JABSCO 36960-2 Series User manual

Model 36960-2 Series
Model 36960-2 Series
ELECTRIC BILGE PUMPS
FEATURES
•Self-Priming
•Diaphragm Design Allows Dry Running
•Built-in Hydraulic Pulsation Dampener
•Pumpgard®Strainer Included with Pump
•Corrosion Resistant Materials Throughout
for Sea Water Service
•Meets USCG Regulation 183.410 and
ISO 8846 MARINE for Ignition Protection
PRODUCT SPECIFICATIONS
Open Flow . . . . . . . . . . . . . . . . . . . . . . . . . . 4.0 GPM
Vertical Dry Suction Lift . . . . . . . . . . . 7 Feet (2.1 m)
Ports . . . . . . . . . . . . . . . . . . . . . . . . 3/4” Slip-on Hose
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 lb. (3.2 kg)
INSTALLATION
MOUNTING
Mount upright in a dry location (above highest bilge
water level) on a solid surface. Selection of a dry, cool,
ventilated location will generally extend pump life. Locate
Pumpgard strainer in accessible spot in suction hose.
PLUMBING
For intake and discharge use 3/4” ID non-collapsible
hose. Keep intake and discharge line free of kinks and
restrictions. To protect pump from debris, use the 3/4” in-line
strainer, Model 36200-0000 in the intake line from the bilge.
WIRING
Wire pump in a circuit independent of all other electrical
fixtures. Use stranded copper wire. Install fuse in posi-
tive circuit. See table for recommended wire and fuse
size. See diagram for wiring instructions. Use a 10 amp-
rated switch (44960-Series). After installation, it is rec-
ommended that voltage be checked at the motor termi-
nals with motor operating under full load. Voltage should
not be less than 90% of rated motor voitage.
STANDARD MODELS
Model Voltage Current Fuse Size
36960-2000 12 Vdc 6 Amp 8 Amp
36960-2010 24 Vdc 5 Amp 7 Amp
WINTER STORAGE
When possible it is preferred that the complete pump be
removed and stored in a warm dry place. If this is not
possible the pump must be completely drained, hoses
removed and pump run until all water is expelled.
WIRE SIZE TABLE
Model Model
Wire Length Between 36960-2000 36960-2010
Battery and Motor 12 Volt 24 Volt
1-25 ft. 12 AWG 14 AWG
26-50 ft. 10 AWG 14 AWG
6.31 (160)
7.50 (191)
7.31
(186)
4.75 (111)
DIMENSIONAL DRAWING
Inches (Millimeters)
BATTERY
MANUAL
AUTOMATIC
OFF
FUSE/
BREAKER PUMP
Automatic Bilge Switch
Model 34875-0000 or
Model 30295-1000
per instructions
3-Way Switch
44960-0000
WIRING DIAGRAM FOR
AUTOMATIC OPERATION

U.S.A.
Jabsco
Cape Ann Industrial Park
Gloucester, MA 01930
Tel: [phone]
Fax: [phone]
UNITED KINGDOM
Jabsco
Bingley Road, Hoddesdon
Hertfordsire EN11 OBU
Tel: [phone]
Fax: [phone]
CANADA
Fluid Products Canada
55 Royal Road
Guelph, Ontario N1H 1T1
Tel: [phone]
Fax: [phone]
JAPAN
NHK Jabsco Company Ltd.
3-21-10, Shin-Yokohama
Kohoku-Ku, Yokohama, 222
Tel: [phone]
Fax: [phone]
GERMANY
Jabsco GmbH
Oststrasse 28
22840 Norderstedt
Tel: [phone]
Fax: [phone]
THE PRODUCTS DESCRIBED HEREIN ARE SUBJECT TO THE
JABSCO ONE YEAR LIMITED WARRANTY, WHICH IS AVAILABLE
FOR YOUR INSPECTION UPON REQUEST.
©Copyright 2004, ITT Industries Printed in U.S.A. All Rights Reserved Form: 43000-0532 Rev. 04/2004
17
15
21
7
2
8
9
8
10
21
20
21
21
1
13
11
Key Part No. Description Qty
130202-0000 Motor Kit 12 Vdc 1
130201-0010 Motor Kit 24 Vdc 1
235487-0000 Motor Mount 1
730040-0000 Connecting Rod Assembly* 1
835688-0000 Diaphragm Plate 2
930015-0000 Diaphragm* 1
10 35455-0000 Retainer 1
11 30003-0000 Valve Set (Inlet & Outlet)* ‡ 1 Set
12 44114-1000 Base Assembly ‡ 1
13 37175-0000 Ports (Inlet & Outlet) Barb ‡ 1 Set
14 44127-1000 Pulsation Dampener* 1
15 35686-0000 Bottom Plate ‡ 1
20 44990-0058 Vibration Pad Kit 1 Set
21 43990-0060 Hardware Kit 1 Set
43990-0063 Service Kit*
* Indicates parts contained in Service Kit
‡ Indicates parts supplied with Base Assembly
EXPLODED VIEW TROUBLESHOOTING
Problems Causas
Loss of suction to pump •Air leak in suction line
•Bilge pickup not submerged
•Intake hose kinked or plugged
•
Fouled intake or discharge valve
•Ruptured diaphragm
Rough or noisy operation • Intake or discharge hose
kinked or plugged
•Pump not mounted firmly
•Loosened eccentric set screw
or worn connecting rod assembly
•Ruptured or collapsed
pulsation dampener.
VALVE REPLACEMENT
1. Turn off power to pump. Remove four motor mount tie down bolts.
2. Expose valves by lifting motor mount and the attached
diaphragm assembly from pump base.
3.
Remove valve retaining plate. Remove and clear or replace valves.
4. Install valves, making sure rubber flapper is UP on intake and
DOWN on discharge. Replace valve retaining plate.
5. Replace motor-mount-diaphragm assembly and fasten evenly
to base with the four tie down bolts.
DIAPHRAGM AND CONNECTING ROD
REPLACEMENT
1. Turn off power to pump. Remove four motor mount tie down boIts.
2. Lift motor mount and the attached diaphragm assembly from
pump base.
3.
Remove two diaphragm retainer screws and the diaphragm retainer.
4. Pull connecting rod assembly and diaphragm from motor
mount, then, unscrew bolt to separate diaphragm plates.
5. Loosely reassemble new diaphragm, diaphragm plates, wash-
er and diaphragm boft onto new connecting rod assembly.
6. Slide connecting rod on shaft. Ensure that eccentric is firmly
seated on motor shaft and set screw firmly against flat side of shaft.
7. Tighten connecting rod bolt while maintaining alignment of rod
bearing eccentric. NOTICE. Avoid misalignment or twisting of
rod on eccentric shaft or excessive bearing wear will result.
PULSATION DAMPENER REPLACEMENT
1. Disconnect power leads from pump and remove from mount.
2. Remove nine bottom plate screws and the bottom plate. Pull
out and replace pulsation dampener
3. Replace bottom plate and screws. Tighten evenly to ensure an
air and water seal.
4. Reinstall pump and reconnect power leads.
MARINE SWITCH PANELS
O
NO
F
F
BILGE PUMP
44960-0000
Lighted Switch
w/Boot SPST
O
NO
F
F
BILGE PUMP
44960-0001
Unlighted
SPST
