JAI AD-130GE User manual

1036E-1201
AD-130GE
Digital 2CCD Progressive Scan
Multi-Spectral Camera
Document Version: 1.1
AD-130GE_Ver.1.1_Mar2012
User's Manual

AD-130GE
2
Notice
The material contained in this manual consists of information that is proprietary to JAI Ltd.,
Japan and may only be used by the purchasers of the product. JAI Ltd., Japan makes no
warranty for the use of its product and assumes no responsibility for any errors which may
appear or for damages resulting from the use of the information contained herein. JAI Ltd.,
Japan reserves the right to make changes without notice.
Company and product names mentioned in this manual are trademarks or registered
trademarks of their respective owners.
Warranty
For information about the warranty, please contact your factory representative.
Certifications
CE compliance
As defined by the Directive 2004/108/EC of the European Parliament and of the Council, EMC
(Electromagnetic compatibility), JAI Ltd., Japan declares that AD-130GE complies with the
following provisions applying to its standards.
EN 61000-6-3 (Generic emission standard part 1)
EN 61000-6-2 (Generic immunity standard part 1)
FCC
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Warning
Changes or modifications to this unit not expressly approved by the party
responsible for FCC compliance could void the user’s authority to operate the
equipment.

AD-130GE
Supplement
The following statement is related to the regulation on “ Measures for the Administration
of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “.
The table shows contained Hazardous Substances in this camera.
mark shows that the environment-friendly use period of contained Hazardous
Substances is 15 years.
嶷勣廣吭並㍻
嗤蕎嗤墾麗嵎賜圷殆兆各式根楚燕
功象嶄鯖繁酎慌才忽佚連恢匍何〆窮徨佚連恢瞳麟半陣崙砿尖一隈〇  云恢瞳ゞ 嗤蕎  嗤
墾麗嵎賜圷殆兆各式根楚燕 〃泌和

桟隠聞喘豚㍉
窮徨佚連恢瞳嶄根嗤議嗤蕎嗤墾麗嵎賜圷殆壓屎械聞喘議訳周和音氏窟伏翌
亶賜融延、窮徨佚連恢瞳喘薩聞喘乎窮徨佚連恢瞳音氏斤桟廠夛撹冢嶷麟半
賜斤児繁附、夏恢夛撹冢嶷鱒墾議豚㍉。
方忖仝15々葎豚㍉15定。

AD-130GE
3
Table of Contents
JAI GigE® Vision Camera operation manuals ............................................................ 7
Introduction ................................................................................................. 7
Before using GigE Vision camera.......................................................................... 7
Software installation ....................................................................................... 7
Camera Operation .......................................................................................... 8
1. General.................................................................................................. 8
2. Camera nomenclature ................................................................................ 8
3. Main Features......................................................................................... 9
4. Locations and functions ............................................................................10
4.1. Locations and functions .......................................................................10
4.2. Rear Panel Indicator ...........................................................................11
5. Pin configuration & DIP switch ....................................................................12
5.1. 12-pin Multi-connector (DC-in/GPIO/Iris Video)...........................................12
5.2. Digital Output Connector for Gigabit Ethernet ............................................12
5.3. 6-pin Multi-connector (LVDS IN and TTL IN/OUT) .........................................12
5.4. DIP switches.....................................................................................13
5.4.1 SW800 Trigger input 75 ohms termination ...........................................13
5.4.2 SW100 TTL/Open collector output select ............................................13
5.4.3 SW700 Video output for Auto iris lens.................................................13
6. System Configuration.............................................................................14
6.1. System connection .............................................................................14
6.2. RJ-45 outputs ...................................................................................14
6.3. Sync Mode .......................................................................................15
6.4. Lens considerations ............................................................................15
7. Inputs and outputs interface .....................................................................16
7.1. Overview ........................................................................................16
7.1.1 LUT (Cross Point Switch) ..................................................................16
7.1.2 12-bit Counter ..............................................................................17
7.1.3 Pulse Generators (0 to 3) .................................................................17
7.2. Opto-isolated Inputs/Outputs ................................................................17
7.2.1 Recommended External Input circuit diagram for customer ........................18
7.2.2 Recommended External Output circuit diagram for customer ......................18
7.2.3 Optical Interface Specifications .........................................................19
7.3. Input and output circuits......................................................................19
7.3.1 Iris Video output ...........................................................................19
7.3.1.1 Iris Video input and output .........................................................20
7.3.1.2 Iris video output select..............................................................20
7.3.2 Trigger input................................................................................20
7.3.3 EEN (Exposure Enable) output ...........................................................21
7.4. GPIO Inputs and outputs table ...............................................................22
7.5. Configuring the GPIO module.................................................................23
7.5.1 Input /Output Signal Selector ............................................................23
7.5.2 Pulse generators (20 bit x 4) .............................................................23
7.5.3 GPIO interface in GenICam standard....................................................24
7.5.4 Change polarity ............................................................................24
7.5.5 The restrictions to use TTL In I/F in the AD-130GE ...................................25
7.5.6 Caution when the software trigger is used .............................................26
7.6. GPIO programming examples .................................................................28
7.6.1 GPIO Plus PWC shutter ....................................................................28

