JABSCO 18400-0050 User manual

Model 18400-0050
SELF-PRIMING PUMP
FEATURES
Body: Bronze
Impeller: Jabsco Neoprene Compound
Shaft: 316 Stainless Steel
Shaft Seal: Lip Type
Ports: 3/4" NPT
Weight: 6 lb (approx.)
APPLICATION
Marine Engine Cooling
FOR ENGINE MODELS
ONAN MDJ-C
MDJ-F
Model 18400-0050
DIMENSIONAL DRAWINGS
INCHES (MILLIMETERS)
INSTALLATION INSTRUCTIONS
Engine shaft with drive tang, make sure flange seats
squarely on mounting surface and bolt to engine.
Connect inlet and outlet fittings using pipe compound to
seal threads.
OPERATING INSTRUCTIONS
Pump will self-prime at low or high speeds. Make sure
scoop and inlet line are clear and all connections airtight.
Do not run pump dry for more than 30 seconds. Lack of
water flow may damage impeller. To drain pump, loosen
end cover screws.
SERVICE INSTRUCTIONS
Impeller Replacement: Remove end cover and gas-
ket. Pull impeller out by grasping hub or blades with pliers.
Replace impeller, gasket and end cover. A light coating of
grease in impeller bore will aid priming on dry start up. (Use
correct Jabsco gasket, a thicker or thinner gasket may
cause impeller damage.) Standard gasket in 0.010" thick.
Major Repair: Remove pump from engine to replace
seal, bearings or shaft. To disassemble pump, remove
end cover, gasket and impeller ar outlined above. Press
on impeller end of shaft to remove shaft and bearing

EXPLODED VIEW
PARTS LIST
Key Description Qty. Part No.
1Screw (End Cover) 6 91002-0020
2End Cover 1 11830-0000
*3 Gasket 1 5212-0000
*4 Impeller 1 1210-0001
*6 Seal (Shaft) 1 92700-0060
*7 O-Ring†192000-0210
8Screw (Cam) 1 91003-0090
9Cam Wearplate Assembly 1 5211-0000
10 Seal Spacer 1 3166-0000
11 Body 1
12 Adaptor Ring 1 3376-0000
13 Slinger 1 3286-0000
14 Shaft 1 18404-0000
15 Bearing Seal 1 92700-0060
16 Ball Bearing 1 92600-0130
17 Bearing Spacer 2 3383-0000
Service Kit 90033-0001
*Parts contained in Service Kit.
†O-ring used only in pumps manufactured prior to June, 1993.
assembly. Remove cam and wearplate assembly. Use
screw driver to pry bearing seal out of bearing bore. Press
shaft seal out towards impeller bore. Replace all worn
parts. When installing coupling, support splined end of
shaft. Press bearing seal in bearing bore with lip towards
bearing. Press shaft and bearing assembly into bearing
bore. Press adaptor ring into body. Install slinger on shaft.
Install seal spacer in seal cavity. Install O-ring in seal bore.
Press seal in seal cavity with lip facing toward impeller
bore. Apply a thin coat of sealant to top of cam and cam
screw threads, install wearplate and cam assembly. (Be
sure cam is flush with end cover surface.) Secure with
screw. Lubricate impeller bore, install impeller. Lubricate
impeller face, install gasket and end cover and secure
with screws.
MODEL 18400-0050
THE PRODUCTS DESCRIBED HEREIN ARE SUBJECT TO
THE JABSCO ONE YEAR LIMITED WARRANTY, WHICH
IS AVAILABLE FOR YOUR INSPECTION UPON REQUEST.
U.S.A.
Jabsco
1485 Dale Way, P.O. Box 2158
Costa Mesa, CA92628-2158
Tel: [phone]
Fax: [phone]
UNITED KINGDOM
Jabsco
Bingley Road, Hoddesdon
Hertfordshire EN11 OBU
Tel: [phone]
Fax: [phone]
CANADA
Fluid Products Canada
55 Royal Road
Guelph, Ontario N1H 1T1
Tel: [phone]
Fax: [phone]
JAPAN
NHK Jabsco Company Ltd.
3-21-10, Shin-Yokohama
Kohoku-Ku, Yokohama, 222
Tel: [phone]
Fax: [phone]
GERMANY
Jabsco GmbH
Oststrasse 28
22844 Norderstedt
Tel: [phone]
Fax: [phone]
©Copyright 2000, ITT Industries Printed in U.S.A. All Rights Reserved Form: 43000-0624 Rev. 4/2000
PUMP FLOW CHART
