Invacare 6417 Assembly instructions

Part No 1143201 1Deluxe Overbed Table
For more information regarding Invacare products, parts, and services, please visit www.invacare.com
Deluxe Overbed Table
Model Nos. 6417, 6418
DEALER:TheseinstructionsMUSTbegiventotheuserofthisproduct.
NOTE:CheckALLpartsforshippingdamage.Ifshippingdamageisnoted,DONOTuse.ContactCarrier/Dealerforfurther
instruction.
Safety Summary
Toensurethesafeandproperinstallationofthedeluxeoverbedtable,theseinstructionsMUSTbefollowed:
 WARNING
DO NOT use this product or any available optional equipment without first completely reading
and understanding these instructions and any additional instructional material such as owner’s
manuals, service manuals or instruction sheets supplied with this product or optional equipment.
If you are unable to understand the warnings, cautions or instructions, contact a healthcare
professional, dealer or technical personnel before attempting to use this equipment - otherwise,
injury or damage may occur.
ALWAYS check the overbed table for proper tightness before using.
The deluxe overbed table has a weight limitation of 25 lbs.
 ACCESSORIES WARNING
Invacare products are specifically designed and manufactured for use in conjunction with
Invacare accessories. Accessories designed by other manufacturers have not been tested by
Invacare and are not recommended for use with Invacare products.
 INSTALLATION WARNING
After any adjustments, repair or service and before use, make sure that all attaching component
parts are secure.
Assembling/Disassembling
Model 6417
NOTE:Forthisprocedure,refertoFIGURE 1onpage2.
1. Placetabletoponfloorwithmountingholesfacingup.
2. Securethemasttothetabletopwithsixmounting
screws.Tightensecurely.
3. Securethebasetothemastwiththetwobolts,washers,
andinserts.Tightensecurely.
4. Installthefourcastersintothefourholesprovidedin
thebase.
5. Placetheoverbedtabletotheuprightposition.
6. Todisassemble,reverseSTEPS1‐5.
Model 6418
NOTE:Forthisprocedure,refertoFIGURE 1onpage2.
1. Placethetilttabletoponthefloorwithsupporting
bracketfacingup.
2. Securethemasttothesupportingbracketwiththebolt,
washer,andnut.Tightensecurely.
3. Securethebasetothemastwiththetwobolts,washers,
andinserts.Tightensecurely.
4. Installthefourcastersintothefourholesprovidedin
thebase.
5. Placetheoverbedtabletotheuprightposition.
6. Todisassemble,reverseSTEPS1‐5
Assembly, Installation and Operating Instructions
SAVE THESE INSTRUCTIONS

Deluxe Overbed Table 2Part No 1143201
FIGURE 1 Assembling/Disassembling
Operating the Overbed Table
NOTE:Forthisprocedure,refertoFIGURE 2onpage3.
Adjusting Table Height
 WARNING
ALWAYS check to ensure latching mechanism/height adjustment lever, located underneath the
table top, is properly engaged prior to use.
NOTE:Atransportscrewisusedtosecurethetabletoptothemastinthelowestpositionduringtransportation.Thetransportscrew
islocatedonthemastjustbelowthetabletop.
1. Removethetransportscrewandsaveforfutureuse.RefertoTransportingonpage 3.
2. Squeezethelatchingmechanism/heightadjustmentleveruptowardthetabletop.
3. Adjustthetabletoptothedesiredheight.
NOTE:WhenperformingSTEP4,becarefulnottopresstoohardotherwisethetabletopwillrunthroughmultiplelatchingpointsbefore
lockinginplace.
4. Lightlypressdownonthetabletopuntiltabletopislockedinplace.An“audible”clickwillbeheardwhenlatching
mechanismsecurestabletopinplace.
Adjusting Table Angle
NOTE:AdjustingtableangleisavailableonModel6418only.
1. Squeezetheangleadjustmentleveruptowardthetabletop.
2. Tiltthetabletoptothedesiredangle.
3. Releaseangleadjustablelevertolockinplace.
Mounting
Screws
Bolts
Washers
Inserts
Casters
Casters
Table Top
Base
Tilt Table Top
Bolts
Washers
Inserts
Casters
Casters
Bolt Washer
Nut
Supporting
Bracket
Mast Base
Mast
Mounting
Holes
Model 6417
Model 6418

