Model SF80110-2
Model SF70110-2
Model SF60110-2
Don’t forget to try these other fine Intex products: pools, pool
accessories, inflatable pools and in-home toys, airbeds and boats
available at fine retailers or visit our website.
Due to a policy of continuous product improvement, Intex
reserves the right to change specifications and appearance, which
may result in updates to the instruction manual without notice.
OWNER’S MANUAL
For illustrative purposes only.
IMPORTANT!
DO NOT RETURN PRODUCT TO STORE
To purchase parts and accessories or to obtain non-technical assistance, visit
www.intexcorp.com
For technical assistance and missing parts call us toll-free (for U.S. and Canadian Residents):
1-800-234-6839
Monday through Friday, 8:30am to 5:00pm Pacific Time 342-*PO-R0-1906
IMPORTANT
SAFETY RULES
Read, understand, and follow
all instructions carefully before
installing and using this product.

342
PO
SAVE THESE INSTRUCTIONS
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018
English
Page 2
Warnings.......................................................................... 3
Parts References............................................................ 4-5
Setup Instructions ......................................................... 6-13
Product Specifications................................................... 8
Operating Instructions ................................................... 14-16
Intex Pools Operating Time Table..................................17
Non-Intex Pools Operating Time Table..........................18
Maintenance.................................................................... 19
Long Term Storage..........................................................20
Troubleshooting Guide................................................... 21
Common Pool Problems................................................. 22
General Aquatic Safety................................................... 23
Limited Warranty............................................................. 24
TABLE OF CONTENTS

342
PO
SAVE THESE INSTRUCTIONS
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018
English
Page 3
IMPORTANT SAFETY RULES
Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product.
READ AND FOLLOW ALL INSTRUCTIONS
WARNING
•To reduce the risk of injury, do not permit children to use this product. Always supervise children
and those with disabilities.
•Children must stay away from this product and electrical cord(s).
•Assembly and disassembly by adults only.
•Risk of electric shock. Connect only to a grounding type receptacle, this product is provided with
a ground-fault circuit interrupter. If replacement of the plug or cord is needed, use only identical
replacement parts.
•Always unplug this product from the electrical outlet before removing, cleaning, servicing or
making any adjustment to the product.
• The unit is provided with a ground-fault circuit interrupter (GFCI). To test the GFCI, push the test
button. The GFCI should interrupt power. Push the reset button, power should be restored. If the
GFCI fails to operate in this manner. The GFCI is defective. If the GFCI interrupts power to the
pump without the test button being pushed, a ground current is flowing, indicating the possibility of
an electric shock. Do not use this pump. Disconnect the pump and have the problem corrected by
a qualified service representative before using.
•Do not bury the electrical cord. Locate the cord where it will not be damaged by lawn mowers,
hedge trimmers and other equipment.
•To reduce the risk of electric shock, replace damaged cord immediately. Use a qualified electrician
to replace the cord.
•To reduce the risk of electric shock, do not use extension cords, timers, plug adaptors or converter
plugs to connect unit to electric supply; provide a properly located outlet.
•Do not attempt to plug in or unplug this product while standing in water or when your hands are
wet.
•Do not use an appliance leakage current interrupter (ALCI) in place of a GFCI since the ALCI will
not protect people.
• Position this product away from pool, so as to prevent children from climbing on it and access the
pool.
• Make sure the electrical parameters indicated on the product correspond to the local mains
voltage before you connect the unit.
•To reduce the risk of entrapment hazard, never enter the pool if suction strainer component is
loose, broken, cracked, damaged or missing. Replace loose, broken, damaged, cracked or
missing suction strainer components immediately.
• Never play or swim near suction fittings. Your body or hair may be trapped causing permanent
injury or drowning.
• To prevent equipment damage and risk of injury, always turn pump off before changing the filter
control valve position.
• Never operate this product above the maximum working pressure stated on the filter tank.
• Hazardous Pressure. Improper tank valve cover assembly could cause the valve cover to blow off
and cause serious injury, property damage or death.
• This product is intended to be used only for the purposes described in the manual!
FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN PROPERTY
DAMAGE, ELECTRIC SHOCK, ENTANGLEMENT OR OTHER SERIOUS INJURY
OR DEATH.
This product is for use with storable pools only. Do not use with permanently-installed pools. A storable
pool is constructed so that it is capable of being readily disassembled for storage and reassembled to its
original integrity. A permanently-installed pool is constructed in or on the ground or in a building such that
it cannot be readily disassembled for storage.
To reduce the risk of electric shock the pool must be installed no closer than 6 feet (1.8 m) from any
electrical outlet. Do not place portable appliances closer than 5 feet (1.5 m) from the pool.
These product warnings, instructions and safety rules provided with the product represent some common risks
of water recreation devices and do not cover all instances of risk and danger. Please use common sense and
good judgement when enjoying any water activity.
CAUTION

