Jason.L Switch System User manual

Page 1 of 4
INSTALLATION GUIDE
Switch System
Small Round Meeting Frame
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Note: Please ignore any pre-drilled holes or nut inserts that maybe present in your top(s). They will not match your
particular table/desk base and woods screws will be required to be screwed directly into the underside of the top.
Note: It is important to fully tighten all bolts and screws before attaching the top(s) so that the frame
is suciently rigid. Failure to do this may aect stability once the tops are attached.
Tools Required: Power screwdriver.
Sizes:
700 D
800 D

Table Top (700mm D)
Leg x3
Leg Bracket x3
Beam Bracket x6
Switch Beam x3 (180mm)
L-Bracket x6
1
2
3
4
5
6
Hex Nut x3
L-Bracket screws x3
Hex Head screws x9
M8x25mm Dome Head x3
7
8
9
10
COMPONENTS
SCREWS
Page 2 of 4
INSTALLATION GUIDE
Switch System
Small Round Meeting Frame
Need help!
Call us on
1300 527 665
www.jasonl.com.au
5
4
3
6810
1
7
