JABSCO 4560 Series User manual

Model 4560-Series
4590-Series
4620-Series
Model 4560-Series,
4590-Series, 4620-Series
SELF-PRIMING PUMPS
FEATURES
Body: Bronze Construction
Impeller: Neoprene or Nitrile
Shaft: Stainless Steel
Shaft Seal: Packing Type
Bearings: Plain
Ports: Model 4560-Series 1/2"NPT
Model 4590-Series 3/4"NPT
Model 4620-Series 1"NPT
Weight: Model 4560-Series 3-3/4 lb (1.7 kg)
Model 4590-Series 5 lb (2.3 kg)
Model 4620-Series 5-1/4 lb (2.4 kg)
VARIATIONS AVAILABLE
Model Variation Incorporated
4560-0001 Neoprene Impeller
-0003 Nitrile Impeller
4590-0001 Neoprene Impeller
-0003 Nitrile Impeller
4620-0001 Neoprene Impeller
-0003 Nitrile Impeller
APPLICATIONS
MARINE: Pumping bilges, washdowns, circulating water
in bait tanks, utility dockside pump, engine cooling.
INDUSTRIAL: Circulating and transferring, velocity-mix-
ing, pumping machine tool coolants, return spill, sump
drainage, chemicals, pharmaceuticals, soap, liquors,
ink, dyes, alcohol, various acids, tanning liquors, glycer-
ine, brine, etc.
FARMING: Pumping water for stock, pumping water
from shallow wells and cisterns, pumping liquid ballast
into tractor tires.
PLUMBING & HOME EMERGENCY USE: Pumping out
flooded basements, cesspools, sumps, water heaters
and water closets, drains and sinks, draining fishponds
and pools.
OPERATING INSTRUCTIONS
1. INSTALLATION – Pump may be mounted in any
position. Intake and discharge ports are determined
by the direction of shaft rotation (refer to Dimen-
sional Drawing). Before installing, turn the pump
shaft in the direction of the operating rotation.
2. DRIVE – Belt or Direct with flexible coupling.
Belt Drive: Overtight belt load will reduce pump
bearing life. Direct Drive is recommended for oper-
ating speeds above 1750 RPM.
Direct Drive: Clearance should be left between drive
shaft and pump shaft when installing coupling.
Always mount and align pump and drive shaft before
tightening the coupling set screw.
NOTICE: If the drive pulley or coupling must be pressed
on the shaft, remove the end cover and impeller and
support the shaft from the impeller end during the press
operation. Do not hammer a pulley or coupling on the
shaft. Failure to follow the above instructions can dam-
age the pump.
3. SPEEDS – 100 RPM to the maximum shown in the
performance table. Consult the factory for operation
at speeds above those shown. For longer pump life,
operate at lowest possible speeds.
4. SELF-PRIMING – Primes at low or high speeds. For
vertical dry suction lift of 10 feet, a minimum of 800
RPM is required. Pump will produce suction lift up to
22 feet when wetted. BE SURE SUCTION LINES
AREAIRTIGHT OR PUMP WILL NOT SELF-PRIME.
Other JABSCO models are also available in bronze,
plastic and stainless steel. JABSCO Pureflo®pumps
are also available for sanitary applications.

5. RUNNING DRY – Unit depends on liquid pumped
for lubrication. DO NOT RUN DRY for more than
30 seconds. Lack of liquid will damage the impeller.
6. NOTICE – If pumping light fraction petroleum deriv-
atives, solvents, thinners, highly concentrated or
organic acids, consult Jabsco Chemical Resistance
Table (which is available upon request from ITT
Jabsco) for proper body materials and impeller
compounds. If corrosive fluids are handled, pump
life will be prolonged if pump is flushed with water
after each use or after each work day.
7. PRESSURES – Consult Head Capacity Table for
recommended maximum for continuous operation. If
pressures exceed those shown, consult the factory.
8. TEMPERATURE – Neoprene 45°–180°F (7°–82°C)
Nitrile 50°–180°F (10°–82°C).
9. FREEZING WEATHER – Drain unit by loosening
end cover. The following anti-freeze compounds can
be used without any adverse effects to the neoprene
impeller: Atlas “Permaguard”, DuPont “Zerex” and
“Telar”, Dow Chemical “Dowguard” and Olin
Mathison “Pyro Permanent”. Most Methyl alcohol
(methanol) based antifreeze can be used.
DO NOT USE PETROLEUM BASEDANTI-FREEZE
COMPOUNDS OR RUST INHIBITORS.
