John Thomas 2027 User manual

ITEM NO.: 2027
REVISED AUG 29, 2014 Printed in Vietnam
- 1 -
ASSEMBLY INSTRUCTIONS
Description
Item No.
:
THREE
-
PIECE JUVENILE SET
: 2027

ITEM NO.: 2027
REVISED AUG 29, 2014 Printed in Vietnam
- 2 -
BEFORE ASSEMBLY
Thank you for purchasing this quality product. This product has been designed for easy assembly and
constructed for durability. All parts were checked prior to packaging to insure quality. Prior to beginning
assembly, however, make sure all parts and hardware are included and free of obvious defect. If a part is
missing or defective, please contact the store where purchased. If hardware is missing, or you need help with
assembly, please call toll free 888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from
being scratched.
-Remove all wrapping material, including staples & packing straps before you start to assemble.
-DO NOT tighten all screws and bolts until completely assembled.
-Keep all hardware parts out of reach of children.
WARNING:
Long exposure to rubber or soft plastic may cause a chemical reaction and damage the finish of your
table. Protect the surface of the table with cloth if you are using any product with rubber feet or base.
PART
LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
1/ CHAIR (per piece):
NO Description
Qt
y Sketch NO Description Qty Sketch
A Side frame
(L-R) 2 B Front & back apron 2
C Crossbar 1 D Top crossbar 1
E Wood seat 1
2/ TABLE:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
F Top 1 G Leg frame
(L-R) 2
H Center
crossbar 1
ASSEMBLY TOOLS REQUIRED
NOT INCLUDED

ITEM NO.: 2027
REVISED AUG 29, 2014 Printed in Vietnam
- 3 -
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware in a large bag:
1/ CHAIR: totally same in 2 small bags, for 2 chairs
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
1 Bolt
(M6x50mm) 6
2 Screw
(M4x35mm) 4
3 Barrel nut
( M6x13mm) 6
4 Allen key
(4x80mm) 1
2/ TABLE
:
in a small bag
NO Description Qty Sketch NO Description Qty Sketch
1 Bolt
(M6x50mm) 6
2 Screw
(M4x35mm) 6
3 Barrel nut
( M6x13mm) 6
4 Allen key
(4x80mm) 1
STEP1-chair
Attach stretchers (B), and crossbar (D) to the 1st side frame (A) with bolts (1) and nuts (3). Tighten with
Allen key (4) as shown below.
Note: DO NOT fully tighten any of the bolts, until the chair is assembled, then put on a flat level
surface to make sure the chair is level and then tighten the bolts.

ITEM NO.: 2027
REVISED AUG 29, 2014 Printed in Vietnam
- 4 -
STEP 2 - chair
Attach crossbar (C) to the 1st side frame (A). Then attach the 2nd side frame (A) to the unit with bolts
(1), and nuts (3). Tighten with Allen key (4).
STEP 3
-
chair
Attach the seat (E) to top of the seat frame (from Step 2) with screws (2). Tighten with a screwdriver.

ITEM NO.: 2027
REVISED AUG 29, 2014 Printed in Vietnam
- 5 -
STEP 4 – table
Attach leg frames (G) to the top (F) with bolts (1), and nuts (3). Tighten with Allen key (4).
Attach center crossbar (H) to the leg frames (G) with bolts (1) and nuts (3). Tighten with Allen key (4).
UYO
STEP 5
–
table
Attach aprons of leg frames (G) to top (F) with screws (2). Tighten with a screwdriver as shown below.