342
PO
SAVE THESE INSTRUCTIONS
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018
English
Page 4
PARTS REFERENCE
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
No tools are required for the assembly.
*If this pump was not purchased as part of a pool set, the above parts
can be ordered at www.intexcorp.com if needed.
Parts shown on this page are supplied with the pool package and are shown here for assembly purposes only.
1
5
9
11
2
13 35
20
32
33 34 19
3
6
7
4
12
15
16
17
18
8
10
14
36
37
38
19
20
41
21
22
23 28 29 31
*
21
22
23 24 25
26
*
26
40
21
22
23 28 44 30
*39
43
21
22
23 24 25
39
*27
42

342
PO
SAVE THESE INSTRUCTIONS
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018
English
Page 5
REF. NO. DESCRIPTION QTY. SPARE PART NO.
SF80110-2 SF70110-2 SF60110-2
1 PRESSURE GAUGE 1 11411 11224 11224
2 6-WAY VALVE 1 11378 11496 11496
3 DRAIN OUTLET COVER 1 11131 11131 11131
4 CLAMP 1 11380 11380 11380
5 TANK O-RING 1 11379 11379 11379
6 SAND SHIELD 1 11382 11382 11382
7 CENTER PIPE HUB 1 11815 11813 11814
8 LATERAL 10 11484 - -
12 - 11384 11384
9 DRAIN VALVE CAP 1 11456 11456 11456
10 DRAIN VALVE O-RING 1 11385 11385 11385
11 L-SHAPE O-RING 4 11228 11228 11228
12 HOSE WITH NUTS 2 11009 11009 11009
13 SAND FILTER INTERCONNECTING HOSE 1 11820 11388 11535
14 LEAF TRAP NUT 1 11822 11479 11479
15 LEAF TRAP O-RING 1 11824 11232 11232
16 BASKET 1 11821 11260 11260
17 FILTER HOUSING NUT 1 11261 11261 11261
18 L-SHAPE O-RING 1 11412 11412 11412
19 AIR RELEASE VALVE/SEDIMENT RELEASE VALVE 2 10460 10460 10460
20 VALVE O-RING 2 10264 10264 10264
21*
PLUNGER VALVE (HOSE O-RING & STEP WASHER INCLUDED) 2 10747 10747 10747
22* HOSE O-RING 2 10262 10262 10262
23* STEP WASHER 2 10745 10745 10745
24* STRAINER NUT 2 10256 10256 10256
25* FLAT STRAINER RUBBER WASHER 2 10255 10255 10255
26* THREADED STRAINER CONNECTOR 1 11235 11235 10744
27* ADJUSTABLE POOL INLET JET NOZZLE 1 12369 12369 12369
28* ADAPTOR B 2 10722 10722 10722
29* STRAINER CONNECTOR 1 11070 11070 11070
30* POOL INLET JET NOZZLE 1 12364 12364 12364
31* STRAINER GRID 1 11072 11072 11072
32 SCREW 2 11381 11381 11381
33 PUMP MOTOR & CONTROL 1 12705 12707 12709
34 PRE-FILTER ASSEMBLY 1 11826 11371 11371
35 LEAF TRAP COVER 1 11823 11480 11480
36 SAND FILTER PUMP MOTOR INLET O-RING 2 11457 11457 11457
37 SAND FILTER PUMP TANK 1 12712 12713 12714
38 SAND FILTER PUMP TANK BASE 1 12716 12717 12718
39* AIR JET VALVE 1 12363 12363 12363
40* STRAINER GRID 1 - - 10253
41 PRE-FILTER HOUSING 1 12100 12099 12099
42* INLET THREADED AIR CONNECTOR 1 12371 12372 12372
43* POOL INLET AIR ADAPTOR 1 12368 12368 12368
44* INLET STRAINER CONNECTOR 1 12365 12365 12365
45* AIR JET VALVE CAP (NOT SHOWN) 1 12373 12373 12373
* If this pump was not purchased as part of a pool set, the above parts can be ordered at
www.intexcorp.com if needed.
When ordering parts, be sure to quote the model number and part numbers.

