OWNER'S MANUAL
RM-22T Rotary Machine
WALTER MEIER (Manufacturing) Inc.
427 New Sanford Road
LaVergne, Tennessee 37086 Part No. M-756022
Ph.: 800-274-6848 Revision A 04/2011
www.waltermeier.com Copyright © 2011 Walter Meier (Manufacturing) Inc.

2
Warranty and Service
Walter Meier (Manufacturing) Inc., warrants every product it sells. If one of our tools needs service or repair, one of
our Authorized Service Centers located throughout the United States can give you quick service. In most cases, any
of these Walter Meier Authorized Service Centers can authorize warranty repair, assist you in obtaining parts, or
perform routine maintenance and major repair on your JET
® tools. For the name of an Authorized Service Center in
your area call 1-800-274-6848.
MORE INFORMATION
Walter Meier is consistently adding new products to the line. For complete, up-to-date product information, check with
your local Walter Meier distributor, or visit waltermeier.com.
WARRANTY
JET products carry a limited warranty which varies in duration based upon the product (MW = Metalworking, WW =
Woodworking).
WHAT IS COVERED?
This warranty covers any defects in workmanship or materials subject to the exceptions stated below. Cutting tools,
abrasives and other consumables are excluded from warranty coverage.
WHO IS COVERED?
This warranty covers only the initial purchaser of the product.
WHAT IS THE PERIOD OF COVERAGE?
The general JET warranty lasts for the time period specified in the product literature of each product.
WHAT IS NOT COVERED?
Five Year Warranties do not cover woodworking (WW) products used for commercial, industrial or educational
purposes. Woodworking products with Five Year Warranties that are used for commercial, industrial or education
purposes revert to a One Year Warranty. This warranty does not cover defects due directly or indirectly to misuse,
abuse, negligence or accidents, normal wear-and-tear, improper repair or alterations, or lack of maintenance.
HOW TO GET SERVICE
The product or part must be returned for examination, postage prepaid, to a location designated by us. For the name
of the location nearest you, please call 1-800-274-6848.
You must provide proof of initial purchase date and an explanation of the complaint must accompany the
merchandise. If our inspection discloses a defect, we will repair or replace the product, or refund the purchase price,
at our option. We will return the repaired product or replacement at our expense unless it is determined by us that
there is no defect, or that the defect resulted from causes not within the scope of our warranty in which case we will,
at your direction, dispose of or return the product. In the event you choose to have the product returned, you will be
responsible for the shipping and handling costs of the return.
HOW STATE LAW APPLIES
This warranty gives you specific legal rights; you may also have other rights which vary from state to state.
LIMITATIONS ON THIS WARRANTY
WALTER MEIER (MANUFACTURING) INC., LIMITS ALL IMPLIED WARRANTIES TO THE PERIOD OF THE
LIMITED WARRANTY FOR EACH PRODUCT. EXCEPT AS STATED HEREIN, ANY IMPLIED WARRANTIES OR
MERCHANTABILITY AND FITNESS ARE EXCLUDED. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW
LONG THE IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
WALTER MEIER SHALL IN NO EVENT BE LIABLE FOR DEATH, INJURIES TO PERSONS OR PROPERTY, OR
FOR INCIDENTAL, CONTINGENT, SPECIAL, OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OF
OUR PRODUCTS. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
Walter Meier sells through distributors only. The specifications in Walter Meier catalogs are given as general
information and are not binding. Members of Walter Meier reserve the right to effect at any time, without prior notice,
those alterations to parts, fittings, and accessory equipment which they may deem necessary for any reason
whatsoever. JET
® branded products are not sold in Canada by Walter Meier.

