Jensen JEP-150 User manual

AM/FM Weather Band Clock Radio with
Weather Alert
MODEL: JEP-1 0
USER MANUAL
PLEASE READ THIS USER MANUAL COMPLETELY BEFORE OPERATING
THIS UNIT AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE.

E-1
WARNING
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES
CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE
OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE .
The Caution Marking is located at the back enclosure of the apparatus.
The Rating plate is located at the bottom enclosure of the apparatus
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that product heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the third prong is provided for
your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table recommended
by the manufacturer, or sold with the product. When a cart is used,
use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for
long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.

E-2
1 . This appliance shall not be exposed to dripping or splashing water and that no object
filled with liquids such as vases shall be placed on the apparatus.
16. Do not overload wall outlet. Use only power source as indicated.
17. Use replacement part as specified by the manufacturer.
18. Upon completion of any service or repairs to this product, ask the service technician
to perform safety checks.
19. Power Sources - This product should be operated only from the type of power
source indicated on the marking label. If you are not sure of the type of power supply
to your home, consult your product dealer or local power company. For products
intended to operate from battery power, or other sources, refer to the operating
instruction.
20. Object and Liquid Entry - Never push objects of any kind into this product through
openings as they may touch dangerous voltage points or short-out parts that could
result in a fire or electric shock. Never spill liquid of any kind on the product.
21. Damage Requiring Service - Unplug this product from the wall outlet and refer
servicing to qualified service personnel under the following conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions as an
improper adjustment of other controls may result in damage and will often require
extensive work by a qualified technician to restore the product to its normal
operation.
e) If the product has been dropped or damaged in any way, and
f) When the product exhibits a distinct change in performance - this indicates a need
for service.
22. Main plug is used as disconnect device and it should remain readily operable during
intended use. In order to disconnect the apparatus from the mains completely, the
mains plug should be disconnected from the mains socket outlet completely.
23. The battery (battery or batteries or battery pack) shall not be exposed to excessive
heat such as sunshine, fire or the like.
24. Excessive sound pressure from earphones and headphone can cause hearing loss.
This symbol indicates that this product incorporates doub le insulation
between hazardous mains voltage and user accessible p a r ts.
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF AC PLUG TO WIDE SLOT. FULLY INSERT.
SAVE THESE INSTRUCTIONS

E-3
COMPLIANCE WITH FCC REGULATIONS
This device complies with Part 1 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 1 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes o modifications not exp essly app oved by the pa ty
esponsible fo compliance could void the use ’s autho ity to ope ate the
equipment.
PROTECT YOUR FURNITURE
This system is equipped with non-skid rubber ‘feet’ to prevent the product from
moving when you operate the controls. These ‘feet’ are made from non-migrating
rubber material specially formulated to avoid leaving any marks or stains on your
furniture. However certain types of oil based furniture polishes, wood preservatives or
cleaning sprays may cause the rubber ‘feet’ to soften, and leave marks or a rubber
residue on the furniture.
To prevent any damage to your furniture we strongly recommend that you purchase
small self- adhesive felt pads, available at hardware stores and home improvement
centers everywhere, and apply these pads to the bottom of the rubber ‘feet’ before
you place the product on fine wooden furniture.

E-4
DEAR JENSEN CUSTOMER
Selecting fine audio equipment such as the unit you've just purchased is only the
start of your musical enjoyment. Now it's time to consider how you can maximize the
fun and excitement your equipment offers. This manufacturer and t h e E le c t r onic
Industries Association's Consumer Electronics Group want you to get the most out of
your equipment by playing it at a safe level. One that lets the sound come through
loud and clear without annoying blaring or distortion and, most importantly, without
affecting your sensitive hearing. Sound can be deceiving. Over time your hearing
"comfort level" adapts to higher volumes of sound. So what sounds "normal" can
actually be loud and harmful to your hearing. Guard against this by setting your
equipment at a safe level BEFORE your hearing adapts.
To establish a safe l e v e l :
• Start your volume control at a low setting.
• Slowly increase the sound until you can hear it comfortably and clearly, and without
distortion.
Once you have established a comfo table sound l e v e l :
• Set the dial and leave it there.
Taking a minute to do this now will help to prevent hearing damage or loss in the
future. After all, we want you listening for a lifetime.
We Want You Listening Fo a Li f e t i m e
Used wisely, your new sound equipment will provide a
lifetime of fun and enjoyment. Since hearing damage
from loud noise is often undetectable until it is too late,
this manufacturer and the Electronic Industries
Association ' s Consumer Electronics Group recommend
you avoid prolonged exposure to excessive noise.
Custome 's Re c o d :
The serial number of this product is found on its bottom cover. You should note the
serial number of this unit in the space provided as a permanent record of your
purchase to aid in identification in the event of theft of loss.
Model Number: JEP-1 0 Serial Number:

E-5
LOCATION OF CONTROLS
1 TIME/M+ 10 FM INDICATOR
2 MIN/DOWN/DIM 11 AM INDICATOR
3 HOUR/UP 12 ALARM 1 INDICATOR
4 SNOOZE/SLEEP 13 ALARM 2 INDICATOR
VOL-/AL1 14 PM INDICATOR
6 VOL+/AL2 1 BATTERY DOOR
7 /MODE 16 AC POWER CORD
8 ALERT INDICATOR 17 ANTENNA
9 WB INDICATOR

E-6
POWER SOURCE
AC POWER CONNECTION
This product operates on 120V ~60Hz AC power supply. Plug the AC power cord (#16)
into a household outlet AC source.
INSTALLING THE BACK-UP BATTERY
This unit is equipped with a battery back-up system, it requires 3V 2 x AA (UM-3)
batteries (not included) to maintain the time settings and radio presets during an AC
power outage.
1. Remove the battery door (#1 ).
2. Install two pieces AA size batteries into the battery compartment following the
polarity diagram inside. Use only the specified size and type of batteries.
3. Replace the battery door (#1 ).
Note: The unit will operate without a battery installed but your time & alarm setting will
be lost and will have to be reset in the event of power interruption or failure.
IMPORTANT:
Be sure that the batteries are installed correctly. Wrong polarity may damage the unit
and void the warranty. For best performance and longer operating time, we recommend
the use of good quality alkaline battery.
BATTERY WARNING
1. Be sure that the batteries are installed correctly. Wrong polarity may damage the unit
2. Use only the size and type of batteries specified.
3. If the unit is not to be used for an extended period of time, remove the batteries.
Old or leaking batteries can cause damage to the unit and may void the warranty.
4. Do not try to recharge batteries not intended to be recharged; they can overheat
and rupture. (Follow battery manufacturer’s directions)
. Do not dispose of batteries in fire, batteries may leak or explode
POWER ON/STANDBY
1. In standby mode, press and hold the /MODE BUTTON (#7) to turn on the unit.
2. Press and hold the /MODE BUTTON (#7) again to return the unit to standby mode.
CLOCK OPERATION
TIME SETTING
1. At Standby mode, press Time/M+ button (#1), 12 or 24 Hr will flash on the display.
2. Press MIN/DOWN/DIM (#2) or HOUR/UP BUTTON (#3) repeatedly to select 12 or
24-hour display mode.
3. Press TIME/M+ button (#1) to confirm, the time will flash on the display.
4. Press the HOUR/UP BUTTON (#3) repeatedly to set the hour, press the
MIN/DOWN/DIMBUTTON (#2) repeatedly to set the minute.
Notes:
• If the PM Indicator (#14) is not showing in 12-hour mode, the time displayed
is AM.
• It will auto confirm after it flashes 4 times. Once the time stop flashing, you can
repeat step 1 to step 4 to reset the time.