342
PO
SAVE THESE INSTRUCTIONS
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018
English
Page 6
The strainer grid prevents large objects from jamming and/or damaging the filter pump. If
your pool has an inflatable top ring, install the strainer, nozzle and plunger valve before
inflating the pool liner top ring. The part numbers here onward refer to the parts depicted
in the Parts List section of this manual. To install, do the following:
1. In a counter-clockwise motion unscrew
plunger valve union from the threaded
strainer connector
(26) (see drawing 1).
Be careful not to lose the step rubber
washer
(23). Place the plunger valve on the
ground in a safe place.
2. In a counter-clockwise motion unscrew the
strainer nut
(24) from the threaded
connector
(26). Leave the flat washer (25)
on the connector (26).
3. Install the strainer and plunger valve at the
lower position of pool outlet (marked "+").
From the inside of the pool liner insert the
connector
(26) into one of the pre-cut holes
with the washer remaining on the connector
to be placed against the inside of the liner
wall.
4. Before assembly, lubricate the threads with
a petroleum jelly. With the flat side of the
strainer nut
(24) facing the outside wall of
the liner in a clockwise motion screw the
strainer nut
(24) back onto the threaded
connector
(26) (see drawing 2).
5. Finger tighten the strainer nut (24) onto the
threaded connector
(26).
6. Grasp the plunger valve assembly. Make
sure the step washer (23) is in place.
7. In a clockwise motion screw the plunger
valve union back onto the threaded
connector
(26) (see drawing 3).
8. In a clockwise motion turn the plunger
valve handle to close position. Ensure the
plunger valve is securely closed. This will
prevent water from flowing out during filling
of the pool (see drawing 4).
POOL OUTLET - STRAINER & PLUNGER VALVE SETUP (optional)
2
25 26
INSIDE
LINER WALL
24
3
1
2
1
23
2
1
4
INSIDE
LINER WALL

342
PO
SAVE THESE INSTRUCTIONS
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018
English
Page 7
POOL INLET - NOZZLE & PLUNGER VALVE SETUP (optional)
1. In a counter-clockwise motion unscrew plunger valve
union from the inlet threaded air connector (42) (see
drawing 5). Be careful not to lose the step rubber
washer
(23). Place the plunger valve on the ground in
a safe place.
2. In a counter-clockwise motion unscrew the strainer
nut
(24) from the inlet threaded air connector (42).
Leave the flat washer (25) on the connector (42).
3. Install the nozzle and plunger valve at the upper
position of pool inlet. From the inside of the pool liner
insert the nozzle union (27 & 42) into one of the
pre-cut holes with the washer remaining on the
connector to be placed against the inside of the liner
wall.
4. Before assembly, lubricate the threads with a
petroleum jelly. Then, with the flat side of the strainer
nut
(24) facing the outside wall of the liner in a
clockwise motion screw the strainer nut (24) back
onto the inlet threaded air connector (42) (see
drawing 6).
5. Finger tighten the adjustable pool inlet jet nozzle (27)
and the strainer nut (24) onto the inlet threaded air
connector (42).
6. Grasp the plunger valve assembly. Make sure the
step washer
(23) is in place.
7. Screw the air jet valve (39) over the inlet threaded air
connector
(42).NOTE: Make sure the air jet valve is
securely tighten and facing up. In a clockwise motion
screw the plunger valve union back onto the inlet
threaded air connector (42) (see drawing 7).
8. In a clockwise motion turn the plunger valve handle
to close position. Ensure the plunger valve is securely
closed. This will prevent water from flowing out during
filling of the pool (see drawing 8).
9. Adjust the direction of nozzle head pointing away
from the pool outlet for a better circulation result
(see drawing 9).
10. The pool liner is now ready to fill with water. Consult
the above-ground-pool owner’s manual for filling
instructions.
5
2
1
7
1
2
8
INSIDE
LINER WALL
9
WATER
FLOW
POOL
6
25 42 27
INSIDE LINER
WALL
24
39

342
PO
SAVE THESE INSTRUCTIONS
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018
English
Page 8
PRODUCT SPECIFICATIONS
SETUP INSTRUCTIONS
The sand filter removes suspended particles but does not sanitize your pool. Pool chemistry
is a specialized area and you should consult your local pool service specialist for details.
TOOLS REQUIRED: One (1) Phillips screwdriver
Pump location and mounting:
• The system must be installed on a solid level and vibration-free base.
• Provide a location protected from the weather, moisture, flooding and freezing
temperature.
• Provide adequate access, space and lighting for routine maintenance.
• Pump motor requires free circulation of air for cooling. Do not install the pump in a
damp or non-ventilated location.
A team of 2 or more people is recommended for setting up this product.
Motor pre-filtering assembly setup:
1. Remove the sand filter and its accessories from the packaging carefully and inspect for
any visible damage. For missing or damaged parts contact the appropriate Intex Service
Center listed in the separate “Authorized service Centers” sheet.
2. In a counter-clockwise motion unscrew the leaf trap cover (14) from the pre-filter housing.
Take out the basket (16) and filter housing nut (17) (see drawing 10).
3. Connect the pre-filter housing to the motor water inlet. Note: Align the connector in the
pre-filter housing with the water inlet on the motor (see drawing 11).
11
10
35
17
16
14
Model: SF80110-2 SF70110-2 SF60110-2
Power: 110-120 Volt AC 110-120 Volt AC 110-120 Volt AC
Amperage: 2.1 A 4.0 A 4.8 A
Maximum working pressure: 2 bar (30 psi) 2 bar (30 psi) 2 bar (30 psi)
Effective filtering area: 0.07 m2(0.79 ft2) 0.1 m2(1.07 ft2) 0.13 m2(1.44 ft2)
Maximum Flow Rate:
6055 LPH (1600 GPH) 8140 LPH (2150 GPH) 9275 LPH (2450 GPH)
Recommended filtering
media quantity: No. 20 silica sand 23 Kg (50 Lbs) or
glass sand 16 Kg
(35 Lbs).
No. 20 silica sand
35 Kg (77 Lbs) or
glass sand 25 Kg
(55 Lbs).
No. 20 silica sand
55 Kg (121 Lbs) or
glass sand 38 Kg
(84 Lbs).
Recommended filtering
media (Not included): No. 20 silica sand or glass sand. Particle size range 0.45 to 0.85 mm (0.018 to 0.033 inches). Uniformity Coefficient less than 1.75.
Limited Warranty: see “Limited Warranty”

