InWin PCI-E Riser Cable User manual

PCI-E Riser Cable 4.0 x 16 & Bracket
User Manual

Vertically Mount Your GPU
InWin’s PCI-E Riser Cable allows users to
connect graphics cards vertically to the
motherboard and nicely showcases them.
This 4.0 riser cable is 250mm in length
and is fully compatible with Intel and AMD
motherboards.

* Please ensure no shorts have occurred due to poor PCI card placement.
* To prevent from damaging the cable, please do not fold the PCI-E cable
during installation.
Flat and Bendable Design
The InWin PCI-E riser cable has at design.
It is exible, highly routable and can be
positioned in any suitable direction

Note: Chassis must have at least 6 PCIe slots and be
installed as seen above.
The bracket cannot be properly installed if a solid, metallic
strip is above the PCIe slots.
Graphics Cards Support
The InWin PCI-E Riser Cable & Bracket
set comes with a high quality bracket
that supports the graphics card to the
motherboard. It is also compatible with
most standard ATX chassis.

Installation
4
1
7
5
2
3
6
8

Specications
Dimensions
Model InWin PCI-E Riser Cable InWin PCI-E Riser Cable &
Bracket
Part Number IW-PCIE4-25 IW-PCIE4-25-BRACKET
Interface PCI-E 4.0 x 16
90 Degree Right Angle Riser Adapter Card
Cable Length 250 mm
Materials PCB, FR4, Polyethylene(PE),SECC, Copper Alloy
Temperature
Range (°C) -20 ~ 80 °C
Package
Contents
1. PCI-E Riser Cable x 1
2. Screws x 4
3. Standoffs x 3
4. Standoff Socket x 1
1. PCI-E Riser Cable x 1
2. Vertical VGA Bracket x 1
3. Screws x 5
4. Standoffs x 3
5. Standoff Socket x 1
Net Weight 0.18 KG 0.44 KG
Gross Weight 0.21 KG 0.48 KG
* Our products comply with RoHS regulations.
* Specications may vary based on different regions.
PCI-E Riser Cable
4.0 x 16 & Bracket
PCI-E Riser Cable
4.0 x 16
