IOTA DLS-X Series User manual

Thank you for purchasing IOTA’s DLS-X Series Power Converter/Battery Charger. When utilized properly, your DLS-X
Power Converter/Battery Charger will provide years of dependable service.This Owner’s Manual contains important safety
and operating instructions. READ ALL INSTRUCTIONS AND SAFETY PRECAUTIONS CAREFULLY BEFORE INSTALL-
ING AND OPERATING THE UNIT.
WARNING
Risk of SERIOUS INJURY OR DEATH
This unit is an electrical device. When working with this, or any
electrical device, there exists the potential for
ELECTRICAL SHOCK, EXPLOSION and FIRE hazards.
Before using this equipment, READ AND UNDERSTAND the
instructions, warnings, and safety precautions in this Owner’s
Manual. Failure to read and understand these instructions could
result in SERIOUS INJURY or DEATH.
SAVE THESE INSTRUCTIONS
DANGER
ELECTRICAL SHOCK HAZARD
THIS CHARGER IS AN ELECTRICAL
DEVICE THAT CAN SHOCK AND CAUSE
SERIOUS INJURY.
DO NOT CUT POWER CORDS.
DO NOT SUBMERGE IN WATER OR GET
THE CHARGER WET.
EXPLOSION HAZARD
UNSUPERVISED, INCOMPATIBLE, OR
DAMAGED BATTERIES CAN EXPLODE IF
USED WITH A CHARGER.
DO NOT ATTEMPT TO CHARGE DAMAGED
OR FROZEN BATTERIES.
USE THE CHARGER ONLY WITH BATTER-
IES OF RECOMMENDED VOLTAGE.
OPERATE THE CHARGER IN
WELL-VENTILATED AREAS ONLY.
WARNING
FIRE HAZARD
A CHARGER IS AN ELECTRICAL DEVICE
THAT EMITS HEAT AND CAN BURN.
DO NOT COVER THE CHARGER.
KEEP THE CHARGER AWAY FROM
COMBUSTIBLE MATERIALS.
DO NOT SMOKE OR USE ANY
OTHER SOURCE OF ELECTRICAL
SPARK OR FIRE WHEN OPERATING
THE CHARGER.
CAUTION
When working with the DLS-X unit, always observe the
following guidelines:
• The DLS-X is designed for indoor use. Do not use out-
doors.
• DO NOT expose the DLS-X unit to rain, snow, or other
inclement weather.
• Do not mount the DLS-X in a zero clearance compartment
or in compartments with flammable items such as gasoline
or batteries.
• Do not mount the DLS-X in an area with the potential of
dust, debris, or other foreign materials entering the vents of
the DLS-X.
• Use of an attachment or device with the DLS-X not recom-
mended by IOTA Engineering will void the warranty and
may result in a risk of fire, electrical shock, or injury to
persons.
• To reduce the risk of damage to the electric plug and cord,
always pull by the plug and not the cord when disconnect-
ing the unit.
• DO NOT operate the DLS-X with a damaged cord or plug.
• DO NOT operate the DLS-X if it has been dropped, re-
ceived a sharp blow, or has been otherwise damaged in
any way.
• DO NOT disassemble the DLS-X unit.
• To reduce the risk of electric shock, DISCONNECT the
DLS-X charger from ALL power sources before attempt-
ing any maintenance or cleaning. Turning off any electri-
cal supply or load to the unit is not sufficient and will not
reduce this risk.
• DO NOT use extension cords. Using an improper extension
cord could result in a risk of fire and electric shock, and
may result in property damage, personal injury or death.
RISK OF EXPLOSIVE GASES
WORKING IN THE VICINITY OF LEAD-
ACID BATTERIES IS DANGEROUS.
BATTERIES GENERATE EXPLOSIVE
GASES DURING NORMAL BATTERY
OPERATION. FOR THIS REASON, IT IS
OF UTMOST IMPORTANCE THAT YOU
FOLLOW THE INSTRUCTIONS WHEN
USING THE BATTERY CHARGER.
To reduce the risk of battery explosion, follow
these instructions and those published by the
battery manufacturer and review all Cautions
and Warnings associated with these products.

INSTALLATION GUIDELINES
MOUNTING LOCATION
The IOTA Power Converter/Battery Charger can be
mounted in any position within an enclosed or interior
compartment. Provide sufficient air space to allow unre-
stricted airflow in and around the unit. Provide at least 4″
around the fan of the DLS-X to allow for proper air intake.
