Jetson GEN 1 User manual

1
GEN 1
-MANUAL-

2
TABLE OF CONTENTS
A. Introduction 3
B. Included In The Box 4
C. Features And Specs 5
D. Unboxing 6
E. Charging the Battery 7
F. Operating the Gen 1 8
1. Turning On and Off
2. Turning Lights On and Off
3. Turn Signal Lights
4. The Horn
5. Brake Levers
6. Pedals
7. Kickstand
8. LCD Display Screen
G. Safe Driving 13
H. Care and Maintenance 13
I. Safety Warnings 15
J. Warranty 17
K. Product Registration 18

3
Congratulations on your new Jetson Gen 1! The Gen 1 is an innovative and fun
personal transportation device, ready to take on everyday use. Before your rst
ride, check whether the wheels are damaged, or parts are loose. If there are
any abnormalities, please contact Jetson Customer Support at 1-(888) 976-
9904 or email us at [e-mail].
This product manual can help you understand, use, and maintain your Gen 1. In
order to avoid danger caused by collisions, falls, and loss of control, please use
caution and learn how to ride the Gen 1 safely. Jetson and authorized dealers
cannot be held liable for injury or damage caused from riding the Gen 1. Users
ride at their own risk.
The rider is responsible for consequences caused by violating warnings or
improper operations.
If you want to return this product for any reason, be sure to rst call or email us
before taking it back to the store so we can assist you.
INTRODUCTION

4
INCLUDED IN THE BOX
1. Front LED Headlight
2. Hook
3. Charging Port
4. Seat
5. Seat Cask Lock
6. Rear Handle
7. Motor
8. Rear Brake
9. Chain
10. Pedal
11. Deck
12. Front Brake
1
45
6
89
10
11
12 7
3
2

5
FEATURES AND SPECS
MODEL: GEN 1
WHEEL SIZE: 18”
MAX SPEED: 20 MPH
MAX RANGE: 30-40 MILES
BATTERY TYPE: LITHIUM ION
BATTERY RATED VOLTAGE: 48V, 17Ah
MOTOR TYPE: BRUSHLESS
MOTOR: 500w
CHARGER: 110-240V
CHARGE TIME: 4-5 HOURS
PRODUCT WEIGHT: 125 LBS
WEIGHT LIMIT: 300 LBS
REMOVABLE BATTERY: YES
RECOMMENDED AGE: 18+
1. Kickstand
2. Turn Signal Lights
3. Horn
4. Rear Brake Lever
5. Turn Signal Switch
1
2
6
10
4
6. LCD Display
7.Headlight, Taillight, High Beam Switch
8. Twist Throttle
9. Front Brake Lever
10. Taillight
9
2
3
75
3
8

6
UNBOXING
After removing the cardboard carton, you will have to remove the metal crate
from around the Gen 1. Using the provided tools, unbolt each metal bar from
the top of the crate then unbolt the metal clasps hooked onto the Handlebars
of the Gen 1. Be careful not to scratch the frame of the Gen 1. Please check the
cardboard carton and metal crate for loose parts before discarding.
The Gen 1 comes fully assembled, except for the side mirrors.
To assemble the Side Mirrors, place the stem of the Side Mirrors into the holes
of the Handlebars and turn until secure using the included tools.
Gen 1 with mirrors

7
CHARGING THE BATTERY
Your Gen 1 comes with a built-in rechargeable lithium battery. Always use
the provided charger only. Before your rst ride you must fully charge the
Gen 1 - charge for 12 hours for the rst 3 times you use it. For every ride after,
charge your Gen 1 until it is fully charged, and NOT LONGER. Do not leave any
chargers plugged in overnight, or leave it plugged in past the charge time. The
extension cord should not be plugged directly into the Gen 1 or the battery. It
needs to be plugged into the power supply. You can also charge the Gen 1 by
disconnecting the battery from under the seat and then charging the battery
directly.
1. Plug one end of the power cord into a grounded AC outlet and the other
into the Gen 1’s charging port. The red charging light on the charger unit will
turn on.
2. The red light will turn green once fully charged. Recharge the Gen 1 after
each use.
(Please note: Always plug the charger into the wall rst before the device. If the
wall outlet doesn’t have power and you plug the charger into the device rst, it
will light green, even if the battery is not full. So always plug into the wall rst to
make sure there is power.)
THE CHARGER OFFERS A CHARGING STATUS ON THE TOP OF THE
CHARGER:
CHARGING LIGHT RED: Battery is charging.
CHARGING LIGHT GREEN: Charging is complete.
Charge the battery when the Gen 1 displays low power. When you are done
charging the battery, remember to cover the Charging Port.
Don’t use the Gen 1 if the battery emits strange odors, overheats, or begins
leaking. If the battery does leak, do not touch any leaking materials, as the
battery contains dangerous substances. Do not open the battery and do not
insert anything into the battery.
Only use the provided charger for the Gen 1. Do not charge the battery if it has
over-discharged. It should be discarded for your safety. Do not turn on the Gen
1 while it is charging.