10. GASKET – Use a standard pump part. A thicker
gasket will reduce priming ability. A thinner gasket
will cause the impeller to bind. Std. gasket 0.010"
thick.
11. GREASE CUPS – Fill grease cups with water pump
grease. Grease cup cap should be firmly tightened
about every 50 hours of pump service while pump is
operating. Leakage may occur through grease cups
at pressures above 20 p.s.i. If this occurs, replace
grease cups with ball check grease cups.
12. SPARE PARTS – To avoid costly shut downs, keep
a Jabsco Service Kit on hand.
SERVICE INSTRUCTIONS
DISASSEMBLY
1. Remove end cover screws, end cover and gasket.
2. Remove drive coupling or pulley and loosen packing
nut.
3. Remove shaft and impeller assembly from body.
4. Slide impeller off shaft towards pump drive end.
5. Remove cam screw and cam, clean off Permatex.
6. Remove packing nut and gland.
7. Remove packing with pick or screwdriver.
8. Remove grease cup caps and clean grease cups.
Use a small wire to ensure grease passage is open
to shaft bore.
9. Inspect all parts for wear or damage and replace if
necessary.
ASSEMBLY
1. Dip new packing in SAE 10 or 20 weight oil and
install packing, packing gland and packing nut.
2. Apply sealant to cam screw threads and top and
back end of cam and install in body with cam screw.
3. Install impeller key in shaft (dress if necessary) and
slide the impeller on the shaft from the pump drive
end.
Impeller can be installed in only one direction;
pinned end of keyway toward drive end of pump.
4. Install shaft and impeller assembly in body. (Dip
shaft in SAE 10 or 20 weight oil and lube impeller
bore with water pump grease prior to assembly.)
5. Install gasket and end cover with end cover screws.
6. Fill grease cups full and grease cup caps 3/4 full with
water pump grease. Install grease cup caps and
tighten firmly.
7. Hand tighten packing nut. During operation, tighten
packing nut until pump stops dripping; set locking
nut. NOTE: Packing and shaft life will be improved if
pump is allowed to drip about 3 drops per minute.
After a few minutes of operation, re-tighten grease
cup caps.

PARTS LIST
Model 4560 Model 4590 Model 4620
Key Description Qty. Series Series Series
1Screw (End Cover) 6 91002-0020 91003-0010 91003-0010
2End Cover 1 4565-0000 4595-0000 4595-0000
3Gasket* 1 7083-0000 706-0010 706-0010
4Grease Cup 2 91501-0010 91501-0010 91501-0010
5Impeller* 1
Neoprene 4568-0001 4598-0001 4598-0001
Nitrile 4568-0003 4598-0003 4598-0003
6Key (Impeller Drive)* 1 91402-0010 91402-0010 91402-0010
7Shaft 1 4567-0000 4597-0000 4597-0000
8Cam 1 490-0001 17612-0000 17612-0000
9Screw (Cam) 1 91003-0070 91004-0010 91004-0010
10 Body 1 4564-0000 4594-0000 4624-0000
11 Lock Nut 1 4517-0000 4517-0000 4517-0000
12 Packing (Ring)* 1 3791-0000 3791-0000 3791-0000
13 Packing (Gland) 1 4518-0000 4518-0000 4518-0000
14 Packing Nut 1 4583-0000 4583-0000 4583-0000
Key Pump Drive 1 9215-0000 9215-0000 9215-0000
(not shown)
Service Kit (not shown)
w/ Neoprene Impeller 90003-0001 90004-0001 90004-0001
w/ Nitrile Impeller 90003-0003 90004-0003 90004-0003
* Parts supplied in Service Kit
EXPLODED VIEW

U.S.A.
Jabsco
1485 Dale Way, P.O. Box 2158
Costa Mesa, CA 92628-2158
Tel: [phone]
Fax: [phone]
UNITED KINGDOM
Jabsco
Bingley Road, Hoddesdon
Hertfordsire EN11 OBU
Tel: [phone]
Fax: [phone]
CANADA
Fluid Products Canada
55 Royal Road
Guelph, Ontario N1H 1T1
Tel: [phone]
Fax: [phone]
JAPAN
NHK Jabsco Company Ltd.
3-21-10, Shin-Yokohama
Kohoku-Ku, Yokohama, 222
Tel: [phone]
Fax: [phone]
GERMANY
Jabsco GmbH
Oststrasse 28
22840 Norderstedt
Tel: [phone]
Fax: [phone]
THE PRODUCTS DESCRIBED HEREIN ARE SUBJECT TO
THE JABSCO ONE YEAR LIMITED WARRANTY, WHICH IS
AVAILABLE FOR YOUR INSPECTION UPON REQUEST.