3
For your own safety, read the owner’s manual before operating the rotary machine.
This rotary machine is designed and intended for use by properly trained and experienced
personnel only. If you are not familiar with the proper and safe operation of a rotary machine, do
not use until proper training and knowledge have been obtained.
1. KEEP GUARDS IN PLACE and in working order.
2. KEEP ALL BODY PARTS AWAY FROM MOVING PARTS. Avoid placing any part of your body
near belts, cutters, gears, etc.
3. DO NOT EXCEED 22 GAUGE RATED CAPACITY on this rotary machine.
4. KEEP THE WORK AREA CLEAN. Cluttered areas and work benches invite accidents.
5. KEEP CHILDREN AWAY. All visitors should be kept a safe distance from the work area.
6. MAKE THE WORKSHOP KID PROOF with padlocks, master switches, or by removing starter keys.
7. DON’T FORCE THE MACHINE. It will do the job better and more safely at the rate for which it was
designed.
8. USE THE RIGHT MACHINE. Do not force a machine or attachment to do a job for which it was not
designed.
9. WEAR PROPER APPAREL. Do not wear loose clothing, gloves, neckties, rings, bracelets, or other
jewelry which may get caught in moving parts. Non-slip footwear is recommended. Wear protective
hair covering to contain long hair.
10. ALWAYS USE SAFETY GLASSES. Also use face or dust masks if the cutting operation is dusty.
Everyday eyeglasses only have impact resistant lenses; they are not safety glasses.
11. DON’T OVERREACH. Keep proper footing and balance at all times.
12. MAINTAIN TOOLS WITH CARE. Keep tools sharp and clean for the best and safest performance.
Follow instructions for lubricating and changing accessories.
13. NEVER STAND ON A MACHINE. Serious injury could occur if the machine is tipped.
14. CHECK DAMAGED PARTS. Before further use of the machine, a guard or other part that is
damaged should be carefully checked to determine that it will operate properly and perform its
intended function - check for alignment of moving parts, binding of moving parts, breakage of parts,
mounting, and any other conditions that may affect its operation. A guard or other part that is
damaged should be properly repaired or replaced.
15. SHEET METAL STOCK HAS SHARP EDGES. To prevent cuts, use caution when handling.
16. KEEP HANDS AND FINGERS clear of the area in front and rear of the rotary machine.
17. DO NOT USE THE MACHINE for any purpose other than for which it was designed.
18. FAILURE TO COMPLY with all of these warnings may cause serious injury.
19. SOME DUST CREATED BY power sanding, sawing, grinding, drilling and other construction
activities contains chemicals known to cause cancer, birth defects or other reproductive harm. Some
examples of these chemicals are:
•Lead from lead based paint
•Crystalline silica from bricks and cement and other masonry products, and
•Arsenic and chromium from chemically-treated lumber.
YOUR RISK FROM THESE EXPOSURES varies, depending on how often you do this type of work.
To reduce your exposure to these chemicals: work in a well ventilated area, and work with approved
safety equipment, such as those dust masks that are specifically designed to filter out microscopic
particles
20. DO NOT OPERATE TOOL while under the influence of drugs, alcohol or any medication.

4
Specifications: RM-22T
Stock Number................................................................................................................................ 756022
Capacity......................................................................................................................................22 gauge
Distance Between Shaft Centers ............................................................................................................2”
Depth of Throat to Frame........................................................................................................................7”
Overall Dimensions (LxWxH).................................................................................................... 18”x8”x16”
Net Weight ......................................................................................................................................64 lbs.
Uncrating and Clean-Up
1. Remove the RM-22Tfrom the crate.
2. Carefully clean all rust protected surfaces
with a mild solvent or kerosene and a soft
rag. Do not use lacquer thinner, paint
thinner, or gasoline. These will damage
painted surfaces.
3. Lubricate all moving parts of the machine
with light grease or heavy oil.
4. Carefully move the machine to a well lighted
area and attach to a solid, level work bench.
5. Machine location must allow access to all
sides.
Setup for Rolls
The (#) in the text refers to the breakdown and
parts list.
1. Use the spanner wrench to remove the roll
nut #45 and install the different roll
combinations.
2. According to the material thickness, lower
the upper shaft #11 by turning the handle
assembly #16.
3. Turn the adjusting nut #26 to align the upper
and lower rolls. To facilitate the movement,
push in on the upper roll while turning the
adjusting nut. Tighten the set screw #57.
4. According to the size of the work piece
adjust the gauge stop #31 by turning knurled
nuts #33 to the proper position. You can
also adjust the gauge seat #30 by loosening
the set screw #32.
5. The work piece can now be inserted
between the rolls. Turn handle assembly
#16 until the rolls lightly press on the
material. Slowly turn handle #38 while
handle assembly #16 is rotated to give the
desired shape.
Lubrication
1. There are two grease fittings #24 that need
to be greased once a month.
2. The machine must be lubricated every day
of service with a few drops of oil. An oil
pinhole is located at the end of the lower
shaft #34, and upper shaft #11.
3. Every thirty days of operation grease the
gears by removing the gear cover #36.

