ACL805SUW-BC - Biometric Touch capacitive
Keypad Wiegand Reader - Installation Manual
Description / Operation
ACL805SUW-BC is a Wiegand biometric keypad for access
control applications with backlit keys and programmable
Wiegand output. It offers storage up to 9500 fingerprints,
programmable Wiegand Output (24 to 80 bits) and selectable
PIN code length. Configuration of the readers and fingerprint
enrollment is done through ACL800 BioManager software.
When used with third party controllers, the connection between
the Biometric readers and the PC is done through ACL800FL-
CONV-W converter (RS485 to TCP/IP). Only one converter is
needed per system (one converter for 1, 2, 3...30, 31 biometric
readers).
The tamper switch output can trigger the alarm system, if an
attempt is made to open or remove the unit from the wall.
Specifications
Fingerprint capacity
Up to 9500 fingerprints
Technology
Biometry and keypad
Authentication
Finger, access code, finger or/and access
code
Fingerprints per user
1-10 fingerprints
Interface
Wiegand 24 to 80 bits; default: Wiegand 26bit
Protocol programming
By ACL800 BioManager software
Cable distance
50 m
Fingerprint Sensor
Type
Capacitive
1:1000 identification
time
970 msec, including feature extraction time
Fingerprint enrolment
On the reader or from the USB desktop reader
Panel Connection
Cable, 1 m
Green and Red LED
Externally controlled
Orange LED
Idle mode
Buzzer ON/OFF
Yes
Backlight ON/OFF
Yes, by software setting
Tamper
Yes
Consumption
150 mA
IP Rating
65
Power supply
9 to 14 VDC
Operating
Temperature
-15 to +50°C, noncondensing
Dimensions
100 x 94 x 30 mm
Housing
Moulded aluminium
Mounting
Figure 1: Mounting instructions
If the biometric reader is installed and used outdoor, the reader
MUST be fitted with a cover in order to protect the sensor from
direct rainfall. The operating temperature of the product is
between -15 to + 50ºC. If the reader is installed in an
environment where the temperature can drop below -10ºC
or/and if the sensor could only be exposed to direct sunlight, it
is strongly recommended to install the reader inside a third
party sealed wall mount box (fitted with additional heater if very
low temperature) to keep a constant sensor level performance.
We cannot guarantee the functionality of the product if
measures and advice before are not followed.
It is also strongly recommended to use double technology
biometric readers when use outdoor to offer first higher
security but also the possibility to use different readers
depending on users.

2 / 7 P/N 1073512A• REV 00.00 • ISS 4JUL18
Wiring
Figure 2: Wiring
Wiring description
Connecting Biometric readers to controllers
Figure 3: Wiring instructions
•Connect the lines D0, D1, LR-, LG-, GND and +12V to the
TruPortal controller.
•Connect the RS485 Line (A, B) to the converter. Connect
the converter in the PC.
•Fingerprint enrollment is done from the ACL800
BioManager software. Connection between the biometric
readers and the PC must be established.
•The Biometric readers communicate with each other with
a RS485 and with the ACL800 BioManager software through a
converter.
•The RS485 Line should be configured in the form of a
daisy chain, NOT in a form of a star. Keep the stubs from the
RS485 backbone as short as possible (not more than 5
meters)
•Only one converter per installation is needed, not per
reader.
RS485 tuning
Figure 4: RS485 tuning
•Terminate both ends of the line with 120 Ohm resistor
•If the communication is not established and stable, use the
external resistors provided in the hardware kit.
Enrollment
Figure 5: Enrollment
Configuring the biometric readers in
ACL800 BioManager
ACL800 BioManager is software for fingerprint management of
biometric readers, when used with third party access
controllers.
Main functions:
o Fingerprint enrollment
It can be done by ANY Biometric reader in the network or by
desktop (USB) biometric reader
o Fingerprint transfer
Finger templates can be sent to any reader in the network.
Different users can be sent to different biometric readers
o Wiegand output Configuration
The Wiegand output of the Biometric reader can be
customized bitwise
12 VDC
Red
+12 VDC
GND
Black
Ground
A
Pink
A (RS485)
B
Violet
B (RS485)
Tamp
Blue
Tamper
Tamp
Green
Tamper
LG-
Yellow
LED green -
LR-
Orange
LED red -
D1
White
Data 1
D0
Green
Data 0

P/N 1073512A• REV 00.00 • ISS 4JUL18 3 / 7
Add Portal
•Right-click on “Portals” and select “Add Portal”.
•If the converter used for the biometric readers is RS485 to
TCP/IP, then create a portal by adding the IP Address of the
converter. (Figure 5)
Figure 6: Add Portal
Note: The portal can be added automatically with the “Search”
function.
Add Reader
•Right-click on the portal connected to the reader and
select “Add Reader”
•Select the type of the reader and fill the reader form. Put
the serial number of the biometric reader. The serial number is
written on the back side of the reader, but also can be
searched from the software
Click on “Save”and the reader icon appears under
the selected portal
Right-click on reader and select “Check version”to
see if the reader is online
If reader is online, new line is added on top of the
event table
If reader is not online, following line is added on top of
the event table
Note: The reader can be added automatically with the
“search” function
Edit reader
Right-click on the reader and select “Properties”

