IXXAT iPC-I 320/PCI II User manual

The expert for industrial and automotive communication
Hardware Manual
iPC-I 320/PCI II
Intelligent PC/CAN Interface

IXXAT
Headquarter US Sales Office
IXXAT Automation GmbH IXXAT Inc.
Leibnizstr. 15 120 Bedford Center Road
D-88250 Weingarten USA-Bedford, NH 03110
Tel.: +49 (0)7 51 / 5 61 46-0 Phone: [phone]
Fax: +49 (0)7 51 / 5 61 46-29 Fax: [phone]
Internet: www.ixxat.de Internet: www.ixxat.com
e-Mail: [email protected] e-Mail: [email protected]
Support
In case of unsolvable problems with this product or other IXXAT products
please contact IXXAT in written form by:
Fax: +49 (0)7 51 / 5 61 46-29
e-Mail: [email protected]
Copyright
Duplication (copying, printing, microfilm or other forms) and the electronic
distribution of this document is only allowed with explicit permission of
IXXAT Automation GmbH. IXXAT Automation GmbH reserves the right to
change technical data without prior announcement. The general business
conditions and the regulations of the license agreement do apply. All rights
are reserved.
Document number: 4.01.0039.20000
Version: 1.0

Contents
1 Introduction....................................................................................5
1.1 Overview ............................................................................. 5
1.2 Features............................................................................... 5
1.3 Support ............................................................................... 6
1.4 Returning hardware............................................................ 6
1.5 Block diagram ..................................................................... 7
2Installation ..................................................................................8
2.1 Software installation .......................................................... 8
2.2 Hardware installation ......................................................... 8
3Configuration .............................................................................9
3.1 Settings on the interface .................................................... 9
3.1.1 CAN bus connection .................................................................9
3.1.2 PCI bus connection .................................................................11
3.1.3 Switching between loader and application mode (S401, SW1)11
3.1.4 EPLD update (S401, SW2) .......................................................11
3.2 CAN bus terminal.............................................................. 11
4Appendix...................................................................................12
4.1 Technical Data ................................................................... 12
4.2 Accessories ........................................................................ 13
4.2.1 CAN bus terminal resistor........................................................13
4.3 FCC Compliance ................................................................ 13
4.4 EC Declaration of Conformity........................................... 14
Copyright IXXAT Automation GmbH iPC-I 320/PCI II - Manual, Version 1.0
3

Introduction
1 Introduction
1.1 Overview
With the IXXAT PC/CAN interface iPC-I 320/PCI II you have purchased a high-
quality electronic component which has been developed and manufactured ac-
cording to the latest technological standards.
The aim of this manual is to help you familiarize yourself with your interface, also
referred to in the following as iPC-I 320/PCI II. Please read this manual before be-
ginning with the installation.
1.2 Features
The most important technical features are as follows:
• 5 V - PCI - connection in accordance with PCI specification 2.1,
32 bit, 33 MHz
• 32 bit memory mapped access (needs 8 kBytes memory and 128 Byte I/O ad-
dress space)
• Micro controller DALLAS 80C320 clocked with 22,1184 MHz (code compati-
ble with INTEL 8032)
• 4 kBytes Dual-Port-RAM, 8 semaphore registers
• 2 x 63,75 kBytes flash memory
• Up to 63,25 kBytes code can be downloaded
• Up to 2 x 56 kBytes XDATA-RAM addressable
• One ore two CAN circuits with Philips SJA1000 CAN controller
clocked with 16 MHz
• CAN bus interface according to ISO/IS 11898-2 on board (High Speed);
optional galvanic decoupled
Copyright IXXAT Automation GmbH iPC-I 320/PCI II - Manual, Version 1.0
5

Introduction
1.3 Support
For more information on our products, FAQ lists and installation tips, please refer
to the support section of our website (http://www.ixxat.de), which also contains
information on current product versions and available updates.
If you have any further questions after studying the information on our website
and the manuals, please contact our support department. The support section on
our website contains the relevant forms for your support request. In order to fa-
cilitate our support work and enable a fast response, please provide precise in-
formation on the individual points and describe your question or problem in de-
tail.
If you would prefer to contact our support department by phone, please also
send a support request via our website first, so that our support department has
the relevant information available.
1.4 Returning hardware
To enable fast, correct processing of returns, please apply for an RMA number
before returning hardware using our on-line "RMA form", which you will find in
the Support section on our website.
After applying for the RMA number, you will receive a return delivery note from
us, which you should enclose with the return delivery. If returns are made with-
out an RMA number or a return delivery note, we reserve the right to return the
delivery at your expense. A detailed description of the RMA procedure can be
found in the Support section on our website.
Copyright IXXAT Automation GmbH iPC-I 320/PCI II - Manual, Version 1.0
6

