Jetson JRACER-BLK User manual

Racer Folding Electric Scooter.
A guide for your ride.
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY.
MODEL: JRACERBLK
Designed in Brooklyn | Made in China

Remember to be safe and,
most importantly, have fun!

3
Table of Contents
Safety Warnings
What’s in the Box
Specs & Features
Charging the Battery
Unfolding / Folding the Racer
Handlebar Assembly
Operating the Racer
Using the Thumb Throttle / Handbrake
Riding the Racer
Helmet Safety
Care & Maintenance
........................................................................................................................................................ 
....................................................................................................................................................... 
...................................................................................................................................................... 
.............................................................................................................................................. 
................................................................................................................................ 
.............................................................................................................................................. 
............................................................................................................................................... 
................................................................................................................. 
..................................................................................................................................................... 
......................................................................................................................................................... 
............................................................................................................................................... 

4
Safety Warnings
• Before use, please read the user manual and safety warnings carefully, and make sure you understand and accept all the safety
instructions. The user will be responsible for any loss or damage caused by improper use.
• Before each cycle of operation, the operator shall perform the preoperation checks speciied by the manufacturer: That all guards and
pads originally supplied by the manufacturer are in proper place and in serviceable condition; That the braking system is functioning
properly; That any and all axle guards, chain guards, or other covers or guards supplied by the manufacturer are in place and in serviceable
condition; That tires are in good condition, inlated properly, and have suicient tread remaining; The area that the product is to be
operated should be safe and suitable for safe operation.
• Components shall be maintained and repaired in accordance with the manufacturer’s speciications and using only the manufacturer’s
authorized replacement parts with installation performed by dealers or other skilled persons.
• Warning against recharging non-rechargeable batteries.
• Don’t allow hands, feet, hair, body parts, clothing, or similar articles to come in contact with moving parts, wheels, or drive train, while the
motor is running.
• This product should not be used by children or persons with reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction (IEC 60335-1/A2:2006).
• Unsupervised children should not play with the product (IEC 60335-1/A2:2006).
• Adult supervision is required.
• The rider should not exceed 220 lb.
• Units shall not be operated to perform racing, stunt riding, or other maneuvers, which may cause loss of control, or may cause
uncontrolled operator/passenger actions or reactions.
• Never use near motor vehicles.
• Avoid sharp bumps, drainage grates, and sudden surface changes. Scooter may suddenly stop.
• Avoid streets and surfaces with water, sand, gravel, dirt, leaves, and other debris. Wet weather impairs traction, braking, and visibility.
• Avoid riding around lammable gas, steam, liquid, or dust that could cause ire.
• Operators shall adhere to all of the manufacturer’s recommendations and instructions, as well as comply with all laws and ordinances:
Units without headlights shall be operated only with adequate daylight conditions of visibility, and; Owners shall be encouraged to highlight
(for conspicuity) using lighting, relectors, and for low-riding units, signal lags on lexible poles.
• Persons with the following conditions shall be cautioned not to operate: Those with heart conditions; Pregnant women; Persons with head,
back, or neck ailments, or prior surgeries to those areas of the body; and persons with any mental or physical conditions that may make
them susceptible to injury or impair their physical dexterity or mental capabilities to recognize, understand, and perform all of the safety
instructions and to be able to assume the hazards inherent in unit use.
• Do not ride at night.
• Do not ride after drinking or taking prescription medication.
• Do not carry items when riding.
• Never operate the product barefooted.
• Always wear shoes and keep shoelaces tied.
• Make sure your feet are always placed securely on the deck.
• Operators always shall use appropriate protective clothing, including but not limited to a helmet, with appropriate certiication, and any
other equipment recommended by the manufacturer: Always wear protective equipment such as helmet, knee pads, and elbow pads.
• Always give way to pedestrians.
• Be alert to things in front and far away from you.
• Do not allow distractions when riding, such as answering the phone or engaging in any other activities.
• The product cannot be ridden by more than one person.
• When you ride the product along with other riders, always keep a safe distance to avoid a collision.
• When turning, be sure to maintain your balance.
• Riding with improperly adjusted brakes is dangerous and can result in serious injury or death.
• The brake may become hot while operating, do not touch the brake with your bare skin.

