Rothan
Owner’s Manual

Rothan www.islabikes.co.uk
1. Brake levers
2. Brake pads
3. Saddle
4. Seatpost
5. Seatpost clamp
6. Stem
7. Stem bolts
8. Headset
1. Turn handlebars clockwise and align with front wheel
2. Tighten stem clamp bolt max 7Nm
Failure to correctly tighten stem clamp bolt may result
in serious injury or death. If in doubt, please consult our
technical support team on [phone]
or email [e-mail].
9. Headset spacers
10. Headset adjuster bolt
11. Handlebars
12. Rim
13. Spokes
14. Tyres
15. Frame
16. Fork
Step 1 of 2
Handlebar set up
6
1.Turn
Do Not
Tighten
2.Tighten
Your Rothan must be assembled and checked by a suitable
adult using the steps detailed in this owner’s manual.
5
4
10
1
8
7
9
11
14
12
15
2
16
13
3

Rothan www.islabikes.co.uk
Step 2 of 2
Adjust saddle height
1. Loosen seatpost clamp
2. Move to desired height
3. Tighten clockwise max 5Nm
Seatposts are clearly marked with minimum insertion mark.
Please do not raise saddle above this line.
Set the Rothan saddle height so that the riders feet are at on the ground
with a small bend in the knee.
Tighten

Rothan www.islabikes.co.uk
Safety rst
Before you head o please read our advice for safe scooting. If you are
the responsible adult, parent or guardian we recommend the following
precautions:
Supervising your child’s use of Rothan as they develop the skills
required to scoot independently. This is to avoid falls or collisions
causing injury to your child or other third parties.
Avoid scooting by any busy streets, roads, highways or other
external hazards to prevent serious injury if your child loses control.
Ensure that a helmet is worn and adjusted correctly in accordance
with the manufacturer’s instructions.
Ensure your child is wearing sturdy footwear.
Ensure that your child familiarises themselves with their new
bicycle in a safe environment.
We pride ourselves on light action brakes. Check your child can
come to a stop by pulling the brake lever towards the handlebar.
Walk beside them and assist them in pulling the brake to allow
them to feel its responsiveness.
Your Islabike is set up so the left brake operates the rear.
Be aware braking performance and grip will be drastically reduced
in wet conditions.
Always observe national legal requirements if riding on public
roads. We don’t recommend your child riding at night. If you
are cycling in any other countries or in the EU, please check
national guidelines.
Tumbles are an inevitable part of riding a bike and sometimes the
bike can get damaged. It is very important that a bike is inspected
if an accident occurs. Here are some things to look out for:
Handlebar ends becoming exposed from repeated contact
with the ground or heavy fall. Never let a child ride a bike with
an unplugged handlebar end. You can buy replacement
handlebar grips on our website www.islabikes.co.uk
or call [phone].
Front brake damage can occur in a crash. If the handlebars become
twisted from a crash the cable can wrap itself tightly and damage
the noodle hinge dock. This has been reinforced on our bikes but
they are not indestructible. Always check the front brake operates
correctly and the brake hinges were not damaged after a crash.
You can easily perform a visual inspection by comparing to the rear
brake. You are unsure please contact our technical support team on
[phone] or email [e-mail].

