JABSCO 37202-2712 User manual

Bilge Pump
•900 lph (210 gph) at 3m H²O (30 Kpa)
•Self Priming to 2 metres (6 ft)
•Connections for 19mm (¾") I.D. hose
1. Fit pump in a dry position, as close as possible to
the liquid being pumped, where there is full access
to the pump for service.
2. Use 19mm (¾") i.d. spiral reinforced hose (with a
smooth internal bore), or semi-rigid pipework
systems.
3. Pipe runs should be as straight and as short as
possible, avoiding rising and dipping over
obstructions.
4. Fit strainer on inlet side of pump.
5. All marine pumps discharging overboard must be
installed with the overboard discharge well above
both static and heeled waterlines (Sailboats
normally discharge through the transom).
6. Motor cases may get hot. Prolonged contact during
operation may cause burns.
7. Do no use for pumping petrol, petroleum products,
or fluids with flash points below 37ºC.
Electrical Connections
• Wire the pump in an independent circuit.
• Refer to the diagram for wiring connections.
• Refer to wiring table for fuse and wire size.
• If installing with a two or three way master switch,
ensure that it has a minimum 10 amp capacity.
Wiring Diagram
Installation and Safety
Specifications
Wiring Table
*Cable length is the total distance from the battery to
the pump and back to the battery.
Remove pipework, remove four connecting bolts from
pump, remove motor bracket and diaphragm
assembly.
Valve Replacement
Remove valve retaining plate, remove and replace
valves ensuring correct installation. Replace valve
retaining plate.
Diaphragm Replacement
Unscrew bolt separating diaphragm assembly,
reassemble new diaphragm, diaphragm plate, washer
and bolt onto connecting rod.
Ensure the diaphragm is located centrally before
reassembling the motor, bracket and diaphragm onto
the body.
37202-2712
•New, higher output 15lpm (3.3gpm) bilge pump model
•Quieter Running
•Constructed From Corrosion Resistant Materials
•ISO 8846 MARINE (Ignition Protection)
•ISO 8849 MARINE (Electric Bilge Pumps)
•BSEN 50081 (Electro Magnetic Compatibility)
•Dry Running
•Supplied Complete With Pumpguard
Model No. Fuse Size Cable Length * Wire Size
0 - 7.6m (0 - 25ft) 2.5mm²
7.6 - 15m (25 - 50ft) 4mm²
10 amp
37202-0712
Maintenance
ALWAYS DISCONNECT PUMP FROM
POWER SUPPLY!

Bilge Pump
Connecting Rod Replacement
Undo set screw, remove two motor mounting screws
and pull away from bracket and connecting rod
assembly. Unscrew bolt separating diaphragm
assembly and connecting rod. Reassemble diaphragm,
diaphragm plate, washer, and bolt onto new connecting
rod. Mount motor onto bracket aligning connecting rod
assembly. Tighten set screw. Reassemble diaphragm
assembly and bracket onto body.
Pulsation Dampener Replacement
Remove pump mounting screws. Remove foot screw
and foot. Pull out and replace pulsation dampener
positioning the three ribbed cavity on the discharge
side. Replace foot and foot screw.
Winter Storage
Completely remove water from pump by removing
pipework, and running the pump until all the water is
expelled
Warranty: All products of the company are sold and all services of the company are offered subject to the company’s warranty and terms and conditions of sale, copies of which will be furnished upon request.
©Copyright 2003 ITT Industries 43000-0767 Rev. 01/03
Jabsco
ITT Industries
Jabsco, 20 Icon, Foothill Ranch, CA 92610-3000
Tel : [phone] Fax : [phone]
Jabsco, Bingley Road, Hoddesdon, Hertfordshire, EN11 0BU
Tel : [phone] Fax : [phone]
Fluid Products Canada,55 Royal Road, Guelph, Ontario N1H 1T1
Tel : [phone] Fax : [phone]
NHK Jabsco Co Ltd,3-21-10, Shin - Yokohama, Kohoku-ku, Yokohama 222
Tel : [phone] Fax : [phone]
Jabsco GmbH,Oststraße 28, 22844 Norderstedt
Tel : [phone] Fax : [phone]
USA
UK
CANADA
JAPAN
GERMANY
www.jabsco.com
Exploded View
24
Kit Part No. Description
A 50095-1000 Major Service Kit
B 50096-1712 Motor Kit 12V
C 50097-1000 Connecting Rod Kit
Repair Kits Available
Key Description Qty Part Number A B C
1 Motor 12V 1 1
2 Eccentric Drive 1 1
3 Bracket 1 50092-0000
4 Bearing 1
5 Con Rod 1 1
6 Diaphragm Plate 1 35688-0000 1
7 Diaphragm 1 50099-1000 1
8 Sealing Washer 1 1 1
9Bolt 1 1 1
10 Diaphragm Ring 1 35778-0000
11 Valve Retainer 1 35816-0000 1
12 Valve Set 1 30005-0000 1
13 Body 1 50098-1000 1
14 Pulsation Dampner 1 37179-0000 1
15 Grommet 4 1
16 Foot 1 50094-1000
17 Cover 1 50093-1000
18 Grub Screw 1 1
19 Bolt 4 1 1
20 Lock Washer 2 2 1
21 Motor Screw 2 2 1
22 Nut 4 1 1
23 Screw 1 1
24 Pumpguard 1 46200-0000
Qty per kit
Dimensional Drawings
Dimensions in mm
