Invacare 6418 Assembly instructions

Assembly, Installation and Operating Instructions
NOTE: Check ALL parts for shipping damage. In case of
shipping damage, DO NOT use. Contact Carrier/Dea er
for further instruction.
SAFETY SUMMARY
The following recommendations are made for the safe
assembly of the Tilt Top Overbed Table:
WARNING
DO NOT assemble or use this equipment without
first reading and understanding this instruction
sheet. If you are unable to understand the Warn-
ings, Cautions or Instructions, contact a health-
care professional, dealer or technical personnel
before attempting to install this equipment - oth-
erwise, injury or damage may occur.
After assembly and BEFORE use, ensure ALL at-
taching hardware is securely tightened.
Do NOT remove shipping screw and shipping
strap from column assembly prior to assembly.
The column assembly is spring loaded and may
causeinjury.
ASSEMBLING THE TILT TOP
OVERBED TABLE (FIGURE 1)
NOTE: Before assemb y, refer to WARNINGS in the
SAFETY SUMMARY of this instruction sheet.
1. Lay the tilt top table assembly on a flat surface as
shown in FIGURE 1.
2. Position column assembly onto top bracket.
. Align holes in the column assembly with holes in the
top bracket.
4. Secure column assembly to top bracket and tilt top
table assembly with shoulder bolt and locknut. Se-
curely tighten.
5. Place the base assembly upside down on a flat sur-
face with the top bracket facing UP.
6. Install one (1) caster, by pushing the stem portion
into the base frame, until it snaps into place.
7. Repeat STEP 6 for remaining three ( ) casters.
8. Position bolt plate onto base frame.
9. Secure the bolt plate and base frame to the column
assembly using the two (2) bolts. Hand tighten.
TILT TOP OVERBED TABLE
MODEL NO. 6418
ADJUSTING/TILTING THE TILT
TOP OVERBED TABLE (FIGURE 2)
NOTE: The tab e MUST be in the upright position BE-
FORE adjusting/ti ting.
Adjusting
1. Press DOWN on the lower portion of the release
lever and adjust the Tilt Top Overbed Table UP
or DOWN.
2. Release the lever when at the desired position.
FIGURE 1 - ASSEMBLING THE TILT TOP
OVERBED TABLE
Bo ts
(STEPS 9,11) Bo t P ate
(STEPS 8,9)
Caster
(STEPS 6,7)
Base Frame
(STEPS 6,8,9)
Co umn
Assemb y
(STEPS
2,3,4,12)
Shou der Bo t
(STEP 4)
Shipping
Screw and
Strap
(STEP 12)
Top Bracket
(STEPS 2,3,4)
Ti t Top Tab e
Assemb y
(STEPS 1,4)
Locknut
(STEP 4)
10. Position the table on its side.
NOTE: This wi prevent excess stress on the bo ts when
securing.
11. Securely tighten the two (2) bolts in STEP 9.
12. Remove the shipping screw and shipping strap from
the column assembly.
1 . Adjust or tilt the overbed table, if necessary. Refer to
ADJUSTING/TILTING THE TILT TOP OVERBED
TABLE in this instruction sheet.

F rm N . 98-128 Part N . 1079418 Printed in the USA
INVACARE CORPORATION l ONE INVACARE WAYl Elyria, Ohi 44036
Cust mer Service [phone] l Technical Supp rt [phone]
LIMITED WARRANTY
PLEASE NOTE: THE WARRANTY BELOW HAS BEEN DRAFTED TO COMPLY WITH FEDERAL LAW APPLICABLE
TO PRODUCTS MANUFACTURED AFTER JULY 4, 1975.
This warranty is extended only to the original purchaser/user of our products.
This warranty gives you specific legal rights and you may also have other legal rights which vary from
state to state.
Invacare warrants its product to be free from defects in materials and workmanship for three (3) years
for the original purchaser. If within such warranty period any such product shall be proven to be defec-
tive, such product shall be repaired or replaced, at Invacare's option. This warranty does not include
any labor or shipping charges incurred in replacement part installation or repair of any such product.
Invacare'ssole obligationandyour exclusiveremedyunder thiswarrantyshall belimitedto suchrepair
and/or replacement.
For warranty service, please contact the dealer from whom you purchased your Invacare product. In
the event you do not receive satisfactory warranty service, please write directly to Invacare at the
address below. Provide dealer's name, address, model number, date of purchase, indicate nature of
the defect and, if the product is serialized, indicate the serial number.
Invacare Corporation will issue a return authorization. The defective unit or parts must be returned for
warranty inspection using the serial number, when applicable, as identification within thirty (30) days of
return authorization date. DO NOT return products to our factory without our prior consent. C.O.D.
shipments will be refused; please prepay shipping charges.
LIMITATIONS AND EXCLUSIONS: THE WARRANTY SHALL NOT APPLY TO PROBLEMS ARISING FROM NOR-
MAL WEAR OR FAILURE TO ADHERE TO THE ENCLOSED INSTRUCTIONS. IN ADDITION, THE FOREGOING
WARRANTY SHALL NOT APPLY TO SERIAL NUMBERED PRODUCTS IF THE SERIAL NUMBER HAS BEEN RE-
MOVEDORDEFACED;PRODUCTSSUBJECTEDTONEGLIGENCE,ACCIDENT,IMPROPEROPERATION,MAIN-
TENANCE OR STORAGE; OR PRODUCTS MODIFIED WITHOUT INVACARE'S EXPRESS WRITTEN CONSENT
INCLUDING, BUT NOT LIMITED TO: MODIFICATION THROUGH THE USE OF UNAUTHORIZED PARTS OR AT-
TACHMENTS: PRODUCTS DAMAGED BY REASON OF REPAIRS MADE TO ANY COMPONENT WITHOUT THE
SPECIFIC CONSENT OF INVACARE; PRODUCTS DAMAGED BY CIRCUMSTANCES BEYOND INVACARE'S
CONTROL; PRODUCTS REPAIRED BY ANYONE OTHER THAN AN AUTHORIZED INVACARE DEALER, SUCH
EVALUATION SHALL BE SOLELY DETERMINED BY INVACARE.
THE FOREGOING WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS WARRANTIES, IF ANY,
INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
IT SHALL NOT EXTEND BEYOND THE DURATION OF THE EXPRESSED WARRANTY PROVIDED HEREIN AND THE
REMEDY FOR VIOLATIONS OF ANY IMPLIED WARRANTY SHALL BE LIMITED TO REPAIR OR REPLACEMENT
OF THE DEFECTIVE PRODUCT PURSUANT TO THE TERMS CONTAINED HEREIN. INVACARE SHALL NOT BE
LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES WHATSOEVER.
THIS WARRANTY SHALL BE EXTENDED TO COMPLY WITH STATE/PROVINCIAL LAWS AND REQUIREMENTS.
FIGURE 2 - ADJUSTING/TILTING THE TILT TOP
OVERBED TABLE
Ti t Re ease
Lever
Adjusting
Re ease Lever
Tilting
1. Pull UP on the tilt release lever to activate.
2. Tilt the table to the desired angle and release the
lever.
