Intex SF80220 User manual

195A
(195IO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2013
English
Model SF80220 6 m3
Model SF70220 8 m3
Model SF60220 10 m3
IMPORTANT
SAFETY RULES
Read, understand, and follow
all instructions carefully before
installing and using this product.
Don’t forget to try these other fine Intex products: pools, pool
accessories, inflatable pools and in-home toys, airbeds and boats
available at fine retailers or visit our website.
Due to a policy of continuous product improvement, Intex reserves
the right to change specifications and appearance, which may
result in updates to the instruction manual without notice.
©2013 Intex Marketing Ltd. - Intex Development Co. Ltd. - Intex Trading Ltd.
- Intex Recreation Corp.
All rights reserved/Tous droits réservés/Todos los derechos reservados/Alle
Rechte vorbehalten. Printed in China/Imprimé en Chine/Impreso en China/Gedruckt in China.
®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous
licence de/Marcas registradas utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in einigen
Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Trading Ltd., Intex Development Co. Ltd., G.P.O
Box 28829, Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European
Union by/Distribué dans l’Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union
durch/Intex Trading B.V., Venneveld 9, 4705 RR Roosendaal – The Netherlands
www.intexcorp.com
For illustrative purposes only.
OWNER’S MANUAL
195-*A*-R0-1407

195A
SAVE THESE INSTRUCTIONS
(195IO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2013
English
Page 2
Warnings.......................................................................... 3
Parts References............................................................. 4-5
Setup Instructions ......................................................... 6-13
Product Specifications................................................... 8
Operating Instructions ................................................... 14-16
Intex Pools Operating Time Table.................................. 17
Non-Intex Pools Operating Time Table..........................18
Maintenance.................................................................... 19
Long Term Storage.......................................................... 20
Troubleshooting Guide................................................... 21
Common Pool Problems................................................. 22
General Aquatic Safety................................................... 22
Limited Warranty............................................................. 23
TABLE OF CONTENTS

195A
SAVE THESE INSTRUCTIONS
(195IO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2013
English
Page 3
IMPORTANT SAFETY RULES
Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product.
READ AND FOLLOW ALL INSTRUCTIONS
WARNING
•To reduce the risk of injury, do not permit children to use this product. Always supervise children and those with
disabilities.
•Children must stay away from this product and electrical cord(s).
• Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without
supervision
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards involved.
•Assembly and disassembly by adults only.
•Risk of electric shock. Connect this product only to a grounding type receptacle protected by a ground-fault circuit
interrupter (GFCI) or residual current device (RCD). Contact a qualified electrician if you cannot verify that the
receptacle is protected by a GFCI/RCD. Use a qualified electrician to install the GFCI/RCD, which has a maximum
rate of 30mA. Do not use a portable residual current device (PRCD).
•Always unplug this product from the electrical outlet before removing, cleaning, servicing or making any adjustment
to the product.
•The plug must be accessible after product is installed.
•Do not bury the electrical cord. Locate the cord where it will not be damaged by lawn mowers, hedge trimmers and
other equipment.
•If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
•To reduce the risk of electric shock, do not use extension cords, timers, plug adaptors or converter plugs to
connect unit to electric supply; provide a properly located outlet.
•Do not attempt to plug in or unplug this product while standing in water or when your hands are wet.
•Keep this product more than 2m away from the pool.
• Keep this product more than 3.5m away from the pool (for France only).
•Keep the plug of this product more than 3.5m away from the pool.
• Position this product away from the pool, so as to prevent children from climbing on it and accessing the pool.
•Do not operate this product when pool is occupied.
•This product is for use with storable pools only. Do not use with permanently installed pools. A storable pool is
constructed so that it may be readily disassembled for storage and reassembled to its original configuration.
•To reduce the risk of entrapment hazard, never enter the pool if suction strainer component is loose, broken,
cracked, damaged or missing. Replace loose, broken, damaged, cracked or missing suction strainer components
immediately.
• Never play or swim near suction fittings. Your body or hair may be trapped causing permanent injury or drowning.
• To prevent equipment damage and risk of injury, always turn pump off before changing the filter control valve
position.
• Never operate this product above the maximum working pressure stated on the filter tank.
• Hazardous Pressure. Improper tank valve cover assembly could cause the valve cover to blow off and cause
serious injury, property damage or death.
• This product is intended to be used only for the purposes described in the manual!
FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN PROPERTY DAMAGE, ELECTRIC SHOCK,
ENTANGLEMENT OR OTHER SERIOUS INJURY OR DEATH.
These product warnings, instructions and safety rules provided with the product represent some common risks of
water recreation devices and do not cover all instances of risk and danger. Please use common sense and good
judgement when enjoying any water activity.

