JBL PROTEMP b III User manual

Date: 07.09.2022
Produced by: 1
Country: Sweden
Language: English
JBL PROTEMP b III
Substrate heating for freshwater aquariums
Suitable for:
An undergravel heating cable provides a natural-like thermal flow through the substrate and thus
promotes the transport of nutrients to the roots
Easy to install: place the heating cable in loops on the bottom panel of the aquarium, fasten with the
suction cups
The rising, heated water causes the colder water to flow in and thus ensures water circulation IN the
substrate. In this way, the substrate also becomes a natural aquarium filter
Large cross-section of the heating cable for more power, 24 V safety voltage against hazards, high-
quality power supply unit, spring clips allow mounting without tools
Package contents: untergravel heating cable for aquariums, incl. electr. transformer, heating cable with
cold and warm conductor, suction cup attachment
You may also be interested in You can find a complete overview here: https://www.jbl.de/qr/60490
JBL PROFLORA
Ferropol
Plant fertiliser for freshwater
aquariums
JBL PROFLORA
AquaBasis plus
Long-lasting nutrient substrate
f. freshwater aquarium
JBL PROFLORA
AquaBasis Start
Plant fertiliser starter set for
freshwater aquariums
JBL PROTEMP e300
External heater for all
aquariums from 90 to 300 l

Date: 07.09.2022
Produced by: 2
Country: Sweden
Language: English
JBL PROTEMP b III
Spare parts
JBL slotted suction
cup, 2mm
Holder for heating cables in
aquariums and terrariums
JBL adapter UK for all
flat-pin plugs

Date: 07.09.2022
Produced by: 3
Country: Sweden
Language: English
JBL PROTEMP b III
Product information
Water circulation
Aquatic plants grow better in the wild when they have access to seeping nutrition sources. The plants
absorb their food from these sources. The gently warming undergravel heating causes the warm water
to rise and the cold water, full of dissolved nutrients and minerals, sinks to the bottom. This creates a
thermal water flow, which washes the minerals and trace elements directly to the roots.
Easy to install
When beginning to set up the aquarium, position the heating cable in even-sized loops (in the area
where plants are to be planted) on the cleaned bottom pane. Using the slotted suction cups enclosed,
fasten the heating cable. Bring the cold leads of the cable out of the aquarium and connect them to the
power supply. The black markings on the cable clearly distinguish the cold lead from the heating cable.
Safe to use
The heating cable is silicone-covered and works with an energy-saving power supply with 24 V safety
voltage for hazard-free use. The the power supply unit needs to be mounted in a well-ventilated, splash-
proof place. The undergravel heating results in a slight warming of the substrate, but definitely needs to
be supplemented with a heater thermostat (JBL ProTemp s) for warm water fish. The power supply
units heat up during operation - this is normal and due to technical reasons.
Tip:
If you don't want to use the suction cups to fix the undergravel heating cable, you can also glue the
heating cable with small "silicone drops" and then remove the suction cups.
Contents of the various undergravel heating cable sizes: (power cable length always 1.5 m)
JBL PROTEMP b 10 III: 3.6 m heating cable, 2 m PTC resistor (“cold lead”), 20 slotted suction cups
JBL PROTEMP b 20 III: 4.9 m heating cable, 2 m PTC resistor (“cold lead”), 30 slotted suction cups
JBL PROTEMP b 40 III: 7.0 m heating cable, 2 m PTC resistor (“cold lead”), 30 slotted suction cups
JBL PROTEMP b 60 III: 9.0 m heating cable, 2 m PTC resistor (“cold lead”), 40 slotted suction cups
Further information
FAQ
Blog
Press
Laboratory/calculator
Worth reading
Spare parts
Video
GarantiePlus
Instructions
QR code

