1530CL/SR1530CLR Dimensions
Height 1.69 inches
Width without rails 17 inches
Depth without CMA 20 inches
Maximum weight 22 pounds
Table 2. Intel®Server Systems SR1530HCL/SR1530HCLR and SR1530HCLS/SR1530HCLSR
Dimensions
Height 1.70 inches
Width without rails 16.92 inches
Depth without CMA 25.51 inches (excluding hard drive carriers,
front control panel bezel, rack handles and
front bezel)
Maximum weight 23 pounds

Intel® Server Systems SR1530CL/SR1530HCL/SR1530HCS Introduction
and SR1530CLR/SR1530HCLR/SR1530HCLSR
Revision 2.2
Intel order number D71005-005
3
1.3 System Components
AF001185
A
C
D
B
F
E
G
H
I
K
A
J
A Rack handles (two) G Processor sockets (two)
B PCI cooling fan H System blower fans (two)
C Processor air duct I Hard drives (two)
D PCI add-in card bracket J Control panel
E System memory DIMM sockets K Slimline optical drive
F Power supply
Figure 3. Major System Components - SR1530CL/SR1530CLR (SATA)

Introduction Intel® Server Systems SR1530CL/SR1530HCL/SR1530HCS
and SR1530CLR/SR1530HCLR/SR1530HCLSR
Revision 2.2
Intel order number D71005-005
4
AF001612
A
L
J
E
F
B
H
I
G
A
D
C
K
A Rack handles (two) G Server board
B PCI air baffle H Power supply
C System blower fans (two) I Front panel board
D Processor air duct J Control panel
E System memory DIMM sockets K Hot-swap hard drives (three)
F PCI riser assembly L Slimline optical drive
Figure 4. Major System Components - SR1530HCL/SR1530HCLR (SATA) and
SR1530HCLS/SR1530HCLSR (SAS)

Intel® Server Systems SR1530CL/SR1530HCL/SR1530HCS Introduction
and SR1530CLR/SR1530HCLR/SR1530HCLSR
Revision 2.2
Intel order number D71005-005
5
Note: The I/O connector locations on the back of the chassis are pre-cut, making an I/O shield
unnecessary. The supplied EMI gasket must be installed to maintain electromagnetic
interference (EMI) compliance levels.
AF001183
F
E G H
I
J
CBA D
A AC Power Connector F USB Ports 0 and 1
B Mouse Socket G Serial Port A
C PCI Express* Slot H Video Connector
D PCI-X* Slot I NIC 1 Connector (10/100/1000 Mb)
E Keyboard Socket J NIC 1 Connector (10/100/1000 Mb)
Figure 5. Back Panel Features
1.4 System Boards
The system includes system boards that are used as internal interconnects and provide feature
accessibility. The following provides a brief description for each:
Riser card – The system supports one PCI riser card that supports up to two add-in cards:
One low-profile PCI Express* x8 and one mid-height PCI-X* 133.
Or one low-profile PCI Express* x4 and one mid-height PCI Express* x4.
1.5 Hard Drive and Peripheral Bays
The Intel®Server System SR1530CL/SR1530CLR is designed to support up to two fixed 3.5-
inch SATA (Serial ATA) hard drives and one slimline optical device.

Introduction Intel® Server Systems SR1530CL/SR1530HCL/SR1530HCS
and SR1530CLR/SR1530HCLR/SR1530HCLSR
Revision 2.2
Intel order number D71005-005
6
AF001184
C
AB
A Slimline optical drive bay
B Hard drive bay HDD0 (located under the
slimline optical drive bay)
C Hard drive bay HDD1
Figure 6. Drive Bays (SR1530CL/SR1530CLR)
The Intel®Server Systems SR1530HCL/SR1530HCLR and SR1530HCLS/SR1530HCLSR are
designed to support up to three hot-swap SATA (Serial ATA) or SAS hard drives and one
slimline optical device.
A Slimline optical drive bay
B Hot Swap Hard Drive Bay
Figure 7. Drive Bays - SR1530HCL/SR1530HCLR (SATA) and SR1530HCLS/SR1530HCLSR (SAS)