Part No 1143201 3Deluxe Overbed Table
FIGURE 2 Adjusting Table Height - Adjusting Table Angle
Transporting
CAUTION
Before taking the overbed table apart, adjust the table top to the lowest position and replace the
transport screw so the mast is locked in place before being packed and shipped otherwise dam-
age may result.
1. Adjusttabletolowestheightposition.RefertoAdjustingTableHeightonpage 2.
2. Installthetransportscrewtolockmastinplace(FIGURE 2).
3. Removethetabletopfromthemast.RefertoAssembling/Disassemblingonpage 1.
Transport
Screw
Latching Mechanism/
Height Adjustable
Lever
Angle Adjustment Lever
(Model 6418 only)
NOTE:OnlyModel6418isshown.

LIMITED WARRANTY
PLEASE NOTE: THE WARRANTY BELOW HAS BEEN DRAFTED TO COMPLY WITH FEDERAL LAW
APPLICABLE TO PRODUCTS MANUFACTURED AFTER JULY 4, 1975.
This warranty is extended only to the original purchaser/user of our products.
This warranty gives you specific legal rights and you may also have other legal rights which vary from state to
state.
Invacare warrants its product to be free from defects in materials and workmanship for one year for the original
purchaser. If within such warranty period any such product shall be proven to be defective, such product shall be
repaired or replaced, at Invacare's option with refurbished or new parts. This warranty does not include any labor
or shipping charges incurred in replacement part installation or repair of any such product. Product repairs shall
not extend this warranty - coverage for repaired product shall end when this limited warranty terminates.
Invacare's sole obligation and your exclusive remedy under this warranty shall be limited to such repair and/or
replacement.
For warranty service, please contact the dealer from whom you purchased your Invacare product. In the event
you do not receive satisfactory warranty service, please write directly to Invacare at the address on the back page.
Provide dealer's name, address, model number, date of purchase, indicate nature of the defect and, if the product
is serialized, indicate the serial number.
Invacare Corporation will issue a return authorization. The defective unit or parts must be returned for warranty
inspection using the serial number, when applicable, as identification within thirty days of return authorization
date. DO NOT return products to our factory without our prior consent. C.O.D. shipments will be refused; please
prepay shipping charges.
LIMITATIONS AND EXCLUSIONS: THE WARRANTY SHALL NOT APPLY TO PROBLEMS ARISING FROM
NORMAL WEAR OR FAILURE TO ADHERE TO THE ENCLOSED INSTRUCTIONS. IN ADDITION, THE
FOREGOING WARRANTY SHALL NOT APPLY TO SERIAL NUMBERED PRODUCTS IF THE SERIAL
NUMBER HAS BEEN REMOVED OR DEFACED; PRODUCTS SUBJECTED TO NEGLIGENCE, ACCIDENT,
IMPROPER OPERATION, MAINTENANCE OR STORAGE; OR PRODUCTS MODIFIED WITHOUT
INVACARE'S EXPRESS WRITTEN CONSENT INCLUDING, BUT NOT LIMITED TO: MODIFICATION
THROUGH THE USE OF UNAUTHORIZED PARTS OR ATTACHMENTS: PRODUCTS DAMAGED BY
REASON OF REPAIRS MADE TO ANY COMPONENT WITHOUT THE SPECIFIC CONSENT OF INVACARE;
PRODUCTS DAMAGED BY CIRCUMSTANCES BEYOND INVACARE'S CONTROL; PRODUCTS REPAIRED
BY ANYONE OTHER THAN AN INVACARE DEALER, SUCH EVALUATION SHALL BE SOLELY
DETERMINED BY INVACARE.
THE FOREGOING WARRANTY IS EXCLUSIVE AND IN LIEU OF ANY OTHER EXPRESS WARRANTIES, IF
ANY, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE.
IT SHALL NOT EXTEND BEYOND THE DURATION OF THE EXPRESSED WARRANTY PROVIDED HEREIN
AND THE REMEDY FOR VIOLATIONS OF ANY IMPLIED WARRANTY SHALL BE LIMITED TO REPAIR OR
REPLACEMENT OF THE DEFECTIVE PRODUCT PURSUANT TO THE TERMS CONTAINED HEREIN.
INVACARE SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES
WHATSOEVER.
THIS WARRANTY SHALL BE EXTENDED TO COMPLY WITH STATE/PROVINCIAL LAWS AND
REQUIREMENTS.
