JAI CV-M2CL User manual

Digital Monochrome and Color
2 Megapixel Progressive Scan Camera
CV-M2CL
CV-M8CL
Operation Manual
Camera: Revision D
Manual: Version 2.2
M2-8ManuaDec14.doc
JPT 14-12-05

CV-M2CL and CV-M8CL
Table of Contents
1. General .................................................................................................................... 2
2. Standard Composition ................................................................................................... 2
3. Main Features............................................................................................................. 2
4. Locations and Functions ................................................................................................ 3
5. Pin Assignment ........................................................................................................... 4
5.1. 12-pin Multi-connector (DC-IN/Trigger) ....................................................................... 4
5.2. BNC connector for analog monitor video output............................................................. 4
5.3. Digital Output Connector for Camera Link.................................................................... 4
5.4. Input and Output Circuits........................................................................................ 5
5.4.1. Monitor video output ................................................................................................... 5
5.4.2. Iris video output ......................................................................................................... 5
5.4.3. Trigger input ............................................................................................................. 5
5.4.4. EEN output ...............................................................................................................5
5.4.5. Camera Link interface.................................................................................................. 6
6. Functions and Operations............................................................................................... 7
6.1. Basic functions .................................................................................................... 7
6.1.1. Dual video output ....................................................................................................... 7
6.1.2. Burst trigger.............................................................................................................. 7
6.1.3. Reset continuous trigger mode........................................................................................ 8
6.1.4. PIV mode .................................................................................................................8
6.1.5. Digital video out allocation ............................................................................................ 9
6.1.6. Knee function ............................................................................................................9
6.2. Sensor layout and timing .......................................................................................10
6.2.1. CCD sensor layout ......................................................................................................10
6.2.2. Vertical timing..........................................................................................................10
6.2.3. Horizontal timing single channel ....................................................................................11
6.2.4. Horizontal timing details single channel ...........................................................................11
6.2.5. Horizontal timing dual channel ......................................................................................12
6.2.6. Horizontal timing details dual channel .............................................................................12
6.2.7. LVAL synchronous accumulation .....................................................................................13
6.2.8. LVAL a-synchronous accumulation...................................................................................14
6.2.9. Partial scanning vertical timing......................................................................................15
6.2.10. Vertical binning .......................................................................................................16
6.3. Input/Output of Timing Signals ................................................................................17
6.3.1. Input of Timing Signals ................................................................................................17
6.3.2. Output of Timing Signals ..............................................................................................17
6.4. Trigger Modes.....................................................................................................17
6.4.1. Continuous Operation (Non triggered) ..............................................................................18
6.4.2. Edge Pre-select Mode..................................................................................................19
6.4.3. Reset Continuous Trigger mode......................................................................................20
6.4.4. Pulse Width Control Mode ............................................................................................21
6.4.5. Burst Trigger mode.....................................................................................................22
6.4.6. PIV mode ................................................................................................................23
6.5. Other Functions ..................................................................................................24
6.5.1. Mode and function matrix ............................................................................................25
6.6. Request Functions ...............................................................................................26
6.7. Save and Load Functions........................................................................................26
7. Configuring the Camera................................................................................................28
7.1. Mode setting SW1 on rear ......................................................................................28
7.2. RS-232C/Camera Link switch...................................................................................28
7.3. Internal Switch SW 700..........................................................................................28
7.4. RS-232C control ..................................................................................................29
7.5. CV-M2/M8 CL command list ....................................................................................30
7.6. Camera Control Tool for CV-M2/M8 CL .......................................................................31
7.6.1. Control Tool Windows .................................................................................................31
7.6.2. Camera Control Tool Interface.......................................................................................32
7.6.3. Using the Camera Control Tool ......................................................................................35
8. External Appearance and Dimensions................................................................................36
9. Specifications............................................................................................................36
9.1. Spectral sensitivity ..............................................................................................36
9.2. Specification table...............................................................................................37
10. Appendix ................................................................................................................38
11.3. References.......................................................................................................38
11. Users Record ...........................................................................................................39
- 1 -

CV-M2CL and CV-M8CL
- 2 -
1. General
The CV-M2CL and CV-M8CL are digital 2 megapixel monochrome and color cameras designed for
automated imaging and ITS (Intelligent Traffic Systems) applications, featuring high resolution
and high speed within a uniform and compact housing.