Date: 07.09.2022
Produced by: 4
Country: Sweden
Language: English
JBL PROTEMP b III
Product details
Article data
Product name JBL PROTEMP b10 III JBL PROTEMP b20 III JBL PROTEMP b40 III JBL PROTEMP b60 III
Art. No. 6049000 6049100 6049200 6049300
EAN number 4014162604903 4014162604910 4014162604927 4014162604934
EAN as barcode
Performance 10 W 20 W 40 W 60 W
Range 40-120 l 60-200 l 90-300 l 160-600 l
Expiry months - - - -
RRP incl. VAT 68,11 € 72,86 € 93,70 € 109,38 €
Base price - - - -
Nominal filling quantity - - - -
Base quantity 1 1 1 1
Gross weight 440 g 462 g 584 g 636 g
Net weight 291 g 313 g 435 g 487 g
Weight change - - - -
Disposal
Product name JBL PROTEMP b10 III JBL PROTEMP b20 III JBL PROTEMP b40 III JBL PROTEMP b60 III
Art. No. 6049000 6049100 6049200 6049300
Green dot -
Group electronic waste Small appliances that can be used
in private households Small appliances that can be used in private households Small appliances that can be used in private households Small appliances that can be used in private households
Disposal weight 150 g 150 g 210 g 210 g
Battery type - - - -
Battery return - - - -
Battery rechargeable - - - -
Disposal weight battery 0 g 0 g 0 g 0 g
Non-returnable glass - - - -
PPK 149 g 149 g 149 g 149 g
Plastic small - - - -
Plastic large - - - -
Disposal weight metal 0 g 0 g 0 g 0 g
Features
Product name JBL PROTEMP b10 III JBL PROTEMP b20 III JBL PROTEMP b40 III JBL PROTEMP b60 III
Art. No. 6049000 6049100 6049200 6049300
Animal species
Arowana, Artemia, Axolotl,
Barbels, Bettas, Bichirs/reedfish,
Blowfish, Catfish, Cichlids (South
America), Crayfish, Danions,
Discus, Dwarf shrimps,
Flowerhorn, Gobies, Goldfish,
Gouramis, Guppy, Juvenile fish,
Killifish, Livebearers, Loaches,
Newts, Panchaxes, Rainbowfish,
Snails, Spiny eels, Tetra, Veiltails,
freshwater butterflyfish
Arowana, Artemia, Axolotl,
Barbels, Bettas, Bichirs/reedfish,
Blowfish, Catfish, Cichlids (South
America), Crayfish, Danions,
Discus, Dwarf shrimps,
Flowerhorn, Gobies, Goldfish,
Gouramis, Guppy, Juvenile fish,
Killifish, Livebearers, Loaches,
Newts, Panchaxes, Rainbowfish,
Snails, Spiny eels, Tetra, Veiltails,
freshwater butterflyfish
Arowana, Artemia, Axolotl,
Barbels, Bettas, Bichirs/reedfish,
Blowfish, Catfish, Cichlids (South
America), Crayfish, Danions,
Discus, Dwarf shrimps,
Flowerhorn, Gobies, Goldfish,
Gouramis, Guppy, Juvenile fish,
Killifish, Livebearers, Loaches,
Newts, Panchaxes, Rainbowfish,
Snails, Spiny eels, Tetra, Veiltails,
freshwater butterflyfish
Arowana, Artemia, Axolotl,
Barbels, Bettas, Bichirs/reedfish,
Blowfish, Catfish, Cichlids (South
America), Crayfish, Danions,
Discus, Dwarf shrimps,
Flowerhorn, Gobies, Goldfish,
Gouramis, Guppy, Juvenile fish,
Killifish, Livebearers, Loaches,
Newts, Panchaxes, Rainbowfish,
Snails, Spiny eels, Tetra, Veiltails,
freshwater butterflyfish

Date: 07.09.2022
Produced by: 5
Country: Sweden
Language: English
Features
Animal size For all animal sizes For all animal sizes For all animal sizes For all animal sizes
Animal age group All aquarium fish All aquarium fish All aquarium fish All aquarium fish
Volume of habitat 40-120 L (40-80cm) 60-200 L ( 60-100cm) 90-300 L (80-120cm) 160-600 L (100-150cm)
Material Plastic (ABS), metal (copper),
silicone Plastic (ABS), metal (copper), silicone Plastic (ABS), metal (copper), silicone Plastic (ABS), metal (copper), silicone
Food type - - - -
Colour white / black white / black white / black white / black
Dosage - - - -
Transport conditions - - - -