Rothan www.islabikes.co.uk
Usage guidelines
Your Rothan has been designed to be ridden by children away
from motorised vehicles on smooth paved or grassy areas.
Although we test our bikes beyond their intended weight and
usage, the maximum safe combined rider and luggage weight
limits are as follows:
• Rothan 12 = 20Kg
• Rothan 14 = 28Kg
Nothing lasts forever, including your bike. When the useful life of
your bike or its components are over, continued use is hazardous.
Materials and components may react to wear or stress fatigue in
different ways. If the design life of a component has been exceeded
it may suddenly fail, possibly causing injuries to the rider. Every
bike and its components parts have a nite life. The length of that
life will vary with the construction and materials used in the frame
and components. Your bike and its components are subject to
fatigue. With enough use at high enough loads cracks can develop
that could lead to failure. Cracks, scratches or a change of colour
could indicate that the design life of the component has been
reached and it should be replaced. Extra care should be taken
when inspecting parts that are subject to high levels of stress.
Please note your bike is not intended for the following types of riding:
• Dirt jumping • BMX
• Downhil • Enduro
• Slalom • Parents having a go...
Factors that can reduce product lifespan include:
Impacts to the bike from crashes, bumps or jumps.
Exceeding the maximum weight limit for the bike.
High mileage/usage.
Environmental conditions (unusually damp/saline(salty)
atmosphere, muddy or sandy conditions).
Poor maintenance and use out of correct adjustment.
Unsympathetic riding style.
Factors that can increase product lifespan include:
Regularly cleaning and maintaining your bike.
No impacts to the bike from crashes, bumps or jumps.
Observing the maximum weight limit for the bike.
Environmental conditions (dry, clean, non-corrosive environment).
Sympathetic riding style.
It is not possible to make a bike that is impervious to damage.
If you crash, damage or use the bike beyond its limitations, there is
a higher risk of failure which could result in serious injury or death.
Bikes that are used competitively should be subject to more frequent
and rigorous checks. Take particular care to check the frame tube
junctions and welds as well as all the components for damage or
excessive wear. If in any doubt, please contact our technical support
team on [phone] or email [email protected].
Or take it to a qualied cycle mechanic for inspection.

Rothan www.islabikes.co.uk
Guarantee
Your Islabike comes with a 5-year guarantee on frame and forks and a 2-year
guarantee on parts. This covers faulty manufacturing, but not normal wear
and tear. This guarantee only applies to the original purchaser of the bike.
Your statutory rights are not aected by the guarantee.
Our clearance bikes have the following guarantees, these apply to the
original purchaser and are only valid within the UK.
Ex-display / Demo: 5-years frame and forks / 2-year parts
Second hand: 12-months frame and forks
Our bikes are not guaranteed for racing in sanctioned or competitive
events. The use of a bicycle in hazardous conditions including
changeable and uneven surfaces can put high, unpredictable loads
on the bicycle and its components. Lack of rider skill and experience
can further increase these loads leading to the possibility of serious
damage to the bicycle and/or injury to the rider. If you choose to
participate in these events then please carry out more frequent and
thorough maintenance and checks, including regularly inspecting
the frame, fork, stem, cranks and handlebars for signs of damage.
Discontinue use immediately if anything untoward is spotted and
contact our technical support team on [phone] or email
[e-mail].
Maintenance
Keeping your bike clean and maintained comes with many benets. Not
only will your Islabike perform better but it will be safer, last longer and look
great. To do this we have listed some regular checks to help you along the
way. Of course, if you are unsure of anything we strongly recommend you
seek professional advice or contact our technical support team
on [phone] or email [e-mail].
Firstly, moving parts on your cycle will need lubricating from time to
time. Weather conditions are generally the biggest factor that determine
frequency of maintenance and lubrication. However, it is also heavily
dependent on the frequency, type and duration of riding.
Component Lubricant Frequency
Brake cables Oil Weekly or after washing / rain
Wheel bearings Grease 6 months
Headset n/a Sealed bearings