The color version CV-M8CL is based on a CCD sensor with primary Bayer color mosaic filter. The
color reconstruction should be done in the host PC.
The high-speed shutter function, asynchronous random trigger mode and partial scan mode
allows the camera to capture high quality images of fast moving objects with a high frame rate.
Functions like burst trigger, reset continuous trigger mode, analog iris video output, knee and
gamma function for single channel makes the camera suitable for intelligent traffic systems.
The CV-M2CL/M8CL features the Camera Link standardized multiplexed signal output interface.
The CV-M2CL revision B starting with sn. E520301 is updated with a new CCD sensor. The sensor
gate control mode (SG) is removed. Some minor bugs in the firmware are solved.
The CV-M2CL revision C includes the color version CV-M8CL revision C, and has new updated
boards. For CV-M2CL a vertical binning function has been added.
Revision D is without binning, and some boards are updated.
The latest version of this manual can be downloaded from: www.jai.com
The latest version of Camera Control Tool for CV-M2/M8 can be downloaded from: www.jai.com
For camera revision history, please contact your local JAI distributor.
2. Standard Composition
The standard camera composition consists of the camera main body and tripod mount plate.
The camera is available in the following versions:
CV-M2CL. Digital Monochrome 2 Megapixel Progressive Scan Camera.
CV-M8CL. Digital Color 2 Megapixel Progressive Scan Camera.
3. Main Features
•Digital 1” monochrome and color 2 megapixel progressive scan CCD camera
•Color version with Bayer RGB color mosaic for host PC color reconstruction
•1600 (h) x 1200 (v) effective 7.4 µm square pixels
•10 or 8 bit video output as Camera Link
•17 full frames/second for single channel video readout
•30 frames/second with dual channel video readout
•One push black level and gain calibrations for dual channel readout
•Higher frame rates with 1/2, 1/4 and 1/8 partial scanning
•Programable partial scanning with 1 line interval for start position and width 50 – 1200 lines.
•CV-M2CL has vertical binning for higher sensitivy and frame rate.
•Edge pre-select and pulse width controlled external trigger modes
•Shutter speed 1/17 (off) to 1/14,000 second in 10 steps
•Programable exposure by edge pre-select shutter 1.5H to 1216.5H with 1 H interval
•Burst trigger for 5 different edge pre-selected exposures in sequence
•Analog video output for lens automatic iris control
•Reset continuous trigger mode (RCT) makes it ideal for traffic control (ITS)
•Analog composite monochrome video output for CCIR/EIA monitor
•PIV mode (Particle Image Velocimetry) for 2 short exposures with very short interval
•Short ASCII commands for fast mode setup via serial port
•Setup by Windows NT/Win2000/XP via RS-232C or Camera Link

CV-M2CL and CV-M8CL
4. Locations and Functions
8
76 5
3 42 1
1. CCD sensor
2. Lens mount (C-mount) *)
3. Rear panel with SW1
4. Digital output connector (Camera Link)
5. DC in/Trigger in/RS-232C connector
6. BNC connector for monitor video output
7. Gain potentiometer
8. Mounting holes M3. (8x)
*) Note: Rear protrusion on the C-mount lens must be less than 10 mm.
Fig. 1. Locations
- 3 -

CV-M2CL and CV-M8CL
5. Pin Assignment
5.1. 12-pin Multi-connector (DC-IN/Trigger)
Type: HR10A-10R-12PB-01 Pin no. Signal Remarks
1 GND
2 +12 V DC input
3 GND
4 Iris Video output Analog video for lens iris control in
continuous mode and RCT mode. *)
5 GND
6 RXD in
7 TXD out
RS 232C on 12 pin. Or via Camera Link.
Int. switch SW700 HR/CL (Refer to 7.2)
8 GND
9 EEN out Or via Camera Link
10 Trigger input TI=1. (Or via Camera Link if TI=0 )
11 Factory use For factory test
12 GND
(Hirose) male.
(Seen from rear of camera.)
