iQOS lil SOLID 2.0 User manual

User Guide

2
100 - 60 %60 - 30 %30 - 1 %
1. Name and component of each part
Cover of stick
insertion part
Cap
Styler Deco
Button (Status LED light)
When the device is being charged, the State LED lights
Charging Port
Blue Ice Blue Orange Red
needs to be charged
By pressing the Button or once the device is plugged into a power outlet
through the Charging Port, the charging status of the device is displayed.
* Due the nature of the parts used for the State LED, the brightness and
color of the LED light may vary slightly.
• The State LED blinks while the device is being charged
Charge the device before your first use.
Takes approximately 2 hours to be fully
charged, available for use for approximately
25 sticks
• The State LED goes off after the device is fully charged
When the Cap
is removed
(the number of sticks can vary according to
the use environment)
Only use the USB Cable and AC Power Adaptor
designed for lil SOLID™2.0 that come with your
device.
You may charge the device whenever it is
convenient regardless of the battery charge
status.

3
2. Box Contents
lil SOLID 2.0 Device
User Guide, Safety Warnings and Instructions and Warranty
AC Power Adaptor USB Cable
User Kit
Dual
Cleaner

4
Read all instructions in this User Guide
carefully before use to operate the device
in a safe and correct manner.
3. Safety Warnings and Instructions
The Safety Warnings and Instructions
discussed in this User Guide cannot cover
all possible situations that could occur during
the use of the device. Caution and care must
be exercised when using or maintaining an
electronic device.
Keep these safety warnings
and instructions for future
reference as they contain
important information.
Failure to follow these instructions
may result in personal injuries.

Device electronic and battery
• Do not use the device with its Cap removed.
• Be careful not to drop the device in water.
• This product contains no user-serviceable parts.
Do not attempt to open, modify, disassemble or repair
the battery or any component of this device.
• If the device appears to be damaged, modified,
disassembled, tampered with, or immersed in liquid
after purchase, do not activate the device.
• Do not touch the device, AC Power Adaptor and USB
Cable if they overheat, fume, ignite, spark or burn.
• Do not use the device if it has been exposed to excessive
heat.
• Do not connect the device through electric wires or
other metallic materials. Doing so may cause damage.
• Do not use the device where flammable materials, liquids
or gases are present, or under conditions with high
oxygen supply. Doing so presents an explosion hazard.
• Device, AC Power Adaptor and USB Cable should not be
exposed to any liquid, oils, solvents, etc. Do not touch
the device or its parts if it becomes wet or has been
mmersed in liquids, oils, solvents, etc.

6
Use and storage
• Do not clean the device using liquids, oils, solvents, etc.
• Caution must be exercised so that foreign materials
do not enter the stick insertion part. Do not use device
unless foreign particles have been removed.
• If any fluid leaking from the device comes in contact
with skin, wash the affected area, including hands and
do not touch eyes. In case any fluid comes in contact
with eyes, immediately flush with clean, running water
for at least 15 minutes and seek medical attention.
• Do not use the device if battery is leaking.
• Only use USB Cable and AC Power Adaptor designed
for lil SOLID 2.0. See the Technical Data section of this
User Guide for approved Power Adaptor models. Do not
use other cables and power adaptors - doing so may result
in damage.
• Charge the device indoors only, as indicated by symbol
• Only use [Fiit™] tobacco sticks specifically designed for
lil SOLID device. The performance of the device is not

7
guaranteed if you use it with other consumables.
• Do not modify [Fiit] tobacco sticks in any way or add
any substance to [Fiit] tobacco sticks. Doing so may
cause injury.
• This device is intended for adult-use only. Children and
minors should never use the device under any
circumstances.
• The device and tobacco sticks are prohibited for sale
to minors.
• Do not remove Cap while device is in use or immediately
after use as device may be hot. Allow for device to cool
before removing Cap.
• Even if the tobacco stick is removed during use, the
heating process continues. To stop it, turn off power by
pressing the Button for 2 seconds.
• Clean the device after cooling.
• After removing the tobacco stick from the device, do not
touch the tobacco portion of the stick as it will be hot
after use.
• Handle the device with care. Do not drop this device
or subject it to strong shock.

