Invacare Sonnet Combi User manual

Invacare® Sonnet Combi
Invacare® Sonnet Combi
Manual GB
Invacare EC-Høng A/S
Ident. no.: 913988
Version 02 09.2002

This bedside table is developed for the home care sector and for hospitals. The bedside table contains a number of
functions and qualities, which are specially designed for these health care sections.
Position the additional plate by lifting the plate and lead it to the wished
height. When the additional plate is lowered more than 45º, the plate will
lock in the chosen position. Lower the plate to horizontal. See fig 1.
To lower the additional plate to bottom position: Lift the plate and let it
slip down towards the bottom position.
The bedside table can be operated and used from either the right or the
left side of the bed, depending of what is most convenient.
It is possible to mount the additional plate on both sides of the bedside
table.
When it is necessary to change side, press the sliding bolt with one hand
and pull the additional plate up vertically with the other, until the bracket is
released. The sliding bolt is placed at the top of the back. See fig 2.
Mount the additional plate on the other side of the bedside table, by
pressing the sliding bolt, and then guide the bracket to the bottom position.
When positioning the additional plate: Lift the plate and lead it to the
wished height. Then lower the plate to horizontal.
As soon as the additional plate is lowered to horizontal, is the height of the
plate locked. See fig 3.
Manual for Invacare®Sonnet Combi
Fig. 1
Fig. 2
Fig. 3
2

To ease the cleaning in cases with heavy smudge, is it possible to demount
the drawer and clean it in a rinsing room:
Pull out the drawer until it stops, then lift it up and pull out until the
drawer is released. Take the insert out. See fig 4.
After cleaning the insert and the drawer, remount the insert and push/lift
the drawer back in position in the bedside table.
Use only regular household detergents. Use a sponge or a soft brush to
wash the bedside table.
Never use acids, alkalines or solvents such as acetone or cellulose thinner.
The demountable plastic parts can be cleaned under rinsing water and in an
automatic dishwasher.
The bedside table does not tolerate cleaning in water-jet based cleaning
equipment.
None of the moving parts of the bedside table requires lubricating; they
only have to be clean in order to function satisfactorily.
The Invacare®Sonnet Combi must be stored in a room with a humidity of
10 – 80% and with temperature of 0 – 50º.
The storing room must be frost-proof.
During transport must the additional plate be placed in bottom position.
The closet door and drawers must be closed.
Manual for Invacare®Sonnet Combi
Fig. 4
3