IF USING AN OPTIONAL MOUNTING PLATE - Attach
the mounting plate to the mounting location prior to
attaching the unit.
DO NOT mount the unit in a zero clearance compartment.
DO NOT mount the DLS-X in the same compartment with
flammable items such as gasoline or batteries.There are
no components within the DLS-X unit that, during normal
operation, produce arcs or sparks.However, all electronic
devices have some potential for generating sparks in
the event of failure which can result in explosion or fire.
DO NOT mount the DLS-X in an area that has the
potential of dust, debris, or other foreign materials to
enter in through the DLS-X vents.
DO NOT place the DLS-X directly above the battery; the
gases from the battery can corrode and damage the DLS-X.
IOTA DLS-X Series Power Converter/Battery Chargers
convert 120 volts nominal A.C. to 13.6 volts D.C. As a
power supply, its tightly controlled regulation allows the
user to operate any 12 volt nominal D.C. load up to the
converter’s rated output current.As a battery charger, the
converter will maintain the battery, delivering its full-rated
current when the battery capacity falls sufficiently low.
The voltage is set to deliver its maximum current for the
necessary period of time that minimizes undue stress
to the battery caused by heating of its cells. This helps
to ensure the longest possible life of the battery. Over
time, as the battery nears its full capacity, the converter
will float-charge the battery to prevent self-discharge of
its cells.
PROTECTION FEATURES
The IOTA Power Converters/Battery Chargers are
designed with high quality components to help ensure
years of continuous use. The unit is protected by mul-
tiple protection features for a long, trouble-free life.
1) Reverse Battery Polarity Protection. 2) Brown-Out
Input Protection. 3) Over-Current Protection - cycle by
cycle peak limiting as well as rated current limiting to
maximize the life of the converter. 4) Over-Temperature
Protection. In addition, it is designed with a unique
“proportional” fan control circuit. Fan speed is directly
proportional to the converter’s internal ambient tem-
perature. This enables the fan to turn on and off very
slowly, minimizing unwanted fan-starting noise.
The IOTA DLS-X Series Power
Converters/Battery Chargers are
warranted from defects in materi-
als or workmanship for three years
from date of retail purchase, and
limits the remedies to repair or replacement.This warranty is
valid only in the continental United States and Canada. For
complete warranty details, contact Customer Service or visit
www.iotaengineering.com.
WARRANTY
PRODUCT DESCRIPTION
WARRANT
Y
REPAIR REPLACEMENT
THREE-YEAR
INSTALLATION GUIDELINES (cont.)
BATTERY CONNECTION
Before you connect the DLS-X to the battery, make sure that
the AC power cord is NOT plugged into an electrical outlet.
Disconnect the positive side of the battery before installation.
Connect the positive and negative terminal lugs to battery or
load. Always use the proper size wire based on the amperage
of the converter and the battery. Torque the connections to the
proper rating according to the wire manufacturer’s specifica-
tions. Refer to Illustration 1. Recreational vehicle applications
require a type III circuit breaker be installed within 18″ of the
battery, connecting the battery positive to the line side of the
breaker, and the IOTA unit to the load side. Connect “Chas-
sis Bonding Lug” on the IOTA unit to vehicle chassis or other
grounding source. Refer to Illustration 1.
120 VOLT A.C. INPUT
Plug the unit A.C. input cord into an appropriate 120-volt 3-wire
grounded source. The blue LED indicator light will illuminate,
indicating the presence of AC power. Refer to Illustration 2 for
specifications of the cord provided with your DLS-X unit. See the
Technical Specifications Chart on page 4 for maximum current
draw and required input voltages.
DO NOT USE EXTENSION CORDS - Using an improper
extension cord could result in a risk of fire and electric shock,
and may result in property damage, personal injury or death.
DO NOT OPERATE THE DLS-X WITH A DAMAGED CORD
OR PLUG. Have the cord or plug replaced immediately by
qualified service personnel.
REVERSE POLARITY FUSES
The IOTA Battery Charger/Power Supply is protected against
reverse polarity on the DC output. If a battery or the unit is
hooked up incorrectly, the fuses will blow and can be easily
replaced. Always use the same size and style fuse that came
with the converter.
