JABSCO CENTRI PUPPY 18510-000 Series User manual

Model 18510-000X
“CENTRI PUPPY”
Bronze Centrifugal DC Motor/Pump Unit
With Lip Seal
FEATURES
Body & Impellor Bronze
Seal Lip type, Viton®
Port Size 3/4” NPT Internal
Motor Permanent Magnet, Fully Enclosed
Ignition Protected
Shaft Stainless Steel
Weight 5 lb, (2,3 kg) approx.
Motor meets USCG Electrical Standards (Title 33,
Chapter I, Part 183; Subpart I) for IGNITION PROTEC-
TION on gasoline powered vessels.
Viton is a registered trademark of I.E. DuPont Co.
VARIATION AVAILABLE
Model Description
18510-0000 12Vdc
18510-0001 24Vdc
PERFORMANCE (Nominal 12 Vdc System)
Amps Ft. of Water GPM
8220
6.7 6 14.5
5.4 10 7.5
4.5 12.5 Shutoff
Model 18510-000X
APPLICATION
Suited for many general pumping applications where a
flooded intake condition exists. This pump is NOT
SELF_PRIMING. Typical uses include livewell filling and
circulation, deisel fuel transfer (NOT GASOLINE), and
other applications not requiring a self-priming pump.
INSTALLATION
The pump must be mounted in a dry location – the motor is
not waterproof and must not be submerged. The unit can be
mounted in any desired position. It is best to mount so that
water dripping from loose port connections will not wet the
motor. The pump head may be mounted vertically on a thru-
hull and seacock for applications requiring overboard water
to be pumped aboard. A seacock must be used between the
hull inlet fitting and pump on below-waterline installations.
WARNING
!Explosion hazard. Do not pump
gasoline, solvents, thinners or other
flammable liquids. To do so can cause
an explosion resulting in injury or death.
Explosion hazard. Do not operate with
rivets removed from motor case.
Explosion resulting in personal injury,
death or property damage can occur.
Case openings must be sealed to avoid
explosion and maintain ignition
protected rating.
WARNING
!

ELECTRICAL CONNECTIONS
Connect black wire to negative (-) terminal of battery.
The orange wire should run to a properly sized (see elec-
trical specification) overload protected switch or circuit
breaker, with a wire from switch or breaker to a positive
(+) terminal of battery. Electrical circuit must be indepen-
dent of all other accessories. To prolong motor life, install
pump so normal motor rotation is clockwise. Use proper
wire size as determined by wire table elsewhere on this
sheet.
PLUMBING CONNECTIONS
The intake and outlet ports have internal 3/4” pipe
threads. Brass or plastic pipe fittings may be used to suit
the installation. Plastic fittings that may be subject to
cracking due to vibration should not be used below the
the waterline. PTFE pipe joint tape or compound should
be used if brass fittings are installed in pump. Hose
maybe used with common pipe adaptor installed in the
pump ports.
MAINTENANCE
Check all electrical connections periodically, particularly
in saft water areas. Corrosion can cause loss of perfor-
mance or nonoperation in extreme cases. The motor
should be protected with a corrosion inhibiting spray and
any rust should be removed and the motor repainted.
WIRE SIZE TABLE
CONNECTION LENGTH
BETWEEN BATTERY 12V 24V
AND MOTOR
1-10 ft. (3m) #12 #16
11-20 ft. (6m) #10 #16
21-30 ft. (9m) 8 #12
ELECTRICAL SPECIFICATIONS
BETWEEN BATTERY 12V 24V
Amp Draw 8 4
(Approx.)
Fuse Size 10 5
OPERATION
The pump may be run dry for short periods of time.
Running without liquid allows heat to build up between
seal and shaft, thus shortening seal life. The pump can
run against a closed outlet such as encountered when
using a garden hose type shut-off nozzle. Small particles
of trash and debris will pass through the pump, though
an intake strainer should be fitted K excessive problems
are encountered with pump clogging.
WARNING
!
Explosion hazard. If pump is operated
in an area containing flammable vapors,
wire leads must be joined by insulated
mechanical locking connectors. Loose
or inadequate wire connections can
spark resulting in an explosion. Property
damage, injury or death can occur.
Motor runs hot; about 180°is normal
temperature. Prolonged contact
during operation can cause a burn.
WARNING
!
BATTERY
INLET
PORT
BLACK
WIRE
ORANGE
WIRE
OUTLET
PORT
Overload
Protected
Distribution
Panel
WIRING DIAGRAM

