Intex WL698 User manual

155A
(155IO) POOL LIGHT ENGLISH 7.5” X 9.25” PANTONE 295U 06/18/2019
English
OWNER’S MANUAL
LED Pool-Wall Light
Model
WL698
220 – 240 Volt ~, 50 Hz
Emitter: IP66, Receiver: IP68 ( )
IMPORTANT
SAFETY RULES
Please read, understand, and follow
all instructions carefully before
installing and using this product.
Don’t forget to try these other ne Intex products: pools, pool accessories,
inatable pools and in-home toys, airbeds and boats available at ne
retailers or visit our website.
Due to a policy of continuous product improvement, Intex reserves the right
to change specications and appearance, which may result in updates to the
instruction manual without notice
For illustrative purposes only.
©2019 Intex Marketing Ltd. - Intex Development Co. Ltd. - Intex Recreation
Corp.
All rights reserved/Tous droits réservés/Todos los derechos reservados/Alle
Rechte vorbehalten. Printed in China/Imprimé en Chine/Impreso en China/Gedruckt in China.
®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous
licence de/Marcas registradas utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in einigen
Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Development Co. Ltd., G.P.O Box 28829, Hong
Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European Union by/Distribué
dans l’Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union durch/Intex Trading
B.V., Venneveld 9, 4705 RR Roosendaal – The Netherlands
www.intexcorp.com
1.2 m
155-*A*- R0-2006

155A
SAVE THESE INSTRUCTIONS
(155IO) POOL LIGHT ENGLISH 7.5” X 9.25” PANTONE 295U 06/18/2019
English
Page 2
Warnings.......................................................................................... 3-4
Parts References............................................................................. 4
Setup Instructions........................................................................... 5-6
Installation on Intex Graphite Gray PanelTM Pools....................... 6
Long Term Storage......................................................................... 6
Operation instructions.................................................................... 7
Troubleshooting Guide................................................................... 8
General Aquatic Safety................................................................... 8
Limited Warranty............................................................................. 9
TABLE OF CONTENTS

155A
SAVE THESE INSTRUCTIONS
(155IO) POOL LIGHT ENGLISH 7.5” X 9.25” PANTONE 295U 06/18/2019
English
Page 3
IMPORTANT SAFETY RULES
Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product.
• To reduce the risk of electric shock, do not open this product.
• To reduce the risk of injury, do not permit children to use this product. Always supervise children
and those with disabilities.
• Children must stay away from this product and electrical cord (s).
• Assembly and disassembly by adults only.
• Risk of electric shock. Connect this product only to a grounding type receptacle protected by
a ground-fault circuit interrupter (GFCI) or residual current device (RCD). Contact a qualied
electrician if you cannot verify that the receptacle is protected by a GFCI/RCD. Use a qualied
electrician to install the GFCI/RCD, which has a maximum rate of 30mA. Do not use a portable
residual current device (PRCD).
• Always unplug this product from the electrical outlet before removing, cleaning, servicing or
making any adjustment to the product.
• The supply cord cannot be replaced. If the cord is damaged the appliance should be scrapped.
• The plug must be accessible after produc t is installed.
• To reduce the risk of electric shock, do not use extension cords, timers, plug adaptors or
converter plugs to connect unit to electric supply; provide a properly located outlet.
• Do not immerse the transformer and the external transmitter unit into water.
• Do not bury the electrical cord. Locate the cord where it will not be damaged by lawn mowers,
hedge trimmers and other equipment.
• Do not attempt to plug in or unplug this product while standing in water or when your hands
are wet.
• Do not throw or drop the product.
• Do not stare directly at the light emitted by this product.
• Do not operate the product if transmitter housing or pool light lens is cracked or showing water
leakage; remove from pool or water immediately.
• Do not insert ngers or objects into the openings and holes.
• Strong magnets. Keep this device away from mobile phone and other electronic gadgets.
• Keep the transformer more than 3.5m away from the pool.
• Keep the plug of this product more than 3.5m away from the pool.
• This product is for use with storable pools only. Do not use with permanently installed pools.
A storable pool is constructed so that it may be readily disassembled for storage and
reassembled to its original conguration.
• This product is intended to be used only for the purposes described in the manual!
FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN PROPERTY
DAMAGE, ELECTRIC SHOCK, ENTANGLEMENT OR OTHER SERIOUS
INJURY OR DEATH.
These product warnings, instructions and safety rules provided with the product represent some common risks
of water recreation devices and do not cover all instances of risk and danger. Please use common sense and
good judgement when enjoying any water activity.
WARNING
READ AND FOLLOW ALL INSTRUCTIONS

