Jadever JCL User manual

JADEVER SCALE CO., LTD - www.dongminhphat.com
0 JCL Service Manual - www.cantudong,com
Contents
1. Assembly Drawing
1-1 Explosive view……………………………………………………………………
1-2 Part list…………………………………………………………………………….
1
1
2. Electronic Construction
2-1 Block diagram…………………………………………………………………….
2-2 Circuit diagram……………………………………………………………
2
3. RS-232 Communication
3-1 RS-232 connector………………………………………………………………..
3-2 RS-232 circuit diagram…………………………………………………….......
3-3 Option……………………………………………………………………..
3-5 Time setting………………………………………………………………………
3-6 RS-232 output format…………………………………………………………..
5
5
6
9
10
4. Adjustments and Settings
4-1 Model setting…………………………………………………………………...
4-2 Single point calibration………………………………………………………...
4-3 Linear calibration……………………………………………………………….
4-4 Function setting ………………………………………………………………..
4-5 Scale initialization………………………………………………………………
4-6 Set division……………………………………………………………………...
4-7 Offset value display and key test……………………………………………..
4-8 Unit switch operation…………………………………………………………..
12
12
12
13
15
15
15
15
5. Trouble Shootings
5-1 Primary checks………………………………………………………………...
5-2 Problems and solutions………………………………………………………..
5-3 Error message………………………………………………………………….
16
17
19
6. Parts Replacement
6-1 Main board replacement …………………………………………………….
6-2 Load cell replacement…………………………………………………………
6-3 Rechargeable battery replacement ………………………………………...
6-4 RS-232 replacement………………………………………………………….
6-5 Keypad replacement………………………………………………………….
6-6 LCD replacement………………………………………………………………
20
22
24
24
25
26
7. Applicable Version and Software……………………………………………
27

JADEVER SCALE CO., LTD - www.dongminhphat.com
1 JCL Service Manual - www.cantudong,com
1.Assembly Drawing
1.1 Explosive view
1-2 List of parts
No.
Part Name
Quantity
Part No.
Material No.
1
Xm JCL front panel
1
JCL-1
20-1925-0001
2
Xm Keypad
1
JCL-2
21-0506-0010
3
Xm Leveler
1
JCL-3
02-0108-0003xm(14mm)
4
Xm Transformer
1
JPL-4
61-0003-0400
5
Xm Switch
1
JCL-5
60-0000-0000xm
6
Xm Socket
1
JCL-6
60-0503-0001xm
7
Xm JCL main board
1
JCL-7
80-0124-0000
8
Xm Bottom cover
1
JCL-8
02-0000-6020
9
Xm Lower support
1
JCL-9
10-0425-0100

JADEVER SCALE CO., LTD - www.dongminhphat.com
2 JCL Service Manual - www.cantudong,com
10
Xm Shipping protection screw
1
JCL-10
31-0404-0000xm
11
Xm Leveling foot
4
JCL-11
01-0100-0030
12
Xm RS232 board
1
JCL-12
80-0900-2200xm
13-1
Xm TRUE-TEC load cell-10k
1
JCL-13
51-0701-0010
13-2
Xm TRUE-TEC load cell-20k
1
JCL-13
51-0701-0020
13-3
Xm TRUE-TEC load cell-35k
1
JCL-13
51-0701-0030
14
Xm Rechargeable battery
1
JCL-14
61-0201-0098xm
15
Xm Battery cover
1
JCL-15
02-0000-6030
16
Xm Rear display
1
JCL-16
80-0126-0010
17
Xm Upper support
1
JCL-17
10-0425-0000
18
Xm Upper cover
1
JCL-18
02-0000-6000
19
Xm Rear panel
1
JCL-19
20-1925-0010
20
Xm Plastic weighing pan
1
JCL-20
02-0000-6040
21
Xm Stainless Steel weighing pan
1
JCL-21
12-0000-1200
2. Electronic Structure
2 – 1 System block

JADEVER SCALE CO., LTD - www.dongminhphat.com
3 JCL Service Manual - www.cantudong,com
2-2 Circuit diagram
MCU