342
PO
SAVE THESE INSTRUCTIONS
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018
English
Page 9
4. In a clockwise motion screw filter housing nut (17) onto the motor water inlet (see
drawings 12.1 & 12.2).
5. Replace the basket (16) and leaf trap cover (14) back to the pre-filter housing (see
drawings 13.1 & 13.2).
SETUP INSTRUCTIONS (continued)
Sand tank installation:
1. Place the tank support base on the selected location.
2. Place the tank on the tank support base (see drawing 14.1).
3. Connect the motor pre-filtering assembly unit to the tank support base (see drawing 14.2).
NOTE: Ensure the pre-filter housing water inlet hose connection is facing towards the pool.
IMPORTANT: Some countries, especially in the European community, require the
product to be secured to the ground or to a base in a permanent upright position.
Check your local authorities to determine if there is a regulation in your area
regarding above-the-ground swimming pool filter-pumps. If yes, then the product
can be mounted to a platform using the two holes located in the base.
See drawing 14.3.
The product can be mounted on a cement base or onto a wooden plat form to
prevent accidental falling over.
• The mounting holes are 6.4 mm in diameter and spaced 210 mm for model
SF80110-2 (spaced 224 mm for model SF70110-2 & SF60110-2) apart.
• Use two bolts and lock nuts with a maximum of 6.4 mm in diameter.
13.1 13.2
12.1
17
12.2
17
14
16
35
14.1 14.2 14.3
19
Model SF80110-2: 210 mm
Model SF70110-2 & 60110-2: 224 mm

342
PO
SAVE THESE INSTRUCTIONS
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018
English
Page 10
SETUP INSTRUCTIONS (continued)
Sand loading:
IMPORTANT: Use No. 20 silica sand or glass sand with particle size range 0.45 to
0.85 mm (0.018 to 0.033 inches) and a Uniformity Coefficient less than 1.75.
NOTE: Before loading the tank with sand, ensure the center pipe hub assembly is
securely in place at the bottom of the tank, and vertically centered inside the tank.
1. Place the sand shield (6) over the top of the center pipe. Pour the sand into the tank
at a slow rate (see drawing 15).
2. Fill the tank approximately half way, remove the sand shield (6) from the top (see
drawing 16).
3. Evenly distribute the sand inside the tank, then fill the tank with some water to provide a
cushioning effect when the remaining sand is poured in. This prevents the center pipe
hub
(7) from excessive shock (see drawing 17). Place the sand shield (6) back and
continue to pour the sand into the tank.
4. Sand shall be filled between the “MAX” and “MIN” marked gauge on the center pipe (see
drawing 18).
5. Remove the sand shield (6) (see drawing 16) and evenly spread and level out the sand
by hand
(see drawing 17).
6. Wash away all sand around the top edge of the tank.
15
6
16
6
MAX
MIN
17
7
MAX
MAX
MIN
MIN
MAX
MIN
18
7

342
PO
SAVE THESE INSTRUCTIONS
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018
English
Page 11
6-way valve installation:
1. Lower the 6-way valve over the tank slowly, and ensure the bypass pipe protruding
underneath the 6-way valve fits securely into the center pipe hub (7) top opening
(see drawing 19).
IMPORTANT: There are three hose connection ports on the 6-way valve, ensure the
outlet connection (from filter to the pool) on the valve is facing towards the pool, and the
inlet connection (from motor to valve) is aligned with the motor outlet (see drawing 20).
SETUP INSTRUCTIONS (continued)
WARNING
Improper tank valve and clamp assembly could cause the valve and clamp to blow off
and cause serious injury, property damage or death.
20
WATER
INLET
WATER
OUTLET
2. Place an L-shape o-ring (11) on the 6-way valve inlet connection and on the pump
motor outlet. In a clockwise motion connect the sand filter interconnecting hose (13)
between the pump motor outlet and the 6-way valve inlet connection (see drawing 21).
3. Remove the clamp bolt, and install the clamp around the tank and 6-way valve flanges,
then replace the clamp bolt and use a phillips screwdriver (not included) to tighten it
(see drawing 22).
19
7
21
13
22
4