3
4
5
6
7
8
9
10
11 12
1
2
Fig. 2. 12-pin connector.
*
)
Refer to 5.4.2. for iris video out
p
ut.
5.2. BNC connector for analog monitor video output
On the BNC connector a monochrome composite video signal (CCIR or EIA) for monitoring is
found, if OS=2. The signal can be viewed on a standard monitor as 50 FPS/15.734 kHz 290 lines if
MN=1, or 60 FPS/15.734 kHz 240 lines if MN=0. It is non-interlaced and for single channel only.
The image covers the full format, but the resolution is lower than the digital video output. For
M8CL the image is monochrome and with RGB pixels as the are from the CCD sensor.
5.3. Digital Output Connector for Camera Link
Type: 26 pin MRD connector
13
14
1
26
3M 10226-1A10JL
Fig. 3. Camera Link connector
The digital output signals follow the Camera Link standardized multiplexed signal output
interface. The output driver is NS type DS90CR285, and the receiver is NS type DS90CR286.
The following signals are found on the Digital Output Connector:
SerTC RXD serial data to camera (Int. switch SW 700. Refer to 7.2)
SerTFG TXD serial data to frame grabber (Int. switch SW 700. Refer to 7.2)
CC1 Trigger input (TI=0 for CL. )
CC2 Factory use
X0 to X3 Camera Link multiplexed data out
Xclk Camera Link clock. Used as pixel clock.
In the Channel Link X0 to X3 multiplexed signals the following signals are encoded.
D0 – D9 2 x 10 bit video data out for right and left channel.
LVAL Line VALid. Video line data is valid.
FVAL Frame VALid. Video frame data is valid.
DVAL Data VALid. Effective video pixel data is valid
EEN Exposure ENable.
(Not specified by Camera Link).
LVAL, FVAL, DVAL polarity is positive. EEN is negative. TRIG is negative as factory setting. TRIG
polarity can be changed by TP. For Camera Link interface principle diagram please check Fig. 7.
- 4 -

CV-M2CL and CV-M8CL
5.4. Input and Output Circuits
5.4.1. Monitor video output
On the BNC connector an analog video signal with
GND
75 Video
Output
GND
75 Video
Output 0.3Vpp
0.7Vpp
+0.4V
75 Ω termination
0.3Vpp
0.7Vpp
+0.4V
75 Ω termination
sync is found if OS=2. The signal can be used
for focus and field of view adjustments.
CCIR if MN=1. (50 fps, 17.734 kHz, 290 active lines.)
EIA if MN=0. (60 fps, 17.734 kHz, 240 active lines.)
It is for single channel normal (TR=0) operation only.
Shutter speed <262 LVAL (CCIR). <262 LVAL (EIA).
Video is monochrome composite 1Vpp with 75 Ωtermination.
For M8 the signal level is affected by the Bayer filter.
The signal is shown is also on CL. (Not for trigger modes.)
5.4.2. Iris video output
Iris video
#4/12
+4V
4k7
75
-4V
Iris video
#4/12
+4V
4k7
75
-4V
+4V
4k7
75
-4V
-0.6V
Black
level
0.5Vpp
No termination
-0.6V
Black
level
0.5Vpp
-0.6V
Black
level
0.5Vpp
No termination
The analog video output without composite sync on
pin #4 12 pin Hirose connector is a 75 ΩDC coupled
circuit. It can be used for iris control if the camera is
in normal continuous mode or Reset Continuous Trigger
mode. Iris video is added from both channels.
Black level is –0.6 volt without termination.
Important note on using this signal for iris control.
The signal for iris video output is taken from the video signal after the gain control. If it is used
for auto iris control, output video level can only be adjusted on the lens level adjust.
Fig. 4. Video output.
5.4.3. Trigger input
The trigger inputs on pin #10 12 pin Hirose
connector is AC coupled. To allow a long pulse
width, the input circuit is a flip flop, which is
toggled by the negative or positive differentiated
spikes caused by the falling or rising trigger
edges.
+5V
GND
15k
TTL
1k
GND
100n
1k
68k 100k
1n
1k
Trig input pin #10
+5V
GND
15k
TTL
1k
GND
100n
1k
68k 100k
1n
1k
Trig input pin #10
The trigger polarity can be changed.