155A
SAVE THESE INSTRUCTIONS
(155IO) POOL LIGHT ENGLISH 7.5” X 9.25” PANTONE 295U 06/18/2019
English
Page 4
IMPORTANT SAFETY RULES (continued)
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
PARTS REFERENCES
Before assembling your product, please take a few minutes to check the contents and become familiar
with all the parts.
1
2
3
REF. NO. DESCRIPTION QTY. SPARE PART NO.
1
1
1
POOL LIGHT
TRANSMITTER
TRANSFORMER
12731
12728
12730
NS
09:00
NS
09:00
NS
09:00
NS
09:00
NS
09:00
NS
09:00
NS
09:00
NS
09:00
>3.5m
1
3
2

155A
SAVE THESE INSTRUCTIONS
(155IO) POOL LIGHT ENGLISH 7.5” X 9.25” PANTONE 295U 06/18/2019
English
Page 5
SETUP INSTRUCTIONS
This product is specially designed for above ground pool. The LED pool-wall light uses
magnetic technology to create a light system that safely generates low voltage current through
the pool’s sidewall to a powerful LED light inside the pool.
IMPORTANT
• This product is for use with above ground non-steel wall pools with a thickness of 1mm
(0.04 in) or less.
• Do not use this product as a free standing light.
1. Separate the pool light (1) from the transmitter (2) by hand through the side opening groove. See
drawing (1 & 2).
CAUTION: To avoid nger pinch or injury, always separate the pool light from the transmitter
through the side opening groove.
2. Place the transmitter (2) on the outside of the pool wall and the pool light (1) on the inside of the
pool wall submerged in water. Ensure the transmitter magnetic poles are properly aligned with the
magnetic poles on the pool light unit. See drawing (3).
3. Adjust the position of the pool light by manually sliding the transmitter position sideways and/or
vertically.
4. Plug the assembled unit to an electrical outlet protected by a ground-fault circuit interrupter (GFCI)
or residual current device (RCD).
12
WARNING
• Always unplug this product from the electrical outlet before removing, cleaning,
servicing or making any adjustment to the product.
• Do not operate the product if transmitter housing or pool light lens is cracked or
showing water leakage; remove from pool or water immediately.
• Never place the power transmitter in water.
3

155A
SAVE THESE INSTRUCTIONS
(155IO) POOL LIGHT ENGLISH 7.5” X 9.25” PANTONE 295U 06/18/2019
English
Page 6
SETUP INSTRUCTIONS (continued)
Installation on Intex Graphite Gray PanelTM Pools:
Unscrew the bolts from the section where the LED pool-wall light will be installed, and remove
the clamp covers, the top board and the side boards. Refer to the Panel Pool owner’s manual
for details. For better installation, it is recommended to remove at least 3 side board panels.
Follow above setup instructions 1 to 4.
LONG TERM STORAGE
In areas where freezing temperatures occur, there is risk of ice damage to the product.
It is recommended to remove, clean and store the product in a safe place when
temperature drops below 0 degrees Celsius (32 degrees Fahrenheit).
1. Unplug the power cord from the electrical socket.
2. Remove the transmitter (2) from the outside of the pool wall rst, the pool light (1) unit will
automatically oat to the surface for easy retrieval, then remove the pool light from the
water.
IMPORTANT: To prevent damage to the transmitter from falling to the ground,
always remove the transmitter rst before removing the pool light unit.
3. If deposits or debris are seen inside the holes of the pool light, use a garden hose to ush
them out. Do not scrape the pool-wall light or use brush to clean it.
4. Thoroughly air-dry all components before storage.
5. Store the product and accessories in a dry, temperature controlled location between 0
degrees Celsius (32 degrees Fahrenheit) and 40 degrees Celsius (104 degrees
Fahrenheit).
6. The original packaging can be used for storage.
45

155A
SAVE THESE INSTRUCTIONS
(155IO) POOL LIGHT ENGLISH 7.5” X 9.25” PANTONE 295U 06/18/2019
English
Page 7
OPERATION INSTRUCTIONS
Press the Left / Right button to select the light mode and color.
Press left button Once Twice 3 times
Color
Soft white OFF Color changing
Left Button Right Button
Press right
button
Once Twice 3 times 4 times 5 times 6 times 7 times
Color Soft white Green Teal Blue Purple Color
changing OFF
• Left button: turn the pool light ON and OFF, and sets the light mode.
Note: When the transmitter light is on, press and hold right button for 3 seconds to turn off the
light.
• Right button: turn the transmitter light ON and OFF, and sets the light mode.

