Intex 633 User manual

109
(109) MODEL 633 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 09/26/2008
English
OOWWNNEERR’’SSMMAANNUUAALL
Krystal Clear™
Model 633
Filter Pump
IMPORTANT
SAFETY RULES
Read, Understand, and Follow all
Instructions Carefully before
Installing and using this Product.
IIMMPPOORRTTAANNTT!!
DO NOT RETURN PRODUCT TO STORE
To purchase parts and accessories or to obtain non-technical assistance,
Visit www.intexcorp.com
For technical assistance and missing parts call us toll-free (for U.S. and Canadian Residents):
1-800-234-6839
Monday through Friday, 8:30am to 5:00pm Pacific Time
Don’t forget to try these other fine Intex products: Pools, Pool Accessories,
Inflatable Pools and In-Home Toys, Airbeds and Boats available at fine
retailers or visit our website.
For illustrative purposes only.
109**-R0-0909

109
SAVE THESE INSTRUCTIONS Page 2
(109) MODEL 633 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 09/26/2008
English
TTAABBLLEEOOFFCCOONNTTEENNTTSS
Warnings.......................................................................... 3
Parts List & Reference.................................................... 4-6
Set Up Instructions......................................................... 7-9
Operating Instructions.................................................... 10-11
Pool Care and Chemicals............................................... 11-12
Long Term Storage.......................................................... 12
Troubleshooting Guide................................................... 13
Common Pool Problems................................................. 14
General Aquatic Safety................................................... 15
Limited Warranty............................................................. 16
Pool Safety Sign.............................................................. 17
Intex Service Center Locations...................................... 18

109
SAVE THESE INSTRUCTIONS Page 3
(109) MODEL 633 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 09/26/2008
English
SSAAFFEETTYYRRUULLEESS
This product is for use with storable pools only. Do not use with permanently-installed
pools. A storable pool is constructed so that it is capable of being readily disassembled
for storage and reassembled to its original integrity. A permanently-installed pool is
constructed in or on the ground or in a building such that it cannot be readily
disassembled for storage.
CAUTION
WARNING
• To reduce the risk of injury, do not permit children to use this product. Always
supervise children and those with disabilities.
• Risk of electric shock. Connect this product only to a grounding type receptacle
protected by a ground-fault circuit interrupter (GFCI). Contact a qualified electrician
if you cannot verify that the receptacle is protected by a GFCI.
• Do not bury electrical cord. Locate cord where it will not be damaged by lawn
mowers, hedge trimmers, and other equipment.
• To reduce the risk of electric shock, replace damaged cord immediately. Use a
qualified electrician to replace the cord.
• To reduce the risk of electric shock, do not use extension cords, timers, plug
adaptors or converter plugs to connect unit to electric supply; provide a properly
located outlet.
• Assembly and disassembly by adults only.
• Do not attempt to plug in or unplug this product while standing in water or when
your hands are wet.
• Do not use an appliance leakage current interrupter (ALCI) in place of a GFCI
since the ALCI will not protect people.
• Position this product away from pool to prevent a child from climbing on pump to
access the pool.
• Children must stay away from this product and electrical cord(s).
• Do not operate this product when pool is occupied.
• Always unplug this product from the electrical outlet before removing, cleaning,
servicing or making any adjustment to the product.
• This product is intended to be used only for the purposes described in the manual!
FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN
PROPERTY DAMAGE, ELECTRIC SHOCK, ENTANGLEMENT OR
OTHER SERIOUS INJURY OR DEATH.
These product warnings, instructions and safety rules provided with the product represent
some common risks of water recreation devices and do not cover all instances of risk and
danger. Please use common sense and good judgement when enjoying any water activity.
IMPORTANT SAFETY RULES
Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product.
READ AND FOLLOW ALL INSTRUCTIONS

109
SAVE THESE INSTRUCTIONS Page 4
(109) MODEL 633 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 09/26/2008
English
PPAARRTTSSLLIISSTT
1
9
45
13 14 15
16
2
11 12
8
6
PARTS LIST
3
NOTE: Drawings for illustration purpose only. May not reflect actual product. Not to scale.
10
7

109
SAVE THESE INSTRUCTIONS Page 5
(109) MODEL 633 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 09/26/2008
English
PPAARRTTSSRREEFFEERREENNCCEE
PARTS REFERENCE
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
When ordering parts, be sure to quote the model number and part numbers.
NOTE: Drawings for illustration purpose only. May not reflect actual product. Not to
scale.
1
2
3
4
5
6
7
8
REF. NO. DESCRIPTION QTY. SPARE PART NO.
1
2
2
1
1
1
1
2
THREADED FILTER HOUSING COLLAR
AIR RELEASE VALVE/SEDIMENT RELEASE VALVE
VALVE O-RING
FILTER HOUSING COVER
FILTER HOUSING O-RING
FILTER CARTRIDGE (59905)
AIR RELEASE VALVE B (WITH O-RING)
PUMP HOSE WITH NUTS
10491
10460
10264
10490
10492
10725
10493
2
3
4
5
1
6
8
7
32