Trigger input level 4 V ±2 V.
The trigger-input impedance is 1 kΩ.
The trigger inputs can be changed to
Camera Link input.
Fig. 5. Trigger input.
GND
+5V
2
2
10k
2k2
75
TTL
100
#9/12
GND
+5V
2
2
10k
2k2
75
TTL
100
#9/12
5.4.4. EEN output
On pin #9 on 12 pin Hirose connector EEN is found.
The output circuit is 75 Ωcomplementary emitter
followers. It will deliver a full 5 volt signal.
Output level ≥4 V from 75Ω. (No termination).
EEN output is also on Camera Link.
Fig. 6. EEN output
- 5 -

CV-M2CL and CV-M8CL
- 6 -
5.4.5. Camera Link interface
The video output is Camera Link, where the 2 channels with 10 or 8 bit video are placed in a
base configuration. The digital output signals follow the Camera Link standardized multiplexed
signal output interface. The output driver is NS type DS90CR285, and the receiver is NS type
DS90CR286.
The data bits from the digital video, FVAL, LVAL, DVAL and EEN are multiplexed into the twisted
pairs, which are a part of the Camera Link. Trigger signals and the serial camera control are
feed directly through its own pairs. The trigger input can also be TTL on the 12 pin connector.
(TI=0 for CL. TI=1 for 12 pin). The serial camera control can be switches between the 12 pin
connector or CL by an internal switch SW 700 (HR/CL). Refer to 7.2
The 26 pin MDR connector pin assignment follows the Camera Link base configuration.
For a detailed description of Camera Link specifications, please refer to the Camera Link
standard specifications found on www.jai.com
1
14
13
26
X0
X1
X2
X3
Xclk
SerTFG
SerTC
CC1
CC2
CC3
CC4
Sheilds
4 x
7-1
MUX
8bit 10bit
L2 L0
L3 L1
L4 L2
L5 L3
L6 L4
L7 L5
L8 L6
L9 L7
R2 L8
R3 L9
R4 NC
R5 NC
R6 R8
R7 R9
R8 NC
R9 NC
NC R0
NC R1
NC R2
NC R3
NC R4
NC R5
NC R6
NC R5
LVAL
FVAL
DVAL
EEN
Pclk
A 0 Tx0
A1 Tx1
A2 Tx2
A3 Tx3
A4 Tx4
A5 Tx6
A 6 Tx27
A 7 Tx5
B 0 Tx7
B 1 Tx8
B 2 Tx9
B 3 Tx12
B 4 Tx13
B 5 Tx14
B 6 Tx10
B 7 Tx11
C 0 Tx15
C 1 Tx18
C 2 Tx19
C 3 Tx20
C 4 Tx21
C 5 Tx22
C 6 TX16
C 7 Tx17
Tx24
Tx25
Tx26
Tx23
Txclk
15
2
16
3
17
4
19
6
18
5
21
8
7
20
22
9
10
23
24
11
12
25
Pair 1
Pair 2
Pair 3
Pair 5
Pair 4
Pair 7
Pair 6
Pair 8
Pair 9
Pair 10
Pair 11
Sheilds
TXD out
RXD in
Ext. trig 1 in
Ground
Signal
Connector pin
CV-M2 Camera Camera Link Cable
Camera Signals
To
Frame
Grabber
Ext. Trig 2 in
Camera Link
Pin
1
14
13
26
X0
X1
X2
X3
Xclk
SerTFG
SerTC
CC1
CC2
CC3
CC4
Sheilds
4 x
7-1
MUX
8bit 10bit
L2 L0
L3 L1
L4 L2
L5 L3
L6 L4
L7 L5
L8 L6
L9 L7
R2 L8
R3 L9
R4 NC
R5 NC
R6 R8
R7 R9
R8 NC
R9 NC
NC R0
NC R1
NC R2
NC R3
NC R4
NC R5
NC R6
NC R5
LVAL
FVAL
DVAL
EEN
Pclk
A 0 Tx0
A1 Tx1
A2 Tx2
A3 Tx3
A4 Tx4
A5 Tx6
A 6 Tx27
A 7 Tx5
B 0 Tx7
B 1 Tx8
B 2 Tx9
B 3 Tx12
B 4 Tx13
B 5 Tx14
B 6 Tx10
B 7 Tx11
C 0 Tx15
C 1 Tx18
C 2 Tx19
C 3 Tx20
C 4 Tx21
C 5 Tx22
C 6 TX16
C 7 Tx17
Tx24
Tx25
Tx26
Tx23
Txclk
15
2
16
3
17
4
19
6
18
5
21
8
7
20
22
9
10
23
24
11
12
25
Pair 1
Pair 2
Pair 3
Pair 5
Pair 4
Pair 7
Pair 6
Pair 8
Pair 9
Pair 10
Pair 11
Sheilds
TXD out
RXD in
Ext. trig 1 in
Ground
Signal
Connector pin
CV-M2 Camera Camera Link Cable
Camera Signals
To
Frame
Grabber
Ext. Trig 2 in
Camera Link
Pin
Port/Signal 8bit 10bit Pin No.