195A
SAVE THESE INSTRUCTIONS
(195IO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2013
English
Page 4
PARTS REFERENCE
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
" * ": Optional.
1
5
9
11
2
13
35
20
32
33 34 19
3
6
7
4
12
15
16
17
18
8
10
14
36
37
38
19
20
22
21
23 24 25 26 27
22
23 28 29 30
21
23 24
21
22
25 26
23 28
21
22
29 31
**
**

195A
SAVE THESE INSTRUCTIONS
(195IO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2013
English
Page 5
REF. NO. DESCRIPTION QTY. SPARE PART NO.
SF80220 SF70220 SF60220
1 PRESSURE GAUGE 1 11411 11224 11224
2 6-WAY VALVE 111378 11496 11496
3 DRAIN OUTLET COVER 1 11131 11131 11131
4CLAMP 111380 11380 11380
5 TANK O-RING 1 11379 11379 11379
6 SAND SHIELD 111382 11382 11382
7 CENTER PIPE HUB 111815 11813 11814
8 LATERAL 10 11484 11384 11384
9 DRAIN VALVE CAP 1 11456 11456 11456
10 DRAIN VALVE O-RING 111385 11385 11385
11 L-SHAPE O-RING 411228 11228 11228
12 HOSE WITH NUTS 2 11010 11010 11010
13 SAND FILTER INTERCONNECTING HOSE 111820 11388 11535
14 LEAF TRAP NUT 111822 11479 11479
15 LEAF TRAP O-RING 111824 11232 11232
16 BASKET 111821 11260 11260
17 FILTER HOUSING NUT 1 11261 11261 11261
18 L-SHAPE O-RING 1 11412 11412 11412
19 AIR RELEASE VALVE / SEDIMENT RELEASE VALVE 2 10460 10460 10460
20 VALVE O-RING 2 10264 10264 10264
21* PLUNGER VALVE (HOSE O-RING & STEP WASHER INCLUDED) 2 10747 10747 10747
22* HOSE O-RING 2 10262 10262 10262
23* STEP WASHER 2 10745 10745 10745
24* STRAINER NUT 2 10256 10256 10256
25* FLAT STRAINER RUBBER WASHER 2 10255 10255 10255
26* THREADED STRAINER CONNECTOR 2 11235 11235 11235
27* ADJUSTABLE POOL INLET NOZZLE 1 11074 11074 11074
28* ADAPTOR B 2 10722 10722 10722
29*STRAINER CONNECTOR 2 11070 11070 11070
30*POOL INLET NOZZLE 1 11071 11071 11071
31*STRAINER GRID 1 11072 11072 11072
32 SCREW 211381 11381 11381
33 PUMP MOTOR & CONTROL 111818 11806 11808
34 PRE-FILTER ASSEMBLY 111826 11371 11371
35 LEAF TRAP COVER 111823 11480 11480
36 SAND FILTER PUMP MOTOR INLET O-RING 211457 11457 11457
37 SAND FILTER PUMP TANK 111804 11802 11803
38 SAND FILTER PUMP TANK BASE 111816 11800 11801
" * ": Optional.
When ordering parts, be sure to quote the model number and part numbers.
PARTS REFERENCE
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.

195A
SAVE THESE INSTRUCTIONS
(195IO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2013
English
Page 6
The strainer grid prevents large objects from jamming and/or damaging the filter pump. If
your pool has an inflatable top ring, install the strainer, nozzle and plunger valve before
inflating the pool liner top ring. The part numbers here onward refer to the parts depicted
in the Parts List section of this manual. To install, do the following:
1. In a counter-clockwise motion unscrew
plunger valve union from the threaded
strainer connector (26) (see drawing 1).
Be careful not to lose the step rubber
washer (23). Place the plunger valve on
the ground in a safe place.
2. In a counter-clockwise motion unscrew the
strainer nut (24) from the threaded
connector (26). Leave the flat washer (25)
on the connector (26).
3. Install the strainer and plunger valve at the
lower position of pool outlet (marked "+").
From the inside of the pool liner insert the
connector (26) into one of the pre-cut holes
with the washer remaining on the
connector to be placed against the inside
of the liner wall.
4. Before assembly, lubricate the threads with
a petroleum jelly. With the flat side of the
strainer nut (24) facing the outside wall of
the liner in a clockwise motion screw the
strainer nut (24) back onto the threaded
connector (26) (see drawing 2).
5. Finger tighten the strainer nut (24) onto the
threaded connector (26).
6. Grasp the plunger valve assembly. Make
sure the step washer (23) is in place.
7. In a clockwise motion screw the plunger
valve union back onto the threaded
connector (26) (see drawing 3).
8. In a clockwise motion turn the plunger
valve handle to close position. Ensure the
plunger valve is securely closed. This will
prevent water from flowing out during filling
of the pool (see drawing 4).
POOL OUTLET - STRAINER & PLUNGER VALVE SETUP (optional)
2
25 26
INSIDE
LINER WALL
24
1
23
2
1
3
1
2
4
INSIDE
LINER WALL