JADEVER SCALE CO., LTD - www.dongminhphat.com
4 JCL Service Manual - www.cantudong,com
POWER
AD

JADEVER SCALE CO., LTD - www.dongminhphat.com
5 JCL Service Manual - www.cantudong,com
DISPLAY
REAR DISPLAY

JADEVER SCALE CO., LTD - www.dongminhphat.com
6 JCL Service Manual - www.cantudong,com
3. RS-232 communication
3-1 RS-232 connector
3-2 RS-232 Circuit Diagram

JADEVER SCALE CO., LTD - www.dongminhphat.com
7 JCL Service Manual - www.cantudong,com
3-3 Option
Scale to printer
Scale to BP545D(TDP) printer
Scale to SH-24（TP）printer
Universal 25 pin (male) to 9 pin (male) RS-232
connecting cable.
Universal 25 pin (male) to 25 pin (male) RS-232
connecting cable.
Scale to ZEBRA printer
Scale to EZ printer
Universal 25 pin(male) to 9 pin(male) RS-232
connecting cable.
Universal 25 pin(male) to 9 pin(male) RS232
connecting cable.
Scale to PC
1. Get receiving program ready on your computer.
2. Please set the print mode as “Prt.Co” (continuous print, the scale will output the data to
the PC continuously).
Commonly used 9 female ~25male RS232 connecting wire.
Note: The hollow dots represent male connectors and the black dots represent female
connector.

JADEVER SCALE CO., LTD - www.dongminhphat.com
8 JCL Service Manual - www.cantudong,com
Scale to light tower
The pin of light tower
Pictures
The light tower should be connected to the 25-pin
(male) socket.
Light tower to scale
That is commonly used 25pin port (male) ~ 25 pin
port (female) RS232 connecting wire.
Note: The hollow dots represent the male
connectors and the black dots, female connectors.
Note: after the light tower connected to scale properly, the corresponding lamp will light
up to indicate the result of quantity check.
Red lamp on: The quantity of weighing articles on the weighing pan exceeds the upper limit.
Green lamp on: The quantity of weighing articles on the weighing pan is between upper and
lower limits.
Orange lamp on: The quantity of weighing articles on the weighing pan is less than lower limit
and the weight of the articles is more than 20 divisions.

JADEVER SCALE CO., LTD - www.dongminhphat.com
9 JCL Service Manual - www.cantudong,com
Scale to PC and light tower
Example of option
Option
External Device
Print out format
AP1
RS232+RTC+Relay
＋
TDP

AP2
RS232+RTC+Relay
＋
SH-24（TP）

Wire connection
Pictures
Note: The hollow dots represent the
male connectors and the black dots
are for female connectors.

JADEVER SCALE CO., LTD - www.dongminhphat.com
10 JCL Service Manual - www.cantudong,com
AP3
RS232+RTC+Relay
＋
ZEBRA

Applicable to the quality control of
the factory product quantity or
weight and that of the total
production line.
LED Light Tower
EZ
+

2008-06-28
14:47:25
G.W.:+ 4.000kg
U.W.: 20.000g/pcs
Total: 200pcs
AP4
RS232+RTC+Relay
＋
PC


JADEVER SCALE CO., LTD - www.dongminhphat.com
11 JCL Service Manual - www.cantudong,com
3-4 RS-232 output format
Baud Rate ：2400、4800、9600
Data Bit ：8
Parity ：N ( None )
Stop Bit ：1
Code ：ASCII
Bit Format ：
LSB
MSB
0
1
2
3
4
5
6
7
8
Start
Bit
Parity
Stop
Bit
Data Format：
Kg
G/N
.
W
.
：
+/-
k
g
CR
LF
weight
U
.
W
.
：
g
/
p
c
s
CR
LF
Unit weight
T
o
t
a
l
：
p
c
s
CR
LF
pcs
Example:
G.W. ：+ 2.2352 kg
U.W. ：+ 0.5352 g/pcs
Total ：4176 pcs
lb
G/N
.
W
.
：
+/-
l
b
CR
LF
weight
U
.
W
.
：
l
b
/
p
c
s
CR
LF
Unit weight
T
o
t
a
l
：
p
c
s
CR
LF
pcs
Example:
G.W. ：+ 2.2352 lb
U.W. ：+ 0.5352 lb/pcs
Total ：4pcs
G = GROSS N = NET
4. Adjustments and Settings
4-1 Maximum Weighing Capacity & Division Setting
Capacity Setting:
Turn on the power while pressing key M+/SAVE .The screen will show Capacity such as
3.000KG.

