Jetson BREEZE JMY3000-BLK User manual

USER GUIDE MANUAL
MODEL#: JMY3000-BLK | VERSION: 042016

• Scooter • Charger
• Tool kit • Pump
IN THE BOX
Congratulations on purchasing your brand new Jetson®Breeze
Electric Scooter. The Jetson®Breeze is a stylish and reliable folding electric
scooter. With a long range of 15-20 miles per charge, the breeze can take
you anywhere you want to go. Use it for your daily commute and still have
enough juice for those fun leisure strolls. Charging takes up to 5 hours to fully
recharge those 15-20 miles. With a backlight LCD display, and front and
back brakes, you know you’ll be safe riding at all times of the day. Please
ride safe, follow your local laws, and take it for a breeze!
Before taking the Breeze for a ride, please get adjusted to its speed and
turning radius and sensitivity to avoid any injury.
SPECIFICATIONS
• Range: Up To 20 Miles Per Charge
• Speed: Up To 18 Mph
• Weight Limit: 325 Lbs
• Braking System: Front + Rear Disc Brake
(Brake For Each)
• Motor: 250 Watt Brushless Electric Motor
• Charge Time: 4 Hour Fully Charged
• Battery: Lithium-Ion 36V 8.8Ah
• Tire: 10 Inches
• Weight: 32 Lbs
SAFETY FEATURES
• 3 Rear Reectors + Brake Lights
• Anti-slid Grips For Foot Control
• Easy Grip Handlebars
• Energy-saving Auto-shutdown
FEATURES
• No Assembly Required
• Backlit LCD Display With Speed,
Odometer and Battery Guage
• Thumb Throttle Speed Contol
• 3 Speed Options
• Integrated Quick-Alert Bell
• Aluminum Alloy Frame With
Concealed Battery
• Protective Mudguard
• Built-in Kickstand
• Quick Release Lock + Fold
Technology
• Compact And Portable For
Travel
• Collapsible Handlebars
• Height Adjustable
• Water-Resistant

Jetson Breeze Features .....…..…........….………………….....…………….………3
Jetson Breeze Main Parts ................................................................................4-5
Warnings & General information ..………........………..……..........………...…6-7
Serial Number ……………………….……..………………….......…………………...8
Opening & Folding the Jetson Breeze ...……………....……...…..………….9-15
Operation ..………………………………………………………………………....…16
Charging & Battery .....……………………………………………….….…..………17
Throttle ............................................................................................................18-21
Safety / Tires air pressure …....……………...….…………………………......….....22
Driving Technique .......……………………..…………...……..…...................23-24
Jetson Breeze Quick Maintenance .................................................................25
Flat Tire Repair Instruction ..…………………….....…………..……….........…27-35
Removing Rear Plastic Covers ..........................................................................28
Disconnecting Motor Connectors ...................................................................29
Removing Rear Motorized Wheel ...............................................................30-31
Replacing Flat Tire Tube ...............................................................................32-33
Reassembling Rear Wheel ...............................................................................34
Plastic Covers Assembly ....................................................................................35
1
Table of Contents:

2

THUMB THROTTLE
LCD DISPLAY WITH SPEED,
BATTERY METER & ODOMETER
FOLDING TBAR
SELF LOCKING /
RELEASE BUTTON
LITHIUM ION
BATTERY 36V-8.8Ah
ALUMINIUM DECK
ANTI SKID GRIPS
2 REFLECTORS
REAR DISC
BRAKE
EFFICIENT INTEGRAL
BRUSHLESS HUB MOTOR
BATTERY CHARGER
CONNECTOR KICKSTAND
QUICK FOLDING
MECHANISM
BELL
EASY GRIP
HANDLEBARS FRONT BRAKE LEVER
REAR DISC BRAKE LEVER
QUICK RELEASE
FRONT V-BRAKES
ALLOY WHEEL
10 INCH
PNEUMATIC TIRES
REMOVABLE
BRACKETS ON
EACH CORNER
FOR MAINTENANCE
ACCESSIBILITY
HEIGHT ADJUSTABLE
HANDLEBARS
MUDGUARD
CARRY HANDLE
FRONT & BACK
BRAKES LIGHTS
3
JETSON®BREEZE FEATURES

REAR DISC BRAKE
QUICK FOLDING MECHANISM WHEEL MOTOR
ALUMINIUM DECK WITH CARRY HANDLE + ANTI SKID GRIPS
BATTERY CHARGER CONNECTOR
4
WARNINGS & GENERAL INFORMATION

QUICK RELEASE
FRONT BRAKE LEVER / REAR DISC BRAKE LEVER
SPEED CONTROL THROTTLE
WITH LCD DISPLAY
MAINTENANCE PLASTIC COVER
KICKSTAND
5
WARNINGS & GENERAL INFORMATION

WARNING !
WHY IS IT NECESSARY TO READ THIS USER MANUAL ?
This Manual was written to help you understand the proper use and
maintenance of the Jetson®Breeze.
It is important for you to understand the Jetson®Breeze; its features
and performance, so that you enjoy every ride.
Also, it is important that your rst ride with the Jetson®Breeze is in an
open area.
The Jetson®Breeze needs a short period for all moving parts such as
hinges and brakes to adjust themselves into their correct position.
IMPORTANT INFORMATION
READ THIS MANUAL
The responsibility for the Jetson®Breeze maintenance is
yours, and will help reduce risks of injuries.
Before riding, please ensure that the brake levers, and
thumb throttle LCD display are all tightly secure before
using the device.
6
WARNINGS & GENERAL INFORMATION

Always follow the local laws and regulations.
Never ride your scooter in conditions of poor visibility.
Do not do stunts, wheelies or jumps. They will increase your
chances of injury and damage your Jetson®Breeze.
Never carry passengers.
GENERAL WARNING
JETSON®is not liable for incidental damages or consequential
damages due directly or indirectly to the use of this product.
PLEASE NOTICE
Ensure that the Self locking/release button is inserted all the way in
to the middle folding mechanism/bridge.
BEFORE RIDING:
7
WARNINGS & GENERAL INFORMATION

RECORD SERIAL NUMBERS:
Write down the serial number of your Jetson®Breeze. Keep this
information separately and in a safe place.
Each Jetson®Breeze has a unique serial number. These numbers can
provide information that may be useful later on for insurance claims and
in case of loss or theft.
Jetson®Breeze serial number location:
1. The number is on the top of the board, on the side of the front wheel.
2. Note the serial number and keep it in a safe place.
8
SERIAL NUMBER