195A
SAVE THESE INSTRUCTIONS
(195IO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2013
English
Page 7
POOL INLET - NOZZLE & PLUNGER VALVE SETUP (optional)
1. In a counter-clockwise motion unscrew
plunger valve union from the threaded
strainer connector (26) (see drawing 5).
Be careful not to lose the step rubber
washer (23). Place the plunger valve on
the ground in a safe place.
2. In a counter-clockwise motion unscrew the
strainer nut (24) from the threaded
connector (26). Leave the flat washer (25)
on the connector (26).
3. Install the nozzle and plunger valve at the
upper position of pool inlet. From the inside
of the pool liner insert the connector (26)
into one of the pre-cut holes with the
washer remaining on the connector to be
placed against the inside of the liner wall.
4. Before assembly, lubricate the threads with
a petroleum jelly. With the flat side of the
strainer nut (24) facing the outside wall of
the liner in a clockwise motion screw the
strainer nut (24) back onto the threaded
connector (26) (see drawing 6).
5. Finger tighten the adjustable pool inlet
nozzle (27) and the strainer nut (24) onto
the threaded connector (26).
6. Grasp the plunger valve assembly. Make
sure the step washer (23) is in place.
7. In a clockwise motion screw the plunger
valve union back onto the threaded
connector (26) (see drawing 7).
8. In a clockwise motion turn the plunger
valve handle to close position. Ensure the
plunger valve is securely closed. This will
prevent water from flowing out during filling
of the pool (see drawing 8).
9. Adjust the direction of nozzle head pointing
away from the pool outlet for a better
circulation result (see drawing 9).
10. The pool liner is now ready to fill with
water. Consult the above-ground-pool
owner’s manual for filling instructions.
5
9
2
1
7
1
2
8
INSIDE
LINER WALL
6
25 26 27
INSIDE
LINER WALL
24
WATER
FLOW
Pool

195A
SAVE THESE INSTRUCTIONS
(195IO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2013
English
Page 8
PRODUCT SPECIFICATIONS
SETUP INSTRUCTIONS
NOTE: NOT SUITABLE FOR USE WITH KCP-LOW -SALT AUTOMATIC SALTWATER SYSTEM
(MODEL 6110/6220)
The sand filter removes suspended particles but does not sanitize your pool. Pool chemistry
is a specialized area and you should consult your local pool service specialist for details .
TOOLS REQUIRED: One (1) Phillips screwdriver
Pump location and mounting:
• Thesystemmustbeinstalledonasolidlevelandvibration-freebase.
• Providealocationprotectedfromtheweather,moisture,floodingandfreezing
temperature.
• Provideadequateaccess,spaceandlightingforroutinemaintenance.
• Pumpmotorrequiresfreecirculationofairforcooling.Donotinstallthepumpina
damp or non-ventilated location.
A team of 2 or more people is recommended for setting up this product.
Motor pre-filtering assembly setup:
1. Remove the sand filter and its accessories from the packaging carefully and inspect for any
visible damage.
2. In a counter-clockwise motion unscrew the leaf trap cover (14) from the pre-filter housing.
Take out the basket (16) and filter housing nut (17) (see drawing 10).
3. Connect the pre-filter housing to the motor water inlet. Note:Align the connector in the
pre-filter housing with the water inlet on the motor (see drawing 11).
11
10
35
17
16
14
Model: SF80220 SF70220 SF60220
Power: 220-240 Volt AC 220-240 Volt AC 220-240 Volt AC
Wattage: 370 W 550 W 650 W
Maximum working pressure: 2 bar (30 psi) 2 bar (30 psi) 2 bar (30 psi)
Effective filtering area: 0.07 m2(0.79 ft2)0.1 m2(1.07 ft2)0.13 m2(1.44 ft2)
Maximum Flow Rate: 6055 LPH (1600 GPH) 8137 LPH (2150GPH) 10030 LPH (2650 GPH)
Recommended filtering
media quantity:
No. 20 silica sand
23 Kg (50 Lbs) or
glass sand 16 Kg
(35 Lbs).
No. 20 silica sand
35 Kg (77 Lbs) or
glass sand 25 Kg
(55 Lbs).
No. 20 silica sand
55 Kg (121 Lbs) or
glass sand 38 Kg
(84 Lbs).
Recommended filtering
media (Not included):
No. 20 silica sand or glass sand. Particle size range 0.45 to 0.85
mm (0.018 to 0.033 inches). Uniformity Coefficient less than 1.75.
Limited Warranty: see “Limited Warranty”

