j5 create Ultra Station User manual

JUD500
Ultra Station
User Manual

2
Table of Contents
GETTING STARTED..............................................................................................................................5
INSTALLATION FOR WINDOWS..........................................................................................................6
Device Driver Installation..........................................................................................................6
Verify Device Driver Installation ...............................................................................................8
Setup The Sound .......................................................................................................................9
Device Driver Un-installation ..................................................................................................11
INSTALLATION FOR MAC ................................................................................................................12
Device Driver Installation........................................................................................................12
Setup The Sound .....................................................................................................................15
Verify Device Driver Installation .............................................................................................16
Device Driver Un-installation ..................................................................................................16
INSTALLATION FOR WORMHOLE ....................................................................................................17
GETTING STARTED-MAC ..........................................................................................................17
GETTING STARTED-Windows....................................................................................................18
FUNCTIONS INSTRUCTIONS: WINDOWS 7.......................................................................................19
FUNCTIONS INSTRUCTIONS: WINDOWS XP ....................................................................................23
FUNCTIONS INSTRUTIONS: MAC .....................................................................................................28
FUNCTIONS INSTRUTIONS: WORMHOLE .........................................................................................30
TECHNICAL SUPPORT ......................................................................................................................39
WARRANTY OF j5 create ................................................................................................................39

ULTRA STATION USER MANUAL
3
This intelligent USB 3.0 Laptop Docking Station enables you to add a 2nd monitor instantly via
HDMI or VGA connectors. When you need to get things done fast, simply connect your
monitor, keyboard, mouse, Ethernet, speakers, microphone and any other USB3.0 / 2.0
peripheral to your laptop with one USB 3.0 cable. Now you can use the Ultra Station’s
Keyboard / Mouse “Wormhole” functions to drag & drop across two computers for file
copying & sharing. It is the perfect solution for expanding your Ultrabook or MacBook ® into a
full sized workstation and it increases productivity with its cross-platform multitasking ability.
Required Environments
 Microsoft Windows 7/XP (32-bit or 64-bit) Compatible
 Mac OS X 10.6 Snow Leopard /10.7 Lion Compatible
 Available USB port(USB 3.0 is recommended)
 Minimum System Requirements
CPU: Intel 2 core Quad 2.33 GHz
RAM: 2 GB DDR2
 iPad: USB connection kit
Note for Video Player:
*Windows XP user: “Windows Media Player” is recommended for video playback
*Windows XP user & MAC user: Windows XP & MAC products are not supported by USB
3.0 at this time, therefore we suggest USB 2.0 for ‘office application’ only; Video
Playback is not recommend due to USB 2.0 bandwidth limitations causing limited video
performance.
Physical Specifications
Power (1)
Power Button
Blue Light when power is supplied to the docking station.
Power Mode
Self-powered
Power Adapter
Input: AC 100-240V, 50~60 Hz
Output: DC 5V/4A

4
Host (2)
Upstream Port
USB 3.0 Micro B Female connector
Cable
USB 3.0 Micro B to Type A
Hub
Downstream Port
(3)
USB 3.0 Type-A Female Connector with Battery Charge
Downstream Port
(4)
USB 3.0 Type-A Female Connector
Downstream Port
USB 2.0 Type-A Female Connector
Video
VGA Port (5)
DB 15pin Female Connector
HDMI Port(6)
Standard HDMI Female Connector (Include Audio)
Support Modes
Extended, Mirror, Primary Display
Display Rotation: 0°, 90°, 180°, 270°
Resolutions and
Color Depth
Aspect Ratio
Resolution
Color Depth
Wide Screen Display
16:9
2048 x 1152
16,32 bits
16:10
1920 x 1200
16,32 bits
16:9
1920 x 1080
16,32 bits
16:10
1680 x 1050
16,32 bits
16:9
1600 x 900
16,32 bits
16:10
1440 x 900
16,32 bits
16:9
1360 x 768
16,32 bits
16:10
1280 x 800
16,32 bits
15:9
1280 x 768
16,32 bits
16:9
1280 x 720
16,32 bits
Standard Display
4:3
1600 x 1200
16,32 bits
4:3
1400 x 1050
16,32 bits
5:4
1280 x 1024
16,32 bits
4:3
1280 x 960
16,32 bits
4:3
1152 x 864
16,32 bits
4:3
1024 x 768
16,32 bits
4:3
800 x 600
16,32 bits
Ethernet (9)
Ethernet Port
10/100 Base-T Ethernet RJ-45 connector
Audio
Microphone(8)
3.5 mm stereo audio in

ULTRA STATION USER MANUAL
5
Speaker(7)
3.5 mm stereo audio out
Wormhole Switch(11)
Wormhole port
USB 2.0 mini B Female connector
Cable
USB 2.0, mini B to Type-A (2 meter)
Transfer Rate
Up to 20 Mbps, transfer rate
Physical Specification
Housing Material
Aluminum
Dimensions
Main body: 386.4(W)x 28.5(H)x22(D) mm
Weight
138g
Package Contents
 Ultra Station (JUD500)
 USB 2.0 cable
 USB 3.0 cable
 Power Adapter (5V/4A)
 Driver CD with E-manual
 Quick Installation Guide
GETTING STARTED
Notes for Before Installation
 Install the driver completely before inserting the USB cable into your computer
 Run the setup program as an administrator to avoid errors in installation
 Connect the VGA or HDMI Cable of Display to the VGA or HDMI port of Ultra Station
first before connecting the USB cable to the computer
 Un-install the previous driver first before installing the latest driver