JADEVER SCALE CO., LTD - www.dongminhphat.com
12 JCL Service Manual - www.cantudong,com
1) Use key M-/HI or PRINT/LO to choose the capacity.
Use key MR or TARE to move the decimal point.
Use key SMPL to choose the unit.
2) Or use key G/N/SET to set the capacity freely, use key MR or TARE to shift leftwards
or rightwards, use M-/HI or PRINT/LO to set the value or move the decimal point, and
use SMPL to choose the unit.
After setting the capacity, use key M+/SAVE to save the setting and advance to division
setting.
Division Setting:
After enter the division setting parameter, the screen will show Division such as 0.2G.
1) Use key M-/HI or PRINT/LO to choose the division.
Use key MR or TARE to move the decimal point.
2) Or use key G/N/SET to set the capacity freely, use key MR or TARE to shift leftwards or
rightwards, use M-/HI or PRINT/LO to set the value or move the decimal point.
After setting, use key M+/SAVE to save the setting and advance to calibration, or use key
ZERO/ESC to cancel the settings and return to weighing mode.
4-2 Single point calibration
1）Press and hold key TARE while powering on the scale. The screen displays “CAL” and unit
chosen, then release the keys.
2）Press key TARE to enter the zero point calibration mode, with “ 0.00 ” appears then
flashes. （Please put no load on the weighing pan at the moment.）
3) Wait till “ 1.00kg (the value of 1/3 full capacity) " appears or set the calibration value by
pressing G/N/SET , and use key MR or TARE to shift leftwards or rightwards, use M-/HI
or PRINT/LO to set the value and use M+/SAVE to save value. Put the corresponding
weights on the weighing pan and press key TARE, the calibration procedure starts, press
M+/SAVE and the calibration procedure will be completed with a“ ” displayed on the
screen and return to normal weighing mode.

JADEVER SCALE CO., LTD - www.dongminhphat.com
13 JCL Service Manual - www.cantudong,com
4-3 Linear calibration
1）Press and hold key TARE while powering on the scale. The screen displays “CAL” and unit
chosen, then release the keys.
2）Press key TARE to enter the zero point calibration mode, with “ 0.00 ” appears then
flashes. （Please put no load on the weighing pan at the moment.）
3) Wait till “ 1.00kg (the value of 1/3 full capacity) " appears or set the calibration value by
pressing G/N/SET , and use key MR or TARE to shift leftwards or rightwards, use M-/HI
or PRINT/LO to set the value and use M+/SAVE to save value. Put the corresponding
weights on the weighing pan and press key TARE, the calibration procedure starts.
4) After finishing, put additional 500g and the screen will show 1.5kg. Use TARE to start the
second point calibration.
5) Repeat the procedure 4) to continue the linear calibration, and press M+/SAVE and the
calibration procedure will be completed with a“ ” displayed on the screen and return to
normal weighing mode.
4-4 Offset value display and keypad test
1) Turn on the power while pressing key G/N/SET; Use MR or TARE to make the scale
displays CHECK(SET 00), and press G/N/SET again, the screen show MPC, version, date
and offset value.
2) Under the offset showing screen, press each button to check if they word according to
following tips: Use numeric buttons to show NUM*, Use SMPL to show SMPL, Press
G/N/SET to make green light(GN) on, Press G/N and backlight on(UWS), press
+PRINT/HI and red light(Hi) on, Press MR to show MR, Press TARE to show TARE, and
press M+/SAVE to show MP, Press -PRINT/LO and make orange light (LO) on. Press
ZERO/ESC to return SET 00 screen and CHECK flashes.
Press key ZERO/ESC any time to go back to weighing mode
About offset value:
The offset value of no load condition should be higher than 10000, and lower 700,000 in full
load condition.

