TYRE INFLATOR
DIGITAL - TDR
OPERATING INSTRUCTIONS
PRODUCT NO. 10.3100 Tyre Inator Digital - TDR
COMPLIES WITH
EN12645: 2014*

TYRE INFLATOR
DIGITAL - TDR
The Jamec Pem TDR Digital Tyre Inator represent quality and guaranteed
accuracy. The classic handheld, slimline design is easy to hold and is
designed to last in rugged workshop environments.
FEATURES
Includes Certicate of calibration
Multi scale gauge
Wire sheathed hose eliminates kinking
Impact absorbing bumpers
Tough die cast aluminium housing
Accuracy exceeds EC Standards
Rubber grip on chuck
Backlit digital display
Auto ON, upon pressure sensing
SPECIFICATIONS
Operation Inate / deate / measure
Supply pressure max. 200 psi
Max. inflation 174 psi
Chuck type Hold on
Chuck style Dual angle
Scale psi, kPa, bar
Inlet size 1/4" BSP
Hose length 500mm
Accuracy ± 2 psi @ 25 - 75 psi
Inflation volume L/min 500 L/min @ 188 psi
Power source 2 x AAA (included)
Battery life (continuous use) 80 hr
Auto off 8 sec
Weight .95 kg
Advised application Industrial, workshops
MAINTENANCE MONTHLY
Remove the ‘oil’ screw on the side of the gauge and place 2-3 drops of
‘light’ oil into the gauge mechanism.
IMPORTANT
This tyre inator must only be connected to air line systems which have
clean dry air. Any moisture in the air line system may cause damage to
the operation of this tyre inator and void warranty.
Air pre-lters must be used with this inator to ensure product accuracy
and longevity.
OPERATION
TO READ PRESSURE:
Remove tyre valve cap. With clip-on air chuck lever depressed, rmly press
chuck onto tyre valve stem and release lever, ensure that no air leaks.
Check pressure gauge.
Digital - the digital display will activate once the tyre pressure is sensed.
If no pressure is sensed the display will not turn on. Press the tyre inator
lever to add air into the tyre, before reading the pressure.
Analogue - the dial gauge will activate once the tyre pressure is sensed. If
no pressure is sensed ,press the tyre inator lever to add air into the tyre,
before reading the pressure.
TO INFLATE:
With clip-on air chuck lever depressed, rmly press chuck onto tyre valve
stem and release lever, ensure that no air leaks.
Fully depress the tyre inator lever for an appropriate period of time and
release the lever. Check pressure gauge and repeat the procedure until
correct pressure level is achieved.
TO DEFLATE:
With clip-on air chuck lever depressed, rmly press chuck onto tyre valve
stem and release lever, ensure that no air leaks. Depress the tyre inator
lever half way (until air can be heard to be escaping) for an appropriate
period of time and release the lever. Checkpressure gauge and repeat the
procedure until correct pressure level is achieved.
SAFETY
Never exceed the maximum pressure of the tyre. Check that the hose and
chuck are in good condition with no damageorcracks. Ensure safe working
environment when using compressed air. Return to authorised service agent
for repair and maintenance.
WARNING
To avoid risk of personal injury, especially to the eyes, face and skin
DONOT direct the air stream at any person, or any part of the body.
Thisequipment is not intended for use by children without adult
supervision. The manufacturer reserves the right to change product
features at any time without notice.

BATTERY CHANGE
This inator requires 2 x AAA batteries. If the voltage of the batteries fall
below 2.6 volts, the battery icon will ash continuously until it shuts down.
If the voltage of the batteries fall below 2.5 volts, the low “LO” battery icon
appears while the power is on and then shuts down automatically. The
batteries must be changed if the battery icon ashes.
1. Unscrew the battery cap
Scale
change
button
2. Slide the batteries into the inator with the positive
end facing out of the inator
3. Replace the battery cap carefully and do not over
tighten
SCALE CHANGE
Press and hold the scale change button to activate the display, once the
display is activated press and hold the button for 2 seconds to change the
display scale.

Distributed by
TRADEPEM INDUSTRIAL PTY LTD.
CALIBRATION CERTIFICATE
This Tyre Inator Part Number: 10.3100 has been calibrated in its normal
working position on test equipment with an accuracy that is traceable to
standards according to: EN12645: 2014
Serial Number:
Date:
ALLOWABLE TOLERANCE
PSI
± 1.2 Up to and including 58 psi
± 2.3 Between 58 & 145 psi inclusive
± 3.6 Greater than 145 psi
TEST RESULTS
REFERENCE PRESSURE PSI 29.0 58.0 87.0 116.0
DISPLAY PRESSURE PSI
COMPLIES WITH
EN12645: 2014*
* Tyre pressure measuring Instruments, devices for Inspection of pressure and/or
Ination/Deation of tyres for motor vehicles.
IMPORTANT
No responsibility is accepted for incorrect use of this product.
