Bed Rails
Parts Catalog Issued: Apr 9, 2012

The information contained in this document is subject to change without notice. This catalog contains
service parts for Form No. 92-048. If you have any questions regarding this catalog, please contact one
of our Customer Service Representatives.
For Customer Service Support Call:
1-800-333-6900
For Faxed In Orders Call:
1-800-678-4682 or
1-440-366-0709
For Technical Service Call:
1-800-832-4707
Literature Can Be Found at:
www.invacare.com or
1-800-828-6272
SYMBOL DEFINITION
Throughout this catalog you will notice letters to draw your attention to specific footnotes which are located at the
bottom of the page or below specified charts.
HARDWARE MEASUREMENTS
Examples: = Special Comments
= General information pertaining to that specific page
= No Longer Available
NOTE:
NLA
The measurements for the hardware will be listed as follows:
Screws, Bolts
Washers
Spacers
For your convenience, we have supplied an area for you to list your Invacare Representatives.
A,B,C etc.
Diameter X Thread Count/Pitch X Length
Inside Diameter X Outside Diameter X Thickness
Inside Diameter X Outside Diameter X Length
Name Phone Numbers
© 2012 Invacare Corporation, Elyria, Ohio. Invacare, the Medallion Design and Yes, you can. are registered trademarks and CareGuard is a Trademark of
the Invacare Corporation.
Parts Catalog Usage Guide
1
Form No. 92-048
To order call toll free 1-800-333-6900, or www.invacare.com

Bariatric Bed Rails - BAR6640IVC ........................................................................................... 28
Bed Rail Explanation Chart ...................................................................................................... 4
Crossbrace Assembly - 6626Y2 ............................................................................................... 11
Deluxe Quick Clip-On Bed Rail - 6658 ..................................................................................... 31
Deluxe Spring Loaded Bed Rails - 6628 & 6628-TSS .............................................................. 17
Deluxe Telescoping Bed Rail & Crossbrace Assembly - 6625/6625L ...................................... 12
Economy Bed Rail - 6640 ......................................................................................................... 27
Economy Telescoping Bed Rail - 6650 .................................................................................... 29
Half Length Assist Rail - 6632 .................................................................................................. 25
Half Length Bed Rails - 6630 ................................................................................................... 21
Packaging - Literature & Decals ............................................................................................... 6
Parts Catalog Usage Guide ...................................................................................................... 3
Standard Quick Clip-On Bed Rails - 6627 ................................................................................ 15
Standard Spring Loaded Bed Rails - 6629 ............................................................................... 19
Standard Telescope Bed Rails - 6623 ...................................................................................... 9
Telescoping Home Bed Rail - 6631 .......................................................................................... 23
TABLE of CONTENTS
Description
Page
Number
2
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 92-048

Parts Catalog Usage Guide
3
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 92-048

Bed Rail Explanation Chart
Standard Telescoping
Model Number Tubing Size Assembly or Channel
Style Length Bed Type
Homecare
Extended Care
47-74"Clamp with Wing Nut7/8"
6623 NLA
(Discontinued 1/03) Homecare
Extended Care
47-74"Quick Clip-On7/8"
6627 NLA
(Discontinued 2/96) Homecare
Extended Care
55"
Self-Adjusting
Spring-Loaded
7/8"6629
Deluxe Telescoping
Model Number Tubing Size Assembly or Channel
Style Length Bed Type
Homecare
Extended Care
47-74"Clamp with Wing Nut1"
6625 NLA
(Discontinued 2/03) Homecare
Extended Care
56"
Self-Adjusting
Spring-Loaded
1"6628
Homecare
Extended Care
with TSS Mattress
56"
Self-Adjusting
Spring-Loaded
1"6628TSS
Conventional Home
Single and
Double Beds (36"-69"
Wide)
37.5-56.5"
Round Tube Fits
Between Mattress and
Box Spring
7/8"6631
Homecare
Extended Care
47-74"Quick Clip-On1"
6658 NLA
(Discontinued 10/95)
Half Rail
Model Number Tubing Size Assembly or Channel
Style Length Bed Type
Homecare
Extended Care 2 sets
per bed
Recommended
32"
Dual Flat Channel with
Wing Nut Clamp
Assembly
1"6630
4
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 92-048