109
SAVE THESE INSTRUCTIONS Page 6
(109) MODEL 633 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 09/26/2008
English
PPAARRTTSSRREEFFEERREENNCCEE
PARTS REFERENCE (continued)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
NOTE: Drawings for illustration purpose only. May not reflect actual product. Not to
scale.
9
10
11 12 13 14 15
9
10
11 12 13 14 16
9
10
11
12
13
14
15
16
REF. NO. DESCRIPTION QTY. SPARE PART NO.
2
2
2
2
1
1
PLUNGER VALVE (HOSE O-RING & STEP WASHER INCLUDED)
HOSE O-RING
STEP WASHER
STRAINER NUT
FLAT STRAINER RUBBER WASHER
THREADED STRAINER CONNECTOR
ADJUSTABLE POOL INLET NOZZLE
STRAINER GRID
10747
10262
10745
10256
10255
10744
11074
10253

109
SAVE THESE INSTRUCTIONS Page 7
(109) MODEL 633 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 09/26/2008
English
SSEETT--UUPPIINNSSTTRRUUCCTTIIOONNSS
1. Grasp the strainer and plunger valve
mechanism.
2. In a counter-clockwise motion unscrew
plunger valve union from the threaded
strainer connector (14). Be careful not to
lose the step rubber washer (11). Place
the plunger valve on the ground in a safe
place (see drawing 1).
3. In a counter-clockwise motion unscrew
the strainer nut (12) from the threaded
connector (14). Leave the flat
washer (13) on the connector (14).
4. Install the strainer and plunger valve at the
lower position of pool outlet (marked "+").
From the inside of the pool liner insert
the connector (14) into one of the pre-cut
holes with the washer remaining on the
connector to be placed against the inside
of the liner wall.
5. With the flat side of the strainer nut (12)
facing the outside wall of the liner in a
clockwise motion screw the strainer nut (12)
back onto the threaded connector (14)
(see drawing 2). Before assembly, lubricate
the threads with a petroleum jelly.
6. Finger tighten the strainer grid (16) and
the strainer nut (12) onto the threaded
connector (14).
7. Grasp the plunger valve assembly. Make
sure the step washer (11) is in place.
8. In a clockwise motion screw the plunger
valve union back onto the threaded
connector (14) (see drawing 3).
9. Examine the plunger valve to see if the
handle is pushed fully down to the "0/1"
position. If not, then grasp the handle at
the top and push down turning the
handle in a clockwise direction until the
plastic protruding notch anchors in
the "0/1" position. This will prevent
water from flowing out during filling
(see drawings 4.1 & 4.2).
The strainer grid prevents large objects from jamming and/or damaging the
filter pump and the plunger valve assembly prevents water from flowing into
the filter pump while the filter cartridge is being placed or cleaned. If your
pool has inflatable top ring, install the strainer, nozzle and plunger valve
before inflating the pool liner top ring.
1
2
3
4.1
4.2
13 14 16
INSIDE
LINER WALL
INSIDE
LINER
WALL
12
2
1
1
2
1
2
POOL OUTLET - STRAINER & PLUNGER VALVE SET-UP

109
SAVE THESE INSTRUCTIONS Page 8
(109) MODEL 633 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 09/26/2008
English
POOL INLET - NOZZLE & PLUNGER VALVE SET-UP
SSEETT--UUPPIINNSSTTRRUUCCTTIIOONNSS
5
7
8.1
8.2
INSIDE
LINER
WALL
POOL
9
2
1
1
2
1
2
6
13 14 15
INSIDE
LINER WALL
12
WATER
FLOW
1. Grasp the nozzle and plunger valve
mechanism.
2. In a counter-clockwise motion unscrew
plunger valve union from the threaded
strainer connector (14). Be careful not to
lose the step rubber washer (11). Place
the plunger valve on the ground in a safe
place (see drawing 5).
3. In a counter-clockwise motion unscrew
the strainer nut (12) from the threaded
connector (14). Leave the flat washer (13)
on the connector (14).
4. Install the nozzle and plunger valve at the
upper position of pool inlet. From the inside
of the pool liner insert the connector (14)
into one of the pre-cut holes with the
washer remaining on the connector to be
placed against the inside of the liner wall.
5. With the flat side of the strainer nut (12)
facing the outside wall of the liner in a
clockwise motion screw the strainer nut (12)
back onto the threaded connector (14) (see
drawing 6). Before assembly, lubricate the
threads with a petroleum jelly.
6. Finger tighten the adjustable pool inlet
nozzle (15) and the strainer nut (12) onto
the threaded connector (14).
7. Grasp the plunger valve assembly. Make
sure the step washer (11) is in place.
8. In a clockwise motion screw the plunger
valve union back onto the threaded
connector (14) (see drawing 7).
9. Examine the plunger valve to see if the
handle is pushed fully down to the "0/1"
position. If not, then grasp the handle at
the top and push down turning the handle
in a clockwise direction until the plastic
protruding notch anchors in the "0/1"
position. This will prevent water from
flowing out during filling (see drawings 8.1
& 8.2).
10. Adjust the direction of nozzle head pointing
away from the pool outlet for a better
circulation result (see drawing 9).
11. The pool liner is now ready to fill with
water. Consult the above-ground-pool
owner’s manual for filling instructions.