AD-130GE
4
7.6.2 Internal Trigger Generator ...............................................................29
8. Video Signal Output.................................................................................30
8.1. Sensor layout ...................................................................................30
8.2. Partial scan (JAI Partial Scan ON) ...........................................................31
8.3. Digital Video Output (Bit Allocation) ........................................................32
8.3.1 Bit Allocation (Pixel Format / Pixel Type) –(monochrome sensor).................32
8.3.1.1 GVSP_PIX_MONO8 (8bit).............................................................32
8.3.1.2 GVSP_PIX_MONO10 (10bit) ........................................................32
8.3.1.3 GVSP_PIX_MONO10_PACKED (10 bit) ..............................................33
8.3.1.4 GVSP_PIX_MONO12 (12 bit) .........................................................33
8.3.1.5 GVSP_PIX_MONO12_PACKED (12 bit) ..............................................33
8.3.2 Bit Allocation (Pixel Format / Pixel Type) –(Bayer mosaic color sensor)..........33
8.3.2.1 GVSP_PIX_BAYRG8 ―BayerRG8‖ ....................................................33
8.3.2.2 GVSP_PIX_BAYRG10 ―Bayer RG10‖ ................................................34
8.3.2.3 GVSP_PIX_BAYRG12 ―Bayer RG12‖ ................................................34
8.3.2.4 GVSP_PIX_BAYRG10_Packed (Bayer10bit, Packed output) .....................34
8.3.2.5 GVSP_PIX_BAYRG12_Packed （Bayer12bit, Packed output）................34
8.3.2.4 GVSP_PIX_RGB8_PACKED ―RGB 8Packed‖ ........................................34
8.3.2.5 GVSP_PIX_RGB10V1_PACKED ―RGB 10V1 Packed‖...............................35
8.3.2.6 GVSP_PIX_RGB10V2_PACKED ―RGB 10V2 Packed‖...............................35
8.4. Video timing ....................................................................................36
8.4.1 Horizontal Timing ..........................................................................36
8.4.2 Vertical Timing ..........................................................................37
8.4.3 Partial Scan Vertical Timing ..............................................................38
9. Network configuration..............................................................................40
9.1. GigE Vision Standard Interface...............................................................40
9.2. Equipment to configure the network system...............................................40
9.2.1 PC ............................................................................................40
9.2.2 Cables........................................................................................40
9.2.3 Network card (NIC) ........................................................................40
9.2.4 Hub...........................................................................................41
9.3. Recommended Network Configurations.....................................................41
9.3.1 Guideline for network settings .........................................................41
9.3.2 Video data rate (network bandwidth) ..................................................42
9.3.3 Simplified calculation (Approximate value)............................................43
9.3.4 Note for 100BASE-TX connection ........................................................44
9.4. GigE camera connecting examples ..........................................................44
9.4.1 Using a switching hub for 1 port .........................................................44
9.4.2 Connecting a camera to each port of a multi-port NIC...............................45
9.4.3 The data transfer for multiple cameras ................................................45
9.4.3.1 If delayed readout is not used in continuous mode .............................45
9.4.3.2 If delayed readout is not used in trigger mode ..................................46
9.4.3.3 If delayed readout is used ..........................................................46
10. Functions (Conforming to GenICam SFNC 1.3) ....................................................47
10.1. Acquisition function ..........................................................................47
10.1.1 Basic image acquisition flow ............................................................47
10.1.2 Acquisition mode .........................................................................48
10.1.2.1 Single Frame.........................................................................48
10.1.2.2 Continuous mode ...................................................................49
10.2. Trigger Control ................................................................................50
10.2.1 TriggerSelector(TriggerMode)...........................................................50