342
PO
SAVE THESE INSTRUCTIONS
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018
English
Page 12
SAND FILTER PUMP HOSE CONNECTION SETUP
The 6-way valve has three hose connection ports.
1. Connect one hose (12) end to the pre-filter inlet and the other end of the hose to the
lower plunger valve with the strainer. Ensure the hose nuts are securely tightened.
2. Connect the second hose (12) between the 6-way valve water outlet and the upper
plunger valve with the inlet-nozzle. Ensure the hose nuts are securely tighten.
3. The third hose connection port (drain/waste outlet) on the 6-way valve shall be directed
to a proper draining receptacle using a hose or pipe (not provided). Remove the drain
cap before attaching the drain/waste hose or pipe.
4. The sand filter pump is now ready to filter the pool.
WARNING
• Position this product away from the pool, so as to prevent children from climbing
on it and accessing the pool.
(ILLUSTRATION NOT TO SCALE)
Long hose
Short hose
For Pools with Dual Suction Outlets Configuration:
In order to comply with the requirement of the Virginia Grahame Baker Act (for USA and
Canada), your pool is designed with dual suction outlets and one inlet fittings. Parts in grey
highlight on this page are supplied with the pool set package and are shown here for assembly
purposes only. If this pump was purchased as part of a pool set, refer to the pool owner’s
manual for more details.
WATER
INLET
WATER
OUTLET
MOTOR WATER
OUTLET PRE-FILTER
WATER INLET
WATER LEVEL
OUTSIDE
LINER WALL
PLUNGER
VALVE
L-SHAPE
O-RING
TO
DRAIN
L-SHAPE
O-RING
AIR RELEASE VALVE
AIR JET VALVE
INLET THREADED
AIR CONNECTOR

342
PO
SAVE THESE INSTRUCTIONS
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018
English
Page 13
SAND FILTER PUMP HOSE CONNECTION SETUP (continued)
For INTEX pool with 1-1/4” (32mm) connections/hoses:
Make sure the air jet valve (39) is securely tighten onto the pool inlet air adaptor (43) and facing
up.
For NON-INTEX pool:
Connect the hose (12) to the pool inlet/outlet connection with a large hose clamp. Tighten
securely.
POOL
LARGE HOSE
CLAMP
12
44
28
(Adaptor B) 43 39 30 29 31
23 28
(Adaptor B)
23

342
PO
SAVE THESE INSTRUCTIONS
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018
English
Page 14
OPERATING INSTRUCTIONS
Valve Position Function Water Flow Direction
FILTER
(see drawing 23) Normal filtration and regular
vacuuming of pool From pump through filter media to pool
BACKWASH
(see drawing 24) Reverses water flow to clean filter
media From pump through filter media to valve waste/drain outlet
RINSE
(see drawing 25)
For initial startup cleaning of the sand, and
leveling the sand bed after backwashing
From pump through filter media to
valve waste/drain outlet
WASTE
(see drawing 26)
For vacuuming directly to waste,
lowering pool level or to drain the pool
From pump to valve waste/drain
outlet bypassing the filter media
RECIRCULATE
(see drawing 27)
For circulating water back to pool
without going through the filter media From pump through valve to pool bypassing the filter media
CLOSED
(see drawing 28)
Shuts off all flow to filter and pool
“Do not use this setting with pump running”
6-way valve positions and function:
• Risk of electric shock. Connect this product only to a grounding type receptacle protected
by a ground-fault circuit interrupter (GFCI) or residual current device (RCD). Contact a
qualified electrician if you cannot verify that the receptacle is protected by a GFCI/RCD.
Use a qualified electrician to install the GFCI/RCD, which has a maximum rate of 30 mA.
Do not use a portable residual current device (PRCD).
•To reduce the risk of electric shock, do not use extension cords, timers, plug adaptors or
converter plugs to connect unit to electric supply; provide a properly located outlet.
• Do not attempt to plug in or unplug this product while standing in water or when your
hands are wet.
• Never operate this product above the maximum working pressure stated on the filter tank.
• Always switch off pump before changing the 6-way valve position.
• Operating this product without water flowing through the system can cause a build up of
hazardous pressure which can result in an explosive situation, serious injury, property
damage or death.
• Never test this pump with compressed air. Never operate the system with water
temperature above 35°C (95°F).
WARNING
RE
T
L
I
F
E
S
N
I
R
ET
A
L
U
C
RI
C
E
R
E
S
O
LC
ETSA
W
B
23
E
SN
IR
ETALU
C
RICER
HSAW
K
C
A
B
E
S
O
LC
E
TSAW
24
RE
TLI
F
ES
N
IR
E
TALU
C
RICER
H
SAWKCAB
ETSA
W
25
R
E
T
LI
F
E
S
NI
R
ER
H
S
AW
K
CA
B
ESO
L
C
ETSAW
26
R
E
T
LIF
ESN
I
R
E
TA
L
U
C
R
I
CE
R
H
S
A
W
K
C
A
B
E
S
O
L
C
27
R
E
TL
I
F
ETALUC
R
ICER
H
S
AWK
CA
B
ES
O
LC
ETSAW
28
Control panel description:
ON / OFF button LOCK / UNLOCK button TIMER button
LED Reading Definition
00 Stand-by mode (start-up / operating cycle finished)
01 Minimum operating hour (1 hour remaining)
02-11 Operating hours (2 - 11 hours remaining)
12 Maximum operating hours (12 hours remaining)
FP Timer OFF (pump operating continuously)
Power saving mode
.