5
Breakdown for the RM-22T Rotary Machine

6
Parts List for the RM-22TRotary Machine
Index Part
No. No. Description Size Quantity
1..........RM22N-1......................Body Assembly...................................... ...............................................1
2..........RM22N-2......................Base Assembly...................................... ...............................................1
10........RM22N-10....................Key........................................................6x6x20....................................4
11........RM22N-11....................Upper Shaft........................................... ...............................................1
12........RM22N-12....................Adjust Seat............................................ ...............................................1
13........RM22N-13....................Spring.................................................... ...............................................1
14........RM22N-14....................Screw.................................................... ...............................................1
16........RM22N-16....................Handle Assembly................................... ...............................................1
17........RM22N-17....................Collar .................................................... ...............................................1
18........RM22N-18....................Spring Pin..............................................5x32........................................1
19........RM22N-19....................Spring Collar ......................................... ...............................................1
20........RM22N-20....................Spring.................................................... ...............................................1
21........RM22N-21....................Collar .................................................... ...............................................1
22........RM22N-22....................Set Screw..............................................M12x40...................................2
23........RM22N-23....................Hex Nut.................................................M12........................................2
24........RM22N-24....................Oil Cup.................................................. ...............................................2
25........RM22N-25....................Gear...................................................... ...............................................2
26........RM22N-26....................Adjusting Nut......................................... ...............................................1
29........RM22N-29....................Collar .................................................... ...............................................2
30........RM22N-30....................Gauge Seat........................................... ...............................................1
31........RM22N-31....................Gauge Stop........................................... ...............................................2
32........RM22N-32....................Set Screw.............................................. ...............................................1
33........RM22N-33....................Knurled Nut........................................... ...............................................4
34........RM22N-34....................Lower Shaft........................................... ...............................................1
36........RM22N-36....................Gear Cover............................................ ...............................................1
37........RM22N-37....................Button Head Hex Screw ........................ ...............................................2
38........RM22N-38....................Handle................................................... ...............................................1
43........RM22N-43....................Bushing................................................. ...............................................2
44........RM22N-44....................Beading Roll (set).................................. ...............................................2
............RM22N-44-1.................Turning Roll (set)................................... ...............................................2
............RM22N-44-2.................Closing Roll (set)................................... ...............................................2
............RM22N-44-3.................Jogging Roll (set)................................... ...............................................2
............RM22N-44-4.................Flanging Roll (set) ................................. ...............................................2
............RM22N-44-5.................Crimping Roll (set)................................. ...............................................2
45........RM22N-45....................Roll Nut................................................. ...............................................2
49........RM22N-49....................Base...................................................... ...............................................1
50........RM22N-50....................Screw.................................................... ...............................................1
52........RM22N-52....................Handle................................................... ...............................................1
53........RM22N-53....................Socket Head Cap Screw........................M8x40.....................................1
54........RM22N-54....................Socket Head Cap Screw........................M8x15.....................................1
55........RM22N-55....................Pin.........................................................8x45........................................1
56........RM22N-56....................Set Screw..............................................M8x16.....................................1
57........RM22N-57....................Set Screw..............................................M6x6.......................................1
58........RM22N-58....................C-Ring...................................................20...........................................1
59........RM22N-59....................Pin.........................................................5x20........................................1
60........RM22N-60....................Hex Nut.................................................M8..........................................1
............RM22N-61....................Spanner Wrench (not shown) ................ ...............................................1
............RM22N-ID.....................ID Label (not shown).............................. ...............................................1
............RM22N-W.....................Warning Label (not shown).................... ...............................................1
............RM22N-J ......................JET Label (not shown)........................... ...............................................1

7

8
WALTER MEIER (Manufacturing) Inc.
427 New Sanford Road
LaVergne, Tennessee 37086
Phone: [phone]
www.waltermeier.com