6
1. Start Device Driver Installation (please refer to your PC system OS installation in next section)
*Note: install driver completely before following steps.
2. Plug the Power Adapter to Port 1
3. Connect USB 3.0 Cable Micro-B connector to Port2 ,type A to host laptop
4. Connect HDMI or VGA Cable of Display device to Port 5 or 6
5. Connect Ethernet Cable to Port 9
6. Connect Audio Cable(audio out, audio in)to Port 7 & 8
7. Lay your laptop on the top of the j5 Ultra Station
8. Push the “j5” power button
9. USB HUB port 3,4,10 are now ready to use
10. Connect USB 2.0 Cable Micro-B connector to Port 11, and Type-A connector to the USB
port of the second computer. To Start the Wormhole Switch Function ,Please refer to the
Installation for Wormhole
INSTALLATION FOR WINDOWS
Device Driver Installation
This section illustrates the simple device driver installation guide for Windows 7 operating
system. When your computer is ready to use insert the Driver CD into CD-ROM drive. The setup
program should be launched automatically; if it doesn’t, go to “Computer,”click on your
optical drive, and manually run the setup CD. Double Click on “Setup.exe” to start.
※Make sure the USB cable is unplugged from your PC or Notebook before executing the
installation program.
1. The installation page will be launched. To
start click on “ Install the Latest Driver”. Please
make sure the network is available or press
“Install Driver” to start the installation
2. After pressing the installation option, the
InstallShield Wizard will launch, click Next>
to continue

ULTRA STATION USER MANUAL
7
3. Read the license agreement, check “I
accept the terms of the license
agreement,” click Next >
4. When Install Shield Wizard is complete,
select “Yes, I want to restart my computer
now.” Click Finish to restart.
5. After restarting your computer connect the
ULTRA STATION USB Cable to your PC or
Notebook. The “Installing device driver
software” message will pop-up.
6. Windows 7:
When the driver software has been
installed successfully the message below
will appear on your computer.
Windows XP :An icon ( ) will be seen
on the lower right toolbar.Driver software
was installed successfully when the below
message is shown
The Display functions of the ULTRA STATION will be activated after the computer restarted. You
might see the mirror display is shown on the display device.
Windows 7:
You can modify the corresponding
position of each extend display via
display settings. Go to “START” →
“Control Panel” →“Appearance and
Personalization” →“Adjust screen
resolution”
※or Right click on the desktop and go
to “Screen Resolution”
When the Screen Resolution Window
pops up, you can identify each
monitor’s number by clicking
“Identify.” You can drag the Monitor
to the location you want.

8
Windows XP:
You can modify the corresponsive
position of each extend display via
display settings.
Go to “START” →“Control Panel” →
“Display Properties”→“Settings”
When Display Properties windows
appears, each monitor‟s number can
be identified by clicking “ “ identify”
Drag the monitor to the location you
want.
Note:
If your internal graphics card is Dual Display Ports…..
When using one ULTRA STATION
The display device which connected to the 2nd VGA port will be numbered 3rd monitor, the
display device which connected to the ULTRA STATION will be numbered 2nd monitor.
Verify Device Driver Installation
The following procedure is for verifying the driver installation status of the ULTRA STATION
Windows 7:
Right Click “My Computer” “Manager”
“Device Manager” click “+” sign of
“Network adapter” & “Sound, video and
game control” & “Universal Serial Bus
controllers”
Windows XP:
Right Click “My Computer”, “Manager” → “Device Manager” click “+” sign of “Display
Adapter” & “Network adapter” & “Sound, video and game controllers” &“Universal Serial Bus
controllers”

ULTRA STATION USER MANUAL
9
Setup The Sound
Microsoft’s audio system restricts the audio function to one output at a time; therefore, when
using the USB HDMI display Device only one output will receive audio.
The following explains how to set-up and change the default sound output from the display
device connected with the USB 3.0 ULTRA STATION.
Windows 7:
1. Go to “Control Panel> Hardware and
Sound” and select “Changes system
sounds”
2. The speaker options are shown below.

10
3. To change the default sound output, use
your mouse to right click in the sound
options box on your desktop, then select
“Test”to choose which speaker you want
to use as your default.
4. Select the Speaker you want and then
click “Set Default”
Windows XP:
1. Go to “Control Panel> Sounds, Speech,
and Audio Devices” and select “Changes
the speaker settings”.
2. The speaker options are shown below.
Note:
A. The speakers are numbered according to the number if USB ports detected by your
computer system.
B. The Default sound will output from the ULTRA STATION with the greatest number of USB
ports.

