JABSCO 4720 Series User manual

Model 4720-Series
SELF-PRIMING PUMP
FEATURES
Body: Type 316 Stainless Steel
Impeller: Neoprene or Nitrile
Seal: Lip Type
Shaft: Steel Motor Shaft with special
Stainless Steel Sleeve
Ports: 1/2" NPT Internal
Motor: 1/3 HP, 115/230 Vac, 60 Hz,
Single Phase, T.E.F.C., 1725 RPM,
Continuous Duty, 56-Frame,
Capacitor start with automatic reset
thermal overload protector; 6 foot
cord with three prong plug.
Weight: 35 lb (15.9 kg)
Model 4720-Series
SECONDS. Lack of liquid will damage the impeller and
seal.
PRESSURES - For continuous operation, pressure
should not exceed 20 psi (1.4 kg/cm2).
TEMPERATURE - Neoprene Impeller 45° to 180° F
(8° - 82° C), Nitrile Impeller 50° to 180° F (10° to 82° C).
SPARE PARTS -AJabsco Service Kit should be kept on
hand to maintain all but the most badly worn pumps.
NOTICE - When corrosive fluids are handled, pump life
will be prolonged if pump is flushed with water after each
use or after each work day. For further information,
consult Jabsco Chemical Resistance Table, which is
available upon request.
VARIATIONS AVAILABLE
MODEL NO. DESCRIPTION
4720-0001 NEOPRENE IMPELLER
4720-0003 NITRILE IMPELLER
APPLICATIONS
CHEMICAL - Industrial Motor Pump Unit Circulating,
Transferring and Filtering of Chemicals, Plating
Solutions, Pharmaceuticals, Cosmetics and Farm
Chemicals, Emptying and Filling Carboys, Vats, Tanks,
Barrels or Entire Systems.
OPERATING INSTRUCTIONS
INSTALLATION - Pump may be installed in any position.
Rotation of motor determines the location of the pump
intake. The motor is normally wired for clockwise rotation
when looking at pump cover, with inlet port on the right.
SELF-PRIMING - Vertical, dry suction lift of 10'. Pump
will produce suction lift up to 22' when wet. BE SURE
SUCTION LINES ARE AIRTIGHT or pump will not self-
prime.
DISCHARGE - When transferring liquids further than
25', use I" ID discharge Iine.
RUNNING DRY - Unit depends on liquid pumped for
lubrication. DO NOT RUN DRY FOR MORE THAN 30
WARNING
!Explosion hazard. Do not use where flammable
vapors are present. Do not pump solvents,
thinners or gasoline. To do so can cause an
explosion which can result in injury or death.

SERVICE INSTRUCTIONS
DISASSEMBLY
TO REPLACE IMPELLER
1. Remove end cover cap screws, end cover, gasket
and wearplate.
2. Grasp impeller hub with water pump pliers and with-
draw impeller from body. Check seal and internal
parts, for wear. Replace worn parts if necessary.
TO REPLACE SEAL ASSEMBLY
3. Loosen adaptor clamp nut and remove pump head
from motor Use a screwdriver to spread the clamp
slighty to facilitate removal.
4. See above Step #1.
5. Remove body, gasket and wearplate from adaptor.
Push impeller from body bore.
6. Remove seal liner and seal by pressing from motor
end of adaptor.
7. Remove seal from liner. Check all parts for wear.
Replace if questionable.
ASSEMBLY
TO REPLACE IMPELLER
1. Coat body bore and end of impeller extended insert
with a light film of water pump grease. Align detent
in impeller extended insert with keyway in shaft.
Depress the two impeller blades which fit under the
cam, and carefully push the impeller into the body
bore. Use a screwdriver in the drain slot area to push
the neoprene slinger up onto the end of the extended
impeller. Rotate the impeller in a clockwise direction
to assure the impeller blades are in the correct
position for easy starting.
2. Replace wearplate, gasket, end cover and
secure with end cover cap screws.
TO REPLACE SEAL ASSEMBLY
3. Install seal liner in bore of adaptor, aligning bolt
holes carefully.
4. Dip seal in water for lubrication and push into seal
liner bore with lip facing outwards. Wipe a thin film of
grease on lip of seal.
5. Install wearplate against liner, install gasket, align
bolt holes.
6. Push the impeller into the body and rotate the
impeller in a clockwise direction to align blades for
correct direction of rotation. Place the body impeller
assembly over the gasket and wearplate, and
carefully insert the impeller extended insert through
the seal.
7. Install the four capscrews through the adaptor flange
and screw into threaded holes in body flange.
Tighten bolts evenly and securely.
8. Repeat Step #2.
9. Align the tab in the slinger bore with the keyway in
the shaft and push the slinger part way onto the
shaft.
10. Align the detent in the impeller extended insert with
the keyway in the shaft and push the pump head
onto the motor hub, firmly against the motor. Tighten
the adaptor clamp nut just enough to prevent the
pump head from turning on the motor hub. If too
tight, motor bearing will seize the shaft and become
damaged during operation. Attach short lengths of
hose to suction and discharge ports and place both
hose ends in a bucket of water, before plugging
motor in, to check operation.

