Jason.L Quadro Square 3P Run workstation User manual

ASSEMBLY INSTRUCTIONS
Quadro Square
3P Run workstation
Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm
Page 1 of 7
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Tools Required: Power screwdriver; Allen key set (provided)
2 persons required for installation

ASSEMBLY INSTRUCTIONS
Quadro Square
3P Run workstation
Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm
Table top x3
Leg Quadro Square x2
Connector frame x2
Beam x3
Plastic bracket x12
A
B
C
D
E
Allen key x2J
M8x20MM CSK x6
M8x20MM Socket head x6
M6x20MM Socket head x12
M6x30MM Socket head x12
F
G
H
I
COMPONENTS
SCREWS
Page 2 of 7
Need help!
Call us on
1300 527 665
www.jasonl.com.au
D
E
F G H I
A
C
B

ASSEMBLY INSTRUCTIONS
Quadro Square
3P Run workstation
Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm
Using Allen Key provided, attach 2 plastic brackets per leg (E)
(as per picture above) using M6x20MM (H) Socket head screw.
Do the same with Connector frame (C).
Using Allen Key provided, attach M8x20MM Socket head (G)-
screw socket half way into leg for both legs (B) and into
Connector frame (C).Page 3 of 7
Need help!
Call us on
1300 527 665
www.jasonl.com.au
G
H
STEP 01 STEP 02

ASSEMBLY INSTRUCTIONS
Quadro Square
3P Run workstation
Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm
STEP 03
Adjust extendable beam (D) to desired
length using markers and secure beam
at that length using screws provided
Page 4 of 7
Need help!
Call us on
1300 527 665
www.jasonl.com.au
50
1200
1300
1400
1500
1600
1700
1800
1900
2000
50

ASSEMBLY INSTRUCTIONS
Quadro Square
3P Run workstation
Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm
Attach beam (D) to legs (B) and Connector frame (C)
using nut insert in legs. See point attached
Frame looks like this. Using Allen Key, attach beam (D) with Socket (F)
STEP 05
Page 5 of 7
Need help!
Call us on
1300 527 665
www.jasonl.com.au
F
F
F
F
F
F
STEP 04
TOP VIEW

ASSEMBLY INSTRUCTIONS
Quadro Square
3P Run workstation
Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm
STEP 06
Page 6 of 7
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Place desktops ontop of frame. Nut inserts in top will align with plastic
joiner brackets using M6x30MM (I) sockets attach tops to frame.
I
TABLE TOPS
BOTTOM VIEW

ASSEMBLY INSTRUCTIONS
Quadro Square
3P Run workstation
Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm
Page 7 of 7
Need help!
Call us on
1300 527 665
www.jasonl.com.au
TABLE TOPS
BOTTOM VIEW
The following nut inserts should be used for this specific desk / workstation
nut insertnut insert nut insertnut insertnut insertnut insert
