Intex DP30110 User manual

326
PO
English
(326PO) POOL DRAIN PUMP ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 06/08/2017
English
IMPORTANT
SAFETY RULES
Read, understand, and follow all
instructions carefully before installing
and using this product.
POOL DRAIN PUMP
Model DP30110
IMPORTANT!
DO NOT RETURN PRODUCT TO STORE
To purchase parts and accessories or to obtain non-technical assistance, visit
www.intexcorp.com
For technical assistance and missing parts call us toll-free (for U.S. and Canadian Residents):
1-800-234-6839
Monday through Friday, 8:30am to 5:00pm Pacific Time
Don’t forget to try these other fine Intex products: pools, pool
accessories, inflatable pools and in-home toys, airbeds and boats
available at fine retailers or visit our website.
Due to a policy of continuous product improvement, Intex reserves
the right to change specifications and appearance, which may
result in updates to the instruction manual without notice.
326-*PO-R0-1806
OWNER’S MANUAL
For illustrative purposes only.

(326PO) POOL DRAIN PUMP ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 06/08/2017
326
PO
SAVE THESE INSTRUCTIONS
English
Page 2
Warnings................................................................................ 3
Parts Reference..................................................................... 4
Setup Instructions................................................................. 4
Troubleshooting Guide......................................................... 5
Long Term Storage............................................................... 5
Limited Warranty................................................................... 6
TABLE OF CONTENTS
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference
that may cause undesired operation of the device.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.

(326PO) POOL DRAIN PUMP ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 06/08/2017
326
PO
SAVE THESE INSTRUCTIONS
English
Page 3
IMPORTANT SAFETY RULES
Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product.
WARNING
•To reduce the risk of injury, do not permit children to use this product. Always supervise
children and those with disabilities.
•Children must stay away from this product and electrical cord(s).
•Assembly and disassembly by adults only.
•Risk of electric shock. Connect this product only to a grounding type receptacle protected
by a ground-fault circuit interrupter (GFCI). Contact a qualified electrician if you cannot
verify that the receptacle is protected by a GFCI. Use a qualified electrician to install the
GFCI, which has a maximum rate of 30mA.
•Risk of electric shock – This pump is supplied with a grounding conductor and
grounding-type attachment plug. To reduce the risk of electric shock, be certain that it is
connected only to a properly grounded, grounding-type receptacle.
•Always unplug this product from the electrical outlet before removing, cleaning, servicing or
making any adjustment to the product.
•Do not bury the electrical cord. Locate the cord where it will not be damaged by lawn
mowers, hedge trimmers and other equipment.
•To reduce the risk of electric shock, the supply cord cannot be replaced. If the cord is
damaged, the appliance should be replaced immediately.
•To reduce the risk of electric shock, do not use extension cords, timers, plug adaptors or
converter plugs to connect unit to electric supply; provide a properly located outlet.
•Do not attempt to plug in or unplug this product while standing in water or when your hands
are wet.
•Do not use an appliance leakage current interrupter (ALCI) in place of a GFCI since the
ALCI will not protect people.
• Do not operate this product when the pool is occupied.
• This product is intended to be used only for the purposes described in the manual!
FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN PROPERTY DAMAGE,
ELECTRIC SHOCK, ENTANGLEMENT OR OTHER SERIOUS INJURY OR DEATH.
CAUTION
This pump has been evaluated for use with water only.
These product warnings, instructions and safety rules provided with the product represent
some common risks of water recreation devices and do not cover all instances of risk and
danger. Please use common sense and good judgement when enjoying any water activity.

(326PO) POOL DRAIN PUMP ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 06/08/2017
326
PO
SAVE THESE INSTRUCTIONS
English
SETUP INSTRUCTIONS
Page 4
PARTS REFERENCE
Before assembling your product, please take a few minutes to check the
contents and become familiar with all the parts.
NOTE: Drawings for illustration purpose only. Actual
product may vary. Not to scale.
REF.
NO. DESCRIPTION QTY. SPARE PARTS NO.
1POOL DRAIN PUMP 1 12665
2 HOSE SEAL 1 10134
3 HOSE CLAMP 1 11489
4 HOSE (1-1/4” X 16.4ft) 1 12656
5GARDEN HOSE ADAPTOR 1 12667
When ordering parts, be sure to quote the model number and part numbers. No tools
are required for the assembly.
NOTE: Maximum pool water depth not to exceed 48 in (1.22 m). To protect the
pump motor from running dry, disconnect the power cord from the electrical outlet
once the water has been drained out or when the remaining water is below the
drainage pump base.
Insert
Garden hose
(Not included)
4
3
5
Insert
Power cord
Water level
Inside of the Pool Wall
3
Or
1
5
4
2
3