342
PO
SAVE THESE INSTRUCTIONS
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018
English
Page 15
Initial startup and operation:
Before operating, be sure that:
• All the hoses have been connected and tightened securely, and correct amount of filter sand
have been loaded.
• The entire system is connected to a grounding type receptacle protected by a ground-fault
circuit interrupter (GFCI) or residual current device (RCD).
OPERATING INSTRUCTIONS (continued)
CAUTION
The filter control valve has a closed position. The pump should never be on when
the valve is in the closed position. If the pump is operated with the valve closed,
explosive situation could exist.
1. Turn both plunger valve handles fully counter-clockwise until they stop. This opens the valves
to allow water to flow into the sand filter pump. With water flowing into sand filter pump, the
water pressure will allow the air trapped inside to escape from the air release valves (19).
When all the air has escaped water will flow out of the valves (19). When this occurs gently
finger tighten the valves (19) in a clockwise direction.
2. Ensure the drain/waste outlet on the 6-way valve is not
covered and directed to a proper draining receptacle.
3. Ensure the pump is off, depress the 6-way valve and turn
it to the “BACKWASH” position (see drawings 24 & 29).
IMPORTANT: To prevent damage to the 6-way valve,
always depress the valve handle before turning.
Always switch off pump before changing the 6-way
valve position.
4. Press to switch on the system, and then press to set
the operating TIMER hours (see “Operating the system under TIMER mode or manually”
section for details). Water is circulating backward through the sand media and to waste/drain
outlet. Backwash until a clear flow of water is observed in the waste/drain outlet or through
the drain sediment window.
NOTE: If the LED display flashes “00”, the device is in stand-by mode and the pump will not
operate. The initial backwash of the filter is recommended to remove any impurities or fine
sand particles in the sand media.
5. Switch off the pump, change the 6-way valve to “RINSE” position (see drawing 25).
6. Switch on the pump and run the pump for about one minute to level out the sand bed after
backwashing the sand media.
7. Switch off the pump, change the 6-way valve to “FILTER” position (see drawing 23).
8. Switch on the pump. The system is now operating in the normal filtering mode. Run the pump
until the desired pool water clearance is obtained and no more than 12 hours per day. For the
initial startup, it is recommended setting the system to a longer TIMER operating hours or “FP”
for the pump to operate continuously without the TIMER.
9. Record the initial pressure gauge reading when the filter media is clean.
NOTE: During initial setup of the system, it may be necessary to backwash frequently due to
unusual heavy dirt present in the water and sand. After that, as the filter removes dirt and
impurities from the pool water, the accumulated dirt in the sand media will cause the pressure
to rise and the flow to diminish. If there is no vacuuming device attached to the system and
the pressure gauge reading is in the yellow zone it is time to backwash the sand media, see
“BACKWASH” under “initial startup and operation” section. Vacuuming device (i.e. Intex auto
pool cleaner) attached to the system may also cause the flow to diminish and the pressure to
rise. Remove any vacuuming device from the system and check if the pressure gauge
reading has dropped from the yellow zone to the green zone.
10.Monitor the pressure gauge reading, and check that the inlet and outlet openings are not
obstructed on a weekly basis. If the pressure gauge indicates yellow it is time to backwash
the filter media.
29
1
2