195A
SAVE THESE INSTRUCTIONS
(195IO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2013
English
Page 9
4. In a clockwise motion screw filter housing nut (17) onto the motor water inlet (See
drawings 12.1 & 12.2).
5. Replace the basket (16) and leaf trap cover (14) back to the pre-filter housing (See
drawings 13.1 & 13.2).
SETUP INSTRUCTIONS (continued)
Sand tank installation:
1. Place the tank support base at the selected location.
2. Place the tank on the tank support base (See drawing 14.1).
3. Connect the motor pre-filtering assembly unit to the tank support base (See drawing 14.2).
NOTE: Ensure the pre-filter housing water inlet hose connection is facing towards the pool.
IMPORTANT: Some countries, especially in the European community, require the
product to be secured to the ground or to a base in a permanent upright position.
Check your local authorities to determine if there is a regulation in your area
regarding above-the-ground swimming pool filter-pumps. If yes, then the product
can be mounted to a platform using the two holes located in the base.
See drawing 14.3.
The product can be mounted on a cement base or onto a wooden plat form to
prevent accidental falling over.
 • Themountingholesare6.4mmindiameterandspaced100mmformodel
SF80220 (spaced 115 mm for model SF70220 & SF60220) apart.
 • Usetwoboltsandlocknutswithamaximumof6.4mmindiameter.
12.1
17
12.2
17
13.213.1
14
16
35
14.1 14.2 14.3
Model SF80220: 100 mm
Model SF70220 & SF60220: 115 mm
19

195A
SAVE THESE INSTRUCTIONS
(195IO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2013
English
Page 10
SETUP INSTRUCTIONS (continued)
Sand loading:
IMPORTANT: Use No. 20 silica sand or glass sand with particle size range 0.45 to 0.85 mm
(0.018 to 0.033 inches) and a Uniformity Coefficient less than 1.75.
NOTE: Before loading the tank with sand, ensure the center pipe hub assembly is
securely in place at the bottom of the tank, and vertically centered inside the tank.
1. Place the sand shield (6) over the top of the center pipe. Pour the sand into the tank at
a slow rate. (see drawing 15).
2. Fill the tank approximately half way, remove the sand shield (6) from the top.
(see drawing 16).
3. Evenly distribute the sand inside the tank, then fill the tank with some water to provide a
cushioning effect when the remaining sand is poured in. This prevents the center pipe hub
(7) from excessive shock (see drawing 17). Place the sand shield (6) back and continue to
pour the sand into the tank.
4. Sand shall be filled between the “MAX” and “MIN” marked gauge on the center pipe.
Evenly spread and level out the sand by hand (see drawings 17 & 18).
5. Remove the sand shield (6).
6. Wash away all sand around the top edge of the tank.
MAX
MIN
MAX
MIN
18
7
15
6
16
6
MAX
MIN
17
7

195A
SAVE THESE INSTRUCTIONS
(195IO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2013
English
Page 11
6-way valve installation:
1. Lower the 6-way valve over the tank slowly, and ensure the bypass pipe protruding
underneath the 6-way valve fits securely into the center pipe hub (7) top opening
(see drawing 19).
IMPORTANT: There are three hose connection ports on the 6-way valve, ensure the outlet
connection (from filter to the pool) on the valve is facing towards the pool, and the inlet
connection (from motor to valve) is aligned with the motor outlet (see drawing 20).
SETUP INSTRUCTIONS (continued)
WARNING
Improper tank valve and clamp assembly could cause the valve and
clamp to blow off and cause serious injury, property damage or death.
2. Place an L-shape o-ring (11) on the 6-way valve inlet connection and on the pump motor
outlet. In a clockwise motion connect the sand filter interconnecting hose (13) between
the pump motor outlet and the 6-way valve inlet connection (see drawing 21).
3. Remove the clamp bolt, and install the clamp around the tank and 6-way valve flanges,
then replace the clamp bolt and use a phillips screwdriver (not included) to tighten it
(see drawing 22)
20
WATER
INLET
WATER
OUTLET
19
7
21
13
22
4

195A
SAVE THESE INSTRUCTIONS
(195IO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2013
English
Page 12
SAND FILTER PUMP HOSE CONNECTION SETUP
The 6-way valve has three hose connection ports.
1. Connect one hose (12) end to the pre-filter inlet and the other end of the hose to the lower
plunger valve with the strainer. Ensure the hose nuts are securely tightened.
2. Connect the second hose (12) between the 6-way valve water outlet and the upper plunger
valve with the inlet-nozzle. Ensure the hose nuts are securely tighten.
3. The third hose connection port (drain/waste outlet) on the 6-way valve shall be directed to
a proper draining receptacle using a hose or pipe (not provided). Remove the drain cap
before attaching the drain/waste hose or pipe.
4. The sand filter pump is now ready to filter the pool.
WARNING
• Keepthisproductmorethan2mawayfromthepool.
• Keepthisproductmorethan3.5mawayfromthepool(forFranceonly).
• Keeptheplugofthisproductmorethan3.5mawayfromthepool.
• Positionthisproductawayfromthepool,soastopreventchildrenfrom
climbing on it and accessing the pool.
(ILLUSTRATION NOT TO SCALE)
>3.5M
>2M
6-WAY VALVE
WATER
INLET
WATER
OUTLET
MOTOR
MOTOR
WATER
OUTLET
PRE-
FILTER
WATER INLET
WATER LEVEL
ADJUSTABLE
POOL INLET
NOZZLE
THREADED
STRAINER
CONNECTOR
OUTSIDE
LINER WALL
PLUNGER
VALVE
POWER
CORD
L-SHAPE
O-RING
L-SHAPE
O-RING
TO
DRAIN
According to the International Standard, IEC 60364-7-702, on electrical installation of swimming
pools and other basins equipments, the following installation distances must be respected:
• The filter pump must be position more than 2m away from the pool walls.
• The power cord plug to the 220-240 volt electrical power source of the filter pump must
be position more than 3.5 m away from the pool walls.
Check your local authorities to determine the appropriate standard and requirements for
“electrical installation of swimming pools and basins equipments”. The following table is for
reference only:
International
France
Germany
The Netherlands
Country/Region Standard Number
IEC 60364-7-702
NF C 15-100-7-702
DIN VDE 0100-702
NEN 1010-702
AIR RELEASE VALVE