ULTRA STATION USER MANUAL
11
3. Select “the Default device” you want, and click “apply”. then click “ Volume” to choose
which speaker you want to use as your default.
Device Driver Un-installation
※Unplug the USB Cable of the ULTRA STATION before uninstalling the driver
1. Click “Start”→Control Panel →
Programs and Features→Uninstall or
change a program Select j5 ULTRA
STATION... Click Uninstall
2. A message will appear confirming that you
want to un-install the application. Click ‘ok’ to
continue.

12
3. When the Driver is completely
uninstalled, select “Yes, I want to restart
my computer now”. Click Finishto
restart.
INSTALLATION FOR MAC
Device Driver Installation
Installing the device driver enables your computer’s operating system to recognize the ULTRA
STATION. Be sure that you are referring to the appropriate installation procedure before you
begin installing.
※Make sure the USB cable is unplugged from your Mac Desktop or Mac Notebook before
executing the setup program.
This section illustrates the device driver installation procedure for a computer running Snow
Leopard.
1. Insert the Driver CD into the CD-ROM
drive ;and run the .dmg file to load drivers
in the“mac_install”folder
2. The installation page will be launched;
To begin installation click on start “ Get Last
Driver online” , please make sure the
networking is available or Press “Install Lan”
to start the installation
3. Click “Continue” to proceed

ULTRA STATION USER MANUAL
13
4. Click “Agree” to proceed
5. Click “ Install” to proceed
6. Type in your password and click “OK”
Installation is processing…This will take a
few moments
7. Installation is completed, click “ Close”
8. After Lan driver installation finished,
Choose the OS version you are using and
press “Install Driver” to start the
installation

14
9. Click “Continue” to proceed
10.Type in your password and click “OK”
11.Click “Continue Installation”
12. Installation is processing…This will take a
few moments
13.Click “Restart” to complete the software
installation

ULTRA STATION USER MANUAL
15
Setup The Sound
Mac audio system restricts the audio function to one output at a time; therefore, when using
the USB ULTRA STATION only one output will receive audio.
1. GO , and then “System Preferences”
2. Go to the “System Preferences” and select
“Sound”
3. The speaker“Output” options are shown below. You can select a device for sound output
by clicking it.

16
Verify Device Driver Installation
The following procedure helps you to verify the driver installation status of USB 3.0 Display
Adapter
1. GO , select “About This Mac”
and select “ More Info…”
2. The picture shows the installation process for the
Ultra Station
Device Driver Un-installation
1. Unplug the USB Cable of ULTRA
STATION from the USB port
2. To un-installation , please press the
“Uninstall Driver” icon
3. Click “Open” to proceed
4. Click “Uninstall and restart” to proceed
5. Type in your password to allow un-
installation and click “OK” to proceed
6. Restart your system.

ULTRA STATION USER MANUAL
17
INSTALLATION FOR WORMHOLE
GETTING STARTED-MAC
1. Connect one end of the Wormhole
Switch to a standard USB port on
one of the two computers. And
connect the other end of the
Wormhole Switch to a USB port on
the second computer.
2. When you initially connect the
Wormhole Switch to the MAC
computer a window will pop up that
says, “Keyboard Setup Assistant”,
follow the steps to select the
keyboard Type.
Tip: You also can change the setting,
Go to “System Preferences”->
“Keyboard”-> “change the keyboard
Type”

18
3. 3. After the Wormhole Switch is plugged
in the “Wormhole” CDROM icon
will appear either on the desktop or on
the “Macintosh HD”. Double click on
the “Wormhole” icon.
4. When the Wormhole Switch is
connected properly the wormhole
launch page will be shown.
GETTING STARTED-Windows
1. Connect one end of the Wormhole
Switch to a standard USB port on one of
the two computers. And connect the
other end of the Wormhole Switch to a
USB port on the second computer.
2. The device will automatically start the
Wormhole Switch software installation
on both computers.
3. An “AutoPlay” option window may
appear. Please click on the option
“Run WKMLoader.exe”

ULTRA STATION USER MANUAL
19
Troubleshooting:
If auto-run is not launched, please follow the steps:
A. Insure both computers are properly connected to
the USB cable.
B. Go to My Computer and double-click the j5
Wormhole Switch icon ( ) to start the application.
4. If the “User Account Control”window
appears on the screen,
Click “Yes”to continue.
5. When the Wormhole Switch is connected properly
the wormhole launch page will be shown.
FUNCTIONS INSTRUCTIONS: WINDOWS 7
Display ID
Smart Display Device ID Detection
Window 7 OS supports VESA defined
DDC/EDID. It will be shown as the Display
device ID whenever it is attached to the
ULTRA STATION.

20
Display Resolution
Fast Access to Display Resolution setting
The resolution list will show when moving
the cursor on Display Resolution. Select
the resolution you want for the ULTRA
STATION.
Default resolution: 1024 x 768 x 32 bit
Display Orientation
The Orientation allows you to turn the
display device, which is connected to
ULTRA STATION
Display Mode
Extended mode (Default)
This feature allows the display device
attached to the ULTRA STATION to work
as an “extended” display of the on-
board screen.
You can adjust the position by clicking
“number” of the display first and select
“Extend these displays” and click
“Apply”