E-7
ALARM SETTING
1. At Standby mode, press the VOL-/AL 1 BUTTON (# ) to enter into the AL1 mode.
The ALARM 1 INDICATOR (#12) will turn on and the time will flash on the display.
2. Press the HOUR/UP BUTTON (#3) to select your desired hour, press the
MIN/DOWN/DIM BUTTON (#2) to select your desired minute.
3. Press the VOL-/AL1 BUTTON (# ) again, the display will show “buZ” or “rAd” or
“OFF” and flash.
4. Press the MIN/DOWN/DIM BUTTON (#2) or HOUR/UP BUTTON (#3) repeatedly
to select wake to buzzer “buZ”  wake to FM radio “rAd”/FM LED light  wake to
AM radio “rAd”/AM LED light  turn off the alarm 1 “OFF”.
. To turn off Radio or Buzzer alarm after it sounds by pressing the /MODE BUTTON
(#7) .
6. The Alarm or Radio will sound for 30 minutes if the /MODE BUTTON (#7) was not
pressed. It will stop automatically and wait for same alarm time on next day
7. Alarm 2 setting is same as Alarm.
Note: You should tune to your desired radio station first before starting to set the alarm
time and choosing the radio alarm mode.
SNOOZE FUNCTION
When the alarm sounds, press the SNOOZE/SLEEP BUTTON (#4) to suspend the
alarm and activate the snooze function, alarm will stop & will sound again 9 minutes
later. If you press SNOOZE/SLEEP BUTTON (#4) again, the alarm will stop momentarily
and sound again in 9 minutes and so on.
NOTES:
• The Snooze interval time is fixed at 9 minutes.
• To turn the Snooze function OFF, press the /MODE BUTTON (#7) once.
LISTENING TO THE RADIO
1. Press and hold /MODE BUTTON (#7) to turn on the JEP-1 0.
2. Press the /MODE BUTTON (#7) to switch to your desired frequency band
(FM/AM/WB).
3. The selected frequency band indicator will light up.
MANUAL SEARCH FOR RADIO STATIONS
Tap the HOUR/UP BUTTON (#3) or MIN/DOWN/DIM BUTTON (#2) repeatedly to
choose your desired radio station.
AUTOMATIC SEARCH FOR RADIO STATIONS (AM/FM BAND)
To automatically search for stations with strong signals, press and hold the HOUR/UP
BUTTON (#3) or MIN/DOWN/DIM BUTTON (#2) until the frequency readout on the
display begins to scan and then release the button. The tuner will stop on the first strong
station it finds.
Press the VOL-/AL1/ VOL+/AL2 BUTTONS (# /#6) to adjust the volume level.
Notes:
• The automatic search function is not available in Weather mode. One of the 7
available channels must be selected manually.

E-8
• Use manual tuning to select weaker stations that might be skipped during automatic
tuning.
• If the automatic tuning does not stop on the exact frequency of the station, for
example, it stops on 88.9 MHz instead of 88.8 MHz, use the manual tuning method to
“fine tune” to the exact frequency of the desired station.
HINTS FOR BEST RECEPTION:
To insure maximum FM tuner reception, unwrap and fully extend the ANTENNA (#17)
for best FM radio reception.
TO SET THE RADIO PRESETS (AM/FM BAND)
1. Press and hold the /MODE BUTTON (#7) to turn on the JEP-1 0.
2. Tap the /MODE BUTTON (#7) to select AM/FM band. The AM/FM INDICATOR
(#11/10) will light up.
3. Tap the HOUR/UP BUTTON (#3) or MIN/DOWN/DIM BUTTON (#2) repeatedly to
choose your desired radio station .
4. Press hold the TIME/M+/BUTTON (#1), the preset location will blink on the LED
display.
. Use HOUR/UP BUTTON (#3) or MIN/DOWN/DIM BUTTON (#2 ) to select the
desired preset number (P01-P30).
6. Press the TIME/M+/BUTTON (#1)) again to confirm the preset.
7. Repeat steps 2 through 6 to preset up to 60 stations (30 AM and 30FM stations).
To ecall one of the p eset stations
1. Press and hold the OFF /MODE BUTTON (#7) to turn on the JEP-1 0.
2. Tap the /MODE BUTTON (#7) to select AM/FM band.
3. Press the TIME/M+/BUTTON (#1), the preset location will light up on the LED display.
4. Tap the HOUR/UP BUTTON (#3) or MIN/DOWN/DIM BUTTON (#2) repeatedly
until you reach the desired preset number/radio station.
SLEEP TIMER
1. Press and hold the SNOOZE/SLEEP BUTTON (#4), the display will show 120
minutes. Repeatedly tap the SNOOZE/SLEEP BUTTON (#4) to select the sleep
timer 110, 100, 90, 80, 70, 60, 0, 40, 30, 20, 10, OFF (in minutes). The unit will
play for the selected length of time then turn off automatically.
2. Repeat step 1 to change or cancel the sleep timer
3. To turn the unit “Off” before the selected length of time, press the /MODE
BUTTON (#7) at any time.
LISTENING TO A WEATHER CHANNEL
1. Press and hold the /MODE BUTTON (#7) to turn on the JEP-1 0.
2. Tap the /MODE BUTTON (#7) to select WB band, WB INDICATOR will turn on .
3. Tap the HOUR/UP BUTTON (#3) or MIN/DOWN/DIM BUTTON (#2) to select the
weather band channel for your area.
4. Press the VOLUME +/AL 2 BUTTON (#6) OR VOLUME -/AL1 BUTTON (# ) to
obtain the desired sound level.
. To turn the radio off, press and hold the /MODE BUTTON (#7).