5
• Applying brakes too hard or too suddenly can lock up a wheel, which could cause you to lose control and fall. Sudden or excessive
application of the brake may result in injury or death.
• If the brake loosens, please adjust with the hexagon wrench, or please contact Jetson Customer Care.
• Replace worn or broken parts immediately.
• Check whether all safety labels are in place and understood before riding.
• The owner shall allow the use and operation of the unit after a demonstration that such operators can understand and operate all
components of the unit before use.
• Do not ride without proper training. Do not ride at high speeds, on uneven terrain, or on slopes. Do not perform stunts or
turn abruptly.
• Recommended for indoor use.
• Prolonged exposure to UV rays, rain and the elements may damage the enclosure materials, store indoors when not in use.
California Proposition 65
WARNING:
This product can expose you to a chemical such as Cadmium that is known to the state of California to cause cancer or birth
defects or other reproductive harm. For more information go to www.p65warnings.ca.gov/product
MODIFICATIONS
Do not attempt to disassemble, modify, repair, or replace the unit or any components of the unit without instruction from Jetson Customer
Care. This will void any warranty, and can lead to malfunctions which may cause injury.
ADDITIONAL OPERATION CAUTIONS
Do not lift the product o the ground while it is on and the wheels are in motion. This can result in freely spinning wheels, which may cause
injury to yourself or others nearby. Do not jump on or o the product, and do not jump while using it. Always keep your feet firmly planted
on the foot rest while in operation. Always check the battery charge before using.
DISPOSAL OF USED BATTERY
Battery may contain hazardous substances which could endanger the environment and human health. This symbol marked on
the battery and/ or packaging indicates that used battery shall not be treated as municipal waste. Batteries should be disposed of
at an appropriate collection point for recycling. By ensuring the used batteries are disposed of correctly, you will help preventing
potential negative consequences for the environment and human health. The recycling of materials will help to conserve natural resources.
For more information about recycling of used batteries, please contact your local municipality waste disposal service.

6
*ADULTS MUST ASSIST CHILDREN IN THE INITIAL ADJUSTMENT PROCEDURES OF THE PRODUCT.
What’s in the Box
1. HANDLEBAR
2. HEADLIGHT
3. USB CHARGING PORT
4. HOOK
5. BELL
6. RELEASE LEVER
7. FRONT FORK
8. FRONT MOTOR WHEEL
9. KICKSTAND
*PLEASE FULLY CHARGE THE BATTERY PRIOR TO USE.
10. DECK
11. REAR FENDER
12. REAR BRAKE LIGHT
13. REAR WHEEL
14. REAR DISC BRAKE
15. CHARGER
16. CHARGER CABLE

7
PLEASE NOTE: IMAGES MAY NOT REFLECT EXACT APPEARANCE OF ACTUAL PRODUCT.
15
1
2
3
4
5
6
8
9
7
10
11
12
13
14
16

9
Specs & Features
• PRODUCT DIMENSIONS: 42.3” L × 18.5” W × 46.3” H
• PRODUCT FOLDED DIMENSIONS: 42.3” L × 18.5” W × 17.7” H
• WEIGHT LIMIT: 220 LB
• PRODUCT WEIGHT: 31 LB
• RECOMMENDED AGE: 12+
• WHEEL SIZE: 8.5”
• MAX SPEED: UP TO 15.5 MPH
• MAX RANGE: UP TO 16 MILES
• BATTERY: 36V, 7.5AH
• BATTERY TYPE: LITHIUM ION
• MOTOR: 250W
• CHARGER: 42V, 1.5A
• CHARGE TIME: UP TO 5 HOURS
• CLIMBING ANGLE: UP TO 15

10
CHARGING PORT
1.1 Charging the Battery
ONLY USE THE INCLUDED CHARGER
• PLUG THE CHARGER INTO THE WALL BEFORE THE CHARGING PORT.
• DON’T TURN ON THE RACER WHILE IT’S CHARGING.
• CHARGE THE BATTERY UNTIL IT IS FULLY CHARGED  UP TO 5 HOURS.
• REPLACE THE COVER OVER THE CHARGING PORT WHEN DONE.
CHARGING INDICATOR ON THE CHARGER:
 CHARGING
 CHARGE COMPLETE
1. Get Started