Port A0 L2 L0 Tx0
Port A1 L3 L1 Tx1
Port A2 L4 L2 Tx2
Port A3 L5 L3 Tx3
Port A4 L6 L4 Tx4
Port A5 L7 L5 Tx6
Port A6 L8 L6 Tx27
Port A7 L9 L7 Tx5
Port B0 R2 L8 Tx7
Port B1 R3 L9 Tx8
Port B2 R4 NC Tx9
Port B3 R5 NC Tx12
Port B4 R6 R8 Tx13
Port B5 R7 R9 Tx14
Port B6 R8 NC Tx10
Port B7 R9 NC Tx11
Port C0 NC R0 Tx15
Port C1 NC R1 Tx18
Port C2 NC R2 Tx19
Port C3 NC R3 Tx20
Port C4 NC R4 Tx21
Port C5 NC R5 Tx22
Port C6 NC R6 Tx16
Port C7 NC R7 Tx17
LVAL Tx24
FVAL Tx25
DVAL Tx26
EEN Tx23
Camera Link bit allocation
TxCLK
A7 A6 EEN C7 B7 B6 A7 A6
C6
C3 C2 DVAL FVAL C5 C4 C3 C2
LVAL
B2 B1 C1 C0 B4 B3 B2 B1
B5
A1 A0 B0 A5 A3 A2 A1 A0
A4
TxOUT3
TxOUT2
TxOUT1
TxOUT0
1 pi xel cycl e
Time slots in Camera Link
Fig. 7. Principle diagram for Camera Link base configuration interface

CV-M2CL and CV-M8CL
6. Functions and Operations
In the following the format and the abbreviations shown in “7.5. CV-M2/M8 command list” are
used for function commands and parameters.
6.1. Basic functions
The M2/M8 cameras are a progressive scan camera with 10 or 8 bit video output in single or dual
channel Camera Link. On a BNC connector on M2, a standard composite video output (CCIR or
EIA) for monitor use is found. The image covers the full format, but the resolution is much lower
than the digital video output. For M8 it is not a correct monochrome image because the Bayer
pattern.
An iris video signal can be used for lens iris control if the camera is in continuous mode or Reset
Continuous Trigger mode.
For M2 a knee function (and gamma for single channel) makes it possible to cover high contrast
scenes.
The CV-M2/M8 camera has 1/2, 1/4 or 1/8 partial scanning. Programmable partial scan, where
the start line and the number of lines can be selected in 1line increments is also available.
There are 5 trigger modes. Normal continuous, reset continuous trigger, edge pre-select, pulse
width control, edge pre-select burst trigger and PIV trigger. (PIV, Particle Image Velocimetry).
The accumulation can be LVAL synchronous or LVAL a-synchronous.
In the following some of the functions are shown in details.
6.1.1. Dual video output
The video read out through Camera Link can be via a single or via double channels. (OS=0 for
single channel, OS=1 for dual channel.) If dual video outputs are used, the frame grabber PC
should reconstruct the image frame from the 2 half images.