Intel® Server Systems SR1530CL/SR1530HCL/SR1530HCS Introduction
and SR1530CLR/SR1530HCLR/SR1530HCLSR
Revision 2.2
Intel order number D71005-005
7
1.6 Power Sub-System
The power sub-system consists of one non-redundant 400-watt power supply. It provides
integrated management features, including over-temperature protection circuitry and over-
voltage protection circuitry.
The power supply operates within the following voltage ranges and ratings:
Parameter Minimum Rated Maximum Start up VAC Power Off VAC
Voltage (110) 90 Vrms 100-127 Vrms 140 Vrms 85Vac +/-4Vac 75Vac +/-5Vac
Voltage (220) 180 Vrms 200-240 Vrms 264 Vrms
Frequency 47 Hz 63 Hz
The power supply must operate within all specified limits over the input voltage ranges shown in
the table. Harmonic distortion of up to 10% THD must not cause the power supply to exceed the
specified limits.
The power supply shall power off if the AC input is less than 75 VAC +/- 5 VAC range. The
power supply shall start up if the AC input is greater than 85 VAC +/- 4 VAC. Application of an
input voltage below 85 VAC shall not cause damage to the power supply, including a fuse blow.
1.7 System Cooling
The system provides two non-redundant blower fans. The Intel®Server System
SR1530CL/SR1530CLR (SATA) also includes an additional PCI cooling fan. When external
ambient temperatures remain within specified limits, the cooling system will provide sufficient air
flow for all drive configurations, processors, supported memory, and add-in cards.
1.8 Rack and Cabinet Mounting Options
The Intel®Server System SR1530CL/SR1530CLR (SATA) can be installed in 19-inch wide by
up to 30-inch deep server cabinets. The system supports three rack mount options:
A fixed mount relay rack/cabinet mount kit which can be configured to mount the system
into either a 2-post or 4-post rack cabinet. (Product order code for the cabinet mount kit:
AXXBRACKETS).
A tool-less full extracting slide rail kit designed to support an optional cable management
arm. (Product order code for the sliding rail kit: AXXHERAIL. Product order code for the
cable management arm: AXXRACKCARM).
A basic slide rail kit designed to mount the chassis into a standard 19-inch by up to 30-
inch deep EIA-310D compatible server cabinet. (Product order code for the slide rail kit:
AXXBASICRAIL).

Power Sub-System Intel® Server Systems SR1530CL/SR1530HCL/SR1530HCS
and SR1530CLR/SR1530HCLR/SR1530HCLSR
Revision 2.2
Intel order number D71005-005
8
2. Power Sub-System
This specification defines a 400-watt non-redundant power supply that supports a 1U rack
mount server system. The power supply and the power supply sub-system shall have five
outputs; 3.3 V, 5 V, 12 V, -12 V, and 5 VSB. The input shall be auto-ranging and power factor
corrected. The form factor is SSI EPS1U at 300 mm depth and wire harness output.
The power supply provides two non-redundant 40 mm fans for self-cooling. The power supply
fans also contribute to the airflow for parts of the system.
2.1 Mechanical Overview
Figure 8. Power Supply Mechanical Drawing

Intel® Server Systems SR1530CL/SR1530HCL/SR1530HCS Power Sub-System
and SR1530CLR/SR1530HCLR/SR1530HCLSR
Revision 2.2
Intel order number D71005-005
9
2.2 Output Connectors
The power supply has a cable harness with five power connectors used to power various
platform sub-systems. The following table defines each power connector.
Table 3. Cable Harness Definition
Label Length (mm) Description
P1 Main power connector
P2 440 Processor power connector
P3 400 Signal connector
P4,5,6 400+160+205
P4,5:SATA drive power connectors
P6:CD connector
From Length To Description
Case 400 P1 Main Power Connector
Case 340 P2 Processor Power Connector
Case 410 P3 Signal Connector
Case 220 P7 2x3 HSBP power connector
P7 100
+145+170 P4,P5,P6 P4,5:SATA drive power connectors P6:CD connector
2.2.1 P1 – Main Power Connector
Connector housing: 24-pin Molex* Mini-Fit Jr.39-01-2245 (94V2) or equivalent
Contact: Molex Mini-Fit, HCS, Female, Crimp 44476 or equivalent
Table 4. P1 – Main Power Connector Pin-out
Pin Signal 18 Awg Color Pin Signal 18 Awg Color
1 +3.3 VDC Orange 13 +3.3 VDC Orange
2 +3.3 VDC Orange 14 -12 VDC Blue
3 COM Black 15 COM Black
4 +5 VDC
1Red 16 PSON# Green
5 COM Black 17 COM Black
6 +5 VDC Red 18 COM Black
7 COM Black 19 COM Black
8 PWR OK Gray 20 Reserved N.C.
9 5VSB Purple 21 +5 VDC Red
10 +12V Yellow 22 +5 VDC Red
11 +12V Yellow 23 +5 VDC Red
12 +3.3 VDC Orange 24 COM Black
Notes:
1. 5V Remote Sense double-crimped into pin 4.

Power Sub-System Intel® Server Systems SR1530CL/SR1530HCL/SR1530HCS
and SR1530CLR/SR1530HCLR/SR1530HCLSR
Revision 2.2
Intel order number D71005-005
10
2.2.2 P2 – Processor Power Connector
Connector housing: 8-pin Molex* 39-01-2085 (94V2) or equivalent
Contact: Molex, Mini-FitJr, HCS, 44476-1111 or equivalent
Table 5. P2 – Processor Power Connector Pin-out
Pin Signal 18 Awg Color Pin Signal 18 Awg Color
1 COM Black 5 +12V Yellow
2 COM Black 6 +12V Yellow
3 COM Black 7 +12V Yellow
4 COM Black 8 +12V Yellow
2.2.3 P3 – Baseboard Signal Connector
Connector housing: 5-pin Molex* 50-57-9705 (94V2) or equivalent
Contacts: Molex 16-02-0087 or equivalent
Table 6. P3 – Baseboard Signal Connector Pin-out
Pin Signal 24 Awg Color
1 I2C Clock White/Green Stripe
2 I2C Data White/Yellow Stripe
3 Reserved NC
4 COM Black
5 3.3RS White/Brown Stripe
2.2.4 P4 and P5 – SATA Hard Drive Power Connectors
Connector housing: JWT* A3811H00-5P (94V2) or equivalent
Contact: JWT A3811TOP-0D or equivalent
Table 7. P4 and P5 – SATA Hard Drive Power Connector Pin-out
Pin Signal 18 Awg Color
1 +3.3V Orange
2 COM Black
3 +5VDC Red
4 COM Black
5 +12V Yellow