Introduction
1.5 Block diagram
FLASH
CAN Bus
A 0..15
PC
iPC-I320/PCI
AD 0..7
A 0..15
SRAM Address
Decoder
2. CAN
Controller
SJA1000
CAN Bus-
Ankopplung
Address
Latch
RESET
RS232 /
SPI
TxD RxD
CAN High
CAN Low
1. CAN
Controller
SJA1000
CAN Bus-
Ankopplung
PCI-Bus
DPRAM and Flags
Microcontroller
DS80C320
PCI-Target Controller
A 0..15AD 0..7
IRQ
Fig. 1-1: Block diagram iPC-I 320/PCI II
Copyright IXXAT Automation GmbH iPC-I 320/PCI II - Manual, Version 1.0
7

Installation
2 Installation
2.1 Software installation
A PC driver is required to operate the interface. This driver is an integral part of
the VCI (Virtual CAN Interface), which can be downloaded free of charge from
the Internet at http://www.ixxat.de.
For installation of the VCI driver under Windows, please refer to the VCI installa-
tion manual.
2.2 Hardware installation
Before inserting the iPC-I 320/PCI II in the PCI slot, you should install the software
driver (see previous section).
For all work on the PC and interface, you must be statically discharged. Work
must be carried out on an earthed, anti-static work mat.
Take the following steps in sequence:
(1) Switch the PC off and remove the mains plug.
(2) Open the PC according to the instructions of the PC manufacturer and find a
suitable slot.
The interface is designed according to the PC standard and can easily be in-
stalled the computer. Do not use force when plugging in.
(3) Make sure the interface sits tightly in the PC.
(4) If your interface is assembled with 2 isolated CAN-circuits, you must fix the
additional slot plate and plug in the header on the interface (see section
3.1.1).
(5) Close the PC; the hardware installation is now complete.
Copyright IXXAT Automation GmbH iPC-I 320/PCI II - Manual, Version 1.0
8

Configuration
3 Configuration
3.1 Settings on the interface
The diagram Fig. 3-1 shows the positions of the plugs and the dip-switches on
the interface.
Fig. 3-1: iPC-I 320/PCI II interface
3.1.1 CAN bus connection
One (common) or two high-speed bus transceivers according to ISO/IS 11898-2
may be present on the iPC-I 320/PCI II interface. The signals of the first bus trans-
ceiver connect with the 9-pin sub-D pin/bush X501/X502. If two isolated bus
transceivers are assembled, the signals for the CAN bus of the second bus trans-
ceiver connect with the header X601. As an option, the bus connection can be
galvanically isolated from the CAN bus.
Copyright IXXAT Automation GmbH iPC-I 320/PCI II - Manual, Version 1.0
9

Configuration
The shield of the CAN socket is connected via a 1 MΩresistor and a 10 nF capaci-
tor to the ground of the CAN connection. In the case of a non-galvanically iso-
lated device version, CAN ground and PC ground have to the same potential.
Maximum interference immunity is achieved when the shield of the CAN cable is
earthed.
The assignment of the Sub-D connectors is shown in Table 3-1.
Pin no. X501/X502 Signal
1 Not connected
2 CAN-Low_1
3 GND/GND_1
4 Not connected
5 Not connected
6 Not connected
7 CAN-High_1
8 Not connected
9 Not connected
Table 3-1: Pin assignment of X501 und X502
The pin assignment of the 10 pin plug X601 for the connection of the second
CAN line is showed in the following table:
Pin no. X601 Signal
1 Not connected
2 Not connected
3 CAN-Low_1
4 CAN-High_1
5 GND/GND_2
6 Not connected
7 Not connected
8 Not connected
9 Not connected
10 Not connected
Table 3-2: Pin assignment of X601
Copyright IXXAT Automation GmbH iPC-I 320/PCI II - Manual, Version 1.0
10