11
PRESS THE LOWER LOCK ON REAR
FENDER TO RELEASE HANDLEBAR STEM
WARNING: ALWAYS CARRY
THE RACER WHEN NOT IN USE.
ROLLING IT MAY CAUSE DAMAGE.
1.2 Unfolding / Folding the Racer

12
LIFT HANDLEBARS AWAY FROM DECK

13
• MAKE SURE THE STEM AND HANDLEBAR ARE SECURE.
• TO FOLD THE CANYON, SLIDE UP THE MINI TAB LOCK
ON THE SIDE OF RELEASE LEVER AND RELEASE.
LOCK THE RELEASE LEVER BY
LIFTING IT UP UNTIL IT CLICKS

14
1.2 Handlebar Assembly
• SLIDE THE HANDLEBAR INTO THE STEM TUBE, TUCKING ANY EXCESS WIRE INTO THE STEM TUBE.
• LINE UP THE SCREW HOLES. INSERT AND TIGHTEN THE FOUR SCREWS USING THE ALLEN KEY. MAKE SURE THE SCREWS
ARE TIGHT AND THE HANDLEBAR IS SECURE.
SCREWS

15
1.3 Operating the Racer
POWER BUTTON
• POWER: HOLD DOWN THE POWER BUTTON FOR 2 SECONDS TO TURN THE RACER ON OR OFF.
• ODOMETER: PRESS POWER BUTTON ONCE TO TOGGLESWITCH BETWEEN TOTAL ODOMETER ODO AND YOUR
TRIP’S ODOMETER TRIP.
• FRONT AND REAR LIGHTS: HOLD DOWN THE LIGHT BUTTON FOR 1 SECOND TO TURN ON LIGHTS. HOLD DOWN
AGAIN TO TURN LIGHTS OFF.
LIGHT BUTTON

16
ERROR CODE MEANINGS:
• E0: COMMUNICATION ERROR
• E1: ABNORMAL CURRENT
• E2: THROTTLE FAILURE
• E3: BRAKE FAILURE
• E4: MOS FAILURE, OVERCURRENT FAILURE
• E5: HALLMOTOR FAILURE
• E6: MOTOR FAILURE
• E7: LOW VOLTAGE ERROR
SPEED MODES: PRESS LIGHT BUTTON TO CYCLE THROUGH SPEED MODES.
MODE 1 MODE 2 MODE 3
UP TO 4MPH UP TO 9MPH UP TO 15.5MPH
SPEED
HEADLIGHT
SINGLE RANGE  TOTAL RANGE
SPEED MODE
BATTERY LEVEL
PRODUCT RANGE, SPEED, BATTERY LIFE, AND OTHER SPECIFICATIONS MAY VARY BASED ON RIDER AND RIDING CONDITIONS.
RANGE MODES:
TRIP
SINGLE RANGE TOTAL RANGE
ODO

17
HANDBRAKE:
SQUEEZE THE HANDBRAKE SLOWLY TO AVOID
STOPPING ABRUPTLY OR LOSING CONTROL.
2.1 Using the Thumb Throttle / Handbrake
2. Make Moves
HANDBRAKE
THUMB THROTTLE
THUMB THROTTLE:
PUSH DOWN ON THE THUMB THROTTLE TO
ACCELERATE. TAKE IT EASY ON THE THROTTLE
UNTIL YOU GET USED TO IT.

18
2.2 Riding the Racer
• PLACE ONE FOOT IN FRONT.
• PLACE THE OTHER FOOT IN BACK, AT A 7090° ANGLE.
• TURN THE HANDLEBAR TO THE LEFT OR RIGHT TO MAKE TURNS.
TO DECELERATE:
• RELEASE THE THROTTLE LEVER
• OR PRESS HANDBRAKE
• OR PRESS FOOT DOWN ON REAR FENDER.
NOTE: ALL OPTIONS CAN BE USED SIMULTANEOUSLY IF NEEDED.
CRUISE CONTROL :
• WHEN YOU GET TO DESIRED SPEED, HOLD DOWN
THUMB THROTTLE FOR 9 SECONDS.
• WHEN YOU HEAR A BEEP  CRUISE CONTROL IS ON.
• PRESS HANDBRAKE TO CANCEL CRUISE CONTROL.