8
TURNING ON AND OFF
To turn the Gen 1 On, unlock the Seat Cask using the provided key in the
lock on the left side of the Seat Cask. Lift the Seat and locate thecircuit
switch. Switch it to On. (It is recommended to turn off the circuit switch when
transporting or storing the Gen 1). Close the Seat and press down rmly to
make sure it is secure. Place the provided key in the Ignition and turn clockwise.
OPERATING THE GEN 1
Turning the
Gen 1 On

9
TURNING LIGHTS ON AND OFF
To turn the Headlight and Taillight on, ip the switch on the right handlebar
to the left. One click to the left turns on the Headlight and Taillight. Two clicks
to the left turns on the Headlight, the Taillight, and the High Beam. There are
two functions for the High Beam. The High Beam switch is located on the
Left Handlebar. Flipping the High Beam Switch up will raise the High Beam.
Flipping the High Beam Switch down will lower the High Beam.
To turn your Gen 1 off, make sure it is not in motion, then turn the key counter
clockwise. Once the key is removed from the Ignition, unlock the Seat Cask and
turn the battery switch to Off.
Turning the
Gen 1 Off
High Beam
Function
Switch
Headlight,
Taillight, and
High Beam
On/ Off
Switch

10
THE HORN
There are two Horn Buttons on the Gen 1, one button is on each Handlebar.
Press either button or both to sound the Horn.
TURN SIGNAL LIGHTS
The switch to use the Turn Signal Lights is on the Left Handlebar. Flip the switch
to the left to turn on the Left Turn Signal Lights and ip the switch to the right to
turn on the Right Turn Signal Lights. When the Turn Signal Lights are activated,
you will also hear a beeping sound.
To turn off the Turn Signal Lights and the beeping sound, press the off button
in the center of the switch.
BRAKE LEVERS
There are two Brake Levers on the Gen 1. The Left Brake Lever is for the Rear
Tire. The Right Brake Lever is for the Front Tire.

11
PEDALS
There are two Pedals that can be used to ride the Gen 1 instead of using the
Motor.
If you do not want to use the Pedals, they can be lifted up. To lift the Pedals up,
press the button on the Pedal in. Then push the Pedal in towards the center of
the Gen 1 and lift it up. To unfold, push the Pedal down.
KICKSTAND
To put the Kickstand down, lift the Gen 1 by the Rear Handle and push the
Kickstand down and forward toward the Front Wheel.
Press
Button
Push In and Up

12
To lift the Kickstand up, lift the Gen 1 by the Rear Handle and push the
Kickstand up and back towards the Rear Wheel.
LCD DISPLAY SCREEN
The LCD Display Screen is an interface that shows the Battery Life Indicator,
Speedometer, and Odometer while in operation. The trip will reset once you
turn off the Gen 1. It also has a backlight so the Gen 1 can be used at night.
Battery
Indicator
Speedometer
Odometer