(326PO) POOL DRAIN PUMP ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 06/08/2017
326
PO
SAVE THESE INSTRUCTIONS
English
LONG TERM STORAGE
1. Disconnect the power cord from the electrical outlet.
2. Clean and air dry all the accessories and parts thoroughly.
3. Store the unit and accessories in a dry place. The storage’s temperature should
be controlled, between 32 ºF (0 ºC) and 104 ºF (40 ºC) storage location.
4. The original packaging can be used for storage.
Page 5
TROUBLESHOOTING GUIDE
PUMP MOTOR
FAILS TO START
DOES NOT PUMP
WATER OR THE
WATER FLOW IS
VERY SLOW
TROUBLE CAUSE SOLUTION
• The drainage pump is not
plugged in.
• The GFCI power outlet socket
is tripped.
• The main household circuit
breaker is tripped.
• Pump motor too hot and
overload protection is activated.
• Air trapped in the pump and
hose.
• Debris clogged underneath
drainage pump base.
• Pool water too dirty with large
debris.
• Pump not sitting upright on the
bottom of the pool floor.
• Water level below the drainage
pump base.
• Make sure the unit is plugged in.
• Reset the GFCI power outlet
socket. If problem persist, contact
a qualified electrician to check the
outlet socket.
• Reset the main circuit breaker. If
problem persist, contact a
qualified electrician to find out
and fix the electrical fault.
• Do not dry run the pump; let the
motor cool down for 30 minutes.
• Purge all the air out of the pump
and hose.
• Clear all the debris underneath
the pump base.
• Remove large debris and particles
from the pool floor and surface
first using a skimmer or leaf net,
and then drain the pool water.
• Keep the pump upright at all
times.
• Disconnect the power cord from
the electrical outlet once the pool
water level is below the pump
base.

(326PO) POOL DRAIN PUMP ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 06/08/2017
326
PO
SAVE THESE INSTRUCTIONS
English
Page 6
LIMITED WARRANTY
Your POOL DRAIN PUMP has been manufactured using the highest quality materials and
workmanship. All Intex products have been inspected and found free of defects prior to
leaving the factory. This Limited Warranty applies only to the POOL DRAIN PUMP and
accessories listed below.
The provisions of this Limited Warranty apply only to the original purchaser and is not
transferable. This Limited Warranty is valid for the period noted below from the date of the
initial retail purchase. Keep your original sales receipt with this manual, as proof of purchase
will be required and must accompany warranty claims or the Limited Warranty is invalid.
POOL DRAIN PUMP Warranty – 1 Year
Hoses & Fittings Warranty – 180 days
If a manufacturing defect is found within the periods noted above, please contact the
appropriate Intex Service Center listed in the separate “Authorized Service Centers” sheet.
The Service Center will determine the validity of the claim. If the Service Center directs you to
return the product, please carefully package the product and send with shipping and
insurance prepaid to the Service Center. Upon receipt of the returned product, the Intex
Service Center will inspect the item and determine the validity of the claim. If the provisions of
this warranty cover the item, the item will be repaired or replaced at no charge.
Any and all disputes regarding the provisions of this Limited Warranty shall be brought
before an informal dispute settlement board and unless and until the provisions of these
paragraphs are carried forth, no civil action may be instituted. The methods and procedures
of this settlement board shall be subject to the rules and regulations set forth by the Federal
Trade Commission (F.T.C.). IMPLIED WARRANTIES ARE LIMITED TO THE TERMS OF
THIS WARRANTY AND IN NO EVENT SHALL INTEX, THEIR AUTHORIZED AGENTS OR
EMPLOYEES BE LIABLE TO THE BUYER OR ANY OTHER PARTY FOR DIRECT OR
CONSEQUENTIAL DAMAGES OR LIABILITIES. Some states, or jurisdictions do not allow
the exclusion or limitation of incidental or consequential damages, so the above limitation or
exclusion may not apply to you.
This Limited Warranty does not apply if the products are subject to negligence, abnormal use
or operation, accident, improper operation, improper voltage or current contrary to operating
instructions, or to damage by circumstances beyond Intex’s control, including but not limited
to, ordinary wear and tear and damage caused by exposure to fire, flood, freezing, rain, or
other external environmental forces. This Limited Warranty applies only to those parts and
components sold by Intex. The Limited Warranty does not cover unauthorized alterations,
repairs or disassembly by anyone other than Intex Service Center personnel.
DO NOT GO BACK TO THE PLACE OF PURCHASE FOR RETURN OR REPLACEMENT.
IF YOU ARE MISSING PARTS OR NEED ASSISTANCE, PLEASE CALL US TOLL-FREE
(FOR U.S. AND CANADIAN RESIDENTS): 1-800-234-6839 OR VISIT OUR WEBSITE:
WWW.INTEXSTORE.COM.
Proof of Purchase must accompany all returns or the warranty claim will be invalid.