8
• Storing the device in places with high temperatures
(such as inside a vehicle or near heat sources such as
radiators or fires), high humidity or low temperatures,
may reduce battery performance.
• Device battery will deplete if left unused for an extended
period of time. Recharge the device before use.
• [Fiit] Tobacco sticks specifically designed for lil SOLID
device are single-use. Do not re-insert a used stick into
the device. The performance of the device is not
guaranteed if used sticks are re-inserted.
• The tobacco stick should never be lit with a match,
lighter, or any other flame source.
• [Fiit] Tobacco sticks may show spots or discoloration
after normal use.
• Do not insert the device in your mouth.
• Do not operate the device where use of electronic
devices is prohibited.
• This device is not intended for use by persons with
reduced physical, sensory or mental capabilities or
lack of knowledge unless they have been given
supervision or instruction to use the product in
a safe way and understand the hazards involved.

9
Tobacco and nicotine
• Being exposed to sweat, UV rays and chemicals in
a repeated manner may discolor the device exterior.
• Proximity to magnetic field may cause malfunction.
• [Fiit] Tobacco sticks contain nicotine, which is addictive.
Nicotine is naturally present in tobacco used in tobacco
sticks.
• Swallowed tobacco sticks can pose a risk of nicotine
intoxication. If tobacco sticks are swallowed, seek
medical attention immediately.
• The best way to reduce tobacco-related health risks
is to quit tobacco and nicotine use altogether.
• Stopping smoking cigarettes or switching to other
nicotine-containing products may require the
adjustment of the dosing of certain medicines
(e.g. theophylline, clozapine, ropinirole).
• Using nicotine-containing tobacco sticks may cause
side effects such as headache, nausea, throat irritation,
or stomatitis. If you experience these symptoms,
stop use of the product immediately.

10
• If you are pregnant, think you may be pregnant, or are
breastfeeding, or have heart disease, diabetes, epilepsy,
seizures or other serious conditions, you should quit
tobacco and nicotine use altogether and consult a health
care professional.
• Use of tobacco sticks may cause an allergic reaction.
Seek medical attention immediately if you experience
any of the following symptoms: swelling of the face, lips,
tongue, etc., and/or difficulty breathing.
Reporting of adverse events or incidents
• If you experience any unwanted health effect when using
the device, consult a health care professional.
• You can report any adverse event or incident directly by
contacting Customer Service Centre - Czech republic:
800 413 413, Slovakia: 0800 400 600.
• By reporting side effects, you can help provide more
information on the safety of this product.

11
①
②
Steps before use
To conserve battery life, the device will return to sleep mode:
The device is in the sleep
mode and does not operate
unless activated for your first
use. To wake up the device
press the Button for
2 seconds or connect the
charger to the charging port.
Get your device. Slide and open the Cover
of the stick insertion part
at the top of the device.
Insert a [Fiit] tobacco stick
designed for lil SOLID into
the stick insertion part with
the tobacco part facing down
and press the stick in until
it touches the bottom of the
stick insertion part.
While the device wakes up,
the Status LED blinks twice
n red, orange, ice blue and
blue, sequentially.
Once the device is activated,
the Status LED blinks in ice
blue for one second and
vibration occurs twice,
simultaneously.
if it is not charged for 24 hours when the Status LED light is red.
• If you insert the stick upside down, the device can break down during use. Please check the insertion direction
of the stick before use.
• Close the cover of the stick insertion part when the device is not in use to prevent any substances from
getting inside.
if it is not used for 7 days when the Status LED light is orange, ice blue, or blue.
4. Use