195A
SAVE THESE INSTRUCTIONS
(195IO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2013
English
Page 13
SAND FILTER PUMP HOSE CONNECTION SETUP (continued)
For INTEX pool size 16' and below:
1. In a counter-clockwise motion unscrew plunger valve union from the threaded strainer
connector (26). Be careful not to lose the step rubber washer (23).
2. Grasp the plunger valve assembly. Make sure the step washer (23) is in place. Connect
adaptor B (28) to plunger valve union.
3. Remove wall plug and then insert the strainer (29 & 31) into the lower position of protruding
hose connection, and the nozzle (29 & 30) into the upper position of protruding hose
connection. Adaptor B (28) fits over the strainer connection (29) inserted into the
connection. Tighten securely.
4. Remove the drain cap (3) before attaching the drain/waste hose or pipe.
For NON-INTEX pool:
Connect the hose (12) to the pool inlet/outlet connection with a large hose clamp. Tighten
securely. Remove the drain cap (3) before attaching the drain/waste hose or pipe.
POOL
LARGE HOSE
CLAMP
12
3
POOL
29 & 30
29 & 31
3

195A
SAVE THESE INSTRUCTIONS
(195IO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2013
English
Page 14
OPERATING INSTRUCTIONS
Valve Position Function Water Flow Direction
FILTER
(see drawing 23)
Normal filtration and regular vacuuming
of pool
From pump through filter media to
pool
BACKWASH
(see drawing 24)
Reverses water flow to clean filter
media
From pump through filter media to
valve waste/drain outlet
RINSE
(see drawing 25)
For initial startup cleaning of the sand, and
leveling the sand bed after backwashing
From pump through filter media to
valve waste/drain outlet
WASTE
(see drawing 26)
For vacuuming directly to waste,
lowering pool level or to drain the pool
From pump to valve waste/drain
outlet bypassing the filter media
RECIRCULATE
(see drawing 27)
For circulating water back to pool
without going through the filter media
From pump through valve to pool
bypassing the filter media
CLOSED
(see drawing 28)
Shuts off all flow to filter and pool
“Do not use this setting with pump running”
6-way valve positions and function:
• Riskofelectricshock.Connectthisproductonlytoagroundingtype
receptacle protected by a ground-fault circuit interrupter (GFCI) or
residual current device (RCD). Contact a qualified electrician if you
cannot verify that the receptacle is protected by a GFCI/RCD. Use a
qualified electrician to install the GFCI/RCD, which has a maximum rate
of 30mA. Do not use a portable residual current device (PRCD).
•To reduce the risk of electric shock, do not use extension cords, timers,
plug adaptors or converter plugs to connect unit to electric supply;
provide a properly located outlet.
• Do not attempt to plug in or unplug this product while standing in water
or when your hands are wet.
• Neveroperatethisproductabovethemaximumworkingpressurestated
on the filter tank.
• Alwaysswitchoffpumpbeforechangingthe6-wayvalveposition.
• Operatingthisproductwithoutwaterflowingthroughthesystemcan
cause a build up of hazardous pressure which can result in an explosive
situation, serious injury, property damage or death.
• Nevertestthispumpwithcompressedair.Neveroperatethesystem
with water temperature above 35° C (95° F).
WARNING
RETLIF
ESNI
R
ETALUCRICER
ES
O
LC
ETSAW
ESN
IR
ETALUCRICER
HSAWKCAB
ESOLC
ETSAW
RETLIF
ESNIR
ETALUCRICER
HSAWKCAB
ETSAW
R
ETLIF
ESNIR
ER
HSAWKCAB
ESOLC
ETSAW
RETLIF
ESNIR
ETALUCRICER
HSAWKCAB
ESOLC
R
ETLIF
ETALUCRICER
HSAWKCAB
ESOLC
ETSAW
B
23
RETLIF
ESNIR
ETALUCRICER
ES
O
LC
ETSAW
ESN
IR
ETALUCRICER
HSAWKCAB
ESOLC
ETSAW
RETLIF
ESNIR
ETALUCRICER
HSAWKCAB
ETSAW
R
ETLIF
ESNIR
ER
HSAWKCAB
ESOLC
ETSAW
RETLIF
ESNIR
ETALUCRICER
HSAWKCAB
ESOLC
R
ETLIF
ETALUCRICER
HSAWKCAB
ESOLC
ETSAW
B
24
RETLIF
ESNIR
ETALUCRICER
ES
O
LC
ETSAW
ESN
IR
ETALUCRICER
HSAWKCAB
ESOLC
ETSAW
RETLIF
ESNIR
ETALUCRICER
HSAWKCAB
ETSAW
R
ETLIF
ESNIR
ER
HSAWKCAB
ESOLC
ETSAW
RETLIF
ESNIR
ETALUCRICER
HSAWKCAB
ESOLC
R
ETLIF
ETALUCRICER
HSAWKCAB
ESOLC
ETSAW
B
25