PARTS LIST
Key Part Number Description Qty.
1 18513-0000 Pump Body 1
2 18514-0000 End Cover 1
3 18515-0000 Impeller 1
4 18516-0000 Gasket 1
5 6342-0000 Slinger 1
6 1040-0001 Seal, Viton 1
7* 18517-0000 Motor 12 Vdc 1
18517-0001 Motor 24 Vdc 1
8 98019-0020 Body Mounting Screw 2
9 91027-0013 End cover Screw 4
10 91602-0020 Lock Washer #10 S.S. 4
11 18753-0557 Impeller Set Screw 1
12 92650-0040 Plug 1
13 92900-0330 Grommet 4
*Includes motor base
2
12 3657 11
104 91813
SECTIONAL VIEW
SERVICE INSTRUCTIONS
Disassembly
1. Remove end cover screws, end cover and gasket.
2. Remove pipe plug in top of body and rotate impeller
so the set screw aligns with the plug hole. Insert a
3/32” allen wrench through the plug hole and loosen
impeller setscrew. Remove the impeller.
3. Remove screws securing the body to the motor and
remove the body.
4. From the inside of the body, insert a dowel into the
seal area and press the seal out of the seal bore.
Assembly
1. From the rear of the body, press the seal into the seal
bore with the lip angled toward the pump cavity.
2. Apply a small amount of grease to the shaft in the
area where the seal contacts it. Slide the body on to
the shaft and secure it t othe motor with the two
mounting screws.
3, Align the impeller set screw with the flat on the motor
shaft and slide the impeller onto the shaft until it hits
the rear of the body. Then slide the impeller forward
about 1/16” and secure it with the set screw. Rotate
the impeller to ensure it does not rub on the body. Re-
install the pipe plug in the pump body.
4. Ensure the body and end cover surfaces are clean
where they contact the gasket. Align the end cover
and new gasket with the body and secure it with the
end cover screws.
MAINTENANCE
Check all electrical connections periodically, particularly
in salt water areas. Corrosion can cause loss of perfor-
mance or non-operation in extreme cases. The motor
should be protected with a corrosion inhibiting spray and
any rustshould be removed and the motor repainted.

© Copyright 2003, ITT Industries Printed in U.S.A. All Rights Reserved Form: 43000-0319 Rev. 3/03
ONE YEAR LIMITED WARRANTY
A. LIMITED WARRANTY:
ITT warrants that at the time of shipment, the products
manufactured by ITT and sold hereunder shall be in con-
formity with applicable written specifications and
descriptions referred to of set forth herein free from
defects in material and workmanship, merchantable, and
suitable for a particuIar purpose, provided such is
implied by State law under the circumstances of this
sale.
B. WARRANTY ADJUSTMENT:
1. ITT agrees to repair or furnish a replacement for, but
not to remove or install, any product or component
thereof which, within one (1) year from date of pur-
chase, shall upon test and examination by ITT prove
defective within the albove warranty. Receipt verifying
purchase date is required to obtain adjustment.
2. Buyer shall notify ITT of any defect within this war-
ranty no later than ninety (90) days after the defect is
discovered.
3. No product will be accepted for return or replacement
without the prior written authorization of ITT. Upon
such authorization, and in accordance with instruc-
tions from ITT, the product will be returned to ITT,
shipping charges prepaid by Buyer. Products
returned to ITT will be addressed as follows:
ITT JABSCO
20 Icon
Foothill Ranch, CA 92610-3000
or to such alternate locations as may be designated
on the product, its container, or this sheet.
Repair or replacement made under this warranty will
be shipped prepaid to Buyer.
C. EXCLUSIONS FROM WARRANTY AND LIMITA-
TION OF LIABILITY:
1. The foregoing warranty is limited solely as set forth
herein and applies only for the period designated
above.
2. ITT SHALL NOT BE LIABLE FOR ANY LOSS, DAM-
AGE, SPECIAL OR CONSEQUENTIAL DAMAGE OF
ANY KIND, WHETHER BASED UPON WARRANTY,
CONTRACT, NEGLIGENCE, OR STRICT LIABILITY
ARISING IN CONNECTION WITH THE SALE, USE,
OR REPAIR OF THE PRODUCT.
3. THE MAXIMUM LIABILITY OF ITT IN CONNECTION
WITH THIS WARRANTY SHALL NOT IN ANY CASE
EXCEED THE CONTRACT PRICE FOR THE PROD-
UCT CLAIMED TO BE DEFECTIVE OR UNSUIT-
ABLE.
4. This warranty does not extend to any product manu-
factured by ITT which has been subjected to misuse,
neglect, accident, improper installation. or use in vio-
lation of instructions furnished by ITT.
5. This warranty does not extend to or apply to any unit
which has been repaired or stored at any place other
than ITT’s factory, or by persons not expressly
approved by ITT, not to any unit the serial number,
model number, or identification of which has been
removed, defaced or changed.
6. Components manufactured by any supplier other
than ITT shall bear only that warranty made by the
manufacturer of that product.
7. This warranty applies to products defined as “con-
sumer products” by the Consumer Product
Warranties Act as from time to time amended.
D. CONSUMER RIGHTS: This warranty gives you spe-
cific legal rights, and you may have other rights which
very from state to state. Some states do not allow exclu-
sion or limitation of damages.
STANDARD WARRANTY: if the products manufactured
and said hereunder are not Consumer Products, the
warranty extended to Buyer shall be as set forth in sub-
paragraphs (A), (B), and (C), EXCEPT THAT ALL
EXPRESS OR IMPLIED WARRANTIES OR MER-
CHANTABILITY OR SUITABILTEY FOR ANY PARTIC-
ULAR PURPOSE ARE EXCLUDED.