Date: 07.09.2022
Produced by: 6
Country: Sweden
Language: English
JBL PROTEMP b III
Electronic label / illuminant
Product name JBL PROTEMP b10 III JBL PROTEMP b20 III JBL PROTEMP b40 III JBL PROTEMP b60 III
Art. No. 6049000 6049100 6049200 6049300
Ambient temperature - - - -
Start time - - - -
Mercury - - - -
Tube length - - - -
Service life - - - -
Lumen - - - -
CRI value - - - -
Dimmable - - - -
Switching cycles - - - -
PAR value - - - -
Energy efficiency class - - - -
UV-A - - - -
UV-B - - - -
UV-C - - - -
Colour temperature - - - -
Base designation - - - -
Technical data
Product name JBL PROTEMP b10 III JBL PROTEMP b20 III JBL PROTEMP b40 III JBL PROTEMP b60 III
Art. No. 6049000 6049100 6049200 6049300
Range in litres - - - -
Range from - to 40-120l 60-200l 90-300l 160-600l
Range in days - - - -
Range tank length 40-80 60-100 80-120 100-150
Output in watts 10 W 20 W 40 W 60 W
Output per hour - - - -
Output per day - - - -
Height - - - -
Length - - - -
Width - - - -
Diameter - - - -
Voltage 230 V 230 V 230 V 230 V
For JBL PROTEMP b 10 III: 3,6 m
Heizkabel, 2 m Kaltleiter, 20 Schlit JBL PROTEMP b 20 III: 4,9 m Heizkabel, 2 m Kaltleiter, 30 Schlit JBL PROTEMP b 40 III: 7,0 m Heizkabel, 2 m Kaltleiter, 30 Schlit JBL PROTEMP b 60 III: 9,0 m Heizkabel, 2 m Kaltleiter, 40 Schlit
T8 26mm (watt) - - - -
T5 16mm (watt) - - - -
Size - - - -
Content for - - - -
Filter container volume - - - -
Volume filter media - - - -
Hose connections pressure/out - - - -
Hose connections suction/in - - - -

Date: 07.09.2022
Produced by: 7
Country: Sweden
Language: English
Technical data
Delivery head - - - -

Date: 07.09.2022
Produced by: 8
Country: Sweden
Language: English
JBL PROTEMP b III
Food type -
Sub product type -
Dosing -

Date: 07.09.2022
Produced by: 9
Country: Sweden
Language: English
Additional information for the specialist trade sector
Article data
Product name JBL PROTEMP b10 III JBL PROTEMP b20 III JBL PROTEMP b40 III JBL PROTEMP b60 III
Art. No. 6049000 6049100 6049200 6049300
VAT 25% 25% 25% 25%
Sales unit (SU) 1 1 1 1
Volume packaging 2.4l 2.4l 2.4l 2.4l
Dimensions (l/w/h) 63 mm/165 mm/235 mm 63 mm/165 mm/235 mm 63 mm/165 mm/235 mm 63 mm/165 mm/235 mm
Layer 59 72 72 72
Pallet 72 216 216 216
Category of products 31 31 31 31
Customs tariff 84198998 84198998 84198998 84198998
Country of origin DE DE DE DE
Type of packaging Faltschachtel/Karton Faltschachtel/Karton Faltschachtel/Karton Faltschachtel/Karton
PU 1 data
Product name JBL PROTEMP b10 III JBL PROTEMP b20 III JBL PROTEMP b40 III JBL PROTEMP b60 III
Art. No. 6049000 6049100 6049200 6049300
PU 1 material None None None None
PU 1 weight - - - -
PU 1 lengh - - - -
PU 1 width/depth - - - -
PU 1 height - - - -
PU 2 data
Product name JBL PROTEMP b10 III JBL PROTEMP b20 III JBL PROTEMP b40 III JBL PROTEMP b60 III
Art. No. 6049000 6049100 6049200 6049300
PU 2 material None None None None
PU 2 weight - - - -
PU 2 lengh - - - -
PU 2 width/depth - - - -
PU 2 height - - - -
Trade data
Product name JBL PROTEMP b10 III JBL PROTEMP b20 III JBL PROTEMP b40 III JBL PROTEMP b60 III
Art. No. 6049000 6049100 6049200 6049300
Till receipt text ProTemp b10 III ProTemp b20 III ProTemp b40 III ProTemp b60 III
Shelf placement - - - -