342
PO
SAVE THESE INSTRUCTIONS
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018
English
Page 16
OPERATING INSTRUCTIONS (continued)
Operating the system under “TIMER” mode or manually:
To operate the sand filter pump in “FILTER” mode under “TIMER” control:
1. Activate the unit:
Press button. Flashing code “00” appears on the LED display, indicating
that the unit is ready to be programmed.
2. Set operating hours:
With code “00” flashing, press button to set the desired operating
hours. See the “Operating Time Table” for the required operating
hours related to each pool size. Pressing will increase the time
from 01 to 12 hours maximum. If you have selected too many hours
keep pressing to repeat the cycle. The built-in timer will now
activate the Sand filter pump, at the same time each day, for the
number of hours you have set.
3. Lock keypad controls:
With the desired hour value showing, press button until you hear a “beep”. Locking the
control buttons into this setting prevents unauthorized changing of the operating cycle.
NOTE: If you forget to lock the keypad controls, the system will automatically lock it and start
working 10 seconds later.
The sand filter pump is now filtering the water and will stop after the operating hours are
completed.
4. Readjust operating time if necessary:
The operating hours can be re-adjusted if necessary. Press button until you hear a “beep”
to unlock the keypad and the current programmed time will flash. Repeat steps 2 to 3.
5. Stand-by/power saving mode:
•When the cycle ends, the LED display shows “00”. The system is
now in Stand-By mode. After 5 minutes the system goes into Power
Saving mode and the LED display shows “.”. The system will
automatically turn itself back on in 24 hours.
• While the system is in Power Saving mode, press any button and the
system will briefly display the programmed time and then “00”.
To view the TIMER preset hours:
While the pump is operating, press button, the display will briefly flash the preset hours for 10
seconds and then display back the remaining operating hours.
To operate the sand filter pump manually (without the “TIMER” mode):
1. To run the pump alone without the “Timer”, press button to turn
on the pump, then press button until the LED displays “FP”, this
indicates that the TIMER is off and the pump is now operating continuously.
2. To stop the pump, press button again.
(1 to 12 hours max per cycle)

342
PO
SAVE THESE INSTRUCTIONS
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018
English
Page 17
INTEX POOLS OPERATING TIME TABLE (WITHOUT INTEX SALTWATER SYSTEM)
Pool Size
Water Capacity (Calculated at
90% for Frame Pool and 80%
for Easy Set & Oval Pool)
Sand filter pump operating
time (For one cycle) / (Hours)
(Gals) (Liters) SF80110-2 SF70110-2 SF60110-2
INTEX ABOVE GROUND POOLS (AGP’s)
EASY SET®
POOL
457cmx84cm (15'x33") 2587 9792 2 - -
457cmx91cm (15'x36") 2822 10681 2 --
457cmx107cm (15'x42") 3284 12430 2 --
457cmx122cm (15'x48") 3736 14141 3 - -
488cmx107cm (16'x42") 3754 14209 3--
488cmx122cm (16'x48") 4273 16173 3 - -
488cmx132cm (16'x52") 4614 17464 3--
549cmx107cm (18'x42") 4786 18115 332
549cmx122cm (18'x48") 5455 20647 4 33
ROUND
METAL
FRAME POOL
457cmx91cm (15'x36") 3282 12422 2 - -
457cmx107cm (15'x42") 3861 14614 3--
457cmx122cm (15'x48") 4440 16805 3--
488cmx122cm (16'x48") 5061 19156 4 --
549cmx122cm (18'x48") 6423 24311 5 3 3
640cmx132cm (21'x52") 9533 36082 6 5 4
732cmx132cm (24'x52") 12481 47241 8 6 6
ULTRA FRAME
POOL
488cmx122cm (16'x48") 5061 19156 4 --
549cmx122cm (18'x48") 6423 24311 5 3 3
549cmx132cm (18'x52") 6981 26423 5 4 3
610cmx122cm (20'x48") 7947 30079 544
671cmx132cm (22'x52") 10472 39637 755
732cmx132cm (24'x52") 12481 47241 8 6 6
792cmx132cm (26'x52") 14667 55515 10 7 7
GRAPHITE GRAY
PANEL POOL
SET™
478cmx124cm (15'8"x49") 4440 16805 3 - -
508cmx124cm (16'8"x49") 5061 19156 4 33
569cmx135cm (18'8"x53") 6981 26423 543
OVAL FRAME
POOL
305cmx549cmx107cm (10'x18'x42")
2885 10920 2 --
366cmx610cmx122cm (12'x20'x48")
4393 16628 3 2 2
RECT. ULTRA
FRAME POOL
274cmx457cmx122cm (9'x15'x48")
3484 13187 3 22
274cmx549cmx132cm (9'x18'x52")
4545 17203 332
305cmx610cmx132cm (10'x20'x52")
5835 22085 4 33
366cmx732cmx132cm (12'x24'x52")
8403 31805 6 4 4
488cmx975cmx132cm (16'x32'x52")
14364 54368 9 7 6
This table shows the required operating time for average use of the sand filter pump with above
ground pools.
If the system is attached to an “Intex Saltwater System” unit, the filter pump running time
should be longer than the required operating time of the Intex Saltwater System unit.
NOTE: The timer setting has an additional 10 minutes over the actual setting.