AD-130GE
5
10.2.1.1 Acquisition ...........................................................................50
10.2.1.2 Exposure .............................................................................50
10.2.2 Triggersoftware ...........................................................................51
10.2.3 Triggersource ...............................................................................51
10.2.4 TriggerActivation...........................................................................51
10.3. Exposure Control..............................................................................52
10.3.1 Exposure Mode ............................................................................52
10.3.2 ExposureTime .............................................................................52
10.3.3 ExposureAuto ...............................................................................53
10.4. ActionControl..................................................................................53
10.4.1 ActionDeviceKey ..........................................................................53
10.4.2 ActionSelector ............................................................................53
10.4.3 ActionGroupMask .........................................................................53
10.4.4 ActionGroupKey...........................................................................53
10.5. Operation Mode ..............................................................................53
10.5.1 The exposure timing when the trigger pulse is input................................54
10.5.1.1 Auto-detect LVAL-sync / async accumulation ..................................54
10.5.1.2 Relation between the external trigger mode and LVAL Sync/Async ........54
10.5.2 Continuous mode .........................................................................55
10.5.3 Edge Pre-Select (EPS) trigger mode....................................................55
10.5.4 Pulse Width Control (PWC) trigger mode .............................................59
10.5.4.1 Timing chart .........................................................................59
10.5.5 Smearless mode...........................................................................61
10.5.5.1 Sync=Sync, LVAL Async, Smearless Enable=True, EPS trigger ................61
10.5.5.2 Sync Mode=Sync, LVAL Async, Smearless Enable=True, PWC trigger ......62
10.5.6 Reset Continuous Trigger (RCT) mode.................................................63
10.5.7 Sequential Trigger Mode (EPS)..........................................................64
10.5.7.1 Setting parameters .................................................................64
10.5.7.2 Initial settings .......................................................................66
10.5.8 Delayed Readout EPS and PWC Modes .................................................66
10.5.9 Multi ROI mode (Multi Region of Interest) ............................................67
10.5.9.1 Setting parameters .................................................................67
10.5.9.2 Initial parameters...................................................................68
10.5.10 Optical Black transfer mode...........................................................68
10.6. Operation Mode and Functions matrix.....................................................69
10.6.1. Sync Mode = SYNC .......................................................................69
10.6.2 SYNC Mode = Async .......................................................................69
11. Other functions ....................................................................................70
11.1. Basic functions ................................................................................70
11.1.1 2CCD optical assembly ...................................................................70
11.1.2 Electronic shutter ........................................................................70
11.1.3 Shading correction........................................................................71
11.1.4 White balance.............................................................................72
11.1.5 Blemish compensation ...................................................................72
11.1.6 Test signal generator.....................................................................73
11.2. Control Tool Screen ..........................................................................73
11.2.1 Feature Tree Information ...............................................................73
11.2.2 Feature Properties (Guru)...............................................................73
12. External Appearance and Dimensions...........................................................79
13. Specifications.......................................................................................80
13.1. Spectral response.............................................................................80

AD-130GE
6
13.2. Specification Table ...........................................................................81
Appendix ....................................................................................................83
1. Precautions ........................................................................................83
2. Typical Sensor Characteristics..................................................................83
3. Caution when mounting a lens on the camera ...............................................83
4. Caution when mounting the camera...........................................................84
5. Exportation ........................................................................................84
6. References.........................................................................................84
Change History .............................................................................................85
User's Record ...............................................................................................86