Bed Rail Explanation Chart
Economy Half Rail
Model Number Tubing Size Assembly or Channel
Style Length Bed Type
Homecare
Extended Care 2 sets
per bed
Recommended or
Bariatric
28.75"
Single Flat
Crossbrace with
Bolt-on Clamp
Assembly
1"6640
Crossbraces Only
Model Number Tubing Size Assembly or Channel
Style Length Bed Type
Homecare
Extended Care
47-74"Clamp with Wing Nut1"
6625L NLA
(Discontinued 9/94) Conventional Home
Single and
Dbl Beds 36 -69"
Wide
39-69"Round Tube Fits1"
6626Y2 NLA
(Discontinued 10/00)
Economy Telescoping
Model Number Tubing Size Assembly or Channel
Style Length Bed Type
Homecare/ Extended
Care
55"
Self-Adjusting
Spring-Loaded
7/8"6650
5
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 92-048

Packaging, Literature & Decals
Standard Telescoping
Model Number Carton Insert Literature
1013307-NLA
1007909
40131X0306623 NLA See Note(s) B
1016042
See Note(s) A
1023492-NLA
1007909
40131X0306627 NLA See Note(s) B
1016042
See Note(s) A
1049390
1007909
40131X0306629 See Note(s) B
1016042
See Note(s) A
A - Quantity - 1 each.
B - Quantity - 2 each
NOTE:
Note: When adjusting or replacing parts, please refer to your Owner's Manual for assistance.
Deluxe Telescoping
Model Number Carton Insert Literature
1016404
1007909
40131X0306625 NLA See Note(s) B
1016042
See Note(s) A
00077X079
1007909 40131X030
6628 See Note(s) E See Note(s) B
1016042
See Note(s) A
00077X079
1007909 40131X030
6628-TSS See Note(s) E See Note(s) B
1016042
See Note(s) A
1023603-NLA
1007909 40131X030
6631 See Note(s) C See Note(s) B
1016042
See Note(s) A
1022905-NLA
1007909
40131X0306658 NLA See Note(s) B
1016042
See Note(s) A
A - Quantity - 1 each.
B - Quantity - 2 each
C - Before 10/17/03.
E - Before 1/31/04.
NOTE:
Note: When adjusting or replacing parts, please refer to your Owner's Manual for assistance.
6
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 92-048

Packaging, Literature & Decals
Half Rail
Model Number Carton Insert Literature
1016386
1007969
40131X102-NLA6630 See Note(s) A
A - Quantity - 1 each.NOTE:
Note: When adjusting or replacing parts, please refer to your Owner's Manual for assistance.
Ecomony Half Rail
CareGuard by Invacare
Model Number Carton Insert Literature
1082514-NLAN/AN/A
6640
See Note(s) A 1125060N/AN/A6640
A - Instruction Sheet no longer available, refer to part #1125060 for replacement.NOTE:
Note: When adjusting or replacing parts, please refer to your Owner's Manual for assistance.
Crossbraces Only
Model Number Carton Insert Literature
1016404
1007909
40131X0306625L NLA See Note(s) B
1016042
See Note(s) A
N/A
1016042
40131X1596626Y2 NLA See Note(s) A
A - Quantity - 1 each.
B - Quantity - 2 each
NOTE:
Note: When adjusting or replacing parts, please refer to your Owner's Manual for assistance.
7
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 92-048

Packaging, Literature & Decals
Economy Telescoping
CareGuard by Invacare
Model Number Carton Insert Literature
1080892-NLA
N/A
N/A
6650 See Note(s) A See Note(s) A See Note(s) A
00077X079 1007909
See Note(s) B See Note(s) B
1016042
See Note(s) B
A - Before 12/15/03.
B - After 12/14/03.
NOTE:
Note: When adjusting or replacing parts, please refer to your Owner's Manual for assistance.
Decals
Part Number Description
Label, Entrapment Warning1130183
8
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 92-048