EXPLODED VIEW
1Screw (End Cover) 4 91106-0070
2End Cover 1 4919-0000
3Wearplate (Body to End Cover) 1 4918-0000
4*Gasket 2 2876-0000
5*Impeller (Neoprene) 1 6174-0001
(Nitrile) - 6174-0003
6Cam 1 2880-0000
7Screw (Cam) 1 91023-0010
8Body 1 2873-0000
9Wearplate (Body to Adaptor) 1 4357-0000
10 *Seal 1 92700-0520
11 Liner 1 4354-0000
12 Adaptor 1 4355-0000
13 Screw (Adaptor) 4 91106-0070
14 Slinger 1 6398-0000
15 Motor (includes Handle, Cord & Plug) 1 18735-0000
16 Nut (Adaptor) 1 91105-0030
17 Bolt (Adaptor) 1 91095-0090
-Replacement Pump Head Only
(Neoprene) - 4730-0001
-Service Kit - 90045-0001
* Parts Included in Service Kit
Key Description Qty. Req. Part Number
PARTS LIST

TOTAL HEAD CAPACITY
Flow at 1725 RPM
PSI KSI FEET METERS GPM I/MIN
4.3 0,3 10 3,0 11.0 41,6
8.7 0,6 20 6,1 10.0 37,9
17.3 1,2 40 12,2 6.7 25,4
21.6 1,5 50 15,2 5.0 18,9
Table shows approximate Head-Flow for new pump in
U.S. GPM and litres per minute with Neoprene impeller.
HEAD VS. FLOW TABLE
U.S.A.
Jabsco
1485 Dale Way, P.O. Box 2158
Costa Mesa, CA 92628-2158
Tel: [phone]
Fax: [phone]
UNITED KINGDOM
Jabsco
Bingley Road, Hoddesdon
Hertfordsire EN11 OBU
Tel: [phone]
Fax: [phone]
CANADA
Fluid Products Canada
55 Royal Road
Guelph, Ontario N1H 1T1
Tel: [phone]
Fax: [phone]
JAPAN
NHK Jabsco Company Ltd.
3-21-10, Shin-Yokohama
Kohoku-Ku, Yokohama, 222
Tel: [phone]
Fax: [phone]
GERMANY
Jabsco GmbH
Oststrasse 28
22840 Norderstedt
Tel: [phone]
Fax: [phone]
THE PRODUCTS DESCRIBED HEREIN ARE
SUBJECT TO THE JABSCO ONE YEAR LIMITED
WARRANTY, WHICH IS AVAILABLE FOR YOUR
INSPECTION UPON REQUEST.
©Copyright 2001, ITT Industries Printed in U.S.A. All Rights Reserved Form: 43000-0227 Rev. 6/2001
DIMENSIONAL DRAWING
Inches (Millimeters)