195A
SAVE THESE INSTRUCTIONS
(195IO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2013
English
Page 15
Initial startup and operation:
Before operating, be sure that:
• All the hoses have been connected and tightened securely, and correct amount of filter sand
have been loaded.
• The entire system is connected to a grounding type receptacle protected by a ground-fault
circuit interrupter (GFCI) or residual current device (RCD).
OPERATING INSTRUCTIONS (continued)
CAUTION
The filter control valve has a closed position. The pump should never be
on when the valve is in the closed position. If the pump is operated with
the valve closed, explosive situation could exist.
1. Turn both plunger valve handles fully counter-clockwise until they stop. This opens the valves
to allow water to flow into the sand filter pump. With water flowing into sand filter pump, the
water pressure will allow the air trapped inside to escape from the air release valves (19).
When all the air has escaped water will flow out of the valves (19). When this occurs gently
finger tighten the valves (19) in a clockwise direction.
IMPORTANT: To prevent air lock, open the lower plunger valve (connected inlet hose)
first and then the upper plunger valve (connected outlet hose). Open the air release
valves, wait until water starts to flow out of the air release valves, close air release
valves.
2. Ensure the drain/waste outlet on the 6-way valve is not covered and directed to a proper
draining receptacle.
3. Ensure the pump is off, depress the 6-way valve and turn
it to the “BACKWASH” position (see drawings 24 & 29).
IMPORTANT: To prevent damage to the 6-way valve,
always depress the valve handle before turning.
Always switch off pump before changing the 6-way
valve position.
4. Switch on the pump (see drawing 30). Water is circulating
backward through the sand media and to waste/drain outlet.
Backwash until a clear flow of water is observed in the
waste/drain outlet or through the drain sediment window.
NOTE: The initial backwash of the filter is recommended to
remove any impurities or fine sand particles in the sand
media.
RETLIF
ESNIR
ETALUCRICER
ES
O
LC
ETSAW
ESN
IR
ETALUCRICER
HSAWKCAB
ESOLC
ETSAW
RETLIF
ESNIR
ETALUCRICER
HSAWKCAB
ETSAW
R
ETLIF
ESNIR
ER
HSAWKCAB
ESOLC
ETSAW
RETLIF
ESNIR
ETALUCRICER
HSAWKCAB
ESOLC
R
ETLIF
ETALUCRICER
HSAWKCAB
ESOLC
ETSAW
B
26
RETLIF
ESNIR
ETALUCRICER
ES
O
LC
ETSAW
ESN
IR
ETALUCRICER
HSAWKCAB
ESOLC
ETSAW
RETLIF
ESNIR
ETALUCRICER
HSAWKCAB
ETSAW
R
ETLIF
ESNIR
ER
HSAWKCAB
ESOLC
ETSAW
RETLIF
ESNIR
ETALUCRICER
HSAWKCAB
ESOLC
R
ETLIF
ETALUCRICER
HSAWKCAB
ESOLC
ETSAW
B
27
RETLIF
ESNIR
ETALUCRICER
ES
O
LC
ETSAW
ESN
IR
ETALUCRICER
HSAWKCAB
ESOLC
ETSAW
RETLIF
ESNIR
ETALUCRICER
HSAWKCAB
ETSAW
R
ETLIF
ESNIR
ER
HSAWKCAB
ESOLC
ETSAW
RETLIF
ESNIR
ETALUCRICER
HSAWKCAB
ESOLC
R
ETLIF
ETALUCRICER
HSAWKCAB
ESOLC
ETSAW
B
28
29
1
2
30
TIMER OFF ON