Intel® Server Systems SR1530CL/SR1530HCL/SR1530HCS Power Sub-System
and SR1530CLR/SR1530HCLR/SR1530HCLSR
Revision 2.2
Intel order number D71005-005
11
2.2.5 P6 – CD Power Connector
Connector housing: Molex* 51065-0400 (94V2) or equivalent
Contact: Molex 50212-8000 contact or equivalent
Table 8. P6 – CD Power Connector Pin-out
Pin Signal 22 Awg Color
1 +5VDC Red
2 COM Black
3 COM Black
4 +12V Yellow
2.2.6 P7 – HSBP Power Connector
Connector housing: 8-pin Molex* 39-01-2085 (94V2) or equivalent
Contact: Molex 2x4 Mini Fit Jr, HCS, 44476-3111 contact or equivalent
Table 9. P7 – CD Power Connector Pin-out
Pin Signal 18 Awg Color Pin Signal 18 Awg Color
1 GND Black 5 +12V
Blue/White
Stripe
2 GND Black 6 NC
3 +5V Red 7 NC
4 NC 8 3.3V Orange
2.3 Efficiency
The following table provides the required minimum efficiency level at various loading conditions.
These are provided at three different load levels; 100%, 50% and 20%. Efficiency shall be
tested over an AC input voltage range of 115 VAC to 220 VAC.
Table 10. Power Supply Efficiency
Loading 100% of Maximum 50% of Maximum 20% of Maximum
Minimum Efficiency 72% 70% 60%
2.4 AC Input Voltage Requirement
The power supply must operate within all specified limits over the following input voltage range,
shown in below table. Harmonic distortion of up to 10% THD must not cause the power supply
to go out of specified limits. The power supply shall power off if the AC input is less than 75
VAC +/- 5 VAC range. The power supply shall start up if the AC input is greater than 85 VAC +/-

Power Sub-System Intel® Server Systems SR1530CL/SR1530HCL/SR1530HCS
and SR1530CLR/SR1530HCLR/SR1530HCLSR
Revision 2.2
Intel order number D71005-005
12
4 VAC. Application of an input voltage below 85 VAC shall not cause damage to the power
supply, including a fuse blow.
Table 11. AC Input Rating
Parameter Minimum Rated Maximum Start up VAC Power Off VAC
Voltage (110) 90 Vrms 100-127 Vrms 140 Vrms 85Vac +/-4Vac 75VAC +/-5VAC
Voltage (220) 180 Vrms 200-240 Vrms 264 Vrms
Frequency 47 Hz 63 Hz
2.5 Protection Circuits
Protection circuits inside the power supply shall cause only the power supply’s main outputs to
shut down. If the power supply latches off due to a protection circuit tripping, an AC cycle off for
15 seconds and a PSON#cycle high for 1 second shall be able to reset the power supply.
2.5.1 Over-current Protection (OCP)
The power supply shall have current limit to prevent the +3.3 V, +5 V, and +12 V outputs from
exceeding the values shown in the following table. If the current limits are exceeded the power
supply shall shutdown and latch off. The latch will be cleared by toggling the PSON#signal or by
an AC power interruption. The power supply shall not be damaged from repeated power cycling
in this condition. -12 V and 5 VSB shall be protected under over-current or shorted conditions so
that no damage can occur to the power supply. Auto-recovery feature is a requirement on 5
VSB rail.
Table 12. Over-current Protection (OCP)
Voltage Over-current Limit (Iout limit)
+3.3V 110% minimum (= 16.5A) ; 150% maximum (= 22.5A)
+5V 110% min (= 11.0A); 150% max (= 15.0A)
+12V 39.6A min; 54.0A max
-12V 0.625A min; 2.0A max
5VSB 6.0A max
2.5.2 Over-voltage Protection (OVP)
The power supply over-voltage protection shall be locally sensed. The power supply shall shut
down and latch off after an over-voltage condition occurs. This latch shall be cleared by toggling
the PSON#signal or by an AC power interruption. The following table contains the over-voltage
limits. The values are measured at the output of the power supply’s connectors. The voltage
shall never exceed the maximum levels when measured at the power pins of the power supply
connector during any single point of fail. The voltage shall never trip any lower than the
minimum levels when measured at the power pins of the power supply connector.
Exception: +5VSB rail should be able to recover after an over-voltage condition occurs.