Standard Telescope Bed Rails
6623
This Model was discontinued 1/8/03
9
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 92-048

Standard Telescope Bed Rails
6623
This Model was discontinued 1/8/03
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1135777 Kit, Telescoping Bed Rail 1 21 A Washer, Nylon (3/16 x 7/16 x 1/8") 1 22 Rivet (3/16 x 7/16") 1 23 Pin, Plunger 1 24 Spring, Plunger (23/64 x 5/8") 1 25 Plug Button, Grey (7/8") 1 26 Knob, Plunger, Grey 1 27 Rail, Telescoping - Outside 1 18 Rail, Telescoping - Inside 1 19 Label, Entrapment Warning 1 1
1021834 Kit, Crossbrace Assembly 1 210 B Barrel, Right 1 111 Barrel, Left 1 111 Washer, Flat (5/16 x 11/16 x 1/16") 1 212 Locknut (5/16-18) 1 213 Nut, Wing (1/4-20) 1 215 Clamp Bar 1 216 Bolt, Carriage (1/4-20 x 1-1/4") 1 217 Channel Only, Granite 1 118 1028789 Kit, Frame Bar (Pair) 1 114 C Bolt, Carriage (1/4-20 x 1-1/4") 1 215 Clamp Bar 1 216 Nut, Wing (1/4-20) 1 217 1012658-NLA NLA - Spacer, Tube 1 2D,E
A - Includes: Items 2-9 and the Warning Label
B - Includes: Items 11-18
C - Includes: Items 15-17
D - Before 8/11/97 only.
E - Not Shown
2/1/04
the rails will have 4 rungs instead of 3 so an inner and an outer Rail needs to be ordered when replacing.
NOTE:
10
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 92-048

Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
16356X000 Barrel Assembly, Right Head End / Left Foot End
(Includes: Plunger Knob and Pin) 1 21
16326X000 Barrel Assembly, Left Head End / Right Foot End
(Includes: Plunger Knob and Pin) 1 21
48806X011-NLA NLA - Button, Snap 1 42 40188X005-NLA NLA - Spring, Torsion 1 43 06626X003-NLA NLA - Tube, Channel, Chrome - Outside 1 24 A 06626X004-NLA NLA - Tube, Channel, Chrome - Inside 1 24 A 1011239-NLA NLA - Label, Caution 1 25 60290X002 Locknut (5/16-18) 1 46 16308X000 Washer, Flat (5/16 x 11/16 x 1/16") 1 47 06626X002-NLA NLA - Crossbrace Assembly 1 28 B
A - Channel Tube is No Longer Available. Order Item number 8.
B - Includes Items 1-7.
NOTE:
Crossbrace Assembly
6626Y2
This model was discontinued 10/4/00
11
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 92-048

Deluxe Telescoping Bed Rail and Crossbrace Assembly
6625/6625L
6625 was discontinued 2/4/03.
6625L was discontinued 9/21/94.
12
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 92-048

Deluxe Telescoping Bed Rail and Crossbrace Assembly
6625/6625L
6625 was discontinued 2/4/03.
6625L was discontinued 9/21/94.
13
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 92-048

Deluxe Telescoping Bed Rail and Crossbrace Assembly
6625/6625L
6625 was discontinued 2/4/03.
6625L was discontinued 9/21/94.
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
16320X006-NLA NLA - Rail, Outside 1 21 16320X007-NLA NLA - Rail, Inside 1 21 1057287 Plug Button, Grey (1") 1 82 40314X001-NLA NLA - Ring, Retaining 1 43 16330X000 Crossbrace Assembly, Grey 1 24 A,D 1010422-NLA NLA - Crossbrace Assembly 1 24 E 1007727 Channel Only, Granite 1 25 D 1007729-NLA NLA - Channel Only 1 25 E 60290X002 Locknut (5/16-18) 1 49 16308X000 Washer, Flat (5/16 x 11/16 x 1/16") 1 410 D 16347X000 Washer, Nylon (3/16 x 7/16 x 1/8") 1 410 E 16326X000 Barrel Assembly, Left Head End / Right Foot End
(Includes: Plunger Knob and Pin) 1 211 B
16356X000 Barrel Assembly, Right Head End / Left Foot End
(Includes: Plunger Knob and Pin) 1 211 B
19000X023 Spring, Plunger (23/64 x 5/8") 1 412 19000X012 Pin, Plunger 1 413 40014X020-NLA NLA - Knob, Plunger 1 414 1028789 Kit, Frame Bar (Pair) 1 115 C Bolt, Carriage (1/4-20 x 1-1/4") 1 26 Clamp Bar 1 27 Nut, Wing (1/4-20) 1 28
A - Includes Items 5-11
B - Includes Items 3, 12-14
C - Includes Items 6-8
D - Used on 6625
E - Used on 6625L
NOTE:
14
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 92-048

