ACL800-BS-USB –Desktop Proximity/Mifare
and Biometric Swipe enrollment Reader -
Installation Manual
Description / Operation
ACL800-BS-USB is an USB desktop fingerprint and
Proximity/Mifare reader that enables easy fingerprint and card
enrollment. The USB desktop reader is used for transfer of the
fingerprint to the ACL800 BioManager software, writing the
same fingerprint into a Mifare card, reading the card details
and reading the card UID. The fingerprints are stored in the
ACL800 BioManager software and can be uploaded in the
installed readers, not in the desktop reader
Specifications
Operating voltage
USB powered
Compatibility
With Biometric Readers with capacitive sensor
(ACL800SUW-BS, ACL805SUW-BS,
ACL800SUW-BSPX, ACL800SUW-BSMF)
Support for 125kHz
- EM Proximity Cards 125kHz
- HID Prox
- Casi Prox
Support for 13,56MHz
- Mifare Classic 4UID 1K & 4K (7UID supported)
- Mifare Ultralight 4UID 1K & 4K (7UID
supported)
- DesFire EV1 2K, 4K & 8K
Windows Compatibility
Windows 7, 8, 10
Operating frequency
125kHz, 13.56 MHz
Card technology
CSN only for the technology : Mifare Classic,
Mifare Plus, Mifare Ultralight, Mifare DESFire
Read range
Up to 6 cm,
depending on the card type and quality
Dimensions of housing
(W x H x D)
100 x 94 x 30mm
Operating environment
Temperature
Relative humidity
−20 to +50°C
0 to 95% noncondensing
IP rating
IP40
Weight shipping
Weight product
120 g
50 g
Enrolling cards
Plug the desktop reader in the PC. The desktop reader is
installed automatically like an USB device.
1. Open the ACL800 BioManager software
2. Go to Settings/System parameters
Figure1: System parameter
3. Select the type of the card and the Wiegand type
Figure 2: Card type selection
4. Place and leave the card (tag) on the Desktop Reader
5. Go to Users, select “New User”, put name and click on the
USB Icon. The ID Number will be presented in the field “User
ID’s (Card numbers). Click “Save new”

2 / 3 P/N 1073493A• REV 00.00 • ISS 4JUL18
Figure 3: Reading card number
Read Card Details
1. Place and leave the card (tag) on the Desktop Reader
2. Go to “Users”. Click on “Read Card Details”
Figure 4: Read card details
The software will show the type of the card, its serial number, if
the Card ID is already enrolled or not and if the card has
written fingerprint inside the memory (Mifare Cards Only).
Figure 5: Read card details
Enrolling Fingerprints from Desktop Reader
ACL800-BS-USB
Plug the desktop reader in the PC.
1. Open the Users Window and click on “New User”. Put a
name, ID(card number). (Figure 6)
Figure 6: Add user
2. Select the USB desktop reader (with left click). (Figure 7)
Figure 7: Select desktop reader
3. Right click on the fingertip and select enroll. Swipe the finger
min. 5 times on the desktop reader. (Figure 8)
Figure 8: Enroll finger
4. If the enrollment is successful, the fingertip will turn green.
Value always shows 201 (Figure 9)

P/N 1073493A• REV 00.00 • ISS 4JUL18 3 / 3
Figure 9: Successful enrollment
5. Repeat point 3 for each finger that should be enrolled.
6. Click on “Save New” and the fingerprints will be sent
automatically to all biometric readers where that user has
access, i.e. to all the readers according to the Access Level
assign to that user.
If the reader is off line, the fingerprints will be sent upon the
connection that is established between the ACL800
BioManager server and the reader. No need for additional
enrollment or actions. The fingerprints will be sent as soon as
communication is established.
Example: If the user has “Unlimited” Access level then the
fingerprints will be sent to all readers, if the user has Access
Level only for Reader1 and Reader 3 then the fingerprints will
be sent only to those two readers.
Note: To check if all the fingerprints are sent to the reader,
right click on the reader and select “Memory Status”. (Figure
10)
Figure 10: Check reader’s memory status
In the event window a line will appear indicating the number of
fingerprints stored in the reader.
Note: If more fingerprints are added for one user, all
fingerprints will send the same Wiegand Code to the controller,
the one written in the field User ID (Card numbers).