12
Start device
Use
Press the Button for 2 seconds and remove the tobacco stick only if you want to stop
the session and the use of the device.
The device with [Fiit] tobacco
stick is ready to use. You
have up to 14 puffs or
5 minutes, whichever
comes first.
To signal the last 30 seconds
of the session or the last
3 puffs, whichever comes
first, the device will vibrate
once and the State LED will
blink in ice blue until the end
of the session.
When the session comes to
an end, the State LED and the
device turn off automatically.
You do not need to press the
Button.
Press the Button for 2
seconds until vibration
occurs.
After 2 seconds, the State LED
blinks in ice blue, and vibration
occurs simultaneously. During
around 25 seconds, the
preheating process starts.
The duration time of the
preheating process can
vary according to the use
environment.
When the preheating process
ends, the State LED lights
come on, and vibration occurs
simultaneously. This means
that the preheating process
has ended, and the stick is
ready for use.

If there are some remnants inside the stick insertion part, refer to of 6. Troubleshooting.
13
3x
Removing the tobacco stick
Consecutive uses
Unscrew the stick to one
direction 3 times or more.
For consecutive use, please repeat the above . May use up to 3 consecutive uses.
Pull the stick out the device. Close the Cover of the stick
insertion part.
If a stick is not removed as described above, the remnants of a used stick may remain inside.

14
◉
Cleaning with the Dual Cleaner
Grab the Dual Cleaner.
Remove the Cap from the
device.
Insert the Cleaning Wiper
into the device and clean
the device by spinning the
Cleaning Wiper.
Insert the Cleaning Brush
into the device and clean the
device by spinning the
Cleaning Brush.
To use the Cleaning Wiper,
gently snap open the side
with the mark.
To use the Cleaning Brush,
gently snap open the side
with the mark.
5. Cleaning and handling
* We recommend cleaning the device after using 20 sticks for optimum performance of the device.
* Do not clean the device during heating or right after the use of the device. Let the device to cool down,
otherwise the Cleaning Wiper or the Cleaning Brush can melt and stick to the device.
* Take care not to let the Cleaning Wiper or the Cleaning Brush come into contact with any liquid, oils,
solvents, etc.
* Take care not to let the Cleaning Wiper or the Cleaning Brush come into contact with eyes.
* Keep the Cleaning Wiper or the Cleaning Brush away from fire.
* Caution should be exercised when using the Cleaning Wiper and Cleaning Brush as they can be sharp.
* Use of other cleaning tools aside from Cleaning Wiper or Cleaning Brush or using excessive force may
damage the heater.

Cleaning with heat
Quickly press the Button
5 times (within 2 seconds).
The State LED blinks in
orange, for 90 seconds, and
the cleaning process
proceeds automatically.
When the cleaning process
ends, the State LED
automatically goes off,
and vibration occurs 2 times.
* Cleaning with heat means heating the remnants stuck to the heater. The heater can get very hot, so do
not let anything come into contact with the heater during or immediately after cleaning with heat.

16
I cannot insert the stick into the device
My device does not work
If there are remnants from the previous stick inside the stick insertion part, a stick may not
be inserted. Remove the remnants by pulling the Cap out of the device and try to insert the
stick again.
Check for any remnants
inside the stick insertion
part.
State LED lights in red for
3 seconds and vibration
occurs 3 times,
simultaneously. The battery
is insufficient. Charge the
device.
State LED blinks in red
5 times. The device is
malfunctioning. Reset the
device.
State LED blinks in orange for
3 seconds. After 3 consecutive
sessions the device will cool
down automatically. Please
wait until the device
temperature is stabilized.
If there are remnants of
a used stick, remove the
Cap from the device.
Remove the remnants from
the Cap.
6. Troubleshooting
* For your safety, the device cannot be used more than 3 times within 18 minutes as it needs to cool down.
It will take 3 minutes 30 seconds before you can have another session.

17
How can I reset the device?
The duration of using the stick is too short.
Press the Button for 8
seconds, even if vibration
occurs within 2 seconds.
The device is reset, and the
State LED blinks twice in red,
orange, ice blue and blue,
sequentially.
When the device is completely
reset, the State LED lights in
ice blue for 1 second, and
vibration occurs twice,
simultaneously.
7. Disposal
The device is designed to provide up to 14 puffs or 5 minutes, whichever comes first.
The warranty period for the device is one year, subject to the terms and conditions described
in the warranty.
• The device uses a lithium ion battery. Dispose your device in accordance with the applicable
regulations.
• Please contact the local municipal authorities to learn more information about the disposal
of the device and the power adaptor.

