IOGear GCS1932M Operating and maintenance instructions

GCS1932M/GCS1934M/GCS1932MX/GCS1934MX
PART NO. Q1499/Q1500
Quick Start Guide
2/4-Port 4K DisplayPort KVMP Switch with
Dual Video Out and RS-232
www.iogear.com

Package Contents
GCS1932M / GCS1934M
1 x GCS1932M / GCS1934M
2 x DisplayPort 1.2 Cables / 4 x DisplayPort 1.2 Cables
2 x USB 3.0 Cables / 4 x USB 3.0 Cables
2 x Audio Cable Sets / 4 x Audio Cable Sets
1 x Power Adapter
1 x Quick Start Guide
1 x Warranty Card
GCS1932MX / GCS1934MX
1 x GCS1932M/ GCS1934M
1 x Power Adapter
1 x Quick Start Guide
1 x Warranty Card
1
Console:
• DisplayPort monitor and/or HDMI monitor
• Standard wired USB keyboard
• Standard 3-button wired USB mouse
• Speakers and Microphones (optional)
Computer:
• DisplayPort port*
• USB Type-A port
• Audio ports (optional)
Operating Systems:
• Windows®2000, Vista, 7, 8.1, 10
• Mac OS X 9.0+
• Oracle®Solaris
• Linux®, UNIX, and other USB supported systems
System Requirements
*MST requires PC Source to be DisplayPort1.2 MST compliant.
DisplayPort 1.1 source will result in mirror viewing.

Overview
A. Port selection pushbuttons
B. Port LEDs
C. Analog 2.1 Audio (Speaker and Microphone)
D. USB 3.0 Hub
E. Console Ports
F. KVM Ports
G. Power Jack
*MST requires PC Source to be DisplayPort1.2 MST compliant.
DisplayPort 1.1 source will result in mirror viewing.
GCS1932M Front View
GCS1932M Rear View
CONSOLE
1
A
1
B1 C1 D
1
E
1
D1 F
1
G
GCS1932M Front View
GCS1932M Rear View

2
GCS1934M Front View
GCS1934M Rear View
CONSOLE
1
A
1
B1 C1 D
1
E
1
D1 F
1
G
GCS1934M Front View
GCS1934M Rear View

Hardware Installation 3
1. Connect the USB keyboard and mouse to the GCS1932M/GCS1934M
console ports
2. Connect the DisplayPort and/or HDMI monitor to the
GCS1932M/GCS1934M console ports
3. Turn the monitor power to ON
4. Connect the main microphone and speakers into the
GCS1932M/GCS1934M microphone and speaker jacks located on the
front side panel. (optional)
5. Connect the secondary microphone and speakers into the
GCS1932M/GCS1934M microphone and speaker jacks located on the
rear side panel. (optional)
6. Connected the DisplayPort connector (not included in
GCS1932MX/GCS1934MX models) into any available DisplayPort port
in the KVM Port section. Connect the USB, microphone, and speaker
connectors (not included in the GCS1932MX/GCS1934MX models)
into the GCS1932M/GCS1934M. Connect the other end of the KVM
cables to their respective DisplayPort, USB, microphone, and speaker
ports on the computers.
7. Connect up to 2 USB peripherals into the USB 3.0 Type-A ports
(front and rear panel of the GCS1932M/GCS1934M)
8. Connect the power adapter to an AC power source. Then, connect
the power adapter cable to the GCS1932M/GCS1934M power jack.
9. Turn all connected computers power to On

HDD
Hardware Installation
CONSOLE
1
7
1
5
1
8
1
2
1
1
1
7
1
4
1
61 6
GCS1932M Rear View
GCS1932M Front View

3
CONSOLE
1
2
1
1
1
7
1
5
1
81 6
1
6
1
6
1
6
HDD
1
7
1
4
GCS1934M Rear View
GCS1934M Front View

Operation
Switch Operation
Switching between connected computer sources:
a. Manual – involves pressing the port selection pushbuttons
located on the GCS1932M/GCS1934M’s front panel.
b. Hotkey – involves entering combinations from the keyboard (list
of complete Hotkey Settings is available in the manual, located
on our website).
c. Mouse – involves clicking the mouse wheel button twice to switch
between ports (mouse emulation must be on, pleae see manual
for a complete Hotkey Settings).
Display Settings
a. DisplayPort 1.1 Source – 2 monitors will be in mirror mode
b. DisplayPort 1.2 with MST Support Source – 2 monitors will be in
mirror or extended mode
For a list of complete Hotkey Settings, please visit our website for
updated manuals:
www.iogear.com/product/GCS1932M
www.iogear.com/product/GCS1934M

EMC Information
Federal Communications Commission Statement (FCC)
Statement:
This equipment has been tested and found to comply with the limits
for a Class B digital service, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. Any changes or
modifications made to this equipment may void the user’s authority
to operate this equipment. This equipment generates, uses, and can
radiate radio frequency energy. If not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly
approved by the party responsible for compliance could void the
user’s authority to operate this equipment.
Switch Operation
Switching between connected computer sources:
a. Manual – involves pressing the port selection pushbuttons
located on the GCS1932M/GCS1934M’s front panel.
b. Hotkey – involves entering combinations from the keyboard (list
of complete Hotkey Settings is available in the manual, located
on our website).
c. Mouse – involves clicking the mouse wheel button twice to switch
between ports (mouse emulation must be on, pleae see manual
for a complete Hotkey Settings).
Display Settings
a. DisplayPort 1.1 Source – 2 monitors will be in mirror mode
b. DisplayPort 1.2 with MST Support Source – 2 monitors will be in
mirror or extended mode
For a list of complete Hotkey Settings, please visit our website for
updated manuals:
www.iogear.com/product/GCS1932M
www.iogear.com/product/GCS1934M

This product carries a 3 Year Limited or Lifetime Warranty. For the
terms and conditions of this warranty, please go to http://ww-
w.iogear.com/support/warranty
Register online at http://www.iogear.com/register
