JABSCO 5850-0001 User manual

Model 5850-0001
Model 5850-0001
SELF-PRIMING PUMP
FEATURES
Body: Bronze
Impeller: Jabsco Neoprene Compound
Shaft: 316 Stainless Steel
Shaft Seal: Lip Type
Ports: 3/4" NPT
Weight: 6 lb (approx.)
APPLICATION
Marine Engine Cooling
FOR ENGINE MODELS
CHRIS CRAFT - M Series (131 to 158 HP)
PALMER - DH 120
KERMATH - Sea Rover
LATHROP - LH Master-LH6-LH - Atom
OSCO - Hercules Diesel 685
UNIVERSAL - Super 6-Model Z
HERCULES - JX
(and others)
OPERATING INSTRUCTIONS
Pump will self-prime at low or high speeds. Make sure
scoop and inlet line are clear and all connections airtight.
Do not run pump dry for more than 30 seconds. Lack of
water flow may damage impeller. To drain pump, loosen
end cover screws.
SERVICE INSTRUCTIONS
IMPELLER REPLACEMENT: Remove end cover and
gasket. Pull impeller out by grasping hub or blades with
pliers. Replace impeller, gasket and end cover. A light
coating of grease in impeller bore will aid priming on dry
start up. (Use correct Jabsco gasket, a thicker or thinner
gasket may cause impeller damage.) Standard gasket is
0.010" thick.
INSTALLATION INSTRUCTIONS
Engage shaft with drive tang, make sure flange seats
squarely on mounting surface and bolt to engine.
Connect inlet and outlet fittings using pipe compound to
seal threads.

U.S.A.
Jabsco
1485 Dale Way, P.O. Box 2158
Costa Mesa, CA 92628-2158
Tel: [phone]
Fax: [phone]
UNITED KINGDOM
Jabsco
Bingley Road, Hoddesdon
Hertfordsire EN11 OBU
Tel: [phone]
Fax: [phone]
CANADA
Fluid Products Canada
55 Royal Road
Guelph, Ontario N1H 1T1
Tel: [phone]
Fax: [phone]
JAPAN
NHK Jabsco Company Ltd.
3-21-10, Shin-Yokohama
Kohoku-Ku, Yokohama, 222
Tel: [phone]
Fax: [phone]
GERMANY
Jabsco GmbH
Oststrasse 28
22840 Norderstedt
Tel: [phone]
Fax: [phone]
THE PRODUCT DESCRIBED HEREIN IS
SUBJECT TO THE JABSCO ONE YEAR LIMITED
WARRANTY, WHICH IS AVAILABLE FOR YOUR
INSPECTION UPON REQUEST.
©Copyright 2000, ITT Industries Printed in U.S.A. All Rights Reserved Form: 43000-0202 Rev. 8/2000
MAJOR REPAIR: Remove pump from engine to replace
seal, bearings or shaft. To disassemble pump, remove
end cover, gasket and impeller as outlined above. Press
on impeller end of shaft to remove shaft and bearing
assembly. Remove cam and wearplate assembly. Use
screw driver to pry bearing seal out of bearing bore.
Press shaft seal out towards impeller bore. Replace all
worn parts. When installing coupling, support splined
end of shaft. Press bearing seal in bearing bore with lip
towards bearing. Press shaft and bearing assembly into
bearing bore. Press adaptor ring into body. Install slinger
on shaft. Install seal spacer in seal cavity. Install 0-ring in
seal bore. Press seal in seal cavity with lip facing toward
impeller bore. Apply a thin coat of sealant to top of cam
and cam screw threads, install wearplate and cam
assembly. (Be sure cam is flush with end cover surface.)
Secure with screw. Lubricate impeller bore, install
impeller. Lubricate impeller face, install gasket and end
cover and secure with screws.
EXPLODED VIEW
PARTS LIST
Part
Key Description Qty. Number
1Screw (End Cover) 6 91002-0020
2End Cover 1 11830-0000
3* Gasket 1 3298-0000
4* Impeller 1 1210-0001
6* Seal (Shaft) 1 92700-0060
7* O-Ring † 1 92000-0210
8Screw (Cam) 1 91003-0010
9Cam Wearplate 1 7884-0000
Assembly
10 Seal Spacer 1 3166-0000
11 Body 1
12 Adaptor Ring 1 3376-0000
13 Slinger 1 3286-0000
14 Shaft 1 5857-0000
15 Bearing Seal 1 92700-0060
16 Ball Bearing 2 92600-0130
17 Bearing Spacer 1 3383-0000
18 Coupling 1 3278-0000
Service Kit 90033-0001
*Parts Contained in Service Kit
†O-ring used only in pumps manufactured prior to June 1993.