Standard Quick Clip-On Bed Rails
6627
This item was discontinued 2/16/96
15
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 92-048

Standard Quick Clip-On Bed Rails
6627
This item was discontinued 2/16/96
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1027096 Plug Button, Grey (7/8") 1 41 19000X023 Spring, Plunger (23/64 x 5/8") 1 42 1012658-NLA NLA - Spacer, Tube 1 23 1012660 Pin, Plunger 1 44 1012656 Knob, Plunger, Grey 1 45 1012669 Rail, Telescoping - Outside 1 26 1012670 Rail, Telescoping - Inside 1 26 1013305-NLA NLA - Telescoping Rail Assembly 1 27 A 40188X009 Button, Single Snap 1 48 1023490-NLA NLA - Crossbrace Assembly 1 29 B 1022789-NLA NLA - Tube, Channel with Barrel - Left Head End /
Right Foot End 1 210
1022790-NLA NLA - Tube, Channel with Barrel - Left Foot End /
Right Head End 1 210
1022842-NLA NLA - Tube, Channel - Center 1 211 1022652-NLA NLA - Clip, Spring 1 212
A - Includes items 1-6
B - Crossbrace Assembly is no longer available. May be replaced with crossbrace from model 6629.
NOTE:
16
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 92-048

Deluxe Spring Loaded Bed Rails
6628 & 6628-TSS
17
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 92-048

Deluxe Spring Loaded Bed Rails
6628 & 6628-TSS
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1121932 Rail, Inside 1 11 F 1121933 Rail, Outside 1 12 F 16347X000 Washer, Nylon (3/16 x 7/16 x 1/8") 1 23 16348X000 Rivet (3/16 x 7/16") 1 24 1057287 Plug Button, Grey (1") 1 85 1122149-NLA NLA - Label, Warning - Reduced Gap 1 16 40314X001-NLA NLA - Ring, Retaining 1 47 40014X020-NLA NLA - Knob, Plunger 1 48 1110764 Clip, Rail - Small 1 29 1110765 Clip, Rail - Large 1 29 1106232 Tube, Channel with Barrel - Inside 1 112 1110951-NLA NLA - Tube, Channel with Barrel, Chrome - Inner
Deluxe 1 112 G
1106234 Tube, Channel with Barrel, Outside 1 113 1110954 Tube, Channel with Barrel, Chrome - Outer Deluxe 1 113 1106235-NLA NLA - Crossbrace Assembly, Chrome 1 214 A,D 1110955 Crossbrace Assembly, Deluxe, Wide 1 214 A,C 16320X007-NLA NLA - Rail, Inside 1 115 16320X006-NLA NLA - Rail, Outside 1 116 1110957 Kit, Bed Rail Hardware 1 1B,E
A - Includes Items 3-12 and the Bed Rail Hardware Kit.
B - Not Shown
C - To be used with a TSS Mattress Only. Crossbraces are extra wide to accommodate the mattress.
D - Both old style and new style models use this crossbrace.
E - Includes the Wing Screws (4) to hold the X-Brace in place on the Bed Frame.
F - 2/1/04 the rails will have 4 rungs instead of 3 so an inner and an outer Rail needs to be ordered when replacing.
G - No longer available as a service part individually. Order item 14 part #1110955 as a replacement.
NOTE:
18
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 92-048

Standard Spring Loaded Bed Rails
6629
19
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 92-048
