jbc PA120-B User manual

Micro Tweezers
Ref. PA120-B
www.jbctools.com

2
C120 Cartridges
(Required but not supplied)
Control Unit
Stand
Ref. PA-SD
Manual ................................................ 1 unit
Ref. 0019081
Packing List
The following items should be included:
Micro Tweezers ...................................... 1 unit
Ref. PA120-B
Micro Tweezer s
Ref. PA120-B
Micro Tweezers
Ref. PA120-B
Features
www.jbctools.com

ø0,7 1,5mm
ø 0,2
5mm
6m m
C120-009 C120-01
0
www.jbctools.com
3
2. Inserting
3. Rotational and Vertical aligning
Changing cartridges
Unlock the manual fixing and remove the
cartridge. If is necessary, you can use a flat
pliers (Ref. PLR-195).
1. Removing
Insert the cartridge as far as the mark for a
proper connection. Before inserting, make
sure the cartridges are clean to ensure the
proper function of the rotational aligning.
Mark
The PA120 -B Micro Tweezers works with C120 cartridge range.
Find the model that best suits your soldering needs in www.jbctools.com
C120-004 C120-001C120-005 C120-009 C120-010
Compatible cartridges
For a rotational alignment, turn the cartridges
in any direction through the wheels.
Don´t forget to lock the manual fixing.!
The tail wheel guarantees that the cartridges
are equally aligned with vertical symmetry.

This product should not be thrown in the garbage.
In accordance with the European directive 2002/96/EC, electronic equipment at the end of their life
must be collected and returned to an authorized recycling facility.
Manual in other languages available on our website
Warranty
JBC’s 2 year warranty covers this equipment
against all manufacturing defects, including the
replacement of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment
must be returned, postage paid, to the dealer
where it was purchased. Please register your
product warranty within 30 days of purchase in
www.jbctools.com/productregistration.
Specifications
0019081-0118
- Weight: 100 g (0.22 lb)
- Max. power per cartridge: 40W
Complies with CE standards.
ESD protected.