13
Helmet: Most serious injuries that occur while riding are head injuries. This
could be prevented by wearing a helmet.
Elbow and Knee Pads: For added protection, always wear elbow and knee
pads when riding your Gen 1, to prevent any serious injuries.
Get to know the Gen 1 before riding it. Test your control over it. Make
your turns slowly and cautiously, and give yourself stopping distance. It is
recommended you practice your rst ride on the Gen 1 in an open space with
no obstacles to disturb you.
DRIVING TECHNIQUE
Foot Position – While riding the Gen 1, either keep your feet on the Pedals or
on the Foot Rest. Do not ride with your feet dangling over the sides. Remain
seated while riding the Gen 1.
To start riding, turn the Twist Throttle slightly. Get accustomed to the
acceleration of the throttle.
PLEASE NOTE: Riding, like most sports, involves risk of injury and damage. By
choosing to ride the Gen 1 the responsibility and all inherent risk is on you. It is
crucial that you know, understand and act according to safety rules.
Turns - The turns on the Gen 1 are commanded by the direction you turn the
Handlebar/Front Wheel in. Before turning, look both ways to make sure your
path is clear. Remember to always use the Turn Signal Lights when turning.
Braking – To come to a stop, squeeze the Brake Levers. Be careful not to
squeeze the Brake Levers too fast, as it may cause too sudden a stop or jerking
motion.
DRIVING RANGE
The average range of the Gen 1 is 30-40 miles. However, a lot of factors will
affect how far you can go per charge:
• Driving surface: A smooth, at surface will increase driving distance.
• Weight: More weight means less distance.
• Ambient temperature: Please ride and store the Gen 1 under
recommended temperature, which will increase its longevity and driv-
ing distance.
• Maintenance: Timely battery charging and maintenance will increase
driving distance.
• Speed and driving style: Maintaining a moderate speed will increase
distance. Frequent starting and stopping, acceleration, and decelertion
will reduce it.
CARE AND MAINTENANCE
SAFE DRIVING

14
SPEED LIMIT
The top speed of the Gen 1 is set to 20 mph.
WEIGHT LIMIT
The maximum load is 300 lbs. Going above the maximum weight limit can
cause injury or damage the Gen 1.
CLEANING THE GEN 1
To clean the Gen 1 carefully wipe with a damp cloth, then dry with a dry cloth.
Do not use water to clean the Gen 1, as the electrical and electronic systems
may get wet, resulting in personal injury or malfunction of the Gen 1. Lube the
chain every so often to keep it smooth.
BATTERY
• Keep the Gen 1 away from re and excessive heat.
• To avoid damage to the battery, never subject the Gen 1 to intense physical
shock, severe vibration, or impact.
• Protect the Gen 1 from water or moisture.
• Never disassemble the Gen 1 or its battery.
• If there are any issues with the battery, please contact Jetson Customer
Support at 1-[phone] or email us at [e-mail].
STORAGE
• If you plan on storing the Gen 1 for a substantial period of time, please make
sure you fully charge the battery before storing. The battery should be fully
charged once a month after this.
• To protect against dust, cover the Gen 1.
• Store the Gen 1 indoors, in a dry place and at a suitable temperature.
• You should bring the Gen 1 into a warm environment (above 50 degrees
Fahrenheit) for charging.
• Do not leave the Gen 1 plugged into the charger for long periods of time.

15
Here are some useful tips to make sure you always have a safe ride:
• Children, the elderly, and pregnant women should not use the Gen 1.
• Do not ride after drinking or taking prescription medication.
• Do not carry items when riding.
• Prior to each ride, inspect each part of the Gen 1 to ensure it has been
maintained correctly and is functioning properly.
• Always give way to pedestrians.
• Always comply with local trafc laws and regulations. Remember, the Gen
1 is a motor vehicle, and is treated as such by local law enforcement. You can
and will be arrested for drunk driving. Many cities have restrictions on where
you can drive motor vehicles, as well as additional restrictions on driving
non-automobiles on streets and highways.
• Be alert to things in front and far away from you.
• Make sure your feet are always placed securely on the pedals or foot rest.
•The Gen 1 cannot be ridden by more than two people. Only up to two people
can ride at a time.
• When you ride the Gen 1 along with other cyclists, always keep a safe
distance to avoid a collision.
• When turning, be sure to maintain your balance.
• Do not allow distractions when riding, such as answering the phone or
engaging in any other activities.
• Avoid riding in the rain or on smooth surfaces such as snow or ice.
• Do not ride on roads with obstacles (such as litter, small stones, etc.).
• Avoid riding in narrow spaces or on steep slopes.
• Avoid riding around ammable gas, steam, liquid, or dust that could cause
re.
• Never operate the product barefooted and keep shoelaces tied.
• Riding with improperly adjusted brakes is dangerous and can result in serious
injury or death.
• Applying brakes too hard or too suddenly can lock up a wheel, which could
cause you to lose control and fall. Sudden or excessive application of the front
brake may pitch the rider over the handlebars, which may result in injury or
death.
SAFETY WARNINGS