195A
SAVE THESE INSTRUCTIONS
(195IO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2013
English
Page 16
OPERATING INSTRUCTIONS (continued)
5. Switch off the pump, change the 6-way valve to “RINSE” position (see drawing 25).
6. Switch on the pump and run the pump for about one minute to level out the sand bed after
backwashing the sand media.
7. Switch off the pump, change the 6-way valve to “FILTER” position (see drawing 23).
8. Switch on the pump. The system is now operating in the normal filtering mode. Run the pump
until the desired pool water clearance is obtained and no more than 12 hours per day.
9. Record the initial pressure gauge reading when the filter media is clean.
NOTE: During initial setup of the system, it may be necessary to backwash frequently due to
unusual heavy dirt present in the water and sand. After that, as the filter removes dirt and
impurities from the pool water, the accumulated dirt in the sand media will cause the pressure
to rise and the flow to diminish. If there is no vacuuming device attached to the system and
the pressure gauge reading is in the yellow zone it is time to backwash the sand media, see
“BACKWASH” under “initial startup and operation” section.
Vacuuming device (i.e. Intex auto pool cleaner) attached to the system may also cause the
flow to diminish and the pressure to rise. Remove any vacuuming device from the system and
check if the pressure gauge reading has dropped from the yellow zone to the green zone.
Operating the system under “TIMER” mode or manually:
To operate the sand filter pump in “FILTER” mode under “TIMER” control:
A. Set the timer dial to the desired operating hours. See operation time table
(see drawing 31).
B. Turn on the pump by pressing the switch to “ ” position, the sand filter pump is now
filtering the water and will stop after the operating hours are completed. The built-in timer
will now operate for the number of hours selected at the same time each day.
C. Operating hours can be re-adjusted if necessary. Follow step A – B.
To operate the sand filter pump manually (without the “TIMER” mode):
A. Turn on the pump by pressing the switch to “-” position, the sand filter pump is now
filtering the water.
B. To turn off the pump, press the switch to “O” position.
IMPORTANT
If you continue to experience difficulty, please contact our Consumer Service
Department for assistance. See separate “Authorized Service Centers” sheet.
31
TIMER OFF ON
TIMER DIAL
(HOURS)

195A
SAVE THESE INSTRUCTIONS
(195IO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2013
English
Page 17
INTEX POOLS OPERATING TIME TABLE (WITHOUT INTEX SALTWATER SYSTEM)
This table shows the required operating time for average use of the sand filter pump with above
ground pools.
If the system is attached to an “Intex Saltwater System” unit, the filter pump running time
should be longer than the required operating time of the Intex Saltwater System unit.
Pool Size
Water Capacity (Calculated at
90% for Frame Pool and 80% for
Easy Set & Oval Pool)
Sand filter pump operating
time (For one cycle) / (Hours)
(Gals) (Liters) SF80220 SF70220 SF60220
INTEX ABOVE GROUND POOLS (AGP’s)
EASY SET®
POOL
457cmx84cm(15'x33") 2587 9792 2
457cmx91cm(15'x36") 2822 10681 2
457cmx107cm(15'x42") 3284 12430 2
457cmx122cm(15'x48") 3736 14141 4
488cmx107cm(16'x42") 3754 14209 4
488cmx122cm(16'x48") 4273 16173 4
488cmx132cm(16'x52") 4614 17464 4
549cmx107cm(18'x42") 4786 18115 4 2 2
549cmx122cm(18'x48") 5455 20647 4 2 2
ROUND
METAL
FRAME POOL
457cmx91cm(15'x36") 3282 12422 2
457cmx107cm(15'x42") 3861 14614 4
457cmx122cm(15'x48") 4440 16805 4
488cmx122cm(16'x48") 5061 19156 4
549cmx122cm(18'x48") 6423 24311 6 4 4
640cmx132cm(21'x52") 9533 36082 6 4 4
732cmx132cm(24'x52") 12481 47241 8 6 6
ULTRA FRAME
POOL
488cmx122cm(16'x48") 5061 19156 4
549cmx122cm(18'x48") 6423 24311 4 4 4
549cmx132cm(18'x52") 6981 26423 6 4 4
610cmx122cm(20'x48") 7947 30079 6 4 4
671cmx132cm(22'x52") 10472 39637 8 4 4
732cmx132cm(24'x52") 12481 47241 8 6 6
792cmx132cm(26'x52") 14667 55515 12 8 8
SEQUOIA SPIRIT®
POOL SET
478cmx124cm(15'8"x49") 4440 16805 4
508cmx124cm(16'8"x49") 5061 19156 4 2 2
569cmx135cm(18'8"x53") 6981 26423 6 4 4
OVAL FRAME
POOL
305cmx549cmx107cm(10'x18'x42") 2885 10920 2
366cmx610cmx122cm(12'x20'x48") 4393 16628 4 2 2
RECT. ULTRA
FRAME POOL
274cmx457cmx122cm(9'x15'x48") 3484 13187 4 2 2
274cmx549cmx132cm(9'x18'x52") 4545 17203 4 2 2
305cmx610cmx132cm(10'x20'x52") 5835 22085 4 4 2
366cmx732cmx132cm(12'x24'x52") 8403 31805 6 4 4
488cmx975cmx132cm(16'x32'x52") 14364 54368 12 86
NOTE: The “12” hours timer setting position has an additional 20 minutes over the actual
setting.