©Copyright 2000, ITT Industries Printed in U.S.A. All Rights Reserved Form: 43000-0065 Rev. 8/2000
NOTE: Progressively longer life may be expected as operating pressures and speeds are reduced. Factory
Application Engineering assistance suggested for operation in light shaded areas and recommended for heavy
shaded areas. Capacitor type motor required. Table shows approximate Head-Flow for new pump in U.S.
gallons per minute and litres per minute, for neoprene compound impeller.
TABULATIONS FROM ABOVE DRAWING
Model A B C D E F G H I J K L M
4560- 7-1/8"5-1/8"1-7/8"Min. 4"2-1/2"1-15/16"3-3/4"3"1-1/2"3/16"1-3/16"4-1/8"1/2"NPT Int.
Series (181) (130,2) (47,6) (101,6) (63,5) (49,2) (95,3) (76,2) (38,1) (4,8) (30,2) (104,8) (2 Places)
4590- 7-7/8"5-9/16"1-3/4"Min. 4-3/16"2-1/2"1-7/8"3-15/16"3-1/8"1-9/16"3/32"1-1/2"4-1/8"3/4"NPT Int.
Series (200) (141,3) (44,5) (106,4) (63,5) (47,6) (100) (79,4) (39,7) (2,4) (38,1) (104,8) (2 Places)
4620- 7-7/8"5-5/8"1-3/4" Min. 4-3/16"2-1/2"1-7/8"3-15/16"3-1/8"1-9/16"1/8"1-1/2"4-3/4"1"NPT Int.
Series (200) (142,9) (44,5) (106,4) (63,5) (47,6) (100) (79,4) (39,7) (3,2) (38,1) (120,7) (2 Places)
HEAD CAPACITY TABLE Model 4560-0001
Total Head 500 RPM 1160 RPM 1750 RPM 2100 RPM 2450 RPM 3000 RPM 3600 RPM
p.s.i. ft. of water GPM hp GPM hp GPM hp GPM hp GPM hp GPM hp GPM hp
(kg/sq cm) (metres) (L/min) (L/min) (L/min) (L/min) (L/min) (L/min) (L/min)
4.3 10 3.0 1/6 7.6 1/4 11.0 1/2 13.0 1/2 15.2 1/2 18.0 3/4 19.6 3/4
(0,3) (3,0) (11,3) (28,8) (41,6) (49,2) (57,5) (68,1) (74,2)
8.7 20 1.8 1/6 6.4 1/4 10.0 1/2 11.5 1/2 13.7 1/2 17.0 3/4 18.8 3/4
(0,6) (6,1) (6,8) (24,2) (37,9) (43,5) (51,9) (64,3) 71,2)
13 30 — — 4.8 1/3 8.5 1/2 10.0 1/2 12.0 1/2 15.3 3/4 17.5 3/4
(0,9) (9,1) (18,2) (32,2) (37,9) (45,4) (57,9) (66,2)
21.6 50 — — — — 5.0 1/2 6.7 3/4 8.5 3/4 11.8 3/4 14.5 1
(1,5) (15,2) (18,9) (25,4) (32,2) (44,7) (54,9)
HEAD CAPACITY TABLE Models 4590-0001, 4620-0001
Total Head 500 RPM 1160 RPM 1750 RPM 2100 RPM 2450 RPM 3000 RPM
p.s.i. ft. of water GPM hp GPM hp GPM hp GPM hp GPM hp GPM hp
(kg/sq cm) (metres) (L/min) (L/min) (L/min) (L/min) (L/min) (L/min)
4.3 10 7.0 1/4 16.5 1/3 25.0 3/4 29.0 3/4 31.0 133.0 1-1/2
(0,3) (3,0) (26,5) (62,5) (94,6) (109,8) (117,3) (124,9)
8.7 20 6.5 1/4 16.0 1/3 24.5 3/4 28.5 3/4 30.5 132.5 1-1/2
(0,6) (6,1) (24,6) (60,6) (92,7) (107,9) (115,4) (123,0)
13 30 6.0 1/4 15.0 1/3 23.0 3/4 27.0 129.0 132.0 1-1/2
(0,9) (9,1) (22,7) (56,8) (87,1) 102,2) 109,8) (121,1)
21.6 50 — — 11.5 1/2 19.0 3/4 22.5 125.0 1-1/2 30.5 2
(1,5) (15,2) (43,5) (71,9) (85,2) (94,6) 115,4)
DIMENSIONAL DRAWING
Inches (Millimetres)