JADEVER SCALE CO., LTD - www.dongminhphat.com
14 JCL Service Manual - www.cantudong,com
Preliminary checks when the offset value is out of the normal range:
1) Is the scale is placed at a flat and stable surface?
2) Is there an overload situation?
3) Is the shipping protection screw removed?
4) Is there anything under the weighing pan?
5) Is the battery electricity capacity ok?
6) Please refer to 2-2 to see if the fault is due the power circuit failure.
Compensation method
: If the offset value is too high, please install a Resistor between S+ and E-. The higher
resistance, the lower the offset value becomes.
E+
E-
S-
S+
: If the offset value is too low, please install a Resistor between S- and E-.
The lower resistance, the higher the offset value becomes.
E+
E-
S-
S+
4-5 Scale initializations
4-5-1 User Initializations and keep its capacity and calibration value
1) Turn on the power while pressing key G/N/SET; the scale displays CHECK(SET 00), and
use MR or TARE to choose the parameter RESET(SET 17), use G/N/SET to show
RESET?, and use M+/SAVE to show RESET—and OK, then back to RESET.
2) Press key ZERO/ESC to return to weighing mode.
B
R
R
A
1

JADEVER SCALE CO., LTD - www.dongminhphat.com
15 JCL Service Manual - www.cantudong,com
4-5-2 Factory Initializations
1) Turn on the power while pressing key SMPL and G/N/SET; the scale displays
F.INIT(SET 00). Press G/N/SET to show F.INIT?, and hold key G/N and G/N/SET again
to show INIT--- and OK and back to F.INIT.
2) Press key ZERO/ESC to return to weighing mode.
4-6 Unit setting menu
1) Factory default unit setting
Turn on the power while pressing key SMPL and G/N/SET; the scale will show
F.INIT(SET 00). And use key MR or TARE to choose parameter F.UNIT(SET 03). Use key
G/N/SET to enter unit switch screen, and use SMPL to choose the unit between kg, g, lb,
lb-oz, 市斤,台斤,台斤-台两,港斤,港斤-港两, pcs, use MR or TARE to choose ON or
OFF. Press M+/SAVE to save the setting and back to F.UNIT. Press key ZERO/ESC to
return to weighing mode.
Note: only the unit set ON could be used by user.
2) unit setting by user
Turn on the power while pressing key G/N/SET; the scale displays CHECK(SET 00)., and
use MR or TARE to choose the parameter UNIT(SET 03).. Use G/N/SET to show the
weight’s unit and unit weight unit ‘s, Press SMPL to choose the unit needed, such as ①KG、
G、、 ② G、G、、③ LB、LB、、④ KG、KG、、, press M+/SAVE to save setting, press
ZERO/ESC to return UNIT flashs, and press ZERO/ESC to return to weighing mode.
4-7 In System Programming (ISP)
Press and hold key SMPL and G/N/SET while powering on the scale. The window
displays “F.INIT” (SET 00), and use MR or TARE to choose the parameter ISP(SET 01),
use G/N/SET to show ISP?. Hold on the key G/N and G/N/SET and show ISP…..and
enter ISP mode.

JADEVER SCALE CO., LTD - www.dongminhphat.com
16 JCL Service Manual - www.cantudong,com
4-8 Function setting
Turn on the power while pressing key G/N/SET; the scale displays CHECK.
Use MR or TARE to step through all the available setting items.
Use G/N/SET to enter the parameter setting.
Then use MR or TARE to set the content values of setting items.
Press M+/SAVE to save the setting and return, or press ZERO/ESC to return without
saving.
Press ZERO/ESC to return normal weighing mode.
Note: Press and hold key SMPL and G/N/SET while powering on the scale. Press the passcode “11” and
press M+/SAVE to enter the advanced parameter setting.
5. Trouble shootings
5-1 Preliminary checks
Is the bubble of the level indicator at the center?
Is the battery electricity capacity ok?
Is power cord connected both with the scale and with the outlet properly?
Is the weighing pan the right one?
Is there anything under the weighing pan?
Is the scale at a flat and steady base?
Are there any vibrating, rotating, and/or reciprocating equipment around?
5-2 Problems and solutions

