CT15R B - C Quick Guide
This Guide is intended for quick consultation only and does not replace the Use and Maintenance
Manual. Before using the machine, read the Use and Maintenance Manual contained in the machi-
ne packaging thoroughly and rigorously respect all the instructions.
PREPARATION/
OPERATION
Fill the detergent tank. Press the ON button.
Press the brush button to activate
suction and water delivery.
Operate the drive lever.
Begin working.
When you have nished cleaning,
proceed as follows:
• Press the brush button.
• Turn the machine off by pres-
sing the ON button for at least 4
seconds.
• Raise the squeegee.
• Close the detergent tank tap.
• If necessary, charge the batteries
(BATTERY VERSION)
Adjust the slope of the handle by pul-
ling the handle release lever.
Open the detergent tank tap.
DAILY MAINTENANCE
Empty the dirty water tank.
Clean the dirty water tank.
1
PLDC03727
IP Cleaning S.p.A. - Viale Treviso, 63 30026 Summaga di Portogruaro - www.ipcworldwide.com

CT15R B - C Quick Guide
REPLACING THE SQUEEGEE BLADES
• remove the two squeegees by unscrewing the screws;
• turn the squeegees over;
• remove the worn blades by pulling them off, and then replace them with new ones, inserting the protruding tooth into the socket;
• replace the squeegee on its support;
AUTOMATIC BRUSH ATTACHMENT
Mounting the brush:
• switch the machine off, unplug the cable version from the power socket; raise the front of the machine by hand; with the other hand, insert the
brush and push it upwards until it clicks into position.
Removing the brush:
• switch the machine off, unplug the cable version from the power socket; raise the front of the machine by hand; with the other hand, remove
the brush by pulling it downwards; lower the machine.
THE MACHINE DOES NOT
COME ON/START UP
CHECK THE BATTERY CHARGE (BATTERY VERSION)
CHECK THE POWER CABLE IS PLUGGED INTO A FUNCTIONING SOCKET (CABLE
VERSION)
THE MACHINE LEAVES THE
FLOOR WET
CHECK THE SQUEEGEE BLADES ARE NOT WORN
CHECK THERE IS NO DEBRIS BETWEEN THE TWO SQUEEGEE BLADES
CHECK THERE IS NO DEBRIS IN THE SUCTION HOSE
CHECK THE DIRTY WATER TANK IS NOT FULL
CHECK THE DETERGENT TANK LID IS CLOSED CORRECTLY
CHECK THE SUCTION HOSE IS CORRECTLY ATTACHED TO THE SQUEEGEE
THE MACHINE LEAVES THE
FLOOR DIRTY
CHECK THE TYPE OF BRUSH IN USE IS SUITABLE FOR THE TYPE OF DIRT AND
FLOOR.
THE MACHINE LEAVES
STRIPES OF WET FLOOR
CHECK THE FLOOR HAS BEEN BRUSHED BEFORE USING THE MACHINE
CHECK THERE IS NO DEBRIS BETWEEN THE TWO SQUEEGEE BLADES
CHECK THE SQUEEGEE BLADES ARE NOT WORN
CHECK THE SQUEEGEE IS CORRECTLY ADJUSTED
Check the detergent output lter is
undamaged and clean.
Clean the brush. Check the battery charge (BATTERY
VERSION).
To recharge the batteries, plug in the
battery charger, using the extension
provided with the machine.
Check the squeegee is clean and the
blades are not damaged.
Check the dirty water tank oat is un-
damaged and clean and moves freely
on the pin.