AD-130GE
7
JAI GigE® Vision Camera operation manuals
To understand and operate this JAI GigE® Vision camera properly, JAI provides the following
manuals.
User’s manual (this booklet) Describes functions and operation of the hardware
JAI SDK & Control Tool User Guide Describes functions and operation of the Control Tool
JAI SDK Getting Started Guide Describes the network interface
User’s manual is available at www.jai.com
JAI SDK & Control Tool User Guide and JAI SDK Getting Started Guide are provided with the JAI
SDK which is available at www.jai.com.
Introduction
GigE Vision is the new standard interface using Gigabit Ethernet for machine vision applications
and it was mainly set up by AIA (Automated Imaging Association) members. GigE Vision is
capable of transmitting large amounts of uncompressed image data through an inexpensive
general purpose LAN cable for a long distance.
GigE Vision also supports the GenICamTM standard which is mainly set up by the EMVA (European
Machine Vision Association). The purpose of the GenICam standard is to provide a common
program interface for various machine vision cameras. By using GenICam, cameras from
different manufactures can seamlessly connect in one platform.
For details about the GigE Vision standard, please visit the AIA web site,
www.machinevisiononline.org and for GenICam, the EMVA web site, www.genicam.org.
JAI GigE Vision cameras comply with both the GigE Vision standard and the GenICam standard.
Before using GigE Vision camera
All software products described in this manual pertain to the proper use of JAI GigE Vision
cameras. Product names mentioned in this manual are used only for the explanation of
operation. Registered trademarks or trademarks belong to their manufacturers.
To use the JAI SDK, it is necessary to accept the ―Software license agreement‖ first.
This manual describes necessary equipment and the details of camera functions.
Software installation
The JAI GigE Vision SDK & Control Tool can be downloaded from the JAI web site at
www.jai.com. The JAI SDK is available for Windows XP and Vista, 32-bit and 64-bit.
For the details of software installation, please refer to the ―Getting Started Guide‖ supplied on
the JAI SDK download page.

AD-130GE
8
Camera Operation
1. General
This manual covers the digital 2-CCD progressive scan multi-spectral camera AD-130GE.
The AD-130GE is a GigE Vision compliant camera, belonging to the JAI C3 Advanced family. The
AD-130GE employs 2 CCDs, one for Bayer color and the other for NIR monochrome utilizing
prism optics so that the AD-130GE can inspect the objects by visible color sensor and Near IR
sensor with the same angle of view.
The AD-130GE provides a frame rate of 31 frames/second at full resolution. Using partial scan,
the camera can achieve faster frame rates up to 145 fps (8 lines height).
The 1/3" CCDs with square pixels offer a superb image quality. The high-speed shutter function
and asynchronous random trigger mode allows the camera to capture high quality images of
fast moving objects.
The camera features a built-in pre-processing function which includes blemish compensation,
shading compensation, Bayer to RGB interpolation, LUT/gamma correction and knee control.
The AD-130GE also complies with the GenICam standard and contains an internal XML file that
is used to describe the functions/features of the camera. For further information about the
GigE Vision Standard, please go to www.machinevisiononline.org and about GenICam, please
go to www.genicam.org.
As an application programming interface, JAI provides an SDK (Software Development Kit). This
SDK includes GigE Vision Filter Driver, JAI Control tool, software documentation and code
examples.
The JAI SDK can be downloaded from www.jai.com.
The latest version of this manual can be downloaded from www.jai.com
For camera revision history, please contact your local JAI distributor.
2. Camera nomenclature
The standard camera composition consists of the camera main body and C-mount protection
cap.
The camera is available in the following versions:
AD-130GE
Where Astands for "Advanced" family, Dstands for "Dual CCD", 130represents the resolution
"1.3 million pixels", 130indicates that this is the first dual-CCD model with this resolution, and
GE stands for "GigE Vision" interface.

AD-130GE
9
3. Main Features
C3 Advanced series progressive scan camera
GigE Vision, GenICam compliant
Multi-spectral 2-channel CCD camera
Simultaneously captures Visible and Near-IR through the same optical path
1/3‖ progressive scan IT CCDs with 1296 (h) x 966 (v) active pixels
3.75 μm square pixels
RGB 24-bit or 32-bit or Raw Bayer 12- or 10- or 8-bit output for visible
12- or 10- or 8-bit output for Near-IR
30 frames/second with full resolution
Variable partial scan is available with user-definable height and starting line
Programmable exposure from 0.4L(11.49μs) to 982L(31.761ms)
Edge Pre-select, Pulse Width Control and Reset Continuous trigger modes
Sequence trigger mode for on-the –fly change of gain, exposure and ROI
Delayed read out mode for smooth transmission of multi camera applications
Blemish compensation built in
Shading compensation circuit built in
LUT (Look Up Table) for gamma correction
AGC (Automatic Gain Control) from 0dB to 21dB
LVAL synchronous/asynchronous operation (auto-detect)
Auto-iris lens video output for lens control
Programmable GPIO with opto-isolated inputs and outputs
Comprehensive software tools and SDK for Windows XP/Vista/7 (32 bit ―x86‖and 64
bit ―x64‖JAI SDK Ver. 1.2.1 and after )