JADEVER SCALE CO., LTD - www.dongminhphat.com
17 JCL Service Manual - www.cantudong,com
Problem
Possible Cause
Basic Inspection and
troubleshooting
Lead-acid battery
defective
Remove battery and power on by using
charging transformer to see if the failure is due
to battery defect.
Charging transformer
problem
Please try a normal charging transformer to
see if the scale can be powered on.
CPU / Crystal
11.0592M (oscillating
circuit) fault
Replacement is needed.
LCD or related LCD
circuit fault
After confirming that there is no broken board
line or short circuit of connection between LCD
and other conducting objects, please replace
LCD.
Power circuit fault
Please check the working voltage of CPU (pin
44)/LM2930/TIP32C/Q7/4069(pin3/6/14)/Q5,
then replace the one which working voltage is
abnormal.
Power on
failure
Malfunction in ON/OFF
switch
Replace the ON/OFF switch
Lead-acid battery
defective
Remove battery and power on by using
charging transformer to see if the failure is due
to battery defect.
Charging transformer
problem
Please try a normal charging transformer to
see if the scale can be powered on.
1. Fuse burn down, replacement is required.
2. Check D2/ Q1(D313)/U5
Q2/Q3/Q4,then replace the defective
components.
3. Charge lamp defective, replacement is
required.
Charging
Failure or
Service Life
Shortened
Components or power
circuit defective
4. The polarity or the charging lamp is
reversed.

JADEVER SCALE CO., LTD - www.dongminhphat.com
18 JCL Service Manual - www.cantudong,com
LCD defective
After confirming that there is no broken board
line or short circuit of connection between
LCD and other conduction objects, please
directly replace LCD.
Component or part
defective
Please check CP19/LM2930 , then replace
the defective one.
Poor LCD
Display
U10(IC6554) related
circuit fault
Please check U10(IC6554) related circuit
fault, replacement is needed for the defective
one.
Component
LM2931,AD5530 or
4.9152M is defective
Replacement is required
Incorrect
weighing
Load cell Malfunction
Replacement is required
Q11 or Q8 defective
Please check / replace Q11 or Q8
Buzzer
does not work
BUZZER defective or
buzzer circuit fault
Replacement is required
Keypad or keypad circuit
fault
Check/replace keypad or keypad circuit.
CPU / CPU program
effective
Check/replace CPU
Keypad
dysfunction
Component 74LS139
defective
Check / replace component 74LS139
Memory
dysfunction
Component
24C02,R29,R30,R31 or
CP18 defective
Please check 24C02,R29,R30,R31and
CP18,then replace the defective components
Wrong setting
Please check /reset external device/ baud
rate/print mode(refer to 3-3)
RS-232 board defective
Please check/replace RS-232 board.
Bad connection between
RS-232 board and main
board
Please check/replace the wire connection
Messy code
occur in the
print out
copies
Defective in external
device
Maintenance/replacement is need.

JADEVER SCALE CO., LTD - www.dongminhphat.com
19 JCL Service Manual - www.cantudong,com
5-3 Error Message
Error message
Problems
Solutions
Initial zero point exceeds ＋
/-30% (take 30% as reference
basis)
1. To check whether there are other alien
articles on the scale pan, remove those
articles.
2. LOAD CELL failure, which requires to be
changed or to contact our Service.
Higher or lower than A/D
resolution range.
1. Check whether it is A/D failure, if yes, please
replace AD.
2. LOAD CELL failure, replacement is required
or contacts our Service.
EEPROM Chksum failure
Re-sold EEPROM or contact our
Service.
The weighed articles are overload.
Do not load the item exceeds the
maximum tolerance.
LCD backlight defective
Replacement is required
LCD backlight no
function
Component defective
Please check/ replace Q9,CPU,P71,
R72,R73,R74,R75,R76
Insufficient cell voltage
Please recharge the battery
Rechargeable failure
If the voltage of the battery is lower than 5.7V
and the battery indication lamp is still in
green color, please immediately replace the
rechargeable battery.
Component defective
Please check/replace R34,R35,R36,Q10
Battery symbol
Bad connection
between R34 and
LM2930
Please repair the wire connection between
the two components.