4 / 7 P/N 1073512A• REV 00.00 • ISS 4JUL18
Edit reader properties and click “Save”button.
Check at event table if the configuration was successful.
Delete reader
Right-click on the reader and select “Delete”reader
ADD user
1. Open the Users Window and create a new user.
Click on “New User”, put a name and ID (card number).
2. Select the reader (with left click) from which the enrollment
will be done.
3. Right click on the fingertip and select enroll.
4. Place the finger on the Reader and fingertip will turn red,
orange or green, with percentage of successful enrollment
shown next to the fingertip.
In these 25 sec. the reader will continuously blink.
5. Repeat point 3 & 4 for each finger that should be enrolled.
6. Click on “Save New” and the fingerprint will be sent
automatically to all Biometric Readers where that user has
access, i.e. to all the readers according to the Access Level
assign to that user.
Example:
If the user has “Unlimited” Access level then the fingerprints
will be sent to all readers, if the user has Access level only for
Reader1 and Reader 3 then the fingerprints will be sent only to
those two readers.
Note:
To check if all the fingerprints are sent to the reader, right click
on the reader and select “Memory Status”.

P/N 1073512A• REV 00.00 • ISS 4JUL18 5 / 7
In the event window, a line will appear indicating the number of
fingerprints stored in the reader.
Note:
If more fingerprints are added for one user, all fingerprints will
send the same Wiegand code to the controller, the one written
in the field User ID (card Number).
Note:
Users can be imported from Excel file or from TruPortal
Deleting fingerprints
In general, the fingerprints are stored in the biometric reader
and in the software.
Deleting one user from the biometric reader
Select the User
Click on “Delete User”. The User, together with its
fingerprints will be deleted from both the software and
the fingerprint readers
Deleting all users from the biometric reader
Right click on the reader and select “Delete all users
from reader”
Delete one or more fingerprints
Select the User and click “Edit”.
Go to the fingertip that needs to be deleted, right click and
select ”Delete” for one finger or “Delete All” for all fingers of the
user
Click “Save”.
With this procedure, the fingerprints are deleted from the
software and from the reader.

6 / 7 P/N 1073512A• REV 00.00 • ISS 4JUL18
Uploading the fingerprints to the biometric
readers
Right click on the biometric reader
Select “Upload all users to reader”
While receiving the fingerprints, the reader will blink.
Note: Use this feature when you change or add a
reader, if pending tasks are deleted in the software or
if there are doubts that fingerprints in the reader
memory are not synchronized with the software
database.
In normal usage, the fingerprints are sent
automatically and this feature is not used.
Wiegand output selection
Select the Wiegand output format of the reader in
Settings/Wiegand
Select among the predefined Wiegand outputs or create
custom one.
Send the configuration to the biometric reader
Safety precautions
Do not install the device in a place subject to direct sun light
without protective cover.
Do not install the device and cabling close to a source of
strong electro-magnetic fields like radio-transmitting antenna.
Do not place the device near or above heating equipment.
If cleaning, do not spray or splash water or other cleaning
liquids but wipe it out with smooth cloth or towel.
Do not let children touch the device without supervision.
Note that if the sensor is cleaned by detergent, benzene or
thinner, the surface will be damaged and the fingerprint can't
be entered.
In the event window a line will appear indicating the number of
fingerprints stored in the reader.
Note: If more fingerprints are added for one user, all
fingerprints will send the same Wiegand code to the controller,
the one written in the field User ID (Card numbers).

P/N 1073512A• REV 00.00 • ISS 4JUL18 7 / 7
Regulatory information
Trademarks and
patents
The trade names used in this document may be
trademarks or registered trademarks of the
manufacturers or vendors of the respective
products.
Manufacturer
Interlogix.
2955 Red Hill Avenue, Costa Mesa, CA 92626
5923, USA
Authorized EU manufacturing representative:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, The Netherlands
Certification
European Union
directives
This product and - if applicable - the supplied
accessories too are marked with "CE" and
comply therefore with the applicable harmonized
European standards listed under the EMC
Directive 2014/30/EU, the RoHS Directive
2011/65/EU.
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European Union.
For proper recycling, return this product to your
local supplier upon the purchase of equivalent
new equipment, or dispose of it at designated
collection points. For more information see:
www.recyclethis.info.
2013/56/EU & 2006/66/EC (battery directive):
This product contains a battery that cannot be
disposed of as unsorted municipal waste in the
European Union. See the product documentation
for specific battery information. The battery is
marked with this symbol, which may include
lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the
battery to your supplier or to a designated
collection point. For more information see:
www.recyclethis.info.
Product warnings
and disclaimers
THESE PRODUCTS ARE INTENDED FOR
SALE TO AND INSTALLATION BY QUALIFIED
PROFESSIONALS. UTC FIRE & SECURITY
CANNOT PROVIDE ANY ASSURANCE THAT
ANY PERSON OR ENTITY BUYING ITS
PRODUCTS, INCLUDING ANY “AUTHORIZED
DEALER” OR “AUTHORIZED RESELLER”, IS
PROPERLY TRAINED OR EXPERIENCED TO
CORRECTLY INSTALL FIRE AND SECURITY
RELATED PRODUCTS.
For more information on warranty disclaimers and
product safety information, please check
www.firesecurityproducts.com/policy/product-
warning/ or scan the following code:
Contact
information and
manuals
For contact information go to: www.interlogix.com
or www.firesecurityproducts.com
To get translations for this and other product
manuals go to: www.firesecurityproducts.com