109
SAVE THESE INSTRUCTIONS Page 9
(109) MODEL 633 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 09/26/2008
English
SSEETT--UUPPIINNSSTTRRUUCCTTIIOONNSS
FILTER PUMP HOSE CONNECTION SET UP
1. Remove the Krystal Clear™ filter pump and hoses from the packaging.
2. Place the filter pump in a location for hose (8) connections to the plunger valve
assemblies.
Note: Some regional regulations may require the filter pump to be
mounted on a stationary platform. There are two mounting holes located
in the pump base for this reason. Consult your local authorities for
filter-pump mounting requirements.
3. Grasp the two pump hoses (8) and connect the hose nuts to the filter pump.
4. In a counter-clockwise motion unscrew the threaded filter housing collar (1)
from the filter housing. Place it in a safe place.
5. The Filter Pump is an airtight system. In a counter-clockwise motion turn both
air release valves (2 & 7) 1 - 2 turns to open.
DO NOT remove air release valves as water will expel with force if the
motor is turned on and injury may occur.
6. Grasp and remove the filter housing cover (4). Check to see if a cartridge is
inside the housing. If yes, replace the cover, finger tighten the housing collar (1)
back onto the filter housing.
7. Gently finger tighten the sediment release valve located at the bottom of the
housing to be sure that water does not leak out.
8. When the pool is filled connect the hose from the bottom of the filter housing to
the highest strainer assembly. The hose connection is made at the bottom of
the plunger valve assembly. Use the hose nut to attach the hose.
9. Connect the 2nd hose to the middle of the motor housing and to the remaining
liner connection.
WARNING
Position this product away from pool to prevent a child from climbing the
pool.
WATER LEVEL
ADJUSTABLE POOL
INLET NOZZLE
PLUNGER VALVE
ASSEMBLY
HOSE NUT
OUTLET HOSE
INSIDE
LINER WALL
STRAINER GRID
FILTER HOUSING
COLLAR
FILTER CARTRIDGE
INSIDE
FILTER HOUSING
COVER
AIR RELEASE
VALVE
MOTOR
HOUSING
HOSE O-RING
POWER CORD
INLET HOSE OUTSIDE
LINER WALL
(ILLUSTRATION NOT TO SCALE)
W
A
T
E
R
F
L
O
W
W
A
T
E
R
F
L
O
W

109
SAVE THESE INSTRUCTIONS Page 10
(109) MODEL 633 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 09/26/2008
English
OOPPEERRAATTIINNGGIINNSSTTRRUUCCTTIIOONNSS
FILTER CARTRIDGE CLEANING OR REPLACEMENT
1. Make sure the filter pump switch is "OFF". The switch is located on the motor
housing.
2. Connect the power cord to a GFCI protected electrical outlet.
It is recommended that the filter cartridge be replaced at least
every 2 weeks.
1. Make sure the filter pump is turned off, and disconnect the power cord from the
electrical outlet.
2. Close both plunger valves. Grasp a plunger valve handle. Turn the handle
counter-clockwise, push down until it stops and then turn it clockwise until the
plastic protruding notch anchors in the "0/1" position. Repeat for the 2nd
plunger valve. This prevents the water from flowing out of the pool.
3. Gently turn the top air release valve 1-2 turns in a counter-clockwise direction.
This will allow the housing cover to be easily removed.
4. In a counter-clockwise direction remove the filter housing collar (1). Place it in a
safe location.
5. Remove the housing cover (4).
6. Remove the "OLD" filter cartridge.
7. Examine the inside of the filter housing.
3. Grasp a plunger valve handle. Turn the handle counter-clockwise, pull up until
it stops, and then turn it clockwise until the metal protruding notch anchors in
the "0/1" position. Repeat for the 2nd plunger valve. This opens the valves to
allow water to flow into the filter pump.
4. With water flowing into filter pump, the water pressure will allow the air trapped
inside to escape from the air release valves (2 & 7). When all the air has
escaped water will flow out of the valves (2 & 7). When this occurs gently finger
tighten the valves (2 & 7) in a clockwise direction.
5. Turn the switch "ON". The filter pump is now filtering the water.
6. Operate the filter pump until the desired water clarity is obtained.
To prevent air lock, open the lower plunger valve (connected inlet hose)
first and then the upper plunger valve (connected outlet hose). Open air
release valves, wait until water starts to flow out of the air release valves,
close air release valves.
IMPORTANT
Risk of electric shock. Connect this product only to a grounding type
receptacle protected by a ground-fault circuit interrupter (GFCI). Contact a
qualified electrician if you cannot verify that the receptacle is protected by
a GFCI.
WARNING
OPERATING INSTRUCTIONS