E-9
Weathe Band Channel F equency Table
CHANNEL Frequency (MHZ)
Ch1 162.400
Ch2 162.42
Ch3 162.4 0
CH4 162.47
CH 162. 00
CH6 162. 2
CH7 162. 0
Note:
With regard to the NOAA Weather Band: You need to identify which channel receives
your local weather report. When you change locations either to another city or state,
you may need to choose a different band to get the local report in that location.
HINTS FOR BEST RECEPTION:
To insure maximum weather band reception, the ANTENNA (#17) should be fully
extended to obtain the best possible station reception.
RECEIVING AN EMERGENCY WEATHER ALERT
In both On and Off modes, the JEP-1 0 will receive emergency broadcast alerts, and
sound an alarm warning if there is a severe weather emergency in your area.
1. The JEP-1 0 will turn on automatically, activate the alarm and turn on the pre-
selected WB channel. The ALERT INDICATOR (#8) flashes. The alarm will stay on
for the duration of the alert broadcast.
2. The ALERT INDICATOR (#8) will not stop flashing until you press SNOOZE/SLEEP
BUTTON (#4) or /MODE BUTTON (#7) to turn it off.
Notes:
• In case there is a power interruption, the JEP-1 0 will continue to receive weather
alerts if you have a battery installed in the unit (see “INSTALLING THE BACK-UP
BATTERY” section of the manual). The clock display will be off, but the ALERT
INDICATOR (#8) will be flashing if there is an alert.
• The radio will continue to drain the battery if left unplugged or without power for a
long period of time. It’s highly recommended that you connect the JEP-1 0 to AC
power to prevent the battery from completely draining and turning the radio off while
in use.
• NOAA Weather band is a service broadcast of the U.S. Government and available in
all 0 states, Puerto Rico and the U.S. Virgin Islands.
• The NOAA Weather Service broadcasts a test alert every Wednesday between 11
am and Noon. To receive the broadcasts, the radio must be within the range of the
local broadcast site, 10 - 40 miles, depending on terrain and obstructions.
To lea n mo e:
Or find the weather band channel for your area, go to: http://www.nws.noaa.gov/nwr/ for
NOAA (National Oceanic & Atmospheric Administration) and http://www.ec.gc.ca/ for
Environment Canada.

E-10
DIMMER OPERATION
In standby mode, press the MIN/DOWN/DIM BUTTON (#2 ) repeatedly to select one of
the two brightness settings (high or low).
CARE AND MAINTENANCE
• Children should be supervised when using this appliance.
• Never wrap the AC POWER CORD around any animal or person. Special care
should be taken with long wire.
• Avoid operating your unit under direct sunlight or in hot, humid or dusty places.
• Keep your unit away from heating appliances and sources of electrical noise such as
fluorescent lamps or motors.
• Unplug the unit from the electrical power outlet immediately in case of malfunction.
CLEANING THE UNIT
• To prevent fire or shock hazard, disconnect your unit from the AC power source when
cleaning.
• The finish on the unit may be cleaned with a dust cloth and cared for as other
furniture, use caution when cleaning and wiping the plastic parts.
• If the cabinet becomes dusty wipe it with a soft dry dust cloth. Do not use any wax or
polish sprays on the cabinet.
• If the front panel becomes dirty or smudged with fingerprints it may be cleaned with a
soft cloth slightly dampened with a mild soap and water solution. Never use abrasive
cloths or polishes as these will damage the finish of your unit.
CAUTION: Never allow any water or other liquids to get inside the unit while cleaning.
CARE AND MAINTENANCE
If you experience difficulties in the use of this music system, please check the following
or call 1-800-777- 331 for Customer Service.
SYMPTOM POSSIBLE CAUSE POSSIBLE SOLUTION
Power does not come on. AC line cord not plugged in. Insert plug firmly into AC
outlet.
The AC outlet has not
power
Try the unit on another
outlet
Unit is of Turn on the unit. No sound.
VOLUME control at
minimum position.
Increase Volume
Noise or sound distorted
FM
AM
- Station not tuned properly
- Antenna is not extended
- AM reception is weak
- Retune Broadcast station
- Fully extend the antenna
- Relocate the position of
the unit