NOTE: Depending on the amperage model of the DLS-X,
fuses may not be present in all slots. Refer to the chart
below for the rating and number of fuses per model:
DLS-15-X
DLS-30-X
DLS-45-X
DLS-55-X
DLS-75-X
DLS-90-X
Model Fuse Rating Fuse Quantity
7.5A
15A
25A
20A
25A
30A
2
2
2
3
3
3

The DLS-X features an accessory port on the fan end of the unit for installing an IQ4-X Charge Control Module for automatic
four-stage charging.
Installing the IQ4-X Charge Control Module gives the user the benefit of automatic Bulk, Absorption, and Float stage charg-
ing. This increases the charging capacity of the IOTA charger, decreases charge times and insures proper and safe battery
charging without over-charging.The green LED on the module will indicate which charging phase the IOTA charger is currently
in.When the unit is first activated, the LED will flash as it reads the number of cells in the battery.The unit will then initiate the
four-stage charging algorithms. The LED indicator will flash according to the active charging stage of the unit. Use the LED
CODE TABLE for reference when checking the LED.
To install an IQ4-X module into the charger, remove the fastening screw on the top of the port faceplate and detach the face-
plate. Plug the control module into the port and secure in place using the original fastening screw. NOTE: the port faceplate
and IQ4-X control module are similar in appearance. You can recognize the IQ4-X Charge Control Module by the presence
of the LED indicator on the face.
ACCESSORY PORT AND IQ4-X CHARGE CONTROL MODULE
*Actual component locations may vary depending on model.
ILLUSTRATION 1 - DLS-X CONNECTIONS*
ILLUSTRATION 2 - AC INPUT PLUG
ILLUSTRATION 3 - IQ4-X MODULE INSTALLATION
NEMA 5-20P PLUG
FOR 20A RECEPTACLE
NEMA 5-30P PLUG
FOR 30A RECEPTACLE
NEMA 5-15P PLUG
FOR 15A RECEPTACLE
SDC1-120-12-15, SDC1-120-12-30,
SDC1-120-12-45, SDC1-120-12-55
SDC1-120-12-75
SDC1-120-12-90
Torque the connections to the proper rating
according to the wire manufacturer’s
specifications.
AMPLIFE
CHARGE CONTROL
MODULE
ACCESSORY PORT
ON END OF SDC1
NEMA 5-20P PLUG
FOR 20A RECEPTACLE
NEMA 5-30P PLUG
FOR 30A RECEPTACLE
NEMA 5-15P PLUG
FOR 15A RECEPTACLE
SDC1-120-12-15, SDC1-120-12-30,
SDC1-120-12-45, SDC1-120-12-55
SDC1-120-12-75
SDC1-120-12-90
NEMA 5-20P PLUG
FOR 20A RECEPTACLE
NEMA 5-30P PLUG
FOR 30A RECEPTACLE
NEMA 5-15P PLUG
FOR 15A RECEPTACLE
SDC1-120-12-15, SDC1-120-12-30,
SDC1-120-12-45, SDC1-120-12-55
SDC1-120-12-75
SDC1-120-12-90
DLS-90-X
NEMA 5-20P PLUG
FOR 20A RECEPTACLE
NEMA 5-30P PLUG
FOR 30A RECEPTACLE
NEMA 5-15P PLUG
FOR 15A RECEPTACLE
SDC1-120-12-15, SDC1-120-12-30,
SDC1-120-12-45, SDC1-120-12-55
SDC1-120-12-75
SDC1-120-12-90
DLS-75-XDLS-15-X, DLS-30-X, DLS-45-X, DLS-55-X,
IQ4-X
Accessory Port
on DLS-X

Distributed By:
TECHNICAL SPECIFICATIONS CHART
68359-012 REV 1700
IOTA ENGINEERING PO BOX 11846 TUCSON, AZ 85734 TEL: [phone]-IOTA (4682) FAX: [phone] WEB: www.iotaengineering.com
13.6V (DC)
+ or - .7%
15 Amps
>13.4V (DC)
200 Watts
<50 mV rms
108 - 132 AC
47-63
3.7 Amps
>80%
30 Amps
Yes
>100%
100 mV rms
<1%
PROPORTIONAL
YES
0° - 40° C
-20° to 80° C
1700/1700/500
10.3″x 6.0″x 2.7″
4.5 lbs
DC Output Voltage (No Load) approx.
Output Voltage Tolerance (No Load)
Output Amperage, Max Continuous
Output Voltage (Full Load) approx.
