Jason.L San Fran System User manual

Special Note: Please ignore any pre-drilled holes or nut inserts that maybe present in your top(s).
They will not match your particular table/desk base and woods screws will be required to be screwed
directly into the underside of the top.
Tools Required: Power screwdriver.
INSTALLATION GUIDE
San Fran System
Square Boardroom Table
Size: 1200mm
Page 1 of 3
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Sizes:
800 x 800
1000 x 1000
1200 x 1200
San Fran System
Square Boardroom Frame
San Fran System
Square Boardroom Frame

Leg x4
Adjustable Foot x4
Leg Cable Cover x4
Beams x4 (490 mm)
2 Way Connector x4
2 Way Connector Cap x4
Table Top x1 (1200 mm)
1
2
3
4
5
6
7
M8x20mm Dome Head x8
M8x20mm Cap Head x4
M5x20mm Self Tapping x14
8
9
10
COMPONENTS
SCREWS
Page 2 of 3
INSTALLATION GUIDE
San Fran System
Square Boardroom Table
Size: 1200mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
7
10
8
9
4
3
1
2
5
6
San Fran System
Square Boardroom Frame
San Fran System
Square Boardroom Frame

01
Slide the 2 way connectors over each leg, and securely lock into place using
M8x20mm cap head bolts.
Ensure the worksurface is centered over the frame. Fully tighten all M5x20mm
self tapping screws through each leg into the worksurface. Page 3 of 3
INSTALLATION GUIDE
San Fran System
Square Boardroom Table
Size: 1200mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Securely connect legs to beams lenghts using the shorter
M8x20mm dome head bolts.
Conceal any power cable using the magnetic leg cable covers.
04
02
03
San Fran System
Square Boardroom Frame
San Fran System
Square Boardroom Frame