Configuration
3.1.2 PCI bus connection
The assignment of the PCI connector is designed in accordance with the PCI
specification 2.2. The iPC-I 320/PCI II can be operated in a 5 V PCI signal envi-
ronment. The maximum PCI bus frequency with which the interface can be oper-
ated is 33 MHz.
3.1.3 Switching between loader and application mode
(S401, SW1)
By using dip switch S401 (SW1), it can be achieved that the board executes a user
defined application after reset, which has to be in flash bank 0. As default, the
IXXAT boot loader, which is in flash bank 1, is executed.
Mode S401, (SW1)
Loader mode (default) OFF
Application mode ON
3.1.4 EPLD update (S401, SW2)
Using dip switch S401 (SW2), allows to perform an EPLD update while the board
is installed in the PC.
Mode S401, (SW2)
Programming disabled (default) OFF
Programming enabled ON
3.2 CAN bus terminal
There is no bus termination resistor for the CAN bus assembled on the iPC-I
320/PCI II board. A bus terminal resistor in the form of a feed-through connector
is available as an accessory from IXXAT (order number 1.04.0075.03000).
Copyright IXXAT Automation GmbH iPC-I 320/PCI II - Manual, Version 1.0
11

Appendix
4 Appendix
4.1 Technical Data
The following data refer to the iPC-I320/PCI II interface version with two Philips
SJA1000 CAN controllers and two galvanically isolated bus transceivers according
to ISO/IS 11898-2.
PCI interface: 32 Bit / 33 MHz, PCI Specification 2.1
Microcontroller: Dallas DS80C320-ECG, 22,1184 MHz
RAM / Flash: 128 kByte / 128 kByte
CAN controller: Philips SJA1000T, 16 MHz
CAN transceiver (high-speed): Texas Instruments SN65HVD251 or
Philips PCA 82C251
Max. number of CAN bus nodes: 120
CAN bus terminal resistor: none
CAN run trip delay: with galv. isolation typically 50 ns, max. 75 ns
CAN baud rates: 5 kBaud – 1 MBaud
Max. CAN throughput per channel:
9500 messages/s (Reception with VCI V3)
2000 messages/s (Transmission with VCI V3)
Galvanic isolation: 500 V AC for one minute between CAN bus and
internal logic
Power supply: 5 V DC ±5 % via PCI slot
Power consumption: typically 320 mA
max. 380 mA
Dimensions: 124 mm x 97,5 mm (without CAN Sub-D9
connectors)
Weight: without additional slot plate for second CAN
approx. 91 g
with additional slot plate for second CAN
approx. 128 g
Working temperature range: 0 - 70 °C
Storage temperature range: -40 °C .. +85 °C
Relative humidity: 10 - 95 %, non-condensing
Copyright IXXAT Automation GmbH iPC-I 320/PCI II - Manual, Version 1.0
12

Appendix
EMC test in accordance with: EN 55022:1998 + A1:2000 + A2:2003
(Limit class B)
EN 55024:1998 + A1:2001 + A2:2003
FCC Rules 47 CFR Part 15 – Subpart B
Alternative IEC/CISPR22:1997 + A1:2000
+ A2:2002 (Limit class B)
Device safety: CSA/UL 60950-00 Class 3862 10, 3862 90
4.2 Accessories
4.2.1 CAN bus terminal resistor
To terminate the CAN bus, a Sub-D9 feed-through connector with integrated 120
Ohm bus terminal resistor is available.
Order number: 1.04.0075.03000
Fig. 4-1: CAN bus terminal resistor and internal wiring
4.3 FCC Compliance
Declaration of conformity
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
• this device may not cause harmful interference, and
• this device must accept any interference received, including interference that
may cause undesired operation.
Class A digital device instructions:
Note: This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are de-
signed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
Copyright IXXAT Automation GmbH iPC-I 320/PCI II - Manual, Version 1.0
13

Appendix
uses, and can radiate radio frequency energy and, if not installed and used in ac-
cordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the
interference at his own expense.
4.4 EC Declaration of Conformity
IXXAT Automation hereby declares
that the product: iPC-I 320/PCI II
with the article numbers: 1.01.0039.10100
1.01.0039.10200
1.01.0039.11110
1.01.0039.11220
1.01.0039.90001
1.01.0039.90002
1.01.0039.90003
1.01.0039.90004
1.01.0039.90006
complies with the EC-directive: 89/336/EEC.
This declaration applies to all devices bearing the CE symbol and loses its validity
if modifications are made to the product.
2006.06.23,
Dipl.-Ing. Christian Schlegel
Managing Director of IXXAT Automation GmbH
Copyright IXXAT Automation GmbH iPC-I 320/PCI II - Manual, Version 1.0
14