Maximum Power Output, Continuous
Ripple and Noise
Input Voltage Range
Input Voltage Frequency
Maximum AC Current (@108Vac)
Typical Efficiency
Max Inrush Current, Single Cycle
Short Circuit Protection
Overload Protection
Line Regulation
Load Regulation
Fan Control
Thermal Protection
Working Temperature Range
Storage Temperature
Withstand Voltage (VDC)†
Approximate Dimensions
Weight
13.6V (DC)
+ or - .7%
30 Amps
>13.4V (DC)
450 Watts
<50 mV rms
108 - 132 AC
47-63
7.3 Amps
>80%
30 Amps
Yes
>100%
100 mV rms
<1%
PROPORTIONAL
YES
0° - 40° C
-20° to 80° C
1700/1700/500
10.3″x 6.0″x 2.7″
4.5 lbs
13.6V (DC)
+ or - .7%
45 Amps
>13.4V (DC)
650 Watts
<50 mV rms
108 - 132 AC
47-63
11 Amps
>80%
30 Amps
Yes
>100%
100 mV rms
<1.5%
PROPORTIONAL
YES
0° - 40° C
-20° to 80° C
1700/1700/500
10.3″x 6.0″x 2.7″
5.0 lbs
13.6V (DC)
+ or - .7%
55 Amps
>13.4V (DC)
800 Watts
<50 mV rms
108 - 132 AC
47-63
13.4 Amps
>80%
30 Amps
Yes
>100%
100 mV rms
<1.5%
PROPORTIONAL
YES
0° - 40° C
-20° to 80° C
1700/1700/500
10.3″x 6.0″x 2.7″
5.0 lbs
13.6V (DC)
+ or - .7%
75 Amps
>13.4V (DC)
1125 Watts
<50 mV rms
108 - 132 AC
47-63
18.2 Amps
>80%
40 Amps
Yes
>100%
100 mV rms
<1.5%
PROPORTIONAL
YES
0° - 40° C
-20° to 80° C
1700/1700/500
12.1″x 7.75″x 2.9″
8.0 lbs
DLS-15-X DLS-30-X DLS-45-X DLS-55-X DLS-75-X DLS-90-X
13.6V (DC)
+ or - .7%
90 Amps
>13.4V (DC)
1350 Watts
<50 mV rms
108 - 132 AC
47-63
21.8 Amps*
>80%
40 Amps
Yes
>100%
100 mV rms
<1.5%
PROPORTIONAL
YES
0° - 40° C
-20° to 80° C
1700/1700/500
12.1″x 7.75″x 2.9″
8.0 lbs
RATINGS AND SPECIFICATIONS
†Primary to Chassis/Primary to Secondary/Secondary to Chassis

CONVERTISSEUR/CHARGEUR DE BATTERIE
GUIDE DE PROPRIÉTAIRE
Merci pour votre achat du Convertisseur/Chargeur de batterie de la série d’IOTA Engineering. Lorsqu’il est utilisé correctement, ce Con-
vertisseur/Chargeur de Batterie DLS-X pourra fonctionner pendant plusieurs années. Ce Manuel du propriétaire contient d’importantes
instructions de sécurité et de fonctionnement. VEUILLEZ LIRE TOUTES LES INSTRUCTIONS ET LES PRÉCAUTIONS DE SÉCURITÉ
ATTENTIVEMENT AVANT D’INSTALLER ET D’UTILISER L’UNITÉ.
AVERTISSEMENT
Risque de GRAVES BLESSURES OU DE MORT
Cette unité est un appareil électrique. Lors de son utilisation ou avec
un quelconque autre appareil électrique, il existe des risques poten-
tiels de CHOC ÉLECTRIQUE, D’EXPLOSION OU D’INCENDIE.
Avant d’utiliser cet équipement, veuillez LIRE ET COMPRENDRE
les consignes, avertissements et précautions de sureté se trouvant
dans le Manuel du Propriétaire.
La mauvaise lecture ou une mauvaise compréhension de ces con-
signes pourrait entraîner de GRAVES BLESSURES voire LA MORT.
SAUVEGARDER CES INSTRUCTIONS
DANGER
RISQUE DE CHOC ÉLECTRIQUE
CE CHARGEUR EST UN APPAREIL ÉLEC-
TRIQUE QUI PEUT CAUSER UN CHOC ET
DES BLESSURES GRAVES.