16
CALIFORNIA WARNING
This product contains chemicals, including lead, which are known to the state
of California to cause cancer, birth defects, and other medical conditions.
MODIFICATIONS
Do not attempt to disassemble, modify, repair, or replace the Gen 1 or any
components of the unit without instruction from Jetson Customer Support. This
will void any warranty, and can lead to malfunctions which may cause injury.
ADDITIONAL OPERATION CAUTIONS
Do not lift the Gen 1 off the ground while it is on and the wheels are in motion.
This can result in freely spinning wheels, which may cause injury to yourself
or others nearby. Do not jump on or off the Gen 1, and do not jump while
using it. Always keep your feet rmly planted on the pedals or foot rest while in
operation. Always check battery charge before using.

17
LIMITED 1 YEAR WARRANTY
TO QUALIFY FOR WARRANTY SERVICE:
1. You must present a copy of the sales receipt from an approved retail partner
within 90 days of purchase.
2. This product cannot be used for rental or commercial use.
3. This product cannot be used for competition.
LIMITATIONS OF LIABILITY
• This Limited 1 Year Warranty is non-transferable after the product’s initial sale.
• No unapproved modications can be made to the product, its performance
or otherwise, in order for this Limited 1 Year Warranty to remain in effect.
• No reimbursement is provided for towing, loss of time, loss of use, inconve-
nience, incidental or consequential damages.
• Warranty is void if weather related water damage is determined. Owner is
responsible for storage and protection from weather.
• Jetson® makes no warranty with respect to products or trade accessories
not made by Jetson®, including, but not limited to, motors, tires, wheels, and
batteries, such products or trade accessories, such items being subject to the
original manufacturer’s warranty, if any.
• This Limited 1 Year Warranty does not cover minor surface blemishes, rips,
tears, or other cosmetic damages due to normal use, or other intentional or
unintentional damage to the product.
• This Limited 1 Year Warranty will not cover any damage which results from the
application of improper cleaners, solvents or chemicals to the product, water
damage, smoke or soot, or from exposure to saltwater, sea breeze or salt.
• This Limited 1 Year Warranty will not cover any damage which results from
aging, such as fading of paint, deterioration of plated surfaces, deterioration of
rubber or plastics, or rusting.
• This Limited 1 Year Warranty does not cover improper repair or misdiagnoses
of problems.
• This Limited 1 Year Warranty only covers parts due to manufacturer defect.
• Damage due to misuse or neglect, use other than as specied in the Owner’s
Manual, or use under abnormal conditions are not covered by this Limited 1
Year Warranty.
OWNER’S WARRANTY RESPONSIBILITIES
As the device’s owner, you are responsible for the performance of the required
maintenance. You may be denied a warranty claim solely because of your
failure to ensure the performance of all scheduled maintenance. As the owner,
you should be aware that you may be denied your warranty coverage if your
device or a part has failed due to abuse, neglect, improper maintenance, or
unapproved modications. For any issue regarding your Jetson® product, call
toll free 1-[phone], or email [email protected].

18
Please complete and mail this card within 10 days of purchase.
Name: _____________________________________________________________________________
Age: _______________________________________________________________________________
Addr
ess: ___________________________________________________________________________
_
City
, State, Zip: ______________________________________________________________________
Email: ______________________________________________________________________________
Home Phone: ___________________________
Work Phone: _____________________________
Pu
rchase Date: _________________________ Purchased From: __________________________
Serial Number: ______________________________________________________________________
Gender: _______________ Occupation: ______________________________________________
Is this your first
Jetson product? ______________________________________________________
Other similar pr
oduct owned before: _________________________________________________
How did you hear about the Gen 1? ______________________________________________
_____________________________________________________________________________________
Co
mplete this form and mail it to:
Attention: Product Registration
Jetson Electric Bikes
1 Rewe Street
Brooklyn, NY 11211
PRODUCT REGISTRATION

19

20
GEN 1
