InWin MR24 User manual

User Manual
ALL-IN-ONE LIQUID CPU COOLER

Product Video Information
MR24/36 Product Video
MR24/36 Installation Guide Video

Get ready to experience the powerful cooling
performance with the InWin MR Series.
The MR Series provides superior cooling with
simplified installation. Its durability paired
with its unique aesthetic design makes it a
great addition to your unique PC.
Product Story

Specifications
MR36MR24
MR24
IW-LC-MR24
Intel® LGA 1700/ 1200/ 20xx/ 1151/ 115x
AMD AM5/AM4/ AMx/ FMx
CPU Socket Support
Radiator
Water Block
Fans
Package Contents
Package Dimensions
(L x W x H)
Aluminium
400 mm
Rubber with Nylon Braided Sleeve
Net Weight
Gross Weight
Warranty
Model
Model Number
1 x InWin MR24 Liquid CPU Cooler
2 x InWin Neptune AN120 Fans
Accessories Bag
Materials
Tube Length
Tube Materials
* InWin's products comply with RoHS regulation.
* Specifications may vary based on different regions.
277 x 120 x 27 mm
10.9 x 4.7 x 1.1"
81 x 68 x 39 mm
3.2 x 2.7 x 1.5"
Aluminium, Copper, Plastic
4200 RPM +/- 10%
DC 12V, 0.34A (0.45A MAX)
Neptune AN120
2 PCS
120 x 120 x 25 mm
4.7 x 4.7 x 1.0"
PWM 900 - 2200 +/- 10% RPM
20.5 dB(A) (Normal)
23.87 - 60.1 CFM
0.36 - 2.27 mm / H2O
4-Pin (12V, PWM), 3-Pin (5V, ARGB)
Long Lifespan Sleeve Bearing
Dimensions
(L x W x H)
Model
Quantity Included
Dimensions
(L x W x H)
Dimensions
(L x W x H)
Speed Mode
Noise Level
Airflow
Air Pressure
Connectors
Bearing Type
322 x 137 x 205 mm
12.6 x 5.3 x 8"
1.4 Kg / 3.08 lbs
1.9 Kg / 4.1 lbs
3 Years
Materials
Pump Pump Speed
Power
MR36
IW-LC-MR36
Intel® LGA 1700/ 1200/ 20xx/ 1151/ 115x
AMD AM5/AM4/ AMx/ FMx
Aluminium
450 mm
Rubber with Nylon Braided Sleeve
1 x InWin MR36 Liquid CPU Cooler
3 x InWin Neptune AN120 Fans
Accessories Bag
397 x 120 x 27 mm
15.6 x 4.7 x 1.1"
81 x 68 x 39 mm
3.2 x 2.7 x 1.5"
Aluminium, Copper, Plastic
4200 RPM +/- 10%
DC 12V, 0.34A (0.45A MAX)
Neptune AN120
3 PCS
120 x 120 x 25 mm
4.7 x 4.7 x 1.0"
PWM 900 - 2200 +/- 10% RPM
20.5 dB(A) (Normal)
23.87 - 60.1 CFM
0.36 - 2.27 mm / H2O
4-Pin (12V, PWM), 3-Pin (5V, ARGB)
Long Lifespan Sleeve Bearing
448 x 137 x 205 mm
17.6 x 5.3 x 8"
1.7 Kg / 3.7 lbs
2.4 Kg / 5.2 lbs
3 Years

MR Series Package Contents
Contents MR24 MR36
Pump & Radiator
A240 mm Radiator 1 -
B360 mm Radiator - 1
Fan CNeptune AN120 Fan 2 3
Accessories Bag
DINTEL LGA1700 CPU Backplate 1
EINTEL 115x / 1200 CPU Backplate 1
FIntel Mounting Bracket 1
GAMD Mounting Bracket 1
HStandoff Screws (LGA 115X/1200) 4
IStandoff Screws (LGA 20xx) 4
JStandoff Screws (LGA 1700) 4
KThumbscrew Caps 4
LRadiator Screws 8 12
MFan Screws 8 12
NAMD Mounting Bolt 2
OThermal Compound 1
PARGB Extension Cables 500 mm 1 2
QPWM Extension Cables 500 mm 1 2

Connection Cables
ARGB Water Block Cable
Pump Cable
PWM Fan Extension Cable
ARGB Extension Cable
490 mm
95 mm
530 mm
500 mm
500 mm

Connection Cables
Please connect the cable according to the instruction below.

Troubleshooting
If your AIO pump or fan does not operate
properly, please follow the instructions
below:
1. Please check your system’s power.
2. Please make sure all the connectors are connected properly.
3. For more technical support, please visit the InWin Forum at
https://forum.in-win.com/
Notices & Warranty
■ Notices
■ Warranty
1. Install in accordance with the user manual’s instructions and safety
warnings. Incorrect installation may burnout the mother- board and
other system components.
2. Keep this product away from areas with high temperatures such as:
heat dissipation machines, air conditioners or other machines which
may generate high temperatures.
3. Please do not put anything in the impeller.
4. Do not modify the cables and/or connectors included with this
product.
5. Please do not put your hands or other objects into the fan blades
when the fan is in operation. And please make sure to keep away
from children and pets.
6. Please only use this product in a computer case.
7. Please keep this product away from any liquids.
8. Please use only this product's exclusively supplied cables. Other
cables may not be compatible and could cause serious damage to
your system and power supply.
1. For more detailed warranty information, please visit the InWin retail
website at www.in-win.com.
2. The actual product is subject to change without prior notice.
IN WIN DEVELOPMENT INC. reserves the right to make any nal
modications.

Copyright © 2023 In Win Development Inc.
All Rights Reserved.