342
PO
SAVE THESE INSTRUCTIONS
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018
English
Page 18
NON-INTEX POOLS OPERATING TIME TABLE
Water Capacity Sand filter pump operating time (For one cycle) / (Hours)
(Gals) (Liters) SF80110-2 SF70110-2 SF60110-2
3000 11355 2 - -
4000 15140 3 2 2
4440 16805 3 3 2
5000 18925 4 3 3
6000 22710 4 3 3
7000 26495 5 4 3
8000 30280 544
9000 34065 6 5 4
10000 37850 7 5 5
11000 41635 7 6 5
12000 45420 8 6 5
13000 49205 9 7 6
14000 52990 9 7 6
15000 56775 10 7 7
16000 60560 10 8 7
17000 64345 11 8 7
18000 68130 12 9 8
19000 71915 12 9 8
20000 75700 - 10 9
21000 79485 - 10 9
22000 83270 - 11 9
23000 87055 - 11 10
24000 90840 - 12 10
25000 94625 - 12 11
26000 98410 - 12 11
This table shows the required operating time for average use of the sand filter pump with above
ground pools.

342
PO
SAVE THESE INSTRUCTIONS
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018
English
Page 19
MOTOR PRE-FILTER CLEANING AND MAINTENANCE
1. Make sure the filter pump is switched off, then disconnect the power cord from the electrical
outlet.
2. Turn both plunger valve handles fully clockwise until they stop. This closes the valve,
prevents the water from flowing out of the pool.
3. Release the pressure first by opening the sediment
release valve
(19) located on the lower side of the
pre-filter housing
(see drawing 30).
4. In a counter-clockwise motion unscrew the leaf trap
cover (14), then remove the basket (16) and leaf trap
o-ring
(15) from the pre-filter housing (see drawing 31).
5. Empty and flush the basket using a garden hose, may use a plastic brush to remove
deposits from the basket. Do not use metal brush.
6. Clean and rinse the inside of the pre-filter housing and the leaf trap O-ring with a garden
hose.
7. Reinstall the leaf trap O-ring, basket and leaf trap cover to the pre-filter housing.
8. Close the sediment release valve (19) back.
1
2
30
31
19
14
15
16
35

342
PO
SAVE THESE INSTRUCTIONS
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018
English
Page 20
1. Before emptying your pool for long term storage, or relocation, be sure the water is directed towards
an acceptable drain water receptacle away from the house. Check local regulations for specific
directions regarding disposal of swimming pool water.
2. Switch off the unit, and disconnect power cord from electrical outlet.
3. When the pool is empty, disconnect all hoses from pump and plunger valves and remove the
strainers/plunger valves from the pool wall.
4. In a counter clockwise motion unscrew the drain valve cap (9) from the drain valve to thoroughly drain
the tank. The drain valve is located at the bottom of the filter tank.
5. Disassemble the pump motor from the tank base.
6. Leave sand filter pump pieces and hoses outside to thoroughly air dry.
7. Coat the following o-rings and washers with petroleum jelly for long term storage:
• L-shape o-rings
(11 & 18).
• Pump hose O-rings (22).
• Strainer valve assembly step washers (23).
• Flat strainer rubber washers (25).
8. Depress the 6-way valve handle and rotate so as to set the pointer on the valve top “N” position.
This allows the water to drain from the valve. Leave the 6-way valve in this inactive position.
9. It is best to place all dry pieces and pump motor in the original packaging for storage. To avoid
condensation or corrosion problem, do not cover or wrap pump motor with plastic bags.
10. Store the pump motor and accessories in a dry place. The storage's temperature should be controlled,
between 0 degrees Celsius (32 degrees Fahrenheit) and 40 degrees Celsius (104 degrees Fahrenheit).
POOL CARE & CHEMICALS
• All pools require care to keep the water clear and hygienically clean. With proper chemical control, your
filter will help attain this objective. Consult your pool supply dealer for instructions regarding the proper
use of chlorine, algaecide and other chemical agents required for sparkling clear water.
• Keep pool chemicals away from children.
• Do not replenish chemicals in pool while pool is occupied. Skin or eye irritations could occur.
• Daily pH checking and chemical treatment of the water is very important and cannot be
overemphasized. Chlorine, algaecide and maintenance of proper pH levels are required when filling the
pool as well as during the season. Consult your local swimming pool supply store for instructions.
• The season's first filling of the pool may have brackish water requiring extra water additives and extra
filtering time. Do not allow swimming in pool until the pH level is balanced. Consult your local swimming
pool supply store for instructions.
• Chlorinated water may damage lawns, gardens or shrubbery as children play in the pool and splash
water outside the pool. Lawn areas underneath the pool liner will be destroyed. Note that some types of
grass may grow through the liner.
• Filter run time depends on pool size, weather and usage level. Experiment with various run times so as
to produce clean clear water.
LONG TERM STORAGE & WINTERIZATION
CAUTION
Concentrated chlorine solutions may damage the pool liner. Always follow the chemical
manufacturer’s directions, and the health and hazard warnings.
CAUTION
Allowing the water to freeze will damage the sand filter and void the warranty. If anti-freeze
solution is needed, use only propylene glycol. Propylene glycol is non-toxic and will not
damage plastic system components; other anti-freezes are highly toxic and may damage
plastic components in the system.