Rothan www.islabikes.co.uk
Brakes
One of the most important safety features of your Islabike. It is a good habit
to check the brakes on a regular basis. This should be done depending on
the type, frequency or duration of riding. If your bike has not been used for
a period of time, we recommend a quick check before riding.
Safety check
Before every ride:
Give the brakes a few pulls to check they are working – If the brakes
feel smooth and the brake levers are not moving all the way back to the
handlebar this is a good sign. If the brakes contact the handlebar or are
difcult to operate please view http://www.islabikes.co.uk/info-hub/how-to-
check-your-brakes-video.
Check pads contact the rim correctly when braking – Pull on one brake
at a time and check the brake pads touch the rims nice and evenly.
Check pads are not fouling the rim – Lift the front of the bike off the
ground with the handlebars and give the front wheel a spin. If the wheel
spins freely your brakes are not fouling. Repeat the process for the rear
ensuring you spin the wheel forwards and your child does not put his/her
hands in the wheel.
Check pads are not worn out – Brake pads do not last forever. Eventually
they will need replacing. Again, this will depend on the type, frequency
and duration of riding. Our brake pads come with a wear indicator line. If
your brakes are now worn down to this line or you cannot nd the line you
should replace your brake pads immediately. We highly recommend this is
carried out by a trained cycle mechanic.
If in doubt please contact our technical support team on
[phone] or email [e-mail].
Wheels
Rim wear - Routinely check your bicycle rims for any wear. Our bikes have
an indicator line that runs the circumference of the rim. When this becomes
ush with the rest of the rim or disappears it is time to replace the wheel.
For new wheels contact our customer service team on [phone]
or email [e-mail]..
Rim trueness – Depending on the type of riding you do your Islabikes
bikes wheels may become untrue or damaged when riding. This means
they will not spin straight and will wobble. If for any reason they are untrue
our wheels can be easily repaired, please contact our technical support
team on [phone] or email [e-mail].
Hubs - Your hubs are tted with cup and cone bearings. Although they
are sealed water and grit can enter your hubs and cause premature
wear. To prolong the life and keep them running smooth and ecient.
We recommend annual maintenance and re-greasing of hub bearings.
Wear
indicator

Rothan www.islabikes.co.uk
Tyres and Tubes
Tyre wear - Regularly check tyres for general wear and tear. Over time
your tyres will become more worn and can become more susceptible
to punctures.
Tyre pressure - Regularly check your Islabike tyre pressure as they slowly
go down over time. To check, simply push your thumb hard onto the tyre or
use a pressure gauge tted to most quality bicycle track pumps. If you can
touch the rim this probably needs some more air.
You should not exceed the maximum tyre pressure printed on the
sidewall of the tyre. We recommend approx. 70% of the maximum
tyre pressure illustrated on your tyre. To inate presta valves you
must rst open the valve by unscrewing and tapping the valve end
to relieve it if stuck. Inate to correct pressure and then carefully
re-tighten to close the valve.
When re-inating a tyre or after changing an inner tube ensure
tyre is seated centrally on rim and continually check around the
rim as you inate to ensure rim is seated correctly and prevent tyre
blowing off rim.
Use our guide to inate your tyres: http://www.islabikes.co.uk/info-hub/how-
to-inate-your-tyres-video.
Valve closed Valve open
Recommended torque settings
All stem bolts 7Nm
Seatpost collar bolt 5Nm
Wheel bolts 8Nm
Brake pads 6Nm
Brake cable pinch bolt 6Nm
Brake arm xing bolts 6Nm
Spares and replacement parts
We carry stock of replacement parts for your Islabike including inner tubes,
tyres and grips. Please visit our website for a list of readily available spares
or contact us on [phone] or email [e-mail].
We only recommend using genuine parts for safety critical components
e.g. brake cables, brake blocks and bolts.
If you can’t nd what you are looking for or are unsure of any compatibility
for older models, please contact our technical support team by phone
or email.
[e-mail]
[phone]
www.islabikes.co.uk/info-hub

Rothan www.islabikes.co.uk
Frame number
Please make a record of your frame number. This is a combination of
letters and numbers unique to your bike stamped to the underside of the
frame. This is required by police and insurance companies in case of loss.
Frame
number
Declaration of conformity
Product Name:
Islabikes Rothan
Manufacturer Address:
Islabikes Ltd, Unit 10 Lower Barns Business Park, Ludlow, Shropshire, SY8
4DS, UK
This declaration of conformity is issued under the sole responsibility of the
manufacturer, Islabikes Ltd.
The object of the declaration is the
Islabikes Rothan as shown in the
image to the right:
This is available in two size variants;
12 & 14.
The object of the declaration described in point 4 is in conformity with the
relevant Union harmonisation legislation and standards:
2009/48/EC & BS EN71 – Safety of Toys*
General Product Safety Regulation
Restriction, Evaluation, Authorisation and Restriction of Chemicals
(REACH) Directive
CE Certication*
* Conformity is based upon third-party advice from Bureau Veritas on the testing required to
reach full compliance.
Isla Rowntree
Product Director & Founder, Islabikes Ltd

Rothan www.islabikes.co.uk

www.islabikes.co.uk
