JAMEC PEM 11.0523 User manual

TYRE INFLATOR
DIGITAL
OPERATING INSTRUCTIONS
PRODUCT NO. 11.0523

TYRE INFLATOR
DIGITAL
The Jamec Pem Digital Tyre Inator features a robust rubber outer with
a durable aluminium body and one touch operation, perfect for industrial
workshops, mechanics and garage.
FEATURES
Includes Certicate of calibration
Multi-scale gauge
Large backlit digital display
Accuracy exceeds EC Standards
Auto on upon pressure sensing
Auto off after 90 seconds
Tough die-cast aluminium housing
Wire sheathed hose eliminates kinking
Impact absorbing bumpers
SPECIFICATIONS
Operation Inate / deate / measure
Supply pressure max. 200 psi
Max. inflation 174 psi
Chuck type Clip on
Chuck style Single straight
Scale psi, kPa, bar
Inlet size 1/4" BSP
Hose length 500 mm
Accuracy 2 psi @ 25 - 75 psi
Inflation volume L/min 1200 L/min @ 200 psi
Power source 2 X AAA
Battery life (continuous use) 65 hr
Auto OFF 90 sec
Weight .8 kg
Advised application Industrial, workshops
MAINTENANCE MONTHLY
Remove the ‘oil’ screw on the side of the gauge and place 2-3 drops of
‘light’ oil into the gauge mechanism.
IMPORTANT
This tyre inator must only be connected to air line systems which have
clean dry air. Any moisture in the air line system may cause damage to
the operation of this tyre inator and void warranty.
Air pre-lters must be used with this inator to ensure product accuracy
and longevity.
OPERATION
TO READ PRESSURE:
Remove tyre valve cap. With clip-on air chuck lever depressed, rmly press
chuck onto tyre valve stem and release lever, ensure that no air leaks.
Check pressure gauge.
Digital - the digital display will activate once the tyre pressure is sensed.
If no pressure is sensed the display will not turn on. Press the tyre inator
lever to add air into the tyre, before reading the pressure.
Analogue - the dial gauge will activate once the tyre pressure is sensed. If
no pressure is sensed ,press the tyre inator lever to add air into the tyre,
before reading the pressure.
TO INFLATE:
With clip-on air chuck lever depressed, rmly press chuck onto tyre
valve stem and release lever, ensure that no air leaks. Fully depress the
tyre inator lever for an appropriate period of time and release the lever.
Checkpressure gauge and repeat the procedure until correct pressure level
is achieved.
TO DEFLATE:
With clip-on air chuck lever depressed, rmly press chuck onto tyre valve
stem and release lever, ensure that no air leaks. Depress the tyre inator
lever half way (until air can be heard to be escaping) for an appropriate
period of time and release the lever. Check pressure gauge and repeat the
procedure until correct pressure level is achieved.
SAFETY
Never exceed the maximum pressure of the tyre. Check that the hose and
chuck are in good condition with no damageorcracks. Ensure safe working
environment when using compressed air. Return to authorised service agent
for repair and maintenance.
WARNING
To avoid risk of personal injury, especially to the eyes, face and skin
DONOT direct the air stream at any person, or any part of the body.
Thisequipment is not intended for use by children without adult
supervision. The manufacturer reserves the right to change product
features at any time without notice.

1. Unscrew front LCD panel using
Phillips head screwdriver. Access
screws through slots in rear of unit.
BATTERY REPLACEMENT
2. Open the front LCD panel using a
at blade screwdriver
3. Insert new battery making
sure of positive and negative
polarity
4. Close front LCD panel
5. Rex front LCD panel by re-tight-
ening screws at rear of unit using
Phillips head screwdriver

Distributed by
TRADEPEM INDUSTRIAL PTY LTD.
CALIBRATION CERTIFICATE
This Tyre Inator Part Number: 11.0523 has been calibrated in its normal
working position on test equipment with an accuracy that is traceable to
standards according to: EN12645: 2014
Serial Number:
Date:
ALLOWABLE TOLERANCE
PSI
± 1.2 Up to and including 58 psi
± 2.3 Between 58 & 145 psi inclusive
± 3.6 Greater than 145 psi
TEST RESULTS
REFERENCE PRESSURE PSI 29.0 58.0 87.0 116.0
DISPLAY PRESSURE PSI
* Tyre pressure measuring Instruments, devices for Inspection of pressure and/or
Ination/Deation of tyres for motor vehicles.
IMPORTANT
No responsibility is accepted for incorrect use of this product.
