InWin SIRIUS PURE User manual

User Manual

Product Video Information
Sirius Pure Product Video

Product Story
Simple but Classic – Siriusly White
Purity at its 󶇰nest. Elegantly vibrant. This
season, we present you not a black appearance,
but a white Sirius, an elegant beautiful design
that will elevate your PC builds!

Package Contents
Triple Pack
1. Sirius Pure ASP120 Fans x 3
2. ARGB One-Click Controller v1.1 x 1
3. Screws x 12
Single Pack
1. Sirius Pure ASP120 Fans x 1
2. Screws x 4

Cable Information
ARGB One-Click Controller
ver. 1.1
Addressable RGB Fan Cable, Addressable RGB
Y-Cable
(Note: Only in Triple Pack)
Addressable RGB Fan Cable
Addressable RGB Y-Cable
GND KEY D 5V+
GND
KEY
D
5V+

Installation
1.
Please make sure the power is o󶇯.
2.
Install the fans in your PC case and mount
them in the designated areas.
3.
The fan cable, Addressable RGB Y-Cable and
their counterparts are attached to each fan.
Please connect as follows:
Connect the fan’s Addressable RGB Y-Cable
to a motherboard’s 3-pin addressable RGB
header. Connect the attached fan cable to
the motherboard’s fan header.
Installing the 2nd fan: Connect the
Addressable RGB Y-Cable and connect it to
the available 3-pin Addressable RGB header
on the previous fan. Connect the fan to the
available fan header from the previous fan.
4. Installing the 3rd fan: Repeat
a
b
c
d
cd
Motherboard’s 3-pin
addressable RGB header
a
Motherboard’s
Fan Header
b
c
d
2nd fan’s
addressable RGB
Y-Cable
2nd fan’s fan
cable

Installation
*
If your motherboard does not support an
addressable header, please use the included
Addressable RGB Modular Controller to
connect to your PSU’s SATA cable and the fan’s
Addressable RGB Y-Cable in order to use the 14
di󶇯erent lighting e󶇯ects.
Hold the button to turn on or o󶇯 the lights.
Tap the button to change the lighting modes.
1Rainbow 8Two-Tone Ring
2LED-Red Breathing 9Diagonal Transition
3LED-Green 10 Rotating LED Trio
4LED-Blue 11 Full Circle
5LED-Purple 12 Flow-Red
6LED-White 13 Flow-Green
7
Light at the end of the
Tunnel
14 Flow-Blue
* InWin reserves the right to change the lighting
modes.
1st fan’s addressable
RGB Y Cable
2nd fan’s addressable
RGB Y Cable
PSU’s
SATA
cable
ARGB One-Click
Controller ver. 1.1

Troubleshooting
If your fan does not operate properly, please
follow the instructions below:
1. Please check your system’s power.
2. Please make sure all the connectors are
connected properly.
Important Notes
1. Please install the fan by following our
instructions.
2. When storing the fan, please keep this product
away from high temperatures. Keep it away
from machines such as heaters that might
cause high temperatures.
3. Please do not put anything in the impeller.
4. Please do not modify the wires or the
connectors provided by InWin.
5. Please do not touch the fan blades when the
fan is in operation.
6. Please only use your fan in a computer case.
7. Please keep this product away from any
liquids.

Product Name Sirius Pure ASP120
Quantity Included Single Pack Triple Pack
Model Number ASP120FAN-1PK ASP120FAN-3PK
Colors White
Fan Size 120 x 120 x 25mm
Materials PC, PBT
Rated Voltage 12V
Rated Power 1.2W
Rated Current 0.1A
ADD RGB Rated Voltage 5V
ADD RGB Rated Power 1.25W
ADD RGB Rated Current 0.25A
Speed Mode PWM 500~1800 RPM
Air Flow 50 CFM
Air Pressure 1.67mm/ H2O
LED Addressable RGB
Connector (Fan to Fan) Original Cable
Connector to M/B 4 Pin (PWM, 12V), 3 Pin (ARGB, 5V)
Noise Level 13-27 dBA (Max.) / 19 dBA (Normal)
Bearing Type Long Lifespan Sleeve Bearing
Gross Weight 200g 600g
Package Dimensions
(L x W x H) 185 x 125 x 30mm 185 x 125 x 80 mm
Warranty 2 Years
Speci󶇰cations
120mm
120mm
25mm
* InWin's products comply with RoHS regulation.
* Speci󶇰cations may vary based on di󶇯erent regions.
