Intermec AC1 User manual

Heading 1
Specifications
Charging Batteries Specifications
Quick Start Guide
AC1 4-Slot Battery Charger
AC1 4-Slot Battery Charger Quick Start Guide
*073530-003*
P/N 073530-003
1
2
:stnemeriuqeRlacirtcelE xA4V21
)375370N/P(ylppusrewopCAcemretnIseriuqeR
zH06-05,CAV042ot001~
:erutarepmeT
gnitarepO)F°311otF°23(C°54otC°0
:erutarepmeTegarotS)F°041otF°4-(C°06otC°02-
:ytidimuHgnitarepOytidimuhevit
alergnisnednoc-non%09ot%01
:ytidimuHegarotSytidimuhevitalergnisnednoc-non%59ot%0
You may need additional information when working with the AC1 and CK30 or CK31 in a
data collection system. Please visit our web site at www.intermec.com to download our
current manuals in PDF format. To order printed versions of the Intermec manuals,
contact your local Intermec representative or distributor.
For More Information
Patent Information
Product is covered by one or more of the following
patents: 5,052,943; 5,195,183; 5,317,691; 5,331,580;
5,544,010; 5,644,471. There may be other U.S. and
foreign patents pending.
6001 36th Avenue West
Everett, WA 98203
U.S.A.
www.intermec.com
© 2004 Intermec Technologies Corp.
All Rights Reserved
You can charge up to four batteries at one time in the charger. The charger fully charges
the batteries in about 5 hours.
To charge batteries
With the battery contacts facing the
charger, slide the battery into one of the
four slots.
Push the battery into the slot to engage
the latch. The Status light for that slot
changes from yellow to green or red to
indicate the battery charge status. See
“Understanding the Status Lights” to learn
what the Status light colors mean.
To remove batteries
•Press the button for that slot and
slide the battery up and out.

What Is the AC1? Installing the AC1 Understanding the Status Lights
The AC1 4-Slot Battery Charger is an accessory for the CK30 and CK31 Handheld
Computers. You use the battery charger to charge up to four AB1 or AB1G batteries at
the same time.
This guide explains how to install and use the battery charger. Before using the AC1,
please read this guide thoroughly and save it for future reference.
What You Need
To use the charger, you need:
•an AC power supply (P/N 073573).
•an AC power cord.
You need to purchase the appropriate power cord for your location. For more information,
contact your Intermec sales representative.
This table explains what the different colors of the Status lights mean.
roloC noitpircseD
rolocoN rewopehterusekaM.rewopgniviecertonsiregrahcyrettabehT
.teltuoCAderewopaotylreporpdet
cennocsiylppus
wolleYydaetS .egrahcotydaersidnarewopCAotdetcennocsiregrahcyrettabehT
neerGgnihsalF.gnigrahcsiyrettabehT
neerGydaetS .degrahcyllufsiyrettabehT
deRgnihsalF:snoitulosesehtyrT.gnigrahctonsiyrettabehT
• .regrahcehtnidellatsniylmrifsiyrettabehterusekaM
• CAderewopaotylreporpdetcennocsiylppusrewopehterusekaM
.teltuo
• C°54dnaC°0neewtebsierutarepmetmoorehterusekaM
.)F°311dnaF°23(
• stcatnocyrettabehtdna1CAehtnosnipgnigrahcehterusekaM
.naelcerayrettabehtno
You must use the appropriate Intermec power supply with this device or
equipment damage may occur.
Attention:Vous devez utiliser la source d’alimentation Intermec adéquate
avec cet appareil sinon vous risquez d’endommager l’équipement.
AC1 4-Slot Battery Charger Quick Start Guide
1
2
Place the battery charger on a flat, stable, and clean surface that is within 1.5 m
(5 ft) of an AC power outlet.
Connect the AC power supply to the power connector on the battery charger
and to an AC power outlet. The Status light in each button turns on, showing
that the battery charger is ready to use.
To prevent fire or electric shock, do not expose the AC1 to rain or moisture.
Avertissement: Pour éviter des risques d’incendie ou de choc électrique, ne pas
exposer le AC1 à la plui ou l’humidité.
Status light
(4 places)
Power
connector
Button
(4 places)
