JAMEC PEM TDR5000 User manual

Part No. 11.0734
TDR5OOO
DIAL GAUGE
TYRE INFLATOR
Instruction Manual

2
TDR5000 Tyre Inator
The new TDR5000 dial tyre Inator features a
lightweight, durable design and one touch
operation, making it the quickest and easiest
to use handheld tyre inator in the TDR range,
perfect for industrial workshops, mechanics
and garages. With a tough diecast aluminium
construction encased in a composite body and
an impact absorbing bumper, it will take a real
beating and ensures easy ination with just the
touch of a trigger.
Features
■IP44 rating - tough, durable
and splash resistant
■Large 80 mm dial gauge
■Multi scale gauge (bar, psi)
■Impact absorbing bumper
■Tough, lightweight diecast aluminium
internal body with composite outer casing
■Wire sheathed hose to eliminate kinking
■Supplied with certicate of calibration
WARNING
To avoid the risk of personal injury, especially to the eyes, face or skin, DO NOT direct the
air stream at any person, or any part of the body. This equipment is not intended for use by
children without adult supervision. The manufacturer reserves the right to change product
features at any time without notice.
Operation
■To read pressure:
Remove tyre valve cap.
With clip-on air chuck lever depressed,
rmly press chuck onto tyre valve stem
and release lever, ensure that no air leaks.
■To inate:
With clip-on air chuck lever depressed,
 rmlypresschuckontotyrevalvestem
and release lever, ensure that no air leaks.
Fullydepressthetyreinatorleverforan
appropriateperiodoftimeandrelease
the lever.
Check pressure gauge and repeat the
procedure until correct pressure level
is achieved.
■To deate:
With clip-on air chuck lever depressed,
rmly press chuck onto tyre valve stem
and release lever, ensure that no air leaks.
Depress the tyre inator lever half way
(until air can be heard to be escaping)
for an appropriate period of time and
release the lever.
Check pressure gauge and repeat the
procedure until correct pressure level
is achieved.
Safety
■Never exceed the maximum pressure
of the tyre.
■Check that the hose and chuck are
in good condition with no damage
or cracks.
■Ensure safe working environment
when using compressed air.
■Return to authorised service
agent for repair and maintenance.

3
Instruction Manual
* Tyre pressure measuring instruments,
devices for inspection of pressure and/or
ination/deation of tyres for motor vehicles.
SPECIFICATIONS
Description TDR5000 dial gauge tyre inator
Reader unit 80 mm dial gauge
Chuck type Clip on
Chuck style Single straight
Inlet size ¼" female
Hose length 500 mm with swivel (19.7")
Dimensions 235L x 90W x 110H mm (9.25"L x 3.5"W x 4.3"H)
Weight 0.68 kg (1.5 lbs)
Accuracy ± 2 psi @ 25–75 psi
Operation Inate, deate, measure
Supply pressure max. 200 psi
Scale / max. ination 174 psi, 12 bar
Ination ow 1200 L/min @ 1375 kPa
(42.4 cfm @ 200 psi)
IP rating IP44
Advised application Industrial, workshops
ALLOWABLE TOLERANCE
BAR
± 0.08 up to and including 4 bar
± 0.16 between 4 bar and 10 bar inclusive
± 0.25 greater than 10 bar
psi
± 1.2 up to and including 58 psi
± 2.3 between 58 and 145 psi inclusive
± 3.6 greater than 145 psi
TEST RESULTS
Reference pressure
BAR PSI
Display pressure
BAR PSI
Calibration Certicate
This Tyre Inator has been calibrated in its normal
working position on test equipment with an accuracy
that is traceable to International Standards according
to: 86/217/EEC.
Serial Number:
Date:

Designedanddistributedby:
Adventure Trading Australia Pty Ltd
jamecpem.com
Considertheenvironment.
Pleasereuseorrecyclethispackaging.
201903
