jbc PA120 User manual

PA120
MICRO TWEEZERS
www.jbctools.com

2
PA120/MICRO TWEEZERS
PA120-A
Micro Tweezers
Cartridge C120
Connectable control units: DI, DD and RM
Connectable compact line: CP
DD-2B/DD-1B/DD-9B
CONTROL UNIT
PA-SD
STAND
Mains
Equipotential connection
PA120-A
MICRO TWEEZERS
MANUAL
INSTALLATION
PA120
MICRO TWEEZERS
ww w.jb cto ols. com

3
PA120-A has an individual temperature control for each cartridge so it is supplied individually.
WARNING: It is esential to tighten this screw for
the tool to function.
Alignment
Screw for fixing
the cartridge
Important: It is esential to insert the cartridge
till the end for a good connection.
Take the mark as reference and check that
both tips of the tweezer coincide.
Consult our wide range of cartridges with more than 300 references in www.jbctools.com.
For special cartridges contact with our distributor.
CHANGING THE CARTRIDGE
CARTRIDGE RANGE
ø 0,3 1,5mm ø 0,5 1,5mm ø0,7 1,5mm 0,6mm
ø 0,2 1,5mm
ø 0,2
ø0,7
5mm 3mm 5mm
C120-007 C120-008
3,5mm
6mm
C120-009 C120-010
C120-902 C120-006 C120-004 C120-011C120-002
C120-001C120-012 C120-003 C120-005 C120-007 C120-008 C120-009 C120-010

0008846-0513
WARRANTY
JBC’s 2 years warranty guarantees this equipment against all manu-
facturing defects, covering the replacement of defective parts and
all necessary labour.
Warranty does not cover product wear due to use or mis-use.
In order for the warranty to be valid, equipment must be returned,
postage paid, to the dealer where it was purchased enclosing this
fully filled in, sheet.
www.jbctools.com
SERIAL Nº
STAMP OF DEALER
DATE OF PURCHASE
TECHNICAL SPECIFICATIONS
- Effective power per cartridge fitted: 20W
- Weight without cartridge: 102 gr. aprox
- ESD Safe
This product should not be
thrown in the garbage.