155A
SAVE THESE INSTRUCTIONS
(155IO) POOL LIGHT ENGLISH 7.5” X 9.25” PANTONE 295U 06/18/2019
English
Page 8
IMPORTANT
If you continue to experience difculty, please contact our Consumer Service Department
for assistance. See separate “Authorized Service Centers” sheet.
TROUBLE SHOOTING GUIDE
GENERAL AQUATIC SAFETY
Water recreation is both fun and therapeutic. However, it involves inherent risks of injury and
death. To reduce your risk of injury, read and follow all product, package and package insert
warnings and instructions. Remember, however, that product warnings, instructions and safety
guidelines cover some common risks of water recreation, but do not cover all risks and or
dangers.
For additional safeguards, also familiarize yourself with the following general guidelines as well
as guidelines provided by nationally recognized Safety Organizations:
• Demand constant supervision. A competent adult should be appointed as a “life guard” or water
watcher, especially when children are in and around the pool.
• Learn to swim.
• Take the time to learn CPR and rst aid.
• Instruct anyone who is supervising pool users about potential pool hazards and about the use of
protective devices such as locked doors, barriers, etc.
• Instruct all pool users, including children what to do in case of an emergency.
• Always use common sense and good judgement when enjoying any water activity.
• Supervise, supervise, supervise.
• Rearrange the orientation of the pool light and
the transmitter. See “setup instructions”.
• Plug the cord rmly into the electrical outlet.
• Tighten the intermediate connection between
the transmitter and the transformer.
• Contact Intex Service Center.
• Rearrange the orientation of the pool light and
the transmitter. See “setup instructions”.
• Contact Intex Service Center.
• Contact Intex Service Center.
DIFFICULT TO ALIGN
THE POOL LIGHT AND
THE TRANSMITTER
THE LED POOL- WALL
LIGHT DOES NOT
LIGHT UP
THE POOL LIGHT UNIT
DOES NOT FLOAT
• Wrong orientation, magnetic
poles are not aligned
correctly.
• The power cord is loose.
• The GFCI/RCD is tripped.
• Wrong orientation and
alignment between the pool
light and the transmitter.
• Water inside pool light unit.
• Possible transmitter or
transformer failure.
• Water inside the pool light
unit.
PROBLEM CAUSE SOLUTION

155A
SAVE THESE INSTRUCTIONS
(155IO) POOL LIGHT ENGLISH 7.5” X 9.25” PANTONE 295U 06/18/2019
English
Page 9
LIMITED WARRANTY
Your LED Pool-Wall Light has been manufactured using the highest quality materials and workmanship.
All Intex products have been inspected and found free of defects prior to leaving the factory. This Limited
Warranty applies only to the LED Pool-Wall Light.
This limited warranty is in addition to, and not a substitute for, your legal rights and remedies. To the extent
that this warranty is inconsistent with any of your legal rights, they take priority. For example, consumer laws
across the European Union provide statutory warranty rights in addition to the coverage you receive from
this limited warranty: for information on EU-wide consumer laws, please visit the European Consumer Center
website at http://ec.europa.eu/consumers/ecc/contact_en/htm.
The provisions of this Limited Warranty apply only to the original purchaser and are not transferable. This
Limited Warranty is valid for a period of one (1) year from the date of the initial retail purchase. Keep your
original sales receipt with this document, as proof of purchase will be required and must accompany warranty
claims or the Limited Warranty will be invalid.
If you nd a manufacturing defect in the LED Pool-Wall Light during the warranty period, please contact
the appropriate Intex Service Center listed in the separate “Authorized Service Centers” sheet. If the item
is returned as directed by the Intex Service Center, the Service Center will inspect the item and determine
the validity of the claim. If the item is covered by the provisions of the warranty, the item will be repaired or
replaced, with the same or comparable item (at Intex’s choice) at no charge to you.
Other than this warranty, and other legal rights in your country, no further warranties are implied. To the
extent possibly in your country, in no event shall Intex be liable to you or any third party for direct or
consequential damages arising out of the use of your LED Pool-Wall Light, or Intex or its agents’ and
employees’ actions (including the manufacture of the product). If your country does not allow the exclusion
or limitation of incidental or consequential damages, this limitation or exclusion does not apply to you.
You should note that this limited warranty does not apply in the following circumstances:
• If the LED Pool-Wall Light is subject to negligence, abnormal use or application, accident, improper
operation, improper voltage or current contrary to operating instructions, improper maintenance or
storage;
• If the LED Pool-Wall Lightis subject to damage by circumstances beyond Intex’s control, including but not
limited to, ordinary wear and tear and damage caused by exposure to re, ood, freezing, rain, or other
external environmental forces;
• To parts and components not sold by Intex; and/or;
• To unauthorized alterations, repairs or disassembly to the LED Pool-Wall Light by anyone other than
Intex Service Center personnel.
The costs associated with the loss of pool water, chemicals or water damage are not covered by this
warranty. Injury or damage to any property or person is not covered by this warranty.
Read the owner’s manual carefully and follow all instructions regarding proper operation and maintenance of
your LED Pool-Wall Light. Always inspect your product prior to use. This limited warranty will be void if use
instructions are not followed.