195A
SAVE THESE INSTRUCTIONS
(195IO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2013
English
Page 18
NON-INTEX POOLS OPERATING TIME TABLE
Water Capacity Sand filter pump operating time (For one cycle) / (Hours)
(Gals) (Liters) SF80220 SF70220 SF60220
3000 11355 2
4000 15140 4 2 2
4440 16805 422
5000 18925 422
6000 22710 4 4 2
7000 26495 6 4 4
8000 30280 6 4 4
9000 34065 6 4 4
10000 37850 8 6 4
11000 41635 86 4
12000 45420 86 6
13000 49205 12 6 6
14000 52990 12 86
15000 56775 12 86
16000 60560 12 8 8
17000 64345 12 8 8
18000 68130 12 12 8
19000 71915 12 12 8
20000 75700 12 8
21000 79485 12 12
22000 83270 12 12
23000 87055 12 12
24000 90840 12 12
25000 94625 12 12
26000 98410 12 12
This table shows the required operating time for average use of the sand filter pump with above
ground pools.

195A
SAVE THESE INSTRUCTIONS
(195IO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2013
English
Page 19
MOTOR PRE-FILTER CLEANING AND MAINTENANCE
1. Make sure the filter pump is switched off, then disconnect the power cord from the electrical
outlet.
2. Turn both plunger valve handles fully clockwise until they stop. This closes the valve, prevents
the water from flowing out of the pool.
3. Release the pressure first by opening the
sediment release valve (19) located
on the lower side of the pre-filter housing
(see drawing 32).
4. In a counter-clockwise motion unscrew the
leaf trap cover (14), then remove the
basket (16) and leaf trap o-ring (15) from the
pre-filter housing (see drawing 33).
5. Empty and flush the basket using a garden hose, may use a plastic brush to remove deposits
from the basket. Do not use metal brush.
6. Clean and rinse the inside of the pre-filter housing and the leaf trap O-ring with a garden
hose.
7. Reinstall the leaf trap O-ring, basket and leaf trap cover to the pre-filter housing.
8. Close the sediment release valve (19).
1
2
32
33
19
14
15
16
35

195A
SAVE THESE INSTRUCTIONS
(195IO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2013
English
Page 20
1. Before emptying your pool for long term storage, or relocation, be sure the water is directed towards
an acceptable drain water receptacle away from the house. Check local regulations for specific
directions regarding disposal of swimming pool water.
2. Switch off the unit, and disconnect power cord from electrical outlet.
3. When the pool is empty, disconnect all hoses from pump and plunger valves and remove the strainers/
plunger valves from the pool wall.
4. In a counter clockwise motion unscrew the drain valve cap (9) from the drain valve to thoroughly drain
the tank. The drain valve is located at the bottom of the filter tank.
5. Disassemble the pump motor from the tank base.
6. Leave sand filter pump pieces and hoses outside to thoroughly air dry.
7. Coat the following o-rings and washers with petroleum jelly for long term storage:
• L-shape o-ring (11 & 18).
• Pump hose O-rings (22).
• Strainer valve assembly step washers (23).
• Flat strainer rubber washers (25).
8. Depress the 6-way valve handle and rotate so as to set the pointer on the valve top “N” position. This
allows the water to drain from the valve. Leave the 6-way valve in this inactive position.
9. It is best to place all dry pieces and pump motor in the original packaging for storage. To avoid condensation
or corrosion problem, do not cover or wrap pump motor with plastic bags.
10. Store the pump motor and accessories in a dry place. The storage's temperature should be controlled,
between 0 degrees Celsius (32 degrees Fahrenheit) and 40 degrees Celsius (104 degrees Fahrenheit).
POOL CARE & CHEMICALS
• All pools require care to keep the water clear and hygienically clean. With proper chemical control, your
filter will help attain this objective. Consult your pool supply dealer for instructions regarding the proper
use of chlorine, algaecide and other chemical agents required for sparkling clear water.
• Keep pool chemicals away from children.
• Do not replenish chemicals in pool while pool is occupied. Skin or eye irritations could occur.
• Daily pH checking and chemical treatment of the water is very important and cannot be
overemphasized. Chlorine, algaecide and maintenance of proper pH levels are required when filling the
pool as well as during the season. Consult your local swimming pool supply store for instructions.
• The season's first filling of the pool may have brackish water requiring extra water additives and extra
filtering time. Do not allow swimming in pool until the pH level is balanced. Consult your local swimming
pool supply store for instructions.
• Chlorinated water may damage lawns, gardens or shrubbery as children play in the pool and splash
water outside the pool. Lawn areas underneath the pool liner will be destroyed. Note that some types
of grass may grow through the liner.
• Filter run time depends on pool size, weather and usage level. Experiment with various run times so
as to produce clean clear water.
LONG TERM STORAGE & WINTERIZATION
CAUTION
Concentrated chlorine solutions may damage the pool liner. Always follow the
chemical manufacturer’s directions, and the health and hazard warnings.
CAUTION
Allowing the water to freeze will damage the sand filter and void the warranty.
If anti-freeze solution is needed, use only propylene glycol. Propylene glycol is
non-toxic and will not damage plastic system components; other anti-freezes
are highly toxic and may damage plastic components in the system.