NE PAS COUPER LES FILS ÉLECTRIQUES.
NE PAS SUBMERGER D’EAU OU MOUILLER
LE CHARGEUR
RISQUE D’EXPLOSION
DES BATTERIES NON-SUPERVISÉES,
INCOMPATIBLES OU ENDOMMAGÉES PEU-
VENT EXPLOSER SI ELLES SONT UTILI-
SÉES AVEC UN CHARGEUR.
NE PAS ESSAYER DE CHARGER DES BAT-
TERIES ENDOMMAGÉES OU GELÉES.
UTILISER SEULEMENT LE CHARGEUR
AVEC DES BATTERIES AU VOLTAGE RE-
COMMANDÉ.
UTILISER LE CHARGEUR SEULEMENT
DANS DES ZONES BIEN VENTILÉES.
AVERTISSEMENT
RISQUE D’INCENDIE
UN CHARGEUR EST UN APPAREIL ÉLEC-
TRIQUE QUI ÉMET DE LA CHALEUR ET
PEUT BRULER.
NE PAS COUVRIR LE CHARGEUR.
CONSERVER LE CHARGEUR HORS DE POR-
TÉE DE MATÉRIAUX COMBUSTIBLES.
NE PAS FUMER OU N’UTILISER AUCUNE
AUTRE SOURCE D’ÉTINCELLE ÉLECTRIQUE
OU DE FEU LORSQUE VOUS UTILISEZ LE
CHARGEUR.
ATTENTION
Lorsque vous travaillez avec l’unité DLS-X, veuillez respecter les
directives ci-dessous:
• Le DLS-X est conçu pour une utilisation intérieure. Ne pas utiliser à
l’extérieur.
• NE PAS exposer l’unité DLS-X à la pluie, neige ou autre intempérie.
• Ne pas monter le DLS-X dans un compartiment à tolérance zéro ou
dans des compartiments avec des objets inflammables tels que de
l’essence ou des batteries.
• Ne pas monter le DLS-X dans une zone où de la poussière, des
débris ou autres matériaux parasites pourraient entrer dans les
conduits du DLS-X.
• L’utilisation d’une attache ou d’un appareil avec le DLS-X n’est
pas recommandée par IOTA Engineering qui annulera la garan-
tie. Il y a également des risques d’incendie, de choc électrique
ou de blessures sur personne.
• Afin de réduire le risque de dommage sur la prise et le fil
électrique, veuillez tirer sur la prise, et non le fil lorsque vous
débranchez l’unité.
• NE PAS utiliser le DLS-X avec un fil ou une prise endommagée.
• NE PAS utiliser le DLS-X s’il est tombé, a reçu un coup ou a été
endommagé d’une manière ou d’une autre. Amenez l’unité DLS-
X auprès d’un endroit de service agréé.
• NE PAS démonter l’unité DSL. Amenez l’unité DLS-X auprès d’un
endroit de service agréé lorsqu’un service ou une réparation est
requise.
• Afin de réduire le risque de choc électrique, DÉBRANCHEZ
le chargeur DLS-X de TOUTES les sources de courant avant
d’effectuer tout nettoyage ou maintenance. Couper tout courant
ou charge électrique vers l’unité n’est pas suffisant et ne réduira
pas le risque.
• NE PAS utiliser de rallonge. L’utilisation d’une mauvaise rallonge
pourrait résulter en un risque d’incendie ou un choc électrique
et pourrait résulter endommager les biens, causer des blessures
personnelles voir la mort.
RISQUE DE GAZ EXPLOSIFS
TRAVAILLER AVEC DES BATTERIES PRINCI-
PALEMENT EN ACIDE EST DANGEREUX. LES
BATTERIES GÉNÈRENT DES GAZ EXPLOSIFS
DURANT LE FONCTIONNEMENT NORMAL DE
LA BATTERIE. DE CE FAIT, IL EST EXTRÈME-
MENT IMPORTANT QUE VOUS SUIVIEZ LES
INSTRUCTIONS LORSQUE VOUS UTILISEZ LE
CHARGEUR DE BATTERIE.
Afin de réduire le risque d’explosion de la bat-
terie, veuillez suivre ces instructions ainsi que
celles publiées par le fabriquant de batterie et
veuillez revoir tous les Avertissements et Dan-
gers associés à ces produits.
INSERT