E-11
RESETTING
If the system does not respond or exhibits erratic or intermittent operation, you may have
experienced an electrostatic discharge (ESD) or a power surge that triggered the internal
microcontroller to shut down automatically. If this occurs, simply disconnect the ac power
cord and remove the system backup battery, wait for at least 3 minutes and then setup
the unit again as if it is a brand-new unit.
SPECIFICATION
Power source: 120V~, 60Hz
Power Consumption: 3W
Back-up source: 3V 2 x AA (UM-3) batteries (not included)
Frequency Range: FM: 87. -108 MHz
AM: 20-1710 kHz
WB:162.400MHz-162. 0MHz;
Speaker Output power: 1×1 0mW RMS
At Spectra, environmental and social
responsibility is a core value of our business.
We are dedicated to continuous implementation
of responsible initiatives with an aim to
conserve and maintain the environment through
responsible recycling.
Please visit us at
http://www.spect aintl.com/g een.htm for more information on Spectra’s green
initiatives or to find a recycler in your area.
90 DAY LIMITED WARRANTY AND SERVICE
VALID IN THE U.S.A. ONLY
SPECTRA MERCHANDISING INTERNATIONAL, INC. warrants this unit to be
free from defective materials or factory workmanship for a period of 90 days
from the date of original customer purchase and provided the product is
utilized within the U.S.A. This warranty is not assignable or transferable. Our
obligation under this warranty is the repair or replacement of the defective
unit or any part thereof, except batteries, when it is returned to the SPECTRA
Service Department, accompanied by proof of the date of original consumer
purchase, such as a duplicate copy of a sales receipt.
You must pay all shipping charges required to ship the product to SPECTRA for
warranty service. If the product is repaired or replaced under warranty, the return
charges will be at SPECTRA’s expense. There are no other express warranties
other than those stated herein.

E-12
This warranty is valid only in accordance with the conditions set forth below:
1. The warranty applies to the SPECTRA product only while:
a. It remains in the possession of the original purchaser and proof of
purchase is demonstrated.
b. It has not been subjected to accident, misuse, abuse, improper service,
usage outside the descriptions and warnings covered within the user
manual or non-SPECTRA approved modifications.
c. Claims are made within the warranty period.
2. This warranty does not cover damage or equipment failure caused by
electrical wiring not in compliance with electrical codes or SPECTRA user
manual specifications, or failure to provide reasonable care and
necessary maintenance as outlined in the user manual.
3. Warranty of all SPECTRA produ ts applies to residential use only and is void when
produ ts are used in nonresidential environment or installed outside the United
States.
This warranty gives you specific legal rights, and you may also have other rights
which vary from state to state. TO OBTAIN SERVICE please remove all batteries
(if any) and pack the unit carefully and send it freight prepaid to SPECTRA at the
address shown below. IF THE UNIT IS RETURNED WITHIN THE WARRANTY
PERIOD shown above, please include a proof of purchase (dated cash register
receipt) so that we may establish your eligibility for warranty service and repair of
the unit without cost. Also include a note with a description explaining how the
unit is defective. A customer service representative may need to contact you
regarding the status of your repair, so please include your name, address,
phone number and email address to expedite the process.
IF THE UNIT IS OUTSIDE THE WARRANTY PERIOD, please include a check
for $ 12.00 to cover the cost of repair, handling and return postage. All out of
warranty returns must be sent prepaid.
It is recommended that you contact SPECTRA first at 1-800-777- 331 or by
email at [e-mail] for updated information on the unit requiring
service. In some cases, the model you have may be discontinued, and
SPECTRA reserves the right to offer alternative options for repair or replacement.
SPECTRA MERCHANDISING INTERNATIONAL, INC.
4230 North Normandy Avenue,
Chicago, IL60634, USA. 1-800-777- 331
To register your product, visit the link on the website below to enter your
information.
http://www.spectraintl.com/wform.htm
1117 Printed in China