A/D
A/D
RL
Camera Link
Interface
2 x 10 bit
Reconstructed
image on display
The two half images
are stored in separate
memory locations.
CV-M2 Camera Frame Grabber Display
R
L
The mirrord half
image R is reversed
and stiched together
with the half image L
A/D
A/D
RL
Camera Link
Interface
2 x 10 bit
Reconstructed
image on display
The two half images
are stored in separate
memory locations.
CV-M2 Camera Frame Grabber Display
R
L
The mirrord half
image R is reversed
and stiched together
with the half image L
Fig. 8. Dual channel read out
6.1.2. Burst trigger
With the burst trigger function TR=4, five previous set edge pre-selected programmable
exposures can be done with a single trigger pulse. The five shutter times can be set with BSH1
through BSH5. (1H through 1216H.)
Trigger
Exposure
Video out
Burst
Shutter
1 2345
1 234 5
Frame
Trigger
Exposure
Video out
Burst
Shutter
1 2345
1 234 5
Frame
Fig. 9. Burst trigger
- 7 -

CV-M2CL and CV-M8CL
6.1.3. Reset continuous trigger mode
The RCT mode makes it possible to use a lens with video controlled iris for intelligent traffic
surveillance applications. TR=2. The camera is running continuously, and the iris is controlled
from the iris video output. When a trigger pulse is applied, the scanning is reset and restarted,
the previous signal is dumped with a fast dump read out, and the new triggered exposure is
started. This fast dump read out has the same effect as “smearless read out”. Smear over
highlighted areas are reduced for the triggered frame.
Trigger
SG
Exposure
Video out
Dump
Read out
Continuous video out Continuous video outTriggered
Frame
Trigger
SG
Exposure
Video out
Dump
Read out
Continuous video out Continuous video outTriggered
Frame
Fig. 10. Reset continuous trigger mode
6.1.4. PIV mode
The Particle Image Velocimetry (PIV) mode (TR=5) can be used in applications where 2 images
should be taken with a very short time interval. It can only be used with strobe flash or lasers as
the only illumination. The first accumulation time is 4 µsec. The second is as long as the time for
a full frame.
Trigger
SG
Exposure
Video out First frame out Second frame out
Expanded view
Trigger
Exposure 1
Exposure 2
1. Flash 2. flash
4 µsec. 1.5µsec.
4 µsec.
EEN
Trigger
SG
Exposure
Video out First frame out Second frame out
Expanded view
Trigger
SG
Exposure
Video out First frame out Second frame out
Expanded view
Trigger
Exposure 1
Exposure 2
1. Flash 2. flash
4 µsec. 1.5µsec.
4 µsec.
EEN
Trigger
Exposure 1
Exposure 2
1. Flash 2. flash
4 µsec. 1.5µsec.
4 µsec.
EEN
Fig. 11. PIV mode
- 8 -

CV-M2CL and CV-M8CL
6.1.5. Digital video out allocation
The set-up and the relations between the analog and digital video are shown below.
0 25 700 800 [mV]
Analog
video out
0
32
890
1023
100%
level
White
clip level
Digital
video out
Black level
[LSB]
0 25 700 800 [mV]
Analog
video out
0
32
890
1023
100%
level
White
clip level
Digital
video out
Black level
[LSB]
Fig. 12. Digital video bit allocation
6.1.6. Knee function
Only in M2CL.
The knee functions can compress the signals in the highlighted areas. The slope over the knee
point is only 20%. The Knee point can be adjusted from 712 to 1023. Knee point at max (1023) is
the same as knee function off. With the knee at 890, the camera can reproduce scene highlight
up to 175%. The image contrast is reduced to 20% for scene luminance higher than the knee
point.
This function can be used in applications where the scene brightness is divided in an area in
shadow, and another in bright sunshine.
0
Scene
luminance
0
32
890
1023
100% video
Digital
video output
Black level
[LSB]
712
Slope 100%
Slope20%
Knee max.
Knee min.
175%
0
Scene
luminance
0
32
890
1023
100% video
Digital
video output
Black level
[LSB]
712
Slope 100%
Slope20%
Knee max.
Knee min.
175%
Fig. 13. Knee function
- 9 -