18
Warranty Period
Warranty Coverage
Exclusions to warranty
8. Warranty
• The duration of this product warranty on lil SOLID device, AC Power Adaptor and USB Cable
is 12 months from the date of purchase.
• In the absence of the proof of purchase, the company reserves the right to voluntarily apply
the warranty duration starting from the manufacturing date of the product in question based
on its own records.
• The company will, at its option (but without affecting your statutory rights), repair or replace
any components which are defective in terms of material or workmanship when used in
accordance with the associated lil SOLID 2.0 User Guide and which are subject to a valid
warranty claim.
• If repair is not possible, replacement will be provided with a product of equivalent functionality.
To the extent permitted by local law, the replacement color and/or model are subject to such
color and/or model availability. In case of replacement of the product under this warranty,
any replacement part becomes your property and the replaced part becomes the property
of the company or entity which makes the exchange.
• The provisions of this warranty are only valid in the country of purchase.
Products with expired warranty or damaged by consumer negligence are excluded from
the warranty service.
The following are excluded from the terms of this warranty:
a) malfunction damage caused by normal wear and tear elements;
b) cosmetic damages (such as scratches, dents, broken plastic etc.) that do not impact the
functionality of the product;
c) damage caused by misuse, abuse, accidents, unsuitable operating environment, natural
disasters, power surge, contact with liquids or fire;
d) malfunction due to use with non-compatible consumables, power adaptor or cable;
e) damage or malfunction caused by attempt to open, modify and repair, either by a user or by
a service provider not accredited by the manufacturer;

19
Claim under warranty
Other
f) damage or malfunction caused by failure to use as described in the associated
lil SOLID 2.0 User Guide;
g) normal battery performance depreciation, unless battery failure has occurred due to
a defect in materials or workmanship;
h) devices containing fully or partially non genuine parts;
i) loss or theft of the product or its parts;
j) operation of the product in a country for which it was not originally designed or approved.
To make a claim under this warranty, please contact your Customer Service Centre number
below for assistance or visit one of our stores. It is recommended to have a proof of
purchase when making a warranty claim.
Under no circumstances is the company liable for any personal or third-party claims for
damages related to the use of the product besides the ones mentioned in this document.
This limitation does not apply for cases where the company is liable towards you under law.
In EU member states buyers may have rights and remedies against the seller for a longer
period, at least two years, in respect to any defect existing at the time of delivery.

Model: HM-1007EMTE
Input: 100-240 V ~ 50-60 Hz 0.35 A
Output: 9.0V 1.67A or 5.0V 2.0A
Output power: 15.0W or 10.0W
Average active efficiency: 86.15% or 82.95%
Efficiency at low load (10%): 81.05% or 80.00%
No load power consumption: <0.07 W
20
lil SOLID 2.0
AC Power Adaptor
USB Cable
Dual Cleaner
BATTERY REMOVAL INSTRUCTIONS (FOR DISPOSAL AND RECYCLING)
9. Technical Data
Model: S-MONO-21
Battery type: Li-ion rechargeable battery
Input: 5.0V 2.0A
The lil SOLID 2.0 is marked with the symbol
that lil SOLID 2.0 can only be charged using the approved Power Adaptor models designed for lil SOLID 2.0.
followed by “xx-1007EMTx,” which indicates
To find out the month and year of manufacturing of the lil SOLID device you should call the
Customer Service Centre and tell the 14-digit alphanumeric code placed under the cap of
the device.
Storage conditions: in dry, conditioned premises, temperature regime: from 5 °C to 30 °C
relative humidity less than 70%.
Customer Service Centre - Czech republic: 800 413 413, Slovakia: 0800 400 600.
Battery must not be removed by the consumer. At the end of product life, only an authorized
recycler may safely remove battery by using the following steps.
